Philips BDL6551V/00 User manual

Philips
LCD monitor
165 cm (65")
Digital Signage
Full HD
BDL6551V
Impress and capture your audience
with a slim bezel 165 cm (65") LCD
Deliver your message in the most demanding applications with this stylish 165 cm (65")
LCD display. Whether used in a network environment, a tiled matrix set up or as a single
public display, your audience will be astonished.
Optimized for public viewing
• Full HD LCD display, 1920x1080p
• High brightness for clearer images
Operational flexibility
• Enhanced zoom feature supports tiled matrix applications
• Designed for 24/7 operation
• Smart insert in the backcover to place a small pc
Lower total cost of ownership
• SmartPower for energy saving
• Brightness automatically adjusts with ambient conditions
Sustainable and safe
• Temperature sensor measures the health condition
• Complies with RoHS standards to care for the environment

BDL6551V/00
Highlights
LCD monitor
165 cm (65") Digital Signage, Full HD
Full HD LCD display 1920x1080p
This display has a resolution that is referred to
as Full HD. The state-of-the-art LCD screen
technology has the full high-definition
widescreen resolution of 1080 progressive
lines, each with 1920 pixels. This allows the
best possible picture quality for HD input
signals with up to 1080 lines. It produces
brilliant flicker-free progressive scan pictures
with optimum brightness and superb colors.
This vibrant and sharp image will provide you
with an enhanced viewing experience.
SmartPower
The backlight intensity can be controlled and
pre-set by the system to reduce the power
consumption by up to 50%, which saves
substantially on energy costs.
Automatic brightness control
The adjustment of display settings to
correspond with ambient light without user
intervention.
Temperature sensor
This public dispay contains a temperature
sensor to monitor the internal health
condition. In case the internal temperature
surpasses the preset threshold, automatically
two internal fans will be activated to cool down
the display to normal conditions.
Compliant with RoHS standards
Philips designs and produces display products
in compliance with strict Restriction of
Hazardous Substances (RoHS) standards that
restrict lead and other toxic substances that
can harm the environment.
Designed for 24/7 operation
Because business never sleeps, our signage
displays are designed for 24/7 use. Taking
advantage of superior components to ensure a
higher level of quality, you can count on this
range of models for complete around-the-
clock reliability.
High brightness
Enjoy a clearer image in areas with greater
ambient brightness thanks to the 700 nit panel.
Your audience can enjoy better image quality
in locations that are away from direct sunlight
yet still brighter than average, optimizing the
viewing experience.
Smart Insert
Professional PC's are part of most public
signage installations. Quite often they increase
the overall depth to the display and cause a lot
of cable clutter. So we have designed this
display with Smart insert in the back cover
which is ideal for the integration of a
professional small form factor PC. On top of
that, the cable management system offers a
great solution to keep your cables neat and
professional looking.

Issue date 2020-10-05
Version: 9.4.1
12 NC: 8670 000 62218
EAN: 87 12581 53795 1
© 2020 Koninklijke Philips N.V.
All Rights reserved.
Specifications are subject to change without notice.
Trademarks are the property of Koninklijke Philips N.V.
or their respective owners.
www.philips.com
BDL6551V/00
Specifications
LCD monitor
165 cm (65") Digital Signage, Full HD
Picture/Display
• Diagonal screen size: 65 inch / 165 cm
• Panel resolution: 1920x1080p
• Optimum resolution: 1920 x 1080 @ 60Hz
• Brightness: 700 cd/m²
• Contrast ratio (typical): 2500:1
• Response time (typical): 8 ms
• Aspect ratio: 16:9
• Viewing angle (H / V): 178 / 178 degree
• Pixel pitch: 0.744 x 0.744 mm
• Display colors: 1.06 Billion colors
• Picture enhancement: 3/2 - 2/2 motion pull down,
3D Combfilter, Motion compens. deinterlacing,
Progressive scan, 3D MA deinterlacing, Dynamic
contrast enhancement
Supported Display Resolution
•Computer formats
Resolution Refresh rate
640 x 480 60, 67, 72, 75Hz
800 x 600 56, 60, 72, 75Hz
1024 x 768 60Hz
1280 x 768 60Hz
1280 x 800 60Hz
1360 x 768 60Hz
1366 x 768 60Hz
1440 x 900 60Hz
1600 x 1200 60Hz
1920 x 1080 60Hz
1920 x 1200 60Hz
•Video formats
Resolution Refresh rate
480i 60Hz
480p 60Hz
576p 50Hz
576i 50Hz
720p 50, 60Hz
1080i 50, 60Hz
1080p 50, 60Hz
Connectivity
• PC: VGA-in D-Sub 15HD, VGA-out D-Sub 15HD,
DVI-D x1, RS232 D-Sub9, RS232 D-sub9 output,
3.5 mm PC audio input x1
• AV input: HDMI x1, Composite (RCA) x1,
Composite (BNC) x1, S-video x1, Audio (L/R) x2,
Component (YPbPr) x1
• AV output: Composite (BNC) x1, Audio (L/R) x1
• Other connections: AC-out, External loudspeaker
connector
Convenience
• Placement: Portrait, Landscape
• Tiled Matrix: 5 x 5
• Picture in picture: PBP, PIP, POP
• Screen saving functions: Pixel shift, Low bright
• Signal Loop Through: RS232, VGA
• Keyboard control: Hidden, Lockable
• Remote control signal: Lockable
• Ease of installation: AC Out, Carrying Handles,
Smart Insert
• Energy saving functions: Ambient light sensor,
Smart Power
• Safety control functions: Heat Control,
Temperature Sensor
• Picture performance: Advanced color control
• Packaging: Reusable box
• Network controllable: RS232
Dimensions
• Bezel thickness: 3.1 cm / 1.22 inch
• Smart Insert mount: 300 x 320 x 64
• Smart insert in inch (WxHxD): 11.81 x 11.89 x
2.52
•Setdimensions(Wx H x D):
1500 x 876 x 123 mm
• Set dimensions in inch (W x H x D):
59.1 x 34.5 x 4.8 inch
• Set dimensions with stand (H x D):
1022 x 423 mm
•Setdimensionswithstand in inch (H x D):
40.2 x 16.7 inch
• Product weight: 56 kg
• Product weight (lb): 110.2
• VESA Mount: 400x400mm (Set), 100x100mm
(Smart insert)
Operating conditions
• Temperature range (operation): 0 - 40 °C
• Relative humidity: 5 - 90 %
• MTBF: 50.000 hour(s)
Power
• Consumption (On mode): Typ. 314W
• Standby power consumption: < 1W
Sound
• Built-in speakers: 2 x 12 W (8 ohm)
Accessories
• Included accessories: Remote Control, Batteries
for remote control, AC Power Cord, VGA cable,
User manual on CD-ROM, Quick start guide
• Optional accessories: Fixed wall mount, Flexible
wall mount, Ceiling mount
• Stand: BM05511
Miscellaneous
• Warranty: Europe/North America: 3 years
• On-Screen Display Languages: English, French,
German, Italian, Polish, Turkish, Russian, Simplified
Chinese
• Regulatory approvals: CE, FCC, Class B, CCC,
RoHS, UL/cUL
•
