Philips BDL6531E User manual

Philips
LCD monitor
165 cm (65")
Digital Signage
Full HD
BDL6531E
Impress and captivate your audience
with the full HD 65" LCD display
Deliver your marketing messages in startling clarity with this Full HD public signage display.
Ideal for projects which need eye-catching design at an affordable price.
Optimized for public viewing
• Full HD LCD display, 1920x1080p
• Slim bezel design for a stylish look
• Advanced in factory color calibration
Lower total cost of ownership
• SmartPower for energy saving
• Brightness automatically adjusts with ambient conditions
• Advanced anti image sticking function
Sustainable and safe
• Complies with RoHS standards to care for the environment
Operational flexibility
• Smart insert in the backcover to place a small pc
• Remote Management and Configuration via RS232

BDL6531E/00
Highlights
LCD monitor
165 cm (65") Digital Signage, Full HD
Advanced anti image sticking
Static images left on-screen for extended
periods of time may leave a "ghost image" or
image sticking effect on LCD displays. Although
image sticking in LCD displays is not permanent,
you want to prevent this to happen, especially in
locations where content is shown 24/7.
Advanced color calibration
Whether installing a video wall in a 3x3, 2x4 or
5x5 set up, you want the color performance of
each image to be consistent in each display used.
Therefore each display is specially calibrated in
the factory to meet the highest standard of
advanced video walls.
Automatic brightness control
The adjustment of display settings to
correspond with ambient light without user
intervention.
SmartPower
The backlight intensity can be controlled and
pre-set by the system to reduce the power
consumption by up to 50%, which saves
substantially on energy costs.
Smart Insert
Professional PC's are part of most public signage
installations. Quite often they increase the
overall depth to the display and cause a lot of
cable clutter. So we have designed this display
with Smart insert in the back cover which is ideal
for the integration of a professional small form
factor PC. On top of that, the cable management
system offers a great solution to keep your
cables neat and professional looking.
Remote Management:: RS232
Remote Management allows the user to control
and adjust the displays remotely via the RS232
protocol. Using CEC commands, you are able to
have full control over all the displays in your
signage network at any time.

BDL6531E/00
Specifications
LCD monitor
165 cm (65") Digital Signage, Full HD
Picture/Display
• Diagonal screen size: 65 inch / 165.1 cm
• Panel resolution: 1920x1080p
• Optimum resolution: 1920 x 1080 @ 60Hz
• Brightness: 500 cd/m²
• Contrast ratio (typical): 2500:1
• Response time (typical): 8 ms
• Aspect ratio: 16:9
• Viewing angle (H / V): 178 / 178 degree
• Pixel pitch: 0.63 x 0.63mm
• Display colors: 16.7 million colors
• Picture enhancement: 3/2 - 2/2 motion pull down,
3D Combfilter, Motion compens. deinterlacing,
Progressive scan, 3D MA deinterlacing, Dynamic
contrast enhancement
Supported Display Resolution
•Computer formats
Resolution Refresh rate
640 x 480 60, 67, 72, 75Hz
800 x 600 56, 60, 72, 75Hz
1024 x 768 60Hz
1280 x 768 60Hz
1280 x 800 60Hz
1280 x 1024 60Hz
1360 x 768 60Hz
1366 x 768 60Hz
1440 x 900 60Hz
1600 x 1200 60Hz
1920 x 1080 60Hz
1920 x 1200 60Hz
•Video formats
Resolution Refresh rate
480i 60Hz
480p 60Hz
576p 50Hz
576i 50Hz
720p 50, 60Hz
1080i 50, 60Hz
1080p 50, 60Hz
Connectivity
• PC: VGA-in D-Sub 15HD, VGA-out D-Sub 15HD,
DVI-D x1, RS232 D-Sub9, RS232 D-sub9 output, 3.5
mm PC audio input x1
• AV input: HDMI x1, Audio (L/R) x1, Component
RCA
• AV output: Composite (BNC) x1, Audio (L/R) x1
• Other connections: External loudspeaker connector
Convenience
•Placement:Landscape
• Tiled Matrix: Up to 5x5
• Picture in picture: PBP, PIP, POP
• Screen saving functions: Pixel Shift, Low Brightness
• Signal Loop Through: RS232, VGA
• Keyboard control: Hidden, Lockable
• Remote control signal: Lockable
• Ease of installation: Carrying Handles, Smart Insert
• Energy saving functions: Ambient light sensor, Smart
Power
• Safety control functions: Heat Control,
Temperature Sensor
• Picture performance: Advanced color control
• Packaging: Reusable box
• Network controllable: RS232
Dimensions
• Bezel thickness: 44mm
• Smart Insert mount: 300 x 320 x 64 mm
• Smart insert in inch (WxHxD): 11.81 x 11.89 x 2.52"
• Set dimensions (W x H x D): 1524 x 892 x 125 mm
• Set dimensions in inch (W x H x D):
60.0 x 35.1 x 4.9 inch
• Product weight: 53.8 kg
• Product weight (lb): 110.2
• VESA Mount: 400 x 400mm (15.7 x 15.7")
Operating conditions
• Temperature range (operation): 0 - 40 °C
• Relative humidity: 5 - 90 %
• MTBF: 50,000 hours hour(s)
Power
• Consumption (On mode): Typ. 314W
• Standby power consumption: <1W
Sound
• Built-in speakers: 2 x 12W (8 Ohm)
Accessories
• Included accessories: Remote Control, Batteries for
remote control, AC Power Cord, VGA cable, User
manual on CD-ROM, Quick start guide
• Optional accessories: Fixed wall mount, Flexible wall
mount, Ceiling mount
Miscellaneous
• Warranty: Europe/North America 3 years
• On-Screen Display Languages: English, French,
German, Italian, Polish, Turkish, Russian, Simplified
Chinese
• Regulatory approvals: CE, FCC, Class B, CCC,
RoHS, UL/cUL, CB, CSA, C-Tick, GOST
Packaging dimensions
• Packaging dimensions (W x H x D):
164.7 x 104.6 x 29.8 cm
• EAN: 87 12581 60391 5
• Gross weight: 63 kg
• Nett weight: 54 kg
• Number of products included: 1
• Packaging type: Carton
•Tareweight:9kg
Product dimensions
• Product dimensions (W x H x D):
152.36 x 89.16 x 12.48 cm
• Product dimensions with stand (W x H x D):
152.36 x 102.57 x 42.17 cm
•Weight:54kg
•
Issue date 2020-10-05
Version: 8.1.1
12 NC: 8670 000 76558
EAN: 87 12581 60391 5
