Philips BDL5545ET/00 User manual

Philips
LCD monitor
140 cm (55")
Multi-touch
Full HD
BDL5545ET
Find a new level of audience interaction
with the multi touch display
Get even closer to your audience than ever before with the touch screen LCD display.
Fast, precise and extremely durable, its high performance is matched by excellent
reliability and functionality.
Operational flexibility
• Optical touch technology for advanced user interaction
• Display Port for faster graphics support
• Open Pluggable Specification Slot
• Smart insert in the backcover to place a small pc
• Remote Management and Configuration via RS232
• Enhanced zoom feature supports tiled matrix applications
•ManyFunctions.OneWire
Lower total cost of ownership
• SmartPower for energy saving
• Advanced anti image sticking function
• Brightness automatically adjusts with ambient conditions
Optimized for public viewing
• Full HD LCD display, 1920x1080p
• Slim bezel design for a stylish look

BDL5545ET/00
Highlights
LCD monitor
140 cm (55") Multi-touch, Full HD
Optical multi-touch
A brand new level of interactivity is now
available thanks to the integrated optical touch
technology. The sensors on the edge of the
screen give you perfect clarity whilst at the
same time offering multi-touch interaction,
opening up all kinds of possibilities for new
interactive applications.
Display Port
Enjoy crystal clear images with the high-
bandwidth graphics support of the Display
Port. As well as transmitting full high-definition
video the Display Port will also transmit audio,
thus eliminating the need for extra cables.
OPS Slot
Developed for the Digital Signage market, the
Open Pluggable Specification (OPS) slot is
designed to make changing or upgrading your
media player mere child’s play. Simply plug
your media player in to the display - and you’re
ready. No matter whether you have an entry
level, mid-range or high-end media player, OPS
is fully compatible bringing you a lower TCO
over the longer term.
Smart Insert
Professional PC's are part of most public
signage installations. Quite often they increase
the overall depth to the display and cause a lot
of cable clutter. So we have designed this
display with Smart insert in the back cover
which is ideal for the integration of a
professional small form factor PC. On top of
that, the cable management system offers a
great solution to keep your cables neat and
professional looking.
SmartPower
The backlight intensity can be controlled and
pre-set by the system to reduce the power
consumption by up to 50%, which saves
substantially on energy costs.
Full HD LCD display 1920x1080p
This display has a resolution that is referred to
as Full HD. The state-of-the-art LCD screen
technology has the full high-definition
widescreen resolution of 1080 progressive
lines, each with 1920 pixels. This allows the
best possible picture quality for HD input
signals with up to 1080 lines. It produces
brilliant flicker-free progressive scan pictures
with optimum brightness and superb colors.
This vibrant and sharp image will provide you
with an enhanced viewing experience.
Advanced anti image sticking
Static images left on-screen for extended
periods of time may leave a "ghost image" or
image sticking effect on LCD displays.
Although image sticking in LCD displays is not
permanent, you want to prevent this to
happen, especially in locations where content
is shown 24/7.
Automatic brightness control
The adjustment of display settings to
correspond with ambient light without user
intervention.
Remote Management:: RS232
Remote Management allows the user to
control and adjust the displays remotely via the
RS232 protocol. Using CEC commands, you
are able to have full control over all the
displays in your signage network at any time.
Slim bezel
A slim bezel design adds a stylish look to a
public display to nicely blend in just about any
environment. Furthermore this design makes
the display ideal for tiled matrix video walls.
Zoom function for tiled matrix
The internal zoom function enables easy
implementation of a video wall matrix, without
the need for expensive external equipment.
Capable of many different configurations,
creating a stunning video wall has become
simplicity itself.
One Wire
Take full control of your display by running all
operational commands as well as your video
signal through just one single HDMI cable. This
unique feature makes it so much easier and
more convenient to ensure the smooth
running and maintenance of your display.
Consumer Electronics Control (CEC)
commands make finding out vital information
about your display absolute childsplay.

Issue date 2019-05-08
Version: 7.2.2
12 NC: 8670 000 76928
EAN: 87 12581 60489 9
© 2019 Koninklijke Philips N.V.
All Rights reserved.
Specifications are subject to change without notice.
Trademarks are the property of Koninklijke Philips N.V.
or their respective owners.
www.philips.com
BDL5545ET/00
Specifications
LCD monitor
140 cm (55") Multi-touch, Full HD
Picture/Display
• Diagonal screen size: 55 inch / 139.7 cm
• Panel resolution: 1920x1080p
• Optimum resolution: 1920 x 1080 @ 60 Hz
• Brightness: 500 cd/m²
• Contrast ratio (typical): 5000:1
• Response time (typical): 8 ms
• Aspect ratio: 16:9
• Viewing angle (H / V): 178 / 178 degree
• Display colors: 1.07 Billion
• Pixel pitch: 0.63 x 0.63 mm
• Picture enhancement: 3/2 - 2/2 motion pull down,
3D Combfilter, Motion compens. deinterlacing,
Progressive scan, 3D MA deinterlacing, Dynamic
contrast enhancement
Supported Display Resolution
•Computer formats
Resolution Refresh rate
640 x 480 60, 67, 72, 75Hz
800 x 600 56, 60, 72, 75Hz
1024 x 768 60Hz
1280 x 768 60Hz
1280 x 800 60Hz
1280 x 1024 60Hz
1360 x 768 60Hz
1366 x 768 60Hz
1440 x 900 60Hz
1600 x 1200 60Hz
1920 x 1080 60Hz
1920 x 1200 60Hz
•Video formats
Resolution Refresh rate
480i 60Hz
480p 60Hz
576p 50Hz
576i 50Hz
720p 50, 60Hz
1080i 50, 60Hz
1080p 50, 60Hz
• MAC 640 x 480: 60 Hz
• MAC 832 x 624: 60 Hz
• MAC 1152 x 870: 60 Hz
Connectivity
• PC: DVI-D x1, RJ45, VGA-in D-Sub 15HD, VGA-
out D-Sub 15HD, RS232 D-Sub9, RS232 D-sub9
output, 3.5 mm PC audio input x1, USB B-Type
• AV input: HDMI x1, Component (BNC) x1
• AV output: Audio (L/R) x1
• Other connections: OPS, Display Port, AC-out
Convenience
• Picture in picture: PBP, PIP, POP
• Signal Loop Through: RS232
• Keyboard control: Hidden, Lockable
• Remote control signal: Lockable
• Ease of installation: AC Out, Carrying Handles,
Smart Insert
• Energy saving functions: Ambient light sensor,
Smart Power
• Packaging: Reusable box
• Network controllable: RS232
• Picture performance: Advanced color control
• Placement: Landscape, Portrait
Operating conditions
• Temperature range (operation): 0 - 40 °C
• Relative humidity: 0 - 90 %
• MTBF: 60,000 hour(s)
Power
• Consumption (On mode): 217W (Typ)
• Standby power consumption: <1W
Sound
• Built-in speakers: 2 x 7W (RMS)
• Output power (RMS): 2 x 7W
Accessories
• Included accessories: Remote Control, Batteries
for remote control, AC Power Cord, VGA cable,
User manual on CD-ROM, Quick start guide
• Optional accessories: Fixed wall mount, Flexible
wall mount, Ceiling mount
Miscellaneous
• On-Screen Display Languages: English, French,
German, Italian, Polish, Turkish, Russian, Simplified
Chinese
• Regulatory approvals: CE, FCC, Class B, UL/cUL,
CCC, RoHS
Dimensions
• Bezel thickness: 41 mm/1.6"
•Setdimensions(Wx H x D):
1299 x 769.8 x 143.7 mm
• Set dimensions in inch (W x H x D):
51.1 x 30.3 x 5.7 inch
• Product weight: 54 kg
• Product weight (lb): 108.5
• VESA Mount: 400 x 200 mm/400 x 400 mm
Packaging dimensions
• EAN: 87 12581 60489 9
• Number of products included: 1
• Packaging type: Carton
Technical specifications
• Touchpoints: 2 Touchpoints, 4mm Safety Glass,
Optical IR Touch Technology s
•
