Philips GreenPerform RC160V User guide

RC160V
Mounting Instruction
Philips Lighting Luminaires (Shanghai) Co., Ltd.
Address: 2F, Building 6, No. 1805, Huyi Highway, Malu
Town, Jiading District, Shanghai, P.R. China
Postal code: 201801
Product Type Power (W)
CCT (K)
V1.0
FrequencyVoltage
50/60Hz
Lumen
Output (lm)
Dimension /
LxWxHxH1 (mm)
IP20
GreenPerform Panel
LEDs
AS/NZS
60598
a
Visible Profile Ceiling Mounting(VPC)
b
Please do not put any pressure on the back and the driver.
safety chain
For safety chain (4x)
The product should install safety chain.
(Safety chain is not included in package.)
ba
W
L
W
L
H1
H1
H
H
W30L120
W60L120
W60L60
1.5m
Input Current
(mA)
220-240V~
RC160V LED30S 840 W60L60 PSU CAU
RC160V LED30S 865 W60L60 PSU CAU
RC160V LED40S 840 W60L60 PSU CAU
RC160V LED40S 865 W60L60 PSU CAU
RC160V LED40S 840 W60L60 PSU OC CAU
RC160V LED40S 840 W30L120 PSU OC CAU
RC160V LED60S 840 W60L120 PSU OC CAU
4000
6500
4000
6500
4000
4000
4000
28
28
36
36
36
36
55
168
168
216
216
216
240
384
3000
3000
4000
4000
4000
4000
6000
595x595x8.3x30
595x595x8.3x30
595x595x8.3x30
595x595x8.3x30
595x595x9.3x31
1195x295x9.3x31
1195x595x11x32
1.68
1.68
1.70
1.70
1.95
2.00
4.63
140
140
170
170
170
170
260

This marking indicates that this product should not be disposed with other household wastes throughout the
EU. To prevent possible harm to the environment or human health from uncontrolled waste disposal, recycle it
responsibly to promote the sustainable reuse of material resources. To return your used device, please use the
return and collection systems or contact the retailer where the product was purchased. They can take this
product for environmental safe recycling.
HCB =50 mm MIC =25 mm SCB =50 mm
(a) HCB (Height clearance to building element)
Minimum distance as specified by the luminaire manufacturer between the top of the recessed luminaire and any building
element above it.
(b) MIC (Minimum insulation clearance)
Minimum distance as specified by the luminaire manufacturer between the top of the recessed luminaire and the building
insulation above it.
(c) SCB (Side clearance to building element)
Minimum distance between the side of the recessed luminaire and any building element as specified in AS/NZS 3000, or as
specified by the luminaire manufacturer.
(d) The minmum distance from the side of luminaire to any building insulation is 0 mm.
Model Run Current (A)
(@230V)
Start Current Duration (μs) /
T(@50% of Ipeak) (μs)
Maximum Number of
Luminaire on MCB 16A
Type B (pcs)
Start (Inrush) Current(A)
/ Ipeak (A)
* Touch current or
protective conductor
current (mA)
The leakage current *(touch current or protective conductor current) of electrical circuit may be greatly dependent upon electrical supply
cables used such as its rating and length, proper connection of electrical supply cables to luminaires and
wiring connection topology of luminaires to the supply electrical circuit amongst other site conditions.
* In some cases referred to as Earth Leakage Current.
Maximum Number of
Luminaire on MCB 16A
Type C (pcs)
Unit: mm
Please read this manual carefully before using the product.
1. For indoor use only.
2. Do not switch on before complete installation.
3. The luminaire shall be installed by a qualified electrician and wired in accordance with the latest IEE electrical
regulations or the national requirements.
4. The external flexible cable or cord of this luminaire cannot be replaced; if the cord is damaged, the luminaire
shall be destroyed.
5. The light source of this luminaire is not replaceable; when the light source reaches its end of life the whole luminaire
shall be replaced.
6. Luminaire must not be used or stored in corrosive environment where hazardous materials such as Sulphur,
Chlorine, phthalates, etc, are present.
7. Risk of overheating or fire if the clearance distances are compromised.
8. This product complies with the CA90 rating as per AS/NZS 60598.2.2:2016. Care should be taken at installation to
allow adequate air flow for optimum lifetime performance.
RC160V LED30S 840 W60L60 PSU CAU
RC160V LED30S 865 W60L60 PSU CAU
RC160V LED40S 840 W60L60 PSU CAU
RC160V LED40S 865 W60L60 PSU CAU
RC160V LED40S 840 W60L60 PSU OC CAU
RC160V LED40S 840 W30L120 PSU OC CAU
RC160V LED60S 840 W60L120 PSU OC CAU
0.140
0.140
0.176
0.176
0.176
0.176
0.263
15.60
15.60
15.80
15.80
15.80
15.80
20.60
206.00
206.00
181.00
181.00
181.00
181.00
181.00
<0.7
30
30
30
30
30
30
20
50
50
50
50
50
50
40
