Philips AZ1836 User manual

Version 1.2
AZ1836
©3141 785 31512
MP3 CD Soundmachine
all versions
Published by LX 0714 Service Audio Subject to modification
© Copyright 2006 Philips Consumer Electronics B.V. Eindhoven, The Netherlands
All rights reserved. No part of this publication may be reproduced, stored in a retrieval
system or transmitted, in any form or by any means, electronic, mechanical, photocopying,
or otherwise without the prior permission of Philips.
CONTENTS
Block diagram................................................................................1-1
Wiring diagram .............................................................................2-2
Display Board
circuit diagram ..........................................................................3-1
layout diagram ..................................................................3-2...3-3
Main Board
circuit diagram ..................................................................4-1...4-2
layout diagram ..................................................................4-3...4-4
CD Board
circuit diagram ..................................................................5-1...5-5
layout diagram .........................................................................5-6
Exploded view diagram .................................................................6-1
Service parts list ............................................................................7-1

1 - 1

2 - 1

3 - 1 3 - 1
CIRCUIT DIAGRAM - DISPLAY BOARD

3 - 2
3 - 2
LAYOUT DIAGRAM - DISPLAY BOARD

LAYOUT DIAGRAM - DISPLAY BOARD
3 - 3 3 - 3

4 - 14 - 1
CIRCUIT DIAGRAM - MAIN BOARD
PART 1

CIRCUIT DIAGRAM - MAIN BOARD
PART 2
4 - 2 4 - 2

4 - 3 4 - 3
LAYOUT DIAGRAM - MAIN BOARD
COMPONENT SIDE

4 - 44 - 4
LAYOUT DIAGRAM - MAIN BOARD
COPPER SIDE

5 - 1
CIRCUIT DIAGARM - CD BOARD
PART 1
5 - 1

CIRCUIT DIAGARM - CD BOARD
PART 2
5 - 2 5 - 2

5 - 3 5 - 3
CIRCUIT DIAGRAM - CD BOARD
PART 3

5 - 4 5 - 4
CIRCUIT DIAGRAM - CD BOARD
MP3 PART 1

5 - 5 5 - 5
CIRCUIT DIAGRAM - CD BOARD
MP3 PART 2

5 - 65 - 6
LAYOUT DIAGRAM - CD BOARD

6 - 1 6 - 1
EXPLODED VIEW DIAGRAM

7 - 1
Service parts list for AZ1836/98
11 996510006646 MAIN BD ASSY
12 996510006647 KEY BD ASSY
13 996510006648 USB BD ASSY
14 996510006649 SENSOR BD ASSY
15 996510006650 CD/USB BD ASSY
16 996500042090 TRANSFORMER EI48 117/234V
17 994000005084 SPEAKER 3" 2W 8OHM
18 994000005085 CD MECHANISM DA11B3VZ (BALL)
19 994000001687 ROD ANTENNA 158-600MM
191 996510002910 16P FLAT FLEX CABLE
192 996510000860 SHOCK ABSORBER (658 TA 30C)
193 996510000861 SHOCK ABSORBER (658 TB 40C)
194 996500042091 CD DOOR SPRING
195 994000005087 BATTERY DOOR
196 996510002912 DAMPER GEAR
197 996510002913 DAMPER GEAR HOLDER
D 996510000423 REMOTE CONTROL ASS'Y "PHILIPS"
F 996500037714 AC CORD SET VDE/BRAZIL APP 1.8

SERVICE PARTSLIST FOR AZ1836B/55
- MISCELLANEOUS -
994000005092 REMOTE CONTROL UNIT "PHILIPS"
!996500037714 AC CORD SET VDE/APP 1.83M
!996500042090 TRANSFORMER EI48 117/234V
994000005084 SPEAKER 2W 8ohm JHD-YD78-29-1
994000005085 CD MECHANISM (SANYO) DA11B3VZ
994000001687 ROD ANTENNA 185~600mm #6158
994000005086 DOOR LOCK #DSL-01B
994000000505 SHOCK ABSORBER (658 TA 30C)
994000000506 SHOCK ABSORBER (658 TB 40C)
996500042091 CD DOOR SPRING
994000005087 BATTERY DOOR
996500042093 CD DOOR
996500037712 HANDLE
996500042092 VOLUME KNOB
SERVICE PARTSLIST FOR AZ1836W/85
- MISCELLANEOUS -
B 996510002911 CD DOOR ABS 433C
C 996510002912 DAMPER GEAR
CDM 994000005085 CD MECHANISM DA11B3VZ (BALL)
CORD !994000001688 AC CORD SET CUL APP 6FT
D 996510002913 DAMPER GEAR HOLDER
E 996510002914 HANDLE FIXER L
F 996510002915 HANDLE FIXER R
FFC 996510002910 16P FLAT FLEX CABLE
G 996500037712 HANDLE
H 996510002916 CD DOOR LENS
I 994000000505 CD DAMPER 658 TA 30
J 994000000506 CD DAMPER 658 TB 40
K 996500042091 CD DOOR SPRING
LOCK 994000005086 DOOR LOCK #DSL-01B
PCB1 996510002907 MAIN BOARS PCB ASSY
PCB2 996510002908 CD/USB BOARS PCB ASSY
RC 996510002906 RC PART (WH) "AZ1836/85"
ROD 994000001687 ROD ANTENNA 158-600MM
SPE 994000005084 SPEAKER 3" 2W 8OHM
TRA !996510002909 TRANS. EI48 120V HF-U48E11TM
Note: Only these parts mentioned in the list are
normal service parts.
