Philips PET717/94 User manual

Register your product and get support at
www.philips.com/welcome
EN User manual
PET717
PET 717_94_IFU_EN.indd Sec3:1PET 717_94_IFU_EN.indd Sec3:1 2009-03-10 2:50:31 PM2009-03-10 2:50:31 PM

3EN
English
1 Important 5
Important safety instructions 5
Notice 7
2 Your portable DVD player 10
Introduction 10
What’s in the box 11
Overview of the main unit 11
Overview of the remote control 14
3 Get started 17
Charge the built-in battery 17
Install the remote control battery 18
Connect additional equipment 19
Connect a TV 19
Connect an amplifier 20
Connect a stereo system 20
Turn on 21
Select an OSD language 22
4 Use your DVD player 23
Play discs 23
Play options 24
Activate PBC 24
Program 25
Repeat 25
Repeat a section 26
Rotate pictures 26
Contents
PET 717_94_IFU_EN.indd Sec1:3PET 717_94_IFU_EN.indd Sec1:3 2009-03-10 2:50:32 PM2009-03-10 2:50:32 PM

4EN
Skip to a title/track/chapter 27
Search 27
Select an audio language 27
Select an audio mode 27
Select a subtitle 27
Select a view angle 28
View disc information 28
Zoom 28
5 Adjust settings 29
Select language options 29
Get the DivX® registration code 29
Select video options 30
Select display ratio 30
Select a view mode 31
Select picture contrast 32
Select audio options 33
Select play preferences 34
Restore original settings 34
Activate screen saver 34
Restrict access 35
Change a password 36
Select JPEG play options 38
6 Troubleshooting 39
7 Product information 41
8 Glossary 42
PET 717_94_IFU_EN.indd Sec1:4PET 717_94_IFU_EN.indd Sec1:4 2009-03-10 2:50:32 PM2009-03-10 2:50:32 PM

5EN
English
1 Important
Important safety instructions
aRead these instructions.
b Keep these instructions.
c Heed all warnings.
d Follow all instructions.
e Do not use this apparatus near water.
f Clean only with dry cloth.
g Do not block any ventilation openings. Install in accordance with the
manufacturer’s instructions.
h Do not install near any heat sources such as radiators, heat registers,
stoves, or other apparatus (including amplifiers) that produce heat.
i Protect the power cord from being walked on or pinched, particularly
at plugs, convenience receptacles, and the point where they exit from
the apparatus.
j Only use attachments/accessories specified by the manufacturer.
k Use only with the cart, stand, tripod, bracket, or table
specified by the manufacturer or sold with the apparatus.
When a cart is used, use caution when moving the cart/
apparatus combination to avoid injury from tip-over.
l Unplug this apparatus during lightning storms or when unused for
long periods of time.
m Refer all servicing to qualified service personnel. Servicing is required
when the apparatus has been damaged in any way, such as power-
supply cord or plug is damaged, liquid has been spilled or objects have
fallen into the apparatus, the apparatus has been exposed to rain or
moisture, does not operate normally, or has been dropped.
nBattery usage CAUTION – To prevent battery leakage which may
result in bodily injury, property damage, or damage to the unit:
PET 717_94_IFU_EN.indd Sec1:5PET 717_94_IFU_EN.indd Sec1:5 2009-03-10 2:50:33 PM2009-03-10 2:50:33 PM

6EN
Install all batteries correctly, + and - as marked on the unit.•
Do not mix batteries (old and new or carbon and alkaline, etc.).•
Remove batteries when the unit is not used for a long time.•
o Apparatus shall not be exposed to dripping or splashing.
p Do not place any sources of danger on the apparatus (e.g. liquid filled
objects, lighted candles).
q This product may contain lead and mercury. Disposal of these
materials may be regulated due to environmental considerations. For
disposal or recycling information, please contact your local authorities
or the Electronic Industries Alliance: www.eiae.org.
Warning
Never remove the casing of this DVD player.•
Never lubricate any part of this DVD player.•
Never place this DVD player on other electrical equipment.•
Keep this DVD player away from direct sunlight, naked flames or heat.•
Never look into the laser beam inside the DVD player.•
Ensure that you always have easy access to the power cord, plug or adaptor to•
disconnect the DVD player from the power.
Hearing safety
Listen at a moderate volume.
Using headphones at a high volume can impair your hearing.This
•
product can produce sounds in decibel ranges that may cause hearing
loss for a normal person, even for exposure less than a minute.The
higher decibel ranges are offered for those that may have already
experienced some hearing loss.
Sound can be deceiving. Over time your hearing ‘comfort level’ adapts
•
to higher volumes of sound. So after prolonged listening, what sounds
‘normal’ can actually be loud and harmful to your hearing.To guard
against this, set your volume to a safe level before your hearing adapts
and leave it there.
PET 717_94_IFU_EN.indd Sec1:6PET 717_94_IFU_EN.indd Sec1:6 2009-03-10 2:50:33 PM2009-03-10 2:50:33 PM

7EN
English
To establish a safe volume level:
Set your volume control at a low setting.
•
Slowly increase the sound until you can hear it comfortably and clearly,•
without distortion.
Listen for reasonable periods of time:
Prolonged exposure to sound, even at normally ‘safe’ levels, can also
•
cause hearing loss.
Be sure to use your equipment reasonably and take appropriate breaks.
•
Be sure to observe the following guidelines when using your headphones.
Listen at reasonable volumes for reasonable periods of time.
•
Be careful not to adjust the volume as your hearing adapts.•
Do not turn up the volume so high that you can’t hear what’s around•
you.
You should use caution or temporarily discontinue use in potentially
•
hazardous situations. Do not use headphones while operating a
motorized vehicle, cycling, skateboarding, etc.; it may create a traffic
hazard and is illegal in many areas.
Caution
Use of controls or adjustments or performance of procedures other than herein•
may result in hazardous radiation exposure or other unsafe operation.
Notice
Any changes or modifications made to this device that are not expressly
approved by Philips Consumer Lifestyle may void the user’s authority to
operate the equipment.
Environmental information
All unnecessary packaging has been omitted.We have tried to make the
packaging easy to separate into three materials: cardboard (box), polystyrene
foam (buffer) and polyethylene (bags, protective foam sheet.)
PET 717_94_IFU_EN.indd Sec1:7PET 717_94_IFU_EN.indd Sec1:7 2009-03-10 2:50:34 PM2009-03-10 2:50:34 PM

8EN
Your system consists of materials which can be recycled and reused if
disassembled by a specialized company. Please observe the local regulations
regarding the disposal of packaging materials, exhausted batteries and old
equipment.
Recycling
Your product is designed and manufactured with high quality materials and
components, which can be recycled and reused. When you see the crossed-
out wheel bin symbol attached to a product, it means the product is covered
by the European Directive 2002/96/EC:
Never dispose of your product with other household waste. Please inform
yourself about the local rules on the separate collection of electrical and
electronic products.The correct disposal of your old product helps prevent
potentially negative consequences on the environment and human health.
Your product contains batteries covered by the European Directive 2006/66 /EC,
which cannot be disposed of with normal household waste.
When you see the crossed-out wheel bin symbol with the chemical symbol
‘Pb’, it means that the batteries comply with the requirement set by the
directive for lead:
PbPb
Please inform yourself about the local rules on separate collection of
batteries.The correct disposal of batteries helps prevent potentially negative
consequences on the environment and human health.
PET 717_94_IFU_EN.indd Sec1:8PET 717_94_IFU_EN.indd Sec1:8 2009-03-10 2:50:34 PM2009-03-10 2:50:34 PM

9EN
English
Always bring your product to a professional to remove/replace the battery.
The making of unauthorized copies of copy-protected material, including
computer programs, files, broadcasts and sound recordings, may be an
infringement of copyrights and constitute a criminal offence.This equipment
should not be used for such purposes.
Recording and playback of material might require consent. See Copyright Act
1956 and The Performer’s Protection Acts 1958 to 1972.
Manufactured under license from Dolby Laboratories.‘Dolby’ and the double
D symbol are trademarks of Dolby Laboratories.
“DivX, DivX” Certified, and associated logos are trademarks of DivX, Inc. and
are used under license.
This DVD player includes this label:
PET 717_94_IFU_EN.indd Sec1:9PET 717_94_IFU_EN.indd Sec1:9 2009-03-10 2:50:34 PM2009-03-10 2:50:34 PM

10 EN
2 Your portable DVD player
Introduction
Your portable DVD player plays digital video discs conforming to the
universal DVD Video standard.With it, you can play movies with cinema-like
picture and stereo (depending on the disc and your playback set-up).
You can also select sound track, subtitle languages, and different angle of view
(again depending on DVD disc). Besides, you can set parental control to
prevent your children to see certain discs.
You can play the following discs on the DVD player (including CD-R, CD-RW,
DVD±R, DVD±RW, and DivX):
DVD-Video
Video CD
Super video CD
Audio CD
DivX® CD
MP3 CD
Discs with JPEG files
PET 717_94_IFU_EN.indd Sec1:10PET 717_94_IFU_EN.indd Sec1:10 2009-03-10 2:50:35 PM2009-03-10 2:50:35 PM

11EN
English
What’s in the box
Check and identify the contents of your package:
Portable DVD player
•
Remote control•
Battery for remote control•
AC power adaptor (ADS-18C-12N 12012GPG)•
AV cable•
User Manual•
Quick Start Guide•
Overview of the main unit
aSETUP
Access or exit the setup menu
•
PET 717_94_IFU_EN.indd Sec1:11PET 717_94_IFU_EN.indd Sec1:11 2009-03-10 2:50:36 PM2009-03-10 2:50:36 PM

12 EN
bMENU
For DVD, access or exit the root menu
•
For VCD and SVCD, turn PBC (playback control) on or off in PBC•
mode
c STOP
Stop disc play
•
d PLAY/PAUSE
Start, pause or resume disc play
•
e Navigation keys
• / / /
Select the up/down/left/right item
• /
Press to skip to the previous or next title/chapter/track
Press and hold for fast-backward or fast-forward search
• OK
Confirm an entry or selection
fOPEN
Open the disc compartment
•
g IR/POWER/CHR
Remote sensor, power indicator, or charge indicator
•
hVOLUME + / -
Adjust volume level
•
fg
IR/POWER/CHROPEN
PET 717_94_IFU_EN.indd Sec1:12PET 717_94_IFU_EN.indd Sec1:12 2009-03-10 2:50:36 PM2009-03-10 2:50:36 PM

13EN
English
i COAXIAL
Connect headphones
•
Socket for coaxial output•
j AV OUT
Socket for audio/video output
•
k POWER ON / OFF/CHR
Turn on/off the DVD player
•
l DC IN 12V
Socket for the AC-DC power adaptor
•
PET 717_94_IFU_EN.indd Sec1:13PET 717_94_IFU_EN.indd Sec1:13 2009-03-10 2:50:37 PM2009-03-10 2:50:37 PM

14 EN
Overview of the remote control
aREPEAT
Select a repeat mode
•
b ZOOM
Zoom into or out of an image
•
m l k j
abc d
r
q
o
p
s
n
e
f
g
h
i
PET 717_94_IFU_EN.indd Sec1:14PET 717_94_IFU_EN.indd Sec1:14 2009-03-10 2:50:37 PM2009-03-10 2:50:37 PM

15EN
English
cOSD DISPLAY
Display the current play status or disc information
•
d TITLE
Access or exit the title menu of a disc
•
e MENU
For DVD, access or exit the root menu
•
For VCD and SVCD, turn PBC (playback control) on or off in PBC•
mode
f
/ / /
Select the up/down/left/right item
• /
Press to skip to the previous or next title/chapter/track
Press and hold for fast-backward or fast-forward search
• OK
Confirm an entry or selection
g
Start, pause or resume disc play
•
h DVD AV OUT
Switch between
• [TV Mode (PAL)], [Dual Screen (NTSC)] and
[AV OUT OFF]
iMUTE
Mute or restore the volume
•
j SUBTITLE
Select a subtitle language
•
k AUDIO LANGUAGE
Select an audio language or an audio channel
•
l ANGLE
Select a viewing angle of a DVD
•
m RETURN
(For VCD, PBC on) Return to the previous menu
•
PET 717_94_IFU_EN.indd Sec1:15PET 717_94_IFU_EN.indd Sec1:15 2009-03-10 2:50:38 PM2009-03-10 2:50:38 PM

16 EN
nNumeric Keypad 0 - 9
Select an item to play
•
o GO TO
Skip to a chapter/track/title or a play time
•
p
Stop disc play
•
q PROGRAM
Access or exit the program menu
•
r REPEAT A-B
Mark the section for repeat play
•
s SETUP
Access or exit the setup menu
•
PET 717_94_IFU_EN.indd Sec1:16PET 717_94_IFU_EN.indd Sec1:16 2009-03-10 2:50:39 PM2009-03-10 2:50:39 PM

17EN
English
3 Get started
Caution
Use the controls only as stated in this user manual.•
Always follow the instructions in this chapter in sequence.
If you contact Philips, you will be asked for the model and serial number of
your DVD player.The model number and serial number are on the bottom of
your DVD player.Write the numbers here:
Model No. __________________________
Serial No. ___________________________
Charge the built-in battery
Caution
Risk of product damage! Ensure that the power supply voltage corresponds to the•
voltage printed on the back or the underside of the DVD player.
Use only the supplied AC adaptor to charge the battery.
•
Note
You can only charge the DVD player when it is in power-off mode.•
1 Switch the POWER ON / OFF/CHR slide selector to the OFF/CHR
position.
PET 717_94_IFU_EN.indd Sec1:17PET 717_94_IFU_EN.indd Sec1:17 2009-03-10 2:50:39 PM2009-03-10 2:50:39 PM

18 EN
2 Connect the supplied AC adaptor to the DC IN 12V socket on the
DVD player and to the AC outlet.
The red charge indicator turns on. It takes about 4 hours to fully»
charge the battery.
When the battery is fully charged, the red charge indicator turns»
off.
Tip
You can only charge the battery when the temperature is between 0°C and 35°C.•
When headphones are connected to the DVD player, the fully charged battery•
lasts about 2.5 hours.
To maximize battery life, recharge the battery immediately after the battery is fully
•
discharged.
When the DVD player is not in use, turn it off.•
Install the remote control battery
Caution
Risk of product damage! Risk of explosion! Keep batteries away from heat,•
sunshine or fire. Never discard batteries in fire.
Risk of decreased battery life! Never mix different brands or types of batteries.
•
Risk of product damage! When the remote control is not used for long periods,•
remove the batteries.
Perchlorate Material - special handling may apply. See www.dtsc.ca.gov/
•
hazardouswaste/perchlorate..
PET 717_94_IFU_EN.indd Sec1:18PET 717_94_IFU_EN.indd Sec1:18 2009-03-10 2:50:39 PM2009-03-10 2:50:39 PM

19EN
English
1Open the battery compartment.
2 Insert 1 CR2025 battery with correct polarity (+/-) as indicated.
3 Close the battery compartment.
CR2025
1
CR2025
2
Connect additional equipment
Caution
Before you connect your DVD player to any additional equipment, turn it off.•
You can connect the DVD player to a TV or an amplifier to enjoy DVDs or
Karaoke.
Connect a TV
On the DVD player,
1 Connect the black end of the supplied AV cable to the AV OUT socket.
On the TV,
1 Connect the white end to the left audio input socket and the red end
to the right audio input socket.
2 Connect the yellow end to the video input socket.
PET 717_94_IFU_EN.indd Sec1:19PET 717_94_IFU_EN.indd Sec1:19 2009-03-10 2:50:40 PM2009-03-10 2:50:40 PM

20 EN
Connect an amplifier
1On the DVD player, connect the black end of the supplied AV cable to
the COAXIAL socket.
2On the amplifier with a Dolby Pro-Logic Decoder, connect the yellow
end of the AV cable to the audio or coaxial input socket.
Connect a stereo system
1On the DVD Player, connect the black end of the supplied AV cable to
the AV OUT socket.
2On the TV, connect the yellow end to the video input socket.
3On the amplifier with a Dolby Pro-Logic Decoder, connect the white
end to the left audio input socket and the red end to the right audio
input socket.
TV
AUDIO IN
VIDEO IN
PET 717_94_IFU_EN.indd Sec1:20PET 717_94_IFU_EN.indd Sec1:20 2009-03-10 2:50:40 PM2009-03-10 2:50:40 PM

21EN
English
Turn on
1Switch the POWER ON / OFF/CHR slide selector to the ON position.
The green power indicator turns on.»
PET 717_94_IFU_EN.indd Sec1:21PET 717_94_IFU_EN.indd Sec1:21 2009-03-10 2:50:41 PM2009-03-10 2:50:41 PM
