ServiceManual
Philips Domestic Appliances and Personal Care
Published by Philips Domestic Appliances and Personal Care Printed in the Netherlands © Copyright reserved Subject to modification
Precision Shaper
HQ-S964
D350 (Norelco)
04/02
PRODUCT INFORMATION
General description:
The Philishave D-Finer is the first Precision shaper.
A precision shaper is a specialized contouring appliance,
created for men with specially shaped beards and sideburns.
It gives ultimate control for defining precise lines and edges
with unlimited styling possibilities.
Materials used:
- housing parts : ABS
- others : POM / steel / Nickel (Shaving foil)
Features:
- 15mm hi-definition trimmer
(Maintenance free cutting element: no oiling required)
- 17mm miniature foil
- Cleaning brush included
Safety
- This product meets the requirements regarding
interference suppression on radio and TV.
- After the product has been repaired, it should function
properly and has to meet the safety requirements as
officially laid down at this moment.
NOTES :
• In order to guarantee the longest possible workinglife
of the battery:
- do not charge for more than 24 hours
- do not keep the charging unit permanently
plugged in
- discharge the battery completely once a year by
letting the motor run until it stops
• If the battery is empty and the consumer wants to
trim his beard, the trimmer has to be charged for at
least 1.5 hours to have enough power for one trim
• The appliance should be charged again, when not
used for a long period
TECHNICAL INFORMATION
- Power supply : Rechargeable (RC)
primary (EU) : 220 - 240 V - 50/60 Hz
secondary (EU) : 1,6 V - 100 mA
primary (USA) : 120 V - 60 Hz
secondary (USA) : 1,6 V - 100 mA
- Charging time : 10 h (NiCd & NiMh)
- Cordless operation time : 40 minutes (NiCd & NiMh)
- Charging indication : LED on adapter
- Dimensions Blister : 16 x 9,4 x 24,7 cm
- Weight Blister : 0,38 kg
- Weight product : 104 g

HQ-S964
D350 (Norelco)
NOTE (only for USA) :
In the time between week 12 - 2003 and week 17 - 2003
(start of production), D350 appliances have been
produced with a wrong typeplate text.
1.) The text on the typeplate of such a appliance tells you:
USE ONLY WITH DIRECT PLUG IN
TRANSFORMER 4203 035 78420
2.) The right text should be:
USE ONLY WITH DIRECT PLUG IN
TRANSFORMER 4203 030 77990
The typeplate text on the adapter is:
MODEL: 4203 030 77990
Be informed, that the adapter is the right one, only the
12NC at the typeplate is wrong on appliances, which were
produced in the time between week 12 - 2003 and week
17 - 2003. From week 18 - 2003 onwards the typeplate of
the appliance is corrected as shown in point 2.
REPAIR INSTRUCTIONS, EXPLODED VIEW & PARTS LIST
For this Precision Shaper only the shown parts will be supplied:
DISASSEMBLY- AND RE-ASSEMBLY ADVISE
- To exchange the Shaving foil assy (3):
Push slightly, till the shaving foil assy (3) falls out of the foil
housing (2).
OPTIONAL (accessories)
- No specific issues
HINTS FOR REPAIRS:
In case of complaints about a poor shaving quality and
the absence of damages to the shaving unit, there is a
possibility of the cutter stroke having become to small
owing to pollution of the shaving head. A drop of thin oil
on the foil and trimmers is likely to remedy this defect.
2
3
4
1
14
13
Pos Service code Description
1
2
3
4
13
14
4203 035 79200
4203 035 79210
4203 035 79220
4203 035 79230
4822 479 30183
4203 035 78390
4203 035 78400
4203 035 78410
4203 035 78420
Protecting cap
Foil housing
Shaving foil assy
Lamination cutter
Cleaning brush
Adapter - EU NiCd / NiMh
Adapter - GB
Adapter - CANADA
Adapter - USA
