Philips Elite SRP4219G/07 User manual

Remote
control
user manual
v2 9/21
SRP4219G/07
SRP4229B/07
Universal
Universelle
Audio/Video
Élite
SRP4229B_07 ENG Manual v2.indd 1SRP4229B_07 ENG Manual v2.indd 1 9/2/21 5:03 PM9/2/21 5:03 PM

2
Setup ................................................................................3
Button functions............................................................4
Programming your remote..........................................6
Direct Code Entry.....................................................6
Auto Code Search....................................................8
Controlling combo devices....................................9
Using your remote .......................................................10
Primary audio control...........................................10
Code identication.................................................11
Reset to factory settings.......................................11
Troubleshooting .......................................................... 12
90-day Limited Warranty.......................................... 12
FCC statement ............................................................. 13
Table of contents
For assistance with this
remote, scan here or visit:
byjasco.com/47597i
SRP4229B_07 ENG Manual v2.indd 2SRP4229B_07 ENG Manual v2.indd 2 9/2/21 5:03 PM9/2/21 5:03 PM

3
Your universal remote requires two (2) AAA
batteries (not included). Alkaline batteries are
recommended.
Battery installation
1. On the back of the remote, pull down on
the textured surface and slide battery cover
downward to remove.
2. Match the (+) and (-) marks on the batteries
to the (+) and (-) marks inside the battery
compartment, then insert two (2) AAA
batteries. Be sure to use fresh batteries.
3. Position battery cover slightly below opening
and push upward to lock into place.
NOTE:If your remote stops operating properly,
replace the batteries with new ones.
Battery precautions
• Do not mix old and new batteries.
• Do not mix alkaline, standard (carbon-zinc), or
rechargeable (Ni-Cd, Ni-MH, etc.) batteries.
• Always remove old, weak or worn-out
batteries promptly and recycle or dispose of
them in accordance with local and national
regulations.
Battery saver
Your remote automatically turns o if the buttons
are held down for more than 8 seconds. This will
save your batteries should your remote get stuck
in a place where the buttons remain depressed
(e.g., between sofa cushions).
Code saver
You have up to 10 minutes to change the batteries
in your remote without losing the codes you have
programmed.
Setup
SRP4229B_07 ENG Manual v2.indd 3SRP4229B_07 ENG Manual v2.indd 3 9/2/21 5:03 PM9/2/21 5:03 PM

4
SETUP
OK
INPUT
DVD
TV
STR
AUD
ENTER
112233
445566
778899
00
ABCD
VOL
CH
LAST
STREAM
EXIT 7
13
14
17
19
20
21
18
16
3
4
1
88
9 9
11 11
2
6
5
15
10
12
Button functions
SRP4229B_07 ENG Manual v2.indd 4SRP4229B_07 ENG Manual v2.indd 4 9/2/21 5:03 PM9/2/21 5:03 PM

5
1. Power - Turns devices ON/OFF
2. TV, STR, DVD, AUD - Selects the device
to control
3. Up/down/left/right menu navigation
4. Last channel - Returns to the previously
selected channel
5. Setup - Used to program the remote
6. Channel up/down
7. Home/Guide - Easily access features on
streaming devices, or Guide on cable/satellite
receivers
8. Info/Options - Displays on-screen show/
content information
9. Menu - Displays the on-screen menu
10. Record, play, stop, rewind, fast forward, pause
11. Numbers - Enter numbers for direct channel
selection
12. Dash (-) - Use to select digital channels,
e.g., 4.1
13. Enter - Some devices require enter to be
pressed after channel selection
14. ABCD - Access additional features for DVRs,
cable and satellite receivers
15. DVD/Blu-ray™open/close - Open/close a
player, or List features on cable/satellite
receivers
16. Exit -Exit on-screen menus
17. Streaming app hotkey - Access top apps like
Netix®, Amazon®Prime, Hulu®and more
18. Volume up/down
19. Mute - Mutes sound
20. Ok - Selects menu items for the controlled
device
21. Input - Selects video inputs
Button functions
SRP4229B_07 ENG Manual v2.indd 5SRP4229B_07 ENG Manual v2.indd 5 9/2/21 5:03 PM9/2/21 5:03 PM

6
Programming your remote
Your remote is designed to control multiple audio/
video devices. To use, you will need to program the
remote for your devices. There are two dierent
methods you can use to program the remote,
Direct Code Entry or Auto Code Search.
• The Direct Code Entry method is the
recommended method, as it is the simplest
and quickest method in most cases.
• The Auto Code Search method searches
through all the codes in the remote to nd a
code for your device.
NOTE:This remote comes preprogrammed for
Roku®boxes and Samsung TVs. Press TV for
Samsung TVs and STR for Roku boxes.
Direct Code Entry (recommended)
1. Locate the Code List included with
your remote. Find the section for the
type of device you wish to control,
(e.g., TV, STR, DVD, AUD). Locate the
brand of your device and circle all the
remote codes for the brand.
2. Press and hold down the SETUP
button on the remote until the red
light on the remote control turns on.
Release the SETUP button. The red
light will remain on.
NOTE:The red light will either be a
small light at the top of the remote or
the power ON/OFF button.
3. Press and release the device button
on the remote for the type of device
you wish to control, (e.g., TV, STR,
DVD, AUD). The red light will blink
once and remain on.
NOTE:Any of the device buttons on the
remote can be programmed to control
any of your devices. For example, you
can use the AUX device button on the
remote to control a satellite receiver,
digital converter box, streaming media
player or any device category in the
Code List.
SETUP
SRP4229B_07 ENG Manual v2.indd 6SRP4229B_07 ENG Manual v2.indd 6 9/2/21 5:03 PM9/2/21 5:03 PM

7
Programming your remote
4. Use the number buttons on the
remote to enter the rst 4-digit
remote code you circled in the
Code List in Step 1. The red light
will turn o after entering the
fourth digit
5. Point the remote at the device.
Test the buttons on the remote to
see if the device responds as you
would expect. If the buttons do not
operate the device, return to Step 2
above and use the next code that
you circled for that device.
6. Repeat steps 1 – 5 for each device you wish
to control.
Programming notes:
• Some codes may operate only a few functions
of your device. There may be another code in
the Code List that controls more functions.
Test other codes in the Code List for more
functionality.
• If you do not nd a remote code that works
your device or there are no codes in the
Code List for your device, use the Auto Code
Search method in the next section to program
your remote.
• For combination devices such as a TV/DVD
combo or TV/VCR combo, you may have to
enter a code for each device.
• Write down the remote codes used to
program the remote for future reference.
112233
445566
778899
00
SRP4229B_07 ENG Manual v2.indd 7SRP4229B_07 ENG Manual v2.indd 7 9/2/21 5:03 PM9/2/21 5:03 PM

8
Programming your remote
1. Manually turn on the device you
wish to control.
NOTE:The Auto Code Search process
cannot be used for devices without
power ON/OFF capability. Use Direct
Code Entry in these cases.
2. Press and hold down the SETUP
button on the remote until the red
light on the remote control turns on.
Release the SETUP button. The red
light will remain on.
NOTE:The red light will either be a
small light at the top of the remote or
the power ON/OFF button.
3. Press and release the device button
on the remote for the type of device
you wish to control, (e.g., TV, DVD,
STR, AUX). The red light will blink
once and remain on.
4. With the remote pointed at the
device, press and release the POWER
button on the remote. The remote
will send 10 dierent codes to the
device. The red light will blink once
for each code and remain on after
sending the 10 codes.
Did the device turn o?
• If YES, go to Step 5.
• If NO, repeat Step 4 to test the
next 10 codes.
5. Manually turn the device back on.
6. With the remote pointed at the
device, press and release the
VOL button. The remote will
re-send the rst code of the 10 codes
from Step 4. The red light will blink
once and remain on.
SETUP
VOL
Auto Code Search
Auto Code Search is a process where you can
search through all the codes stored in the remote
to nd a code for your device. It is recommended
that you read through all the steps below to
familiarize yourself with Auto Code Search before
starting the process.
SRP4229B_07 ENG Manual v2.indd 8SRP4229B_07 ENG Manual v2.indd 8 9/2/21 5:03 PM9/2/21 5:03 PM

9
Programming your remote
Did the device turn o?
• If YES, you have found a code for
the device. Press and release the
same device button you pressed
in Step 3. This will store the code
in the remote. Go to Step 7.
• If NO, continue to press and
release the VOL button until
the device turns o to test the
other 9 codes from Step 4. Be sure
to wait approximately 3 seconds
after each VOL button press to
allow the device time to respond
to the code. When the device
turns o, you have found a code
for your device. Press and release
the same device button pressed in
Step 3. This will store the code in
the remote. Go to Step 7.
NOTE:
• The VOL button can be used to
go backwards through each batch
of 10 codes.
• The red indicator light will ash 2
times after testing the rst or last
code in each batch of 10.
7. Use the remote to turn the device
back on. Test the buttons on the
remote to see if the device responds
as you would expect. If the buttons
do not operate the device, return
to Step 2 and repeat this process to
search for a better code to operate
the device.
8. Repeat this process for each device you wish
to control.
Controlling combo devices
Some combo devices (e.g., TV/VCR, TV/DVD, DVD/
VCR, etc.) will require you to set up two dierent
device buttons to control both parts of the combo
device. For example, if you have a TV/DVD combo,
you may need to set up one code under the TV
button to control the TV and a separate code
under the DVD button to control the DVD.
VOL
VOL
SRP4229B_07 ENG Manual v2.indd 9SRP4229B_07 ENG Manual v2.indd 9 9/2/21 5:03 PM9/2/21 5:03 PM

10
Using your remote
Primary Audio Control
The Primary Audio Control feature allows you to
select a single device that the volume buttons
always control. For example, the remote can be
in TV mode while the volume buttons control
the volume on your audio receiver or sound bar
instead of your TV.
Enabling Primary Audio Control
1. Press and hold down the SETUP
button on the remote until the red
light on the remote control turns on.
Release the SETUP button. The red
light will remain on.
2. Press and release the device button
(TV, AUD, etc.) on the remote for the
device you wish to control
the volume.
3. Press and release the MUTE button.
4. Press and release the VOL button.
The red light will blink twice and
turn o.
Disabling Primary Audio Control
1. Press and hold down the SETUP
button on the remote until the red
light on the remote control turns on.
Release the SETUP button. The red
light will remain on.
2. Press and release the device button
(TV, AUD, etc.) programmed to control
the Primary Audio Control feature.
3. Press and release the MUTE button.
4. Press and release the VOL button.
The red light will blink twice and
turn o.
SETUP
SETUP
VOL
VOL
SRP4229B_07 ENG Manual v2.indd 10SRP4229B_07 ENG Manual v2.indd 10 9/2/21 5:03 PM9/2/21 5:03 PM

11
Using your remote
1. Press and hold down the SETUP
button on the remote until the red
light on the remote control turns on.
Release the SETUP button. The red
light will remain on.
2. Press and release the desired device
button (TV, DVD, STR, AUD) you
would like the code for.
3. Press and release the ENTER button.
4. Press and release the #1 button.
Count the number of times the
remote light ashes. This is the
number corresponding to the rst
digit of the code. Repeat the process
by pressing the #2, #3 and #4
buttons for the remaining digits.
5. Press and release the ENTER button
to exit this mode.
Code identication
Reset to factory settings
1. Press and hold down the SETUP
button on the remote until the red
light on the remote control turns on.
Release the SETUP button. The red
light will remain on.
2. Press and release the MUTE button.
3. Press and release the number #0
button. The red indicator light will
ash twice.
SETUP
SETUP
ENTER
ENTER
00
112233
445566
778899
00
SRP4229B_07 ENG Manual v2.indd 11SRP4229B_07 ENG Manual v2.indd 11 9/2/21 5:03 PM9/2/21 5:03 PM

12
Troubleshooting
The remote does not operate your device.
• Make sure the batteries are fresh and
installed correctly.
• Aim the remote directly at your device and
make sure that there are no obstructions
between the remote and device.
• Make sure you select the appropriate device
on the remote you wish to control; TV for TV
and CBL for cable box.
• Try programming the remote with a dierent
code. See Direct Code Entry section.
• Remote may not be compatible with your
device.
The remote does not operate some features of
your device.
• Sometimes a particular code might operate a
few features but not all. Try programming the
remote with a dierent code from the Code
List. See Direct Code Entry section.
• Remote may not be able to operate all
features of your device or button names may
be dierent than that of your original remotes.
Jasco warrants this product to be free from
manufacturing defects for a period of 90
days from the original date of consumer
purchase. This warranty is limited to the
repair or replacement of this product only
and does not extend to consequential or
incidental damage to other products that
may be used with this unit. This warranty
is in lieu of all other warranties express or
implied. Some states do not allow limitations
on how long an implied warranty lasts
or permit the exclusion or limitation of
incidental or consequential damages, so the
above limitations may not apply to you. This
warranty gives you specic rights, and you
may also have other rights which vary from
state to state.
90-day Limited Warranty
SRP4229B_07 ENG Manual v2.indd 12SRP4229B_07 ENG Manual v2.indd 12 9/2/21 5:03 PM9/2/21 5:03 PM

13
FCC statement
Suppliers Declaration of Conformity
Model #: SRP4219G/07, SRP4229B/07
Jasco Products Company LLC, 10 E. Memorial Rd.,
Oklahoma City, OK 73114, USA | www.byjasco.com
This device complies with Part 15 of the FCC
rules, and Industry Canada license-exempt RSS
standard(s). Operation is subject to the following
two conditions: (1) this device may not cause
harmful interference, and (2) this device must
accept any interference received, including
interference that may cause undesired operation.
FCC NOTE:The manufacturer is not responsible
for any radio or TV interference caused by
unauthorized modications to this equipment.
Such modications could void the user’s authority
to operate the equipment.
NOTE:This equipment has been tested and found
to comply with the limits for a Class B digital
device, pursuant to Part 15 of the FCC rules.
These limits are designed to provide reasonable
protection against harmful interference in a
residential installation. This equipment generates,
uses and can radiate radio frequency energy
and, if not installed and used in accordance with
the instructions, may cause harmful interference
to radio communications. However, there is no
guarantee that interference will not occur in a
particular installation. If this equipment does
cause harmful interference to radio or television
reception, which can be determined by turning the
equipment o and on, the user is encouraged to
try to correct the interference by one or more of
the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the
equipment and receiver.
• Connect the equipment to an outlet on a
circuit dierent from that to which the receiver
is connected.
• Consult the dealer or an experienced radio/TV
technician for help.
ICES-3(B)/NMB-3(B).
SRP4229B_07 ENG Manual v2.indd 13SRP4229B_07 ENG Manual v2.indd 13 9/2/21 5:03 PM9/2/21 5:03 PM

MADE IN CHINA
Philips and the Philips Shield Emblem are
registered trademarks of Koninklijke Philips N.V.
and are used under license. This product has
been manufactured by and is sold under the
responsibility of Jasco Products Company, and
Jasco Products Company LLC, 10 E. Memorial Rd.,
Oklahoma City, OK 73114 is the warrantor in
relation to this product.
This product comes with a 90-day warranty.
Visit www.philips.com/support for warranty details.
Questions? Contact our U.S.-based Consumer
Care at 1-844-816-0320 between 7AM-8PM, M-F,
Central Time.
SRP4229B_07 ENG Manual v2.indd 14SRP4229B_07 ENG Manual v2.indd 14 9/2/21 5:03 PM9/2/21 5:03 PM

SRP4229B_07 ENG Manual v2.indd 15SRP4229B_07 ENG Manual v2.indd 15 9/2/21 5:03 PM9/2/21 5:03 PM

v2 9/21
SRP4219G/07
SRP4229B/07
Universal
Universelle
Audio/Video
Élite
Guide
technique
de la
télécommande
universelle
SRP4229B_07 FRE Manual v2.indd 16SRP4229B_07 FRE Manual v2.indd 16 9/2/21 5:01 PM9/2/21 5:01 PM

17
Conguration.................................................................18
Fonctions des touches................................................19
Programmation de la télécommande .....................21
Entrée Directe de Code.........................................21
Recherche Automatique de Code..................... 23
Commande d’appareils combinés..................... 25
Utilisation de la télécommande............................... 25
Contrôle Audio Principal ..................................... 25
Identication des codes ......................................26
Réinitialisation aux paramètres
du fabricant............................................................. 26
Dépannage.................................................................... 27
Garantie......................................................................... 27
Déclaration de conformité FCC................................28
Table des matières
Pour obtenir de l'aide avec
cette télécommande, scannez
ici ou visitez :
byjasco.com/47597i
SRP4229B_07 FRE Manual v2.indd 17SRP4229B_07 FRE Manual v2.indd 17 9/2/21 5:01 PM9/2/21 5:01 PM

18
La télécommande universelle requiert deux (2)
piles AAA (non comprises). Il est recommandé
d’utiliser des piles alcalines.
Installation des piles
1. Au dos du boîtier de la télécommande,
appuyez sur la surface grenue et glissez le
couvercle des piles pour le retirer.
2. Faites correspondre les marques (+) et (-) des
piles avec celles à l’intérieur du compartiment à
piles, puis insérez deux (2) piles AAA. Assurez-
vous d’utiliser des piles neuves.
3. Placez le couvercle des piles légèrement en
dessous de l’ouverture et poussez vers le haut
pour le bloquer en place.
REMARQUE :Si votre télécommande cesse de
fonctionner, remplacez les piles par des piles neuves.
Précautions relatives aux piles
• Ne mélangez pas des piles neuves avec des
piles usagées.
• Ne mélangez pas des piles alcalines avec des
piles ordinaires (carbone-zinc) ou des piles
rechargeables (Ni-Cd, Ni-MH, etc.)
• Retirez toujours rapidement les piles usagées,
les piles faibles ou les piles mortes et
recyclez-les ou éliminez-les en respectant les
règlements locaux et nationaux.
Économiseur de piles
La télécommande s’éteint automatiquement si
les touches sont enfoncées pendant plus de huit
secondes. De cette façon, l’énergie de vos piles
est économisée si votre télécommande reste
coincée dans un endroit où les touches demeurent
enfoncées (entre les coussins d’un sofa, par
exemple).
Sauvegarde des codes
Vous aurez jusqu’à dix minutes pour remplacer
les piles de votre télécommande sans perdre les
codes programmés.
Conguration
SRP4229B_07 FRE Manual v2.indd 18SRP4229B_07 FRE Manual v2.indd 18 9/2/21 5:01 PM9/2/21 5:01 PM

19
SETUP
OK
INPUT
DVD
TV
STR
AUD
ENTER
112233
445566
778899
00
ABCD
VOL
CH
LAST
STREAM
EXIT 7
13
14
17
19
20
21
18
16
3
4
1
88
9 9
11 11
2
6
5
15
10
12
Fonctions des touches
SRP4229B_07 FRE Manual v2.indd 19SRP4229B_07 FRE Manual v2.indd 19 9/2/21 5:01 PM9/2/21 5:01 PM

20
1. Alimentation – Allume et éteint les appareils
2. TV, STR, DVD, AUD – Sélectionnent l’appareil
à commander
3. Navigation vers le haut, vers le bas, vers la
gauche ou vers la droite
4. Canal précédent - Permet de reveni au canal
précédemment sélectionné
5. Setup - Permet de programmer la
télécommande
6. Canal suivant/précédent
7. Home/Guide – Permet d’accéder facilement à
des fonctions sur les appareils de diusion en
continu actuels; appuyez sur Guide pour les
fonctions des récepteurs de signaux de câble
ou de satellite
8. Info/Options - Ache à l’écran des
renseignements sur la chaîne ou la
programmation en cours
9. Menu - Ache le menu à l'écran
10. Enregistrement, lecture, arrêt, rebobinage,
avance rapide, pause
11. 0 à 9 – Permet d’entrer des chires pour
sélectionner directement un canal
12. Tiret (-) - Permet de sélectionner des canaux
numériques, p. ex. 4-1
13. Enter - Dans le cas de certains appareils, il
faut appuyer sur la touche enter après avoir
sélectionné le canal
14. ABCD - Accédez à des fonctionnalités
supplémentaires pour les DVR, les récepteurs
câble et satellite
15. Commande du lecteur DVD ou Blu-rayMC –
Ouvre ou ferme un lecteur; ou appuyez sur
List pour les fonctions liées aux récepteurs de
signaux de câble ou de satellite
16. Exit - Permet de quitter les menus à l’écra
17. Touches directes pour application de diusion
en continu - Permet d'accéder aux principales
applications telles que Netix®, Amazon®
Prime, Hulu®, etc.
18. Volume suivant/précédent
19. Mute - Coupe le son
20. Ok - Sélectionne les éléments de menu de
l’appareil que vous commande
21. Input - Sélectionne les entrées vidéo
Fonctions des touches
SRP4229B_07 FRE Manual v2.indd 20SRP4229B_07 FRE Manual v2.indd 20 9/2/21 5:01 PM9/2/21 5:01 PM
