Philips FC9082 User manual

ServiceManual
Philips Consumer Lifestyle
Published by Philips Consumer Lifestyle Printed in the Netherlands © Copyright reserved Subject to modification
Vacuum cleaner
FC9082
10/03
PRODUCT INFORMATION
- This product meets the requirements regarding
interference suppression on radio and TV.
- After the product has been repaired, it should function
properly and has to meet the safety requirements as
officially laid down at this moment.
TECHNICAL INFORMATION
- Colour : Dark Raven/Delft Blue
- Power consumption : 1800 W (IEC) 230 V
- Maximum Air displacement : 40 l/s
- Vacuum : 30 kPa
- Duststorage capacity : 3 L
- Cord length : 8 m
- Fiter system : Classic S-Baglong
performance
: 3 layer permanent motor
protection filter
: Ultra clean air washable
HEPA13 exhaust filter
- Net weight : 7.5 kg
ACCESSORIES
- Nozzle : Tri-Active all purpose nozzle
- Tubes : Metal lacquered telescopic tube
- Handgrip : Ergonomic handgrip
- Accessories : Brush, crevice nozzle and
small nozzle
- Accessory storage : Active accessory holder in tube
- Coupling : Button coupling
OPTIONAL (accessories)
- FC8021 : S-bag Classic
- FC8022 : S-bag Clinic
- FC8023 : S-bag Anti-Odour
- FC8038 : Ultra clean air washable HEPA13 exhaust filter

FC9082
- To open the appliance, first remove the exhaust filter cover
and filter.
- Remove the hinge lock-pin (see pictures).
- Remove the dustcover by simultaneously pushing the click
hook in the hinge and bending the hinge outside with a
screwdriver (see picture).
- To be able to remove the upper housing the cord outlet
must be removed using a screwdriver in the lower section
(see picture).
1
2
- After removing the 6 screws (A) the upper housing can be
removed.
- When the repair is finished, check whether all functions of
the appliance work properly.
- To disassemble the cord winder, use TORX screwdriver
no. T10, which is one of a set consisting of T20; T15; T10;
T9; T8; T7 and T6 (code number 4822 395 50145).
REPAIR INSTRUCTION
- The spare parts have been standardized as much as possible.
- Depending on the original cord, the spare cord must be
shortened to the length of the original cord.
- The cord winder spring must be tensioned to the maximum
level and then be rewound approx. 1.5 turn.
- Item 16, safety valve, opens to cool the motor if the air
displacement is too low or if the airflow is blocked.
- To prevent the switch getting damaged by too much force,
a protective ring (pos. 53) was added in the later versions.
If this part is missing it must still be placed as
modification!
DISASSEMBLY- AND RE-ASSEMBLY ADVISE
2-7
= changed

FC9082
PARTS LIST
ELECTRICAL DIAGRAM
MOTOR
POWER
MODULE
Black
Black
M
White
CORD WINDER
Brown
3-7
Pos Service code Description
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
4222 459 45586
4222 459 45614
4222 459 45583
4222 459 45611
4222 459 45616
4222 459 45612
4322 004 93350
4222 459 45615
4222 459 45613
4322 001 74110
4222 459 45625
4222 459 45624
4222 459 45592
4822 480 10228
4322 003 33280
4322 005 16990
4222 459 45595
4222 459 45618
4222 459 45617
4222 459 45619
4222 459 45589
4322 006 23880
4222 459 45590
4222 459 45593
4222 459 45594
4222 459 45606
4322 001 73440
Hinge pin
Dustc. assy FC9082 Dark raven
Dustbag detector incl. spring
Dustbagholder Dark raven
Handle assy Steel grey
Exhaust grille Dark raven
HEPA filter
Cord outlet kit Delft blue
HEPA lock grille Dark raven
Exhaust seal
Support right Dark raven
Support left Dark raven
Control wheel ring Chrome
Inlet filter
Inlet grille
DBFI/valve assy
Brake lever
CW button Dove blue
On/Off button Dove blue
Control wheel Delft blue
Switch lever
PCB assy Pilatus HV
Pedal spring
Backpanel/Dustchamber
Silencer 3
Motor housing top
Bufferring front
Pos Service code Description
28
29
30
31
32
33
34
35
36
37
38
39*
40
41
42
43
44
45
46
47
48
49
50
51
52
53
4322 009 09430
4222 459 45607
4222 459 45608
4322 001 73450
4222 459 45609
4222 459 45621
4222 459 45622
4322 009 00080
4322 005 26610
4222 459 45596
4222 459 45623
4322 006 07410
4322 006 07390
4322 006 07400
4222 459 45602
4222 459 45601
4222 459 45600
4222 459 45620
4222 459 45626
4322 005 27890
4322 005 27840
4322 003 35580
4322 005 27880
4322 004 20480
4322 004 20320
4222 459 48641
Motor Domel 1761 220-240 V
Silencer 4
Motor bracket
Buffer back
Motor housing bottom
Front handle inside Steel grey
Front handle outside Steel grey
Cordwinder no cord!
Contact plate
Rubber knee bend dustchamber
Casterwheel kit Dark raven
Cordset UK/HK 9 m
Cordset Euro 4.8 mm 9 m
Cordset Swiss 9 m
S-Class sealing
Silencer 2
Silencer 1
Lower housing Steel grey
Bend type 5/hose/connection assy
Dark raven
Accessory holder Dark raven
2p telescopic tube act. bush
Dark raven
Crevice nozzle Dark raven
Small nozzle Dark raven
Brush nozzle Dark raven
Tri-active nozzle Dark raven
Protective switch ring
* Standardized colour
= changed

FC9082
EXPLODED VIEW
A
6x
4
2
3
15
6
8
7
12
11
9
10
4-7

FC9082
EXPLODED VIEW
B
8x
C
2x
Y
Z
Black
Black
White
Brown
15
17
14
13
16
24
19
20
21
23
22
53
18
25
5-7

FC9082
EXPLODED VIEW
D
3x
E
26
28
27
29
30
37
35
31
36
33
38
32
34
39 ÷41
42
45
43
44
Z
Y
White
Brown
Black
Black
6-7

FC9082
EXPLODED VIEW
52
Europe Ø 4.8mm 40
Swiss
39U.K. / H.K. 41
50
47
48
51
49
46
7-7
