English
Important safety information
Read this important information carefully before you use the appliance and its accessories and save it
for future reference. The accessories supplied may vary for different products.
Danger
-Never vacuum up water or any other liquid. Never vacuum up
flammable substances and do not vacuum up ashes until they are
cold.
-Never immerse the appliance or the adapter in water or any other
liquid, nor rinse it under the tap.
Warning
-Check if the voltage indicated on the adapter corresponds to the
local mains voltage before you connect the appliance.
-This appliance contains a rechargeable battery that can only be
replaced by a skilled person. Do not open the appliance to
replace the rechargeable battery.
-Always check the appliance before you use it. Do not use the
appliance or the adapter if it is damaged. Always replace a
damaged part with one of the original type.
-The adapter contains a transformer. Do not cut off the adapter to
replace it with another plug, as this causes a hazardous situation.
-This appliance can be used by children aged from 8 years and
above and persons with reduced physical, sensory or mental
capabilities or lack of experience and knowledge if they have
been given supervision or instruction concerning use of the
appliance in a safe way and understand the hazards involved.
Children shall not play with the appliance. Cleaning and user
maintenance shall not be made by children without supervision.
-Always keep the magnetic charging disc away from very small
children.
-The plug must be removed from the socket-outlet before
cleaning or maintaining the appliance.
-Unplug the adapter if you are not going to use the appliance for
some time.
6English

-Do not let the motorized nozzle move over the mains cords of
other appliances or other cables as this may cause a hazard.
-Keep loose clothing, hair and body parts away from the motorized
brushes.
-Do not cover or block the ventilation openings when the
appliance is operating.
-To prevent damage, do not use the appliance if the filter is not
present in the dust container.
-To prevent damage, never put ethereal oils or similar substances
in the water tank or let the appliance pick them up.
-Do not lift or tilt the nozzle when the water tank is assembled and
full, as water may spray out of the water tank.
-Do not block the appliance inlet when operating to prevent
overheating of the appliance.
-Do not store the appliance at a temperature above 40°C or
below 5°C.
-Do not use the appliance in a room with a temperature above
40°C.
-Do not incinerate, disassemble or expose the appliance to
temperatures above 60°C. The rechargeable battery may
explode if overheated.
-The rechargeable battery may only be replaced by qualified
service engineers. Take the appliance to an authorized Philips
service center to have the battery replaced when you can no
longer recharge it or when it runs out of power quickly.
-This vacuum cleaner is designed for household use only. Do not
use this vacuum cleaner to vacuum up building waste, cement
dust, ashes, fine sand, lime and similar substances. Never use the
vacuum cleaner without any of the filters. This could damage the
motor and shorten the life of the vacuum cleaner. Always clean all
parts of the vacuum cleaner as shown in the user manual. Do not
clean any parts with water and/or cleaning agents if this is not
specifically shown in the user manual.
7
English

Caution
-Only charge the appliance with the adapter supplied. Only use
25V adapter ZD12D250050 or 30V adapter ZD12D300050.
-During charging, the adapter becomes warm to the touch. This is
normal.
-Do not plug in, unplug or operate the appliance with wet hands.
-Do not remove the adapter from the wall socket by pulling at the
cord (Fig. 1). Always unplug the appliance by first detaching the
magnetic connector from the magnetic charging disk (Fig. 2).
-Always switch off the appliance after use and before you charge
it.
-Never block the exhaust air openings at the back of the appliance
during vacuuming.
-Do not clean the dust container and the dust container lid in the
dishwasher. They are not dishwasher-proof.
-Do not clean the white material of the filter with a normal vacuum
cleaner or a brush to avoid damage to the material.
-Always use the vacuum cleaner with the filter unit assembled.
-If you clean the washable sponge filter with water, make sure it is
completely dry before you put it back into the filter holder and
dust container. Do not dry the sponge filter in direct sunlight, on
the radiator or in the tumble dryer. Do not clean the filter holder
with water. This part is not washable.
-Replace a washable sponge filter if it can no longer be cleaned
properly or if it is damaged (see 'Ordering accessories').
-Never use any accessories or parts from other manufacturers or
that Philips does not specifically recommend. If you use such
accessories or parts, your warranty becomes invalid.
-Make sure that the temperature in the room where the appliance
is stored or charged is between 5°C and 40°C.
-Make sure that the appliance is installed with the wall fixture
mounted to the wall according to the instructions in the user
manual.
8English

-Be careful when you drill holes in the wall to attach the wall
fixture, to avoid the risk of electric shock.
-If you use the appliance to vacuum fine sand, lime, cement dust
and similar substances, the pores of the filter will become
blocked. Clean the filter regularly.
-As this appliance uses water to clean, the floor may remain wet
and slippery for a while (Fig. 3).
-To prevent damage, never put wax, oil, floor maintenance
products or liquid floor cleaners that are not water-dilutable in
the water tank.
-Only use liquid floor cleaners that are transparent. Do not use
milky or non-transparent floor cleaners.
-Do not mix different types of liquid floor cleaner. When you have
used one liquid floor cleaner, first empty and rinse the water tank
before you add another liquid floor cleaner to the water in the
water tank.
-Never exceed the maximum quantities mentioned on the bottle
when you use a liquid floor cleaner. Do not add more than a few
drops to the water in the water tank, as this tank has a capacity of
200ml.
-Do not clean the metal wetting strip with a sharp object, as this
may damage the strip. Only clean the wetting strip by rinsing it
under the tap. Replace the wetting strip when you can no longer
clean it.
-Replace the wetting strip only with an original strip.
-To guarantee good cleaning results and proper functioning of the
appliance and water tank, always use original Philips cleaning
pads.
-Clean the water tank according to the instructions. The water tank
is not dishwasher-proof.
-Do not use aggressive cleaning agents or tools to clean the Aqua
Boost pedal (Fig. 4).
9
English

-After mopping the floors, do not store the appliance with the
water tank attached on the wall mount. If you do this, the wet
mopping pad will touch the wall and this may damage the wall.
Always remove the water tank before you store the appliance.
Electromagnetic fields (EMF)
This Philips appliance complies with all applicable standards and regulations regarding exposure to
electromagnetic fields.
Using the appliance
Usage restrictions
-Only use the water tank on hard floors with a water-resistant top coat (such as linoleum, enameled
tiles and varnished parquet) and stone floors (such as marble). If your floor has not been treated to
make it water-resistant, check with the manufacturer if you can use water to clean it. Do not use
the water tank on hard floors of which the water-resistant top coat is damaged.
-Only use the water tank on linoleum floors that are properly affixed to prevent linoleum from being
drawn into the mopping nozzle.
-Do not use the water tank to clean carpets.
-Do not move the appliance with water tank assembled sideways, as this leaves water traces. Only
move forwards and backwards.
Note: Runtime duration depends on power level used during cleaning.
Mopping pad and wetting strip
The appliance comes with one wetting strip and two identical microfiber mopping pads. With the
water tank, wetting strip and microfiber mopping pad attached to the standard floor nozzle, you can
clean hard floors.
Using liquid floor cleaner in the water tank
If you want to add a liquid floor cleaner to the water in the water tank, make sure that you use a low-
foaming or non-foaming liquid floor cleaner that can be diluted in water. As the water tank has a
capacity of 200ml, you only have to add a few drops of liquid floor cleaner to the water.
Cleaning the water tank
To clean the water tank, mix one part vinegar with three parts water. Pour this mixture into the water
tank and close the cap. Shake the water tank and put the water tank on a water-resistant surface.
Leave the water-vinegar mixture in the water tank overnight. Then empty the water tank, rinse it
thoroughly with fresh water, and use it normally again.
Caution: Water will leak from the water tank during cleaning, with and without the wetting strip
attached to the nozzle.
To empty the water tank, hold the water tank over a sink, remove the cap and tilt the water tank to the
side of the filling hole. Then turn the water tank over to let the water flow into the sink. To remove the
10 English

remaining water from the water tank, turn the water tank on its long side with the filling hole pointing
towards the sink. Then tilt the water tank forwards to let the remaining water flow out of the water
tank.
Note: Always store the water tank with the cap removed from the filling hole.
Ordering accessories
To buy accessories or spare parts, visit www.philips.com/parts-and-accessories or go to your Philips
dealer. You can also contact the Philips Consumer Care Center in your country (see the international
warranty leaflet for contact details).
Warranty and support
If you need information or support, please visit www.philips.com/support or read the international
warranty leaflet.
Recycling
-This symbol means that this product shall not be disposed of with normal household waste
(2012/19/EU) (Fig. 5).
-This symbol means that this product contains a built-in rechargeable battery which shall not be
disposed of with normal household waste (Fig. 6) (2006/66/EC). Please take your product to an
official collection point or a Philips service center to have a professional remove the rechargeable
battery.
-Follow your country’s rules for the separate collection of electrical and electronic products and
rechargeable batteries. Correct disposal helps prevent negative consequences for the environment
and human health.
Removing the rechargeable battery
Only remove the rechargeable battery when you discard the product. Before you remove
the battery, make sure that the product is disconnected from the wall socket and that
the battery is completely empty.
Take any necessary safety precautions when you handle tools to open the product and
when you dispose of the rechargeable battery.
To remove the rechargeable battery, follow the instructions below.
1Let the appliance run until it stops.
2Remove the dust container from the appliance (Fig. 7).
3Undo the three screws that fix the battery holder to the housing of the appliance (Fig. 8).
4Pull the battery holder out of the appliance (Fig. 9).
11
English

User interface signals and their meaning
Signal Description of signal Meaning of signal
The signal '00' and the battery icon flash on the
display.
The battery is empty.
A number between '00'and '90' flashes on the
display.
The appliance is charging.
The number '100' lights up on the display. After a full charging cycle, this signal
appears to show that the
rechargeable battery is fully charged.
The battery symbol lights up on the display. The appliance is in standby mode
with a fully charged battery.
A number between '00' and '10' together with the
battery icon flash on the display.
The rechargeable battery of the
appliance is low.
The display shows a flashing square and the
orange filter cleaning icon also flashes.
It indicates the recommended time
to check and clean the filter (Fig. 10)
to ensure the best performance of
the appliance.
Error code 'E1' lights up on the display. The appliance is stored or charged at
a temperature below 5°C. Move the
appliance to a warmer room. Do not
store or charge the appliance at a
temperature below 5°C or above
40°C.
Error code 'E4' lights up on the display. The roller brush in the motorized
nozzle or in the mini turbo brush has
become blocked and cannot turn
freely. Switch off the appliance and
check the roller brush for
obstructions or excessive hair
pollution.
Error code 'E6' lights up on the display. The adapter or battery may be
defective, please contact the
Consumer Care Center or take the
appliance to an authorized Philips
service center.
Error code 'E7' lights up on the display. The adapter may be defective,
please contact the Consumer Care
Center or take the appliance to an
authorized Philips service center.
Error code 'SE' lights up on the display. SE stands for service.Please take the
appliance to an authorized Philips
service center.
12 English

Signal Description of signal Meaning of signal
Note: When the appliance is charging on the
charging base, the SE error code may look like the
number 35.
Troubleshooting
This chapter summarizes the most common problems you could encounter with the appliance. If you
are unable to solve the problem with the information below, visit www.philips.com/support for a list
of frequently asked questions or contact the Consumer Care Center in your country.
Problem Possible cause Solution
The appliance does not
work when I push the
slider.
When the battery is empty,
the following icon flashes on
the display:
To charge the battery, connect the
appliance to the charging base or attach
the handheld vacuum cleaner directly to
the magnet on the charging base (Fig.
11).
You have to push the slider
forward to switch on the
appliance.
Push the slider forward to setting 1 to
switch on the appliance. Increase the
suction power further by pushing the
slider to setting 2 or select the turbo
setting to clean very dirty patches at the
highest suction power.
The appliance has a lower
suction power than usual.
The filter and the cyclone are
dirty.
Clean the filter (Fig. 10) and the cyclone
(Fig. 12). The filter light lights up after
several hours of use to indicate that you
have to wash the sponge filter. Make
sure that you wash the sponge filter at
least once a month if you use the
appliance regularly. Make sure that you
remove any hair and dirt that is stuck in
the cyclone.
You have not attached the
dust container lid properly to
the dust container or you
have not attached the dust
container properly to the
appliance. In both cases,
there will be a loss of suction
power.
Make sure that you attach the dust
container lid to the dust container and
the dust container to the appliance
properly.
Dust escapes from the
appliance.
The filter is dirty. Clean the filter (Fig. 10). See also the user
manual.
The filter is not present in the
appliance.
Make sure that the filter is in the
appliance and assembled correctly.
13
English

Problem Possible cause Solution
Something is blocking the
cyclone.
Check the cyclone (Fig. 12) for objects
stuck in it and remove any object that is
blocking the cyclone. Make sure that you
remove any hair and dirt that is stuck in
the cyclone.
If dust falls out of the dust
container, the dust container
lid is probably not attached
properly to the dust
container.
Empty the dust container and attach the
dust container lid correctly.
This icon flashes on the
display:
The filter may be dirty. We advise you to clean the filter (Fig. 10).
If you cleaned the filter recently, you can
disregard this icon. To continue
vacuuming, switch the appliance off and
then on again.
The appliance does not
move smoothly across the
floor when I am cleaning a
carpet.
You selected a too high
suction power.
Reduce the suction power by choosing
setting 1.
The brush does not turn
anymore.
The brush encounters too
much resistance.
Clean the brush with a pair of scissors or
by hand.
The brush may stop turning
when it encounters too much
resistance from high-pile
carpet.
Switch off the appliance and then switch
it back on again.
You have not assembled the
roller brush into the nozzle
properly after cleaning.
Follow the instructions in the cleaning
chapter of the user manual to slide the
roller brush into the nozzle properly.
Secure the roller brush inside the nozzle
by snapping home the locking lever.
The LEDs in the nozzle do
not come on.
You have not attached the
nozzle to the tube or
appliance properly.
Attach the nozzle to the appliance or
handheld properly.
The appliance is not
charging.
The magnetic connector is
not connected properly to
the charging disk or the
adapter is not inserted into
the wall socket properly.
Make sure that the magnetic connector
is connected properly to the charging
disk and that the adapter is inserted into
the wall socket properly.
You have not connected the
correct adapter and cord.
Make sure that you use the correct
adapter and cord.
If you have checked the above and the
appliance still does not charge, take it to
a Philips service center or contact the
Consumer Care Center.
14 English

Problem Possible cause Solution
The mini turbo brush does
not function properly.
The roller brush is blocked. Remove hairs from the brush with a pair
of scissors (see user manual).
The roller brush is blocked by
fabric or surfaces during
cleaning.
Keep the mini turbo brush aligned with
the surface and do not push the turbo
brush into soft surfaces.
The mini turbo brush is not
fully closed.
Make sure that the top and bottom
parts of the mini turbo brush are
properly connected and that there is no
gap between the two parts. Check if the
locking ring is in closed position (see
user manual).
When I use my vacuum
cleaner I sometimes feel
static electricity shocks.
Your vacuum cleaner builds
up static electricity. The lower
the air humidity, the more
static electricity the
appliance builds up.
Discharge the appliance by frequently
holding the tube against other metal
objects in the room (for example the
legs of a table or chair, etc.). You can
also raise the air humidity level in the
room.
You vacuumed up fine sand,
lime or a similar substance.
This also causes static
electricity.
Empty the dust container and clean the
filter (Fig. 10) according to the
instructions in the user manual.
Using the water tank
Problem Possible cause Solution
The water flow from the
water tank is reduced.
The wetting strip is blocked
by dirt.
Remove the wetting strip and clean it.
The microfiber mopping pad
is not placed correctly and
blocks the wetting strip as a
result. This prevents water
from flowing out of the
wetting strip.
Make sure that you place the mopping
pad correctly. Check the user manual for
proper placement.
The water tank is empty or
nearly empty.
Refill the water tank.
You are using a microfiber
mopping pad that is not
supplied by Philips.
Only use an original Philips microfiber
mopping pad. You can buy these
mopping pads in the online Philips shop
at www.shop.philips.com/service or at
your Philips dealer.
Too much water flows out
of the water tank at a too
high speed.
If too much water flows out
of the water tank at a too
high speed, the cap of the
tank is probably not closed
properly.
Check the cap and make sure it is fully
and properly closed.
15
English

Problem Possible cause Solution
The strip is not placed
properly in the bottom of the
water tank.
Check the strip and make sure that it is
fitted properly in the bottom plate of the
water tank.
You pushed the Aqua Boost
pedal too often.
Push the Aqua Boost pedal (Fig. 4) only
once each time and check after each
time if you have achieved the wetness
level you want.
The floor dries with stripes
when I use the water tank.
You added too much liquid
cleaner to the water.
Use only a few drops of liquid cleaner or
use a cleaner that foams less.
16 English

Dansk
Vigtige sikkerhedsoplysninger
Læs disse vigtige oplysninger omhyggeligt igennem, inden apparatet og tilbehøret tages i brug, og
gem dem til eventuel senere brug. Det medfølgende tilbehør kan variere for forskellige produkter.
Fare
-Støvsug aldrig vand eller andre væsker op. Sug aldrig brandbare
stoffer op, og sug ikke aske op, før denne er helt kold.
-Apparatet og adapteren må aldrig kommes ned i vand eller andre
væsker eller skylles under vandhanen.
Advarsel
-Kontrollér, om den angivne netspænding på adapteren svarer til
den lokale netspænding, før du slutter strøm til opladeren.
-Dette apparat indeholder et genopladeligt batteri, som kun må
udskiftes af en kompetent person. Apparatet må ikke åbnes i
forbindelse med udskiftning af det genopladelige batteri.
-Kontrollér altid apparatet, indendu anvender det. Brug ikke
apparatet eller adapteren,hvis en af delene er beskadiget. Udskift
altid en beskadiget del med en tilsvarende original type.
-Adapteren indeholder en transformator. Klip ikke adapteren af for
at udskifte den med et andet stik, da dette vil føre til farlige
situationer.
-Dette apparat må bruges af børn fra 8 år og opefter og personer
med reducerede fysiske, sensoriske eller mentale evner eller
manglende erfaring og viden, hvis de er blevet instrueret i sikker
brug af apparatet og forstår de medfølgende risici. Lad ikke børn
lege med apparatet. Rengøring og vedligeholdelse må ikke
foretages af børn uden opsyn.
-Hold altid den magnetiske opladningsdisk væk fra meget små
børn.
-Stikket skal tages ud af stikkontakten før rengøring og
vedligeholdelse af apparatet.
-Frakobl adapteren, hvis du ikke skal bruge apparatet i et stykke
tid.
17
Dansk

-Lad ikke den motordrevne mundstykke bevæge sig hen over
netledninger til andre apparater eller andre kabler, da det kan
udgøre en risiko.
-Hold løst tøj, hår og kropsdele væk fra de motordrevne børster.
-Dæk eller bloker ikke ventilationsåbningerne, når apparatet er i
brug.
-For at undgå skader må du ikke bruge apparatet, hvis filteret ikke
er placeret i støvbeholderen.
-For at undgå skader må du aldrighælde æteriske oliereller
lignende stoffer i vandtanken, og lad ikke apparatet opsuge disse.
-Undgå at løfte eller vippe mundstykket, når vandtanken er
monteret og fyldt op, da der kan sprøjte vand ud af vandtanken.
-Bloker ikke apparatets indgang, når det er i brug, for at forhindre
overophedning af apparatet.
-Opbevar ikke apparatet ved en temperatur over 40°C eller under
5°C.
-Brug ikke apparatet i et rum med en temperatur over 40°C.
-Apparatet må ikke brændes, adskilles eller udsættes for
temperaturer over 60°C. Det genopladelige batteri kan
eksplodere, hvis det bliver overophedet.
-Det genopladelige batteri må kun udskiftes af uddannede
serviceteknikere. Aflever apparatet til et autoriseret Philips-
servicecenter for at få batteriet udskiftet, når du ikke længere kan
genoplade det, eller når det hurtigt løber tør for strøm.
-Denne støvsuger er kun designet til husholdningsbrug. Brug ikke
denne støvsuger til at opsuge byggeaffald, cementstøv, aske, fint
sand, kalk og lignende. Brug aldrig støvsugeren uden et af filtrene.
Det kan beskadige motoren og forkorte støvsugerens levetid.
Rengør altid alle støvsugerens dele som vist i brugervejledningen.
Rengør ikke hverken dele eller tilbehør med vand og/eller
rengøringsmidler, medmindre dette specifikt er vist i
brugervejledningen.
18 Dansk

Forsigtig
-Brug kun den medfølgende adapter ved opladning af apparatet.
Brug kun 25 V-adapter ZD12D250050 eller 30 V-adapter
ZD12D300050.
-Adapteren blive varm under opladningen. Dette er normalt.
-Undlad at slutte apparatet til stikkontakten, frakoble det eller
betjene det med våde hænder.
-Tag adapteren ud af stikkontakten ved at hive i ledningen (fig. 1).
Tag altid apparatet fra stikkontakten ved at fjerne magnetstikket
fra den magnetiske opladningsdisk (fig. 2).
-Sluk altid for apparatet efter brug, og inden du oplader det.
-Lufthullerne til udblæsningsluften på bagsiden af apparatet må
aldrig blokeres under støvsugningen.
-Kom ikke støvbeholderen og støvbeholderens låg i
opvaskemaskinen. Disse dele tåler ikke opvaskemaskine.
-Rengør ikke filterets hvide materiale med en almindelig støvsuger
eller en børste for at undgå at beskadige materialet.
-Brug altid støvsugeren med filterenheden på.
-Hvis du rengør det vaskbare skumgummifilter med vand, skal du
sørge for, at det er helt tørt, før du sætter det tilbage i
filterholderen og støvbeholderen. Tør ikke skumgummifilteret ved
at lægge det i direkte sollys, på en radiator eller i en tørretumbler.
Rengør ikke filterholderen med vand. Denne del kan ikke vaskes.
-Udskift et vaskbart skumgummifilter, hvis det ikke længere kan
rengøres ordentligt, eller hvis det er beskadiget (se 'Bestilling af
tilbehør').
-Brug aldrig tilbehør eller dele fra andre producenter eller
tilbehør/dele, som ikkespecifikt er anbefalet af Philips. Garantien
bortfalder, hvis du bruger sådant tilbehør eller sådanne dele.
-Sørg for, temperaturen i det rum, hvor apparatet opbevares eller
oplagres, er mellem 5°C og 40°C.
-Sørg for, at apparatet installeres med den vægfaste genstand
monteret på væggen ifølge anvisningerne i brugervejledningen.
19
Dansk

-Pas på, når du borer hullerne til ophængning af den vægfaste
genstand, så du ikke risikerer at få elektrisk stød.
-Hvis du bruger apparatet til at støvsugefint sand, kalk,
cementstøv og lignende materialer,bliver porerne i
filteretblokeret. Rens filteret regelmæssigt.
-Da dette apparat bruger vand til rengøring, kan gulvet forblive
vådt og glat i et stykke tid (fig. 3).
-For at undgå skader må du aldrig hælde voks, olie, produkter til
gulvvedligeholdelse eller flydende gulvrengøringsmidler, der ikke
er vandopløselige, i vandtanken.
-Brug kun flydende gulvrengøringsmidler der er gennemsigtige.
Brug ikke mælkede eller uigennemsigtige gulvrengøringsmidler.
-Bland ikke forskellige typer flydende gulvrengøringsmidler. Når du
har anvendt et flydende gulvrengøringsmiddel, skal du først
tømme og skylle vandtanken, før du hælder et andet flydende
gulvrengøringsmiddel i vandtanken.
-Når du bruger et flydende gulvrengøringsmiddel, må du aldrig
bruge mere end den maksimale mængde, der er angivet på
flasken. Tilsæt ikke mere end et par dråber til vandet i
vandtanken, da denne tank har en kapacitet på 200 ml.
-Rengør ikke metalvædestrimlen med en skarp genstand, da det
vil kunne beskadige strimlen. Vædestrimlen skal kun rengøres ved
at skylle den under vandhanen. Udskift vædestrimlen, når den
ikke længere kan rengøres.
-Vædestrimlen må kun udskiftes med en original strimmel.
-For at sikre gode resultater og optimal funktionsevne bør der altid
anvendes originale rengøringspuder fra Philips.
-Rengør vandtanken i overensstemmelse med vejledningen.
Vandtanken kan ikke vaskes i opvaskemaskinen.
-Brug ikke skrappe rengøringsmidler eller værktøjer til at rengøre
Aqua Boost-pedalen (fig. 4).
20 Dansk

-Når du er færdig med at vaske gulv, må du ikke hænge moppen
på væggen med vandtanken monteret. Det kan medføre skader
på væggen, hvis den våde moppepude rører væggen. Fjern altid
vandtanken, når moppen hænges til opbevaring.
Elektromagnetiske felter (EMF)
Dette Philips-apparat overholder alle branchens gældende standarder og regler angående
eksponering for elektromagnetiske felter.
Sådan bruges apparatet
Begrænsninger for brug
-Vandtanken må kun bruges på hårde gulve med en vandfast overfladebehandling (f.eks. linoleum,
emaljerede klinker eller lakeret parketgulv) og stengulve (f.eks. marmor). Hvis dit gulv ikke er blevet
behandlet, så det er vandfast, så spørg producenten, om du må bruge vand til at gøre det rent.
Brug ikke vandtanken på hårde gulve, hvor den vandfaste overfladebehandling er beskadiget.
-Brug kun vandtanken på linoleumsgulve, der er korrekt fastgjorte, for at undgå, at linoleum bliver
trukket ind i moppemundstykket.
-Vandtanken må ikke bruges til tæpperens.
-Flyt ikke apparatet med sidelæns monteret vandtank, da det efterlader vandstriber. Bevæg kun
apparatet frem og tilbage.
Bemærk: Driftstiden afhænger af, hvor meget strøm der er brugt under rengøringen.
Moppepude og vædestrimmel
Apparatet leveres med én vædestrimmel og to identiske moppepuder af mikrofiber. Med vandtanken,
vædestrimlen og moppepuden af mikrofiber fastgjort til standardgulvmundstykket kan du rengøre
hårde gulve.
Brug af flydende gulvrengøringsmiddel i vandtanken
Hvis du vil tilføje et flydende gulvrengøringsmiddel til vandtanken, skal du sørge for at bruge et
lavtskummende eller ikke-skummende flydende gulvrengøringsmiddel, som kan opløses i vand. Da
vandtanken har en kapacitet på 200 ml, behøver du kun at tilsætte et par dråber flydende
gulvrengøringsmiddel til vandet.
Rengøring afvandtanken
Vandtanken rengøres ved hjælp af en blanding med en del eddike og tre dele vand. Hæld denne
blanding op i vandtanken, og luk låget. Ryst vandtanken, og sæt den på et vandfast underlag. Lad
vandtanken stå med vand/eddike-blandingen natten over. Tøm derefter vandtanken, og skyl den
omhyggeligt med vand. Derefter er den klar til normal brug igen.
Forsigtig: Vand vil lække fra vandtanken under rengøring både med og uden vædestrimlen sat på
mundstykket.
21
Dansk

For at tømme vandtanken skal du holde vandtanken over en vask, fjerne dækslet og vippe
vandbeholderen til siden med påfyldningshullet. Vend derefter bunden i vejret på vandtanken og lad
vandet løbe ned i vasken. For at tømme det resterende vand ud af vandtanken, skal du vende
vandtanken på langs med påfyldningshullet rettet mod vasken. Vip derefter vandtanken fremad for at
lade det resterende vand flyde ud af vandtanken.
Bemærk: Opbevar vandtanken med dækslet taget af påfyldningshullet.
Bestilling af tilbehør
Du kan købe tilbehør og reservedele på www.philips.com/parts-and-accessories eller hos din
Philips-forhandler. Du kan også kontakte det lokale Philips-kundecenter (du kan finde
kontaktoplysninger i den internationale garantifolder).
Reklamationsret og support
Hvis du har brug for hjælp eller support, bedes du besøge www.philips.com/support eller læse i
folderen om international garanti.
Genanvendelse
-Dette symbol betyder, at dette produkt ikke må bortskaffes sammen med almindeligt
husholdningsaffald (2012/19/EU) (fig. 5).
-Dette symbol betyder, at produktet indeholder et indbygget genopladeligt batteri, som ikke må
bortskaffes sammen med almindeligt husholdningsaffald (fig. 6) (2006/66/EF). Aflever produktet
på et officielt indsamlingssted eller hos en Philips-forhandler, hvor du kan få en fagmand til at tage
det genopladelige batteri ud.
-Følg den nationale lovgivning om særskilt indsamling af elektriske og elektroniske produkter og
genopladelige batterier. Korrekt bortskaffelse er med til at forhindre negativ påvirkning af miljøet
og menneskers helbred.
Udtagning af det genopladelige batteri
Det genopladelige batteri må kun tages ud af apparatet, når produktet skal bortskaffes.
Før du fjerner batteriet, skal du sørge for, at produktet er taget ud af stikkontakten, og
at batteriet er fuldstændigt afladet.
Overhold de nødvendige sikkerhedsforanstaltninger, når du anvender værktøj til at åbne
produktet, og når du bortskaffer det genopladelige batteri.
Følg nedenstående vejledning for at fjerne det genopladelige batteri.
1Lad apparatet køre til det stopper af sig selv.
2Tag støvbeholderen ud af apparatet (fig. 7).
3Fjern de tre skruer, der fastgør batteriholderen til apparatets (fig. 8) kabinet.
4Træk batteriholderen ud af apparatet (fig. 9).
22 Dansk
