Philips FC8380/01 User manual

Impact Plus

2

ENGLISH 4
ESPAÑOL 10
POLSKI 16
ROMÂNĂ 22
РУССКИЙ 28
ČESKY 34
MAGYAR 40
SLOVENSKY 46
УКРАЇНСЬКІЙ 52
HRVATSKI 58
EESTI 64
LATVISKI 70
LIETUVIŠKAI 76
SLOVENŠŚINA 82
93
IMPACT PLUS
3
áá««HHôô©©ddGG

Important
◗Only use Philips S-bag`double-layer paper dustbags or the cotton
dustbag provided
◗Never suck up water or any other liquid.Never suck up ashes until
they are cold.
◗When the vacuum cleaner is used to suck up fine dust,the pores
of the dustbag may become clogged,causing the passage of air
through the dustbag to become obstructed.As a result,the
'dustbag full' indicator will indicate that the dustbag needs to be
replaced,even though the dustbag is not full at all.
◗Never use the appliance without the Motor Protection Filter.This
could damage the motor and shorten the life of the appliance.
◗If the mains cord of this appliance is damaged,it may only be
replaced by Philips or a service centre authorised by Philips,as
repair requires special tools and/or parts.
Connecting accessories
C1To connect the hose,push it into the appliance and turn it
clockwise.
To disconnect the hose,turn it anticlockwise and pull it out of the
appliance.
C2Connect the tubes to each other and to the handgrip by
inserting the narrow section into the wider section while
turning it a little.The tube with the clip is the lower tube.
You can connect the accessories in the same way.
Disconnect the accessories and tubes by pulling them and turning them
a little.
C3Telescopic tube (specific types only):
Adjust the tube to the length you find most comfortable during
vacuum cleaning.
4The combi nozzle can be used on either carpets (without
brush) or hard floors (with brush):
ENGLISH4

C◗Push the rocker switch on top of the combi nozzle with your foot
to make the brush strip for cleaning hard floors come out of the
nozzle housing.
C◗Push the rocker switch on the other side to make the brush strip
disappear into the housing.
C5The crevice nozzle can be found in the special storage
compartment.
Vacuum cleaning
C1Pull the cord out of the appliance and put the mains plug in the
wall socket.
Switch the appliance on by pushing the on/off button.
C2To carry the appliance,put the handle in upright position.
ENGLISH 5

C3You can adjust the suction power by means of the slide on the
handgrip.
C4You can adjust the suction power by means of the electronic
suction power control (specific types only).
Storage
C1Switch the appliance off and remove the mains plug from the
wall socket.
Rewind the mains cord by pressing the cord rewind button.
C2Put the appliance in upright position and attach the lower tube
to the appliance by means of the clip.
The clip can be slide along the tube to adjust its height.
Replacing the dustbag
◗Replace the dustbag as soon as the 'dustbag full' indicator has
changed colour permanently.
C1Switch the appliance off and open the cover.
ENGLISH6

C2Push the dustbag holder backwards.
C3Lift the dustbag out of the compartment by pulling the
cardboard lug upwards,which causes the dustbag to be sealed.
C4Slide the cardboard front of the new dustbag into the two
grooves of the dustbag holder.Press it down as far as possible.
C5Pull the dustbag holder forwards ('Click').You cannot close the
cover if no dustbag has been inserted.
Philips S-bag`paper dustbags are available under type number
FC8021.
◗If provided,you can use the cotton dustbag instead of paper
dustbags.
The cotton dustbag can be used and emptied repeatedly.
For removing and inserting the cotton dustbag, simply follow the
instructions for replacing paper dustbags.
To empty the cotton dustbag:
1Remove the clip by sliding it off the dustbag sideways.
2Undo the metal hooks.
3Shake out the contents.
4Close the dustbag by fastening the metal hooks and sliding the
clip back onto the bottom edge of the dustbag.
ENGLISH 7

Filter replacement
AFS Micro Filter
Replace the AFS Micro Filter every 6 months.
The AFS Micro Filter will remove a large part of the smallest particles
from the exhaust air.
C1Open the grill and remove the filter
C2Place the sides (1,2) and the bottom edge (3) of the new filter
properly behind the ridges of the holder.
C3Put the holder back into the vacuum cleaner by first hooking
the bottom edge of the holder into the appliance (1) and then
pushing the holder towards the appliance (2) until it snaps
home.
Make sure the filter holder has been placed properly.
Motor Protection Filter
Replace the Motor Protection Filter once a year.
If you are using the cotton dustbag,wash the Motor Protection Filter in
lukewarm water once a year.
Make sure the Motor Protection Filter is completely dry before you
put it back into the appliance.
C1Switch the appliance off and open the cover.Take out the filter
holder and remove the filter.
2Insert a new filter into the holder with the white side facing
upwards and place the holder back.
Two AFS Micro Filters and one Motor Protection Filter are available
under type number FC8032.
ENGLISH8

Environment
To make recycling possible,the plastics used for this appliance have
been coded.
The cardboard packaging has been made of recycled material and is
fully recyclable.
Insufficient suction power
1Check if the dustbag needs to be replaced.
2Check if the filters need to be replaced.
3Check if the slide on the handgrip is closed.
4Check if the electronic suction power control is at its
maximum setting (specific types only).
C5Check if the nozzle,tube or hose is blocked up.To remove the
obstruction,disconnect the blocked-up item and connect it (as
far as possible) the other way around.Switch the vacuum
cleaner on to force the air through the blocked-up item in
opposite direction.
Information & service
If you need information or if you have a problem,please visit the Philips
Web site at www.philips.com or contact the Philips Customer Care
Centre in your country (you will find its phone number in the
worldwide guarantee leaflet).If there is no Customer Care Centre in
your country,turn to your local Philips dealer or contact the Service
Department of Philips Domestic Appliances and Personal Care BV.
ENGLISH 9

Importante
◗Utilice bolsas S-bag`de Philips,de papel de doble capa.
◗No aspire nunca agua o cualquier otro líquido.No aspire nunca
cenizas hasta que esten frías.
◗Cuando elAspirador se usa para aspirar polvo fino,los poros de la
bolsa para el polvo pueden obturarse,dando lugar a que se
obstruya el paso del aire a través de la bolsa para el polvo.Como
resultado de ello,el indicador "Bolsa llena" indicará que la bolsa
necesita ser cambiada incluso cuando la bolsa para el polvo no
esté completamente llena.
◗No use nunca el aparato sin el Filtro Protector del Motor ya que
podría deteriorar el motor y acortar la vida útil del aparato.
◗Si el cable de red de este aparato se deteriora,sólo puede ser
sustituido por Philips o por uno de los Servicios deAsistencia
Técnica de Philips ya que la reparación requiere piezas y/o
herramientas especiales.
Cómo conectar los accesorios
C1Para conectar la manguera,introdúzcala en el aparato y gírelo
en sentido de las agujas del reloj.
Para desconectar la manguera,gírela en sentido contrario a las agujas
del reloj y sáquelo del aparato.
C2Conecte los tubos entre sí y al mango introduciendo la sección
más estrecha en la más ancha a la vez que lo va girando un
poco.El tubo con brida es el tubo que va más abajo.
Puede montar el resto de los accesorios de igual manera.
Para quitar los accesorios y los tubos,tire de ellos y gírelos ligeramente.
C3Tubo telescópico (sólo para modelos determinados):
Ajuste el tubo a la longitud que considere más cómoda durante el
aspirado.
4La boquilla combinada se puede utilizar tanto sobre alfombras
(sin cepillo) como en suelos lisos (con cepillo):
ESPAÑOL10
