Device power-up
Wiring the controller
Refer to the documentation provided with the ILC 191 ETH 2TX controller
(Order no. 2700976) for installation instructions.
Installing the input modules
Up to ten modules can be used on the bus at a time. The following
modules are applicable for this application:
Refer to the individual module documentation for wiring instructions to
field devices.
Information for the ILC 191 ETH 2TX can be found at
phoenixcontact.net/product/2700976
WARNING:
Always remove power from the device before installation or
removal of modules.
Table 1 Available modules
Order No. Descriptor Provides
2861302 IB IL AI 2/SF-PAC Two analog channels
2861386 IB IL TEMP 2 UTH-PAC Two thermocouple channels
2861328 IB IL TEMP 2 RTD-PAC Two RTD channels
2700173 IB IL 24 DI8/HD-PAC Eight digital inputs
2700172 IB IL 24 DO8/HD-PAC Eight digital outputs

4010_en_C PHOENIX CONTACT 2
SD flash card memory
The PDR-1000 includes a pre-installed 2 GB SD card required for
operation.
Only Phoenix Contact 2 GB cards are supported.

3PHOENIX CONTACT 4010_en_C
Connecting the user interface
1. Connect an Ethernet cable between an RJ45 port on the ILC 191
ETH 2TX controller and a computer.
2. Set the IP address of the computer to 192.168.0.100 or any unused
IP address in 192.168.x.x subnet with a subnet mask of
255.255.255.0.
Figure 1 “Ethernet 2 Properties” dialog box

4010_en_C PHOENIX CONTACT 4
Figure 2 “Internet Protocol Version 4 (TCP/IPv4) Properties” dialog box

5PHOENIX CONTACT 4010_en_C
3. Open a browser (Google Chrome™or Mozilla®Firefox®are
recommended) and enter http://192.168.0.5 in the “Address” field to
load the user interface.
Figure 3 Initial connection loading screen
The loading screen will display with the application is loaded. This
may take some time, depending on the network connection.

4010_en_C PHOENIX CONTACT 6
Configuring the connected modules
The first time connecting to the device will cause a prompt to configure the
hardware setup to match the physical arrangement of modules.
Figure 4 Hardware configuration
Click on each module, and click the appropriate module from the list to
select it. Click the “Save” button when finished.

7PHOENIX CONTACT 4010_en_C
Accessing the administrative settings
The I/O channels, channel groupings, and recorded I/O list must be
configured before logging can begin.
1. Click the “Configuration” button in the top right corner of the screen.
Figure 5 Configuration button on the Dashboard
2. Enter the administrative credentials in the pop-up window. The
default password is private.
3. Navigate to the I/O Configuration page and enter the I/O data as
desired.
Configuration button
