Phoenix Gold TI2 Pointsource User manual

TI2 PointSource
OWNER’S MANUAL

www.phoenixgold.com
Ti2 Pointsource Owner’s Manual
A few words ABOUT Design
Specifications
Ti265ps Ti257ps Ti269ps
RMS Power Handling 100 watts 100 watts 100 watts
PEAK Power Handling 200 watts 200 watts 200 watts
Nominal Impedance 4 ohms 4 ohms 4 ohms
Sensitivity 91dB 91dB 92dB
Mounting Depth 65mm -
2.55 inches
59mm -
2.4 inches
78mm -
3.1 inches
Mounting Diameter 145mm -
5.7 inches
127mm x 182mm -
5 x 7.2 inches
151mm x 221mm
6 x 8.7 inches
Thank you for purchasing the Phoenix Gold Ti2 Pointsource speaker system. It features a 20mm pure silk dome
tweeter that is mounted in a pointsource conguration. The 6.5” midrange has a unique dual roll surround
that eliminates unwanted resonances, acoustical artifacts and dampens mechanical vibrations. The tweeter
and midrange has been specically engineered with complex FEA analysis that perfectly optimizes the motor
structures. In addition, the passive crossovers are computer modeled and then real world (in car tested and
further tweaked) tuned to provide a seamless transition from the midrange to tweeter. Whether you are looking
to upgrade tired factory speakers or desire studio grade performance the Ti2 pointsource systems are the perfect
solution.
FEATURES:
• 20mm Silk Dome Tweeter
• Poly Treated Paper Cone
• Smooth Termination Dual Roll Rubber Surround
• Powder Coated Stamped Steel Basket
• 24dB External Audiophile Crossover
• High Temperature CAE/CAD Motor Structure

www.phoenixgold.com
Ti2 Pointsource Owner’s Manual
Crossover wiring
INSTALLATION:
- The provided external passive crossovers MUST be used with the Ti2 Pointsource speakers. Speaker damage
WILL occur if the external crossovers are not used.
- Installation is simple just follow the clearly marked labels on the wiring and speaker terminals. The wiring
connections are also marked on the internal PCB which is accessible by removing the crossover housing’s top
cover.
- Each speaker has two seperate (and clearly labeled) terminals: one for the tweeter and one for the woofer. Both
terminals must be used and connected to the correct wires on the passive crossover.
- IMPORTANT: USE THE PRE-TERMINATED SPADE TERMINALS FOR EASY INSTALLATION. DO NOT CUT THEM OFF!
The crossover wires are pre-terminated with the correct size spade terminals that match the correct size terminal
on the speaker. This makes installation much faster/easier, and also makes it impossible to mistakenly wire the
woofer wires from the crossover to the tweeter terminal on the speaker.
- Double check all the wiring connections before turning the system on. Most importantly double check the
woofer wires from the crossover are NOT wired to the tweeter terminal of the speaker. The tweeter will be
damaged if this occurs.
Ti
POINTSOURCE
CROSSOVER
2
To Amplifier
or Headunit
To Tweeter To Woofer
T+ T- W+ W-
+ -

www.phoenixgold.com
Phoenix Gold
A Division of AAMP of America™
13190 56th Court
Clearwater, Florida 33760
P: 866-788-4237
[email protected]
www.phoenixgold.com
© 2013 AAMP of Florida, Inc
Designed and Engineered in the USA
