Phoenix Model K8B User manual

Wingspan : 3500mm (137.8 inch)
Length : 1650mm (64.96 inch)
Weight : 3700gr
Radio : 5 servo standard / 6 channel
g
Instruction Manual

fuselage WHEEL ASSEMBLY
• (1) 5mm x 40mm metal pushrod
• (1) 75mm diameter wheel
• (2) 5mm wheel collar
• (4) Wood plate
ELEVATOR CONTROL SYSTEM
• (2) Control horn
• (2) 3mm x 40mm screw
• (2) Horn
• (2) M2 metal clevis
• (2) Silicone tube
• (1) Nylon snap keeper
• (1) Domino connector
• (1) 1,7mm x 100mm metal pushrod
RUDDER CONTROL SYSTEM
• (1) Control horn
• (1) 3mm x 50mm screw
• (1) M2 metal clevis
• (1) Silicone tube
• (1) Nylon snap keeper
• (1) Horn
1
KIT CONTENTS: We have organized the parts as they come out of the box for better identification
during assembly. We recommend that you regroup the parts in the same manner. This will ensure you
have all of parts required before you begin assembly.
KIT CONTENTS
AILERON CONTROL SYSTEM
• (2) Control horn
• (2) 3mm x 40mm screw
• (2) M2 metal clevis
• (2) Horn
• (2) Nylon snap keeper
• (2) Silicone tube
• (8) 2mm x 10mm wood screw
• (2) 1,7mm x 180mm metal pushrod
MISCELLANEOUS ITEMS
• (2) Dihedral
• (4) Wing screw
• (2) 4mm x 30mm nylon screw
• (2) 4mm x 20mm machine screw
• (2) 4mm x 40mm screw
• (4) 4mm flat washer
• (4) 8mm flat washer
• (1) Metal connector
• (1) 1,7mm x 100mm metal pushrod
• (3) 1,7mm x 1300mm metal pushrod
• (2) Plastic cover
• (1) Instruction manual
• (1) Decal sheet

TOOLS AND SUPPLIES NEEDED.
• Medium C/A glue.
• 30 minute epoxy.
• 6 minute epoxy.
• Hand or electric drill.
• Assorted drill bits.
• Modeling knife.
• Straight edge ruler.
• 2 bender plier.
• Wire cutters.
• Masking tape.
• Thread lock.
• Paper towels.
• Rubbing alcohol
SUGGESTION
To avoid scratching your new airplane, do not unwrap
the pieces until they are needed for assembly. Cover
your workbench with an old towel or brown paper,
both to protect the aircraft and to protect the table.
Keep a couple of jars or bowls handy to hold the
small parts after you open the bag.
NOTE:
Please trial fit all the parts. Make sure you have the
correct parts and that they fit and are aligned properly
before gluing! This will assure proper assembly. The
K8B is hand made from natural materials, every
plane is unique and minor adjustments may have to
be made. However, you should find the fit superior
and assembly simple.
The painted and plastic parts used in this kit are fuel
proof. However, they are not tolerant of many harsh
chemicals including the following: paint thinner, C/A
glue accelerator, C/A glue debonder and acetone. Do
not let these chemicals come in contact with the
colors on the covering and the plastic parts.
SAFETY PRECAUTION:
• This is not a toy
• Be sure that no other flyers are using your radio
frequency.
• Do not smoke near fuel
• Store fuel in a cool, dry place, away from
children and pets.
• Wear safety glasses.
• The glow plug clip must be securely attached to
the glow plug.
• Do not flip the propeller with your fingers.
• Keep loose clothing and wires away from the propeller.
• Do not start the engine if people are near. Do not
stand in line with the side of the propeller.
• Make engine adjustments from behind the propeller
only. Do not reach around the spinning propeller.
2
PREPARATIONS
Remove the tape and separate the ailerons from
the wing and the elevators from the stab. Use a
covering iron with a covering sock on high heat to
tighten the covering if necessary. Apply pressure
over sheeted areas to thoroughly bond the
covering to the wood.
1
INSTALLING THE AILERONS
1. Use the modeling knife to cut a strip of covering
from the hinge slots in the wing and aileron.
2. Locate the four CA hinge strip. Snip off the
corners so they go in easier.
3. Test fit the ailerons to the wing with the hinges.
If the hinges don’t remain centered, stick a pin
through the middle of the hinge to hold it in
position.
CUT THE COVERING
AWAY FROM THE SLOT
TEMPORARY PIN
TO KEEP HINGE
CENTERED
4. Remove any pins you may have inserted into
the hinges. Adjust the aileron so there is a
small gap between the LE of the aileron and
the wing. The gap should be small, just enough
to see light through or to slip a piece of paper
through.

3
2
CA glue
5. Apply six drops of thin CA to the top and bottom
of each hinge. Do not use CA accelerator. After
the CA has fully hardened, test the hinges by
pulling on the aileron.
3. Place the servo into the servo tray. Center the
servo within the tray and drill 1,6mm pilot holes
through the block of wood for each of the four
mounting screws provided with the servo.
Remove the covering
3
INSTALLING THE AILERON SERVOS
1. Install the rubber grommets and brass eyelets
onto the aileron servo.
2. Using a modeling knife, remove the covering
from over the pre-cut servo arm exit hole on the
aileron servo tray / hatch. This hole will allow
the servo arm to pass through when installing
the aileron pushrods.
4
6. Repeat step # 2 - # 5 to install the second
aileron servo in the opposite wing half.
5. Place the aileron servo tray / hatch into the
servo box on the bottom of the wing and drill
1,6mm pilot holes through the tray and the
servo box for each of the four mounting screws.
Secure the servo tray in place using the
mounting screws provided ( 2mm x 12mm ).
7. Using masking tape, tape the servo leads on to
the top of the wing.
4. Using the thread as a guide and using masking
tape, tape the servo lead to the end of the
thread: carefully pull the thread out. When you
have pulled the servo lead out, remove the
masking tape and the servo lead from the
thread.
Servo lead
5
6
To the cowl
7
To the cowl

4
8
9. Repeat step # 4 - # 8 to install the second
aileron linkage. After both linkages are
completed, connect both of the aileron servo
leads using a Y-harness you have purchased
separately.
11
To the cowl
Silicone Tube
10
To the cowl
3. Repeat step # 1 - # 2 to install the control horn
on the opposite aileron.
3. Locate one nylon servo arm, and using wire
cutters, remove all but one of the arms. Using a
2mm drill bit, enlarge the third hole out from the
center of the arm to accommodate the aileron
pushrod wire.
4. Plug the aileron servo into the receiver and
center the servo. Install the servo arm onto the
servo. The servo arm should be perpendicular
to the servo and point toward the middle of the
wing.
5. Center the aileron and hold it in place using a
couple of pieces of masking tape.
6. With the aileron and aileron servo centered,
carefully place a mark on the aileron pushrod
wire where it crosses the hole in the servo arm.
7. Using pliers, carefully make a 90 degree bend
down at the mark made. Cut off the excess
wire, leaving about 4mm beyond the bend.
8. Insert the 90 degree bend down through the
hole in the servo arm. Install one nylon snap
keeper over the wire to secure it to the arm.
Install the servo arm retaining screw and
remove the masking tape from the aileron.
2. Attach the clevis to the outer hole in the control
horn. Install a silicone tube on the clevis.
INSTALLING THE AILERON LINKAGES
1. Working with the aileron linkage for now, thread
one nylon clevis at least 14 turns onto one of
the 2mm x 180mm threaded wires.
9
INSTALLING THE CONTROL HORNS
1. One aileron control horn in positioned on each
aileron. Using a ruler and a pen, locate and
mark the location of the control horn. It should
be mounted on the bottom side of the aileron at
the leading edge, in line with the aileron
pushrod.
2. Drill 3mm holes through the aileron using the
control horn as a guide and screw the control
horn in place.
RIGHT WRONG

5
12
13
2. Attach the wing to the fuselage as picture.
1. Remove the covering.
4. Secure the horizontal onto the fuselage.
3. Test the position of the elevator and adjust it as
shown.
14
Plastic Screw
INSTALLING THE RUDDER
1. Repeat step #1 - #5 from installing the aileron
to install the rudder.
17
16
Glue the hinges
by C.A glue
INSTALLING THE HORIZONTAL STABILIZER
INSTALLING THE elevator
- Repeat step #1 - #5 from installing the aileron
to install the elevator.
15
18
2. Remove the covering from the fuselage.

26
25
6
19
20
21
22
23
INSTALLING THE main landing gear
1. The full set wheel.
24
3. Insert the vertical stabilizer into the fuselage.
5. Secure the vertical stabilizer into the fuselage.
2. Secure the collars.
3. Glue the wooden plate to the fuselage.
4. Remove the covering from the fuselage.

7
7. Attach clevis to the third hole in the control
horn. Install a silicone tube on the clevis.
8. Locate one nylon servo arm, and using wire
cutters, remove all but one of the arms. Using a
2mm drill bit, enlarge the third hole out from the
center to accommodate the elevator pushrod
wire.
9. Plug the elevator servo into the receiver and
center the servo. Install the servo arm onto the
servo. The servo arm should be perpendicular
to the servo and point toward the middle of the
fuselage.
10. Be sure both elevator halves are flat. Center
both elevator halves and hold them in place
using a couple of pieces of masking tape.
11. Connect two elevator purshord to the metal
domino connector and secure it. Insert the wire
pushrod into the metal domino connector and
secure it.
27
Elevator servo
Rudder servo
Towing servo
28
Remove the covering
SERVO INSTALLATION
INSTALLING THE FUSELAGE SERVOS
1. Install the rubber grommets and brass collets
into the elevator, rudder and towing servos.
Test fit the servos into the servo tray. Trim the
tray if necessary to fit your servos
2. Mount the servos to the tray using the mounting
screws provided with your radio system.
3. Working from inside the fuselage, slide the
threaded end of the pushrod until it reaches the
exit slot. Carefully reach in with a small screw
driver and guide the pushrod out of the exit
slot.
4. Install the clevis on the elevator pushrod. Make
sure 6mm of thread shows inside the clevis.
5. The control horn should be mounted on the
bottom, left side and right side of the elevator at
the leading edge, in line with the elevator
pushrod.
6. Drill 3mm holes through the elevator using the
control horn as a guide and screw the control
horn in place.
INSTALLING THE ELEVATOR PUSHROD
1. Locate the pushrod exit slot on the right side
and left side of the fuselage. It is located
slightly ahead and below the horizontal
stabilizer.
2. Carefully cut away the covering material from
the slot.
30
Control horn Control horn
29
Control horn elevator
31
Silicone tube
Silicone tube

8
32
Metal Domino
12. With the elevator halves and elevator servo
centered, carefully place a mark on the elevator
pushrod wire where it crosses the hole in the
servo arm.
13. Using pliers, carefully make a 90 degree bend
up at the mark made. Cut off the excess wire,
leaving about 8mm beyond the bend.
14. Insert the 90 degree bend up through the hole
in the servo arm, install one nylon snap keeper
over the wire to secure it to the arm. Install the
servo arm retaining screw and remove the
masking tape the elevator halves.
15. Using thick CA glue, secure the pushrod
sleeves to the pushrod sleeve guide.
INSTALLING THE RUDDER PUSHROD
1. Locate the pushrod exit slot on the left of the
fuselage.
2. Carefully cut away the covering material from
the slot. 8. Locate one nylon servo arm, and using wire
cutters, remove all but one of the arms using a
2mm drill bit, enlarge the third hole out from the
center to accommodate the rudder pushrod
wire.
9. Plug the rudder servo into the receiver and
center the servo. Install the servo arm onto the
servo.
10. Center the rudder and hold it in place using a
piece of masking tape.
11. With the rudder and rudder servo centered,
carefully place a mark on the rudder pushrod
wire where it crosses the hole in the servo arm.
12. Using a pliers, carefully make a 90 degree
bend up at the mark made. Cut off excess wire,
leaving about 8mm beyond the bend.
13. Insert the 90 degree bend up through the hole
in the servo arm. Install one nylon snap keeper
over the wire to secure it to the arm. Install the
servo arm retaining screw and remove the
masking tape from the rudder.
14.Using thick CA glue, secure the pushrod
sleeves to the pushrod sleeve guide.
7. Attach clevis to the third hole in the control
horn. Install a silicone tube on the clevis.
3. Working from inside the fuselage, slide the
threaded end of the remaining pushrod down
the inside of the fuselage until the pushrod
reaches the exit slot. Carefully reach in with a
small screw driver and guide the pushrod out of
the exit slot.
4. Install the clevis on the rudder pushrod. Make
sure 6mm of thread shows inside the clevis.
5. The control horn should be mounted on the left
side of the rudder at the leading edge, in line
with the rudder pushrod.
6. Drill 3mm holes through the rudder using the
control horn as a guide and screw the control
horn in place.
33
34
Control horn
35
Silicone tube

38
INSTALLING THE towing servo
1. Install the metal connector to the servo arm.
2. Bend “L” the metal rod as the picture below.
3. Place the servo arm to the servo and secure it.
9
36
39
43
Receiver
Battery
Switch
!
INSTALLING THE RECEIVER AND BATTERY
1. Plug the servo leads and the switch lead into
the receiver. You may want to plug an aileron
extension into the receiver to make plugging in
the aileron servo lead easier when you are
installing the wing. Plug the battery pack lead
into the switch.
2. Wrap the receiver and battery pack in the
protective foam to protect them from vibration.
Use a rubber band or masking tape to hold the
foam in place.
3. Position the battery pack and receiver behind
the fuel tank. Use the two light plywood pieces,
placed over the battery and receiver and glue
to the fuselage sides to hold the battery and
receiver securely in place. Use 15mm triangle
pieces glued between the fuselage sides and
the plywood pieces to reinforce the joints.
Do not permanently secure the receiver and
battery until after balancing the model.
4. Using a 2mm drill bit, drill a hole through the
side of the fuselage, near the receiver, for the
antenna to exit.
INSTALLING THE SWITCH
1. The switch should be mounted on the fuselage
side, opposite the muffler, close enough to the
receiver so the lead will reach. Use the face
plate of the switch cut out and locate the
mounting holes.
2. Cut out the switch hole using a modeling knife.
Use a 2mm drill bit and drill out the two
mounting holes through the fuselage side.
3. Secure the switch in place using the two
machine screws provided with the radio
system.
37

44
Screw
45
BALANCING
1. It is critical that your airplane be balanced
correctly. Improper balance will cause your
plane to lose control and crash.
THE CENTER OF GRAVITY IS LOCATED 80mm
BACK FROM THE LEADING EDGE OF THE
WING, AT THE FUSELAGE. This location is
recommended for initial test flying and
trimming. There is a 5mm margin forward and
aft. BALANCE A PLANE UPSIDE DOWN WITH
THE FUEL TANK EMPTY.
2. Mount the wing to the fuselage. Using a couple
of pieces of masking tape, place them on the
top side of the wing 80mm back from the
leading edge, at the fuselage sides.
3. Turn the airplane upside down. Place your
fingers on the masking tape and carefully lift
the plane .
4. If the nose of the plane falls, the plane is nose
heavy. To correct this first move the battery
pack further back in the fuselage. If this is not
possible or does not correct it, stick small
amounts of lead weight on the fuselage under
the horizontal stabilizer. If the tail of the plane
falls, the plane is tail heavy. To correct this,
move the battery and receiver forward or if this
is not possible, stick weight into the firewall.
When balanced correctly, the airplane should
sit level or slightly nose down when you lift it up
with your fingers.
80mm
!
LATERAL BALANCE
After you have balanced a plane on the C.G.
You should laterally balance it. Doing this will
help the airplane track straighter.
5. Turn the airplane upside down. Attach one loop
of heavy string to the engine crankshaft and
one to the tail wheel wire. With the wings level,
carefully lift the airplane by the string. This may
require two people to make it easier.
6. If one side of the wing fall, that side is heavier
than the opposite. Add small amounts of lead
weight to the bottom side of the lighter wing
half's wing tip. Follow this procedure until the
wing stays level when you lift the airplane.
Open and close the canopy
- Glue the plastic cover to the fuselage.
- Glue the plastic cover to the fuselage.
10
46
CONTROL THROWS
1. We highly recommend setting up a plane using
the control throws listed.
2. The control throws should be measured at the
widest point of each control surface.
3. Check to be sure the control surfaces move in
the correct directions.
Aileron : 10mm up 10mm down
Elevator : 8mm up 8mm down
Rudder : 30mm right 30 mm left

Aileron Control
10mm
10mm
Rudder Control
30mm
30mm
Elevator Control
8mm
8mm
11
FLIGHT PREPARATION
PRE FLIGHT CHECK
1. Completely charge your transmitter and receiver
batteries before your first day of flying.
2. Check every bolt and every glue joint in your
plane to ensure that everything is tight and well
bonded.
3. Double check the balance of the airplane.
4. Check the control surface.
5. Check the receiver antenna . It should be fully
extended and not coiled up inside the fuselage.
6. Properly balance the propeller.

I/C FLIGHT WARNINGS
Always operate in open areas, away
from factories, hospitals, schools,
buildings and houses etc. NEVER fly
your aircraft close to people or built
up areas.
THE PROPELLER IS DANGEROUS
Keep fingers, clothing (ties, shirt
sleeves, scarves) or any other loose
objects that could be caught or drawn
in, away from the propeller. Take care
at ALL times.
Keep all onlookers (especially small
children and animals) well back from
the area of operation. This is a flying
aircraft, which will cause serious
injury in case of impact with a person
or animal.
NEVER fly near power lines, aerials
or other dangerous areas including
airports, motorways etc.
NEVER use damaged or deformed
propellers or spinners.
DO NOT dispose of empty fuel
containers on a fire, this can lead to
an explosion.
NEVER fly in wet conditions or on
windy or stormy days.
ALWAYS adjust the engine from
behind the propeller, and do not allow
any part of your body to be in line
with the propeller.
12

I/C FLIGHT GUIDELINES
When ready to fly, first extend the
transmitter aerial.
Operate the control sticks on the
transmitter and check that the control
surfaces move freely and in the
CORRECT directions. ALWAYS land the model INTO the
wind, this ensures that the model lands
at the slowest possible speed.
Switch on the transmitter.
Switch off the transmitter.
Check that the transmitter batteries
have adequate power.
Switch off the receiver.
Switch on the receiver. ALWAYS take off into the wind.
Check that the wings are correctly
fitted to the fuselage. If the model does not respond correctly
to the controls, land it as soon as
possible and correct the fault.
Empty the fuel tank after flying, fuel left
in the tank can cause corrosion and
lead to engine problems.
Made in Vietnam
