햲ON/OFF button
햳Color LCD display
햴Keypad
Up Volume up
Down Volume down
Right Next program
Left Previous
program
Center Menu/select/home
햵Mini USB
connection
햶Reset button
햳
햴
햵햶
햲
Quick Guide
Description

Charging the battery
When charging myPilot for
the first time, leave it to
charge for five hours, even
if the battery symbol stops
flashing.
Turning myPilot ON or OFF
To turn myPilot ON or OFF,
press the ON/OFF button for
two seconds until you see
the display turn ON or OFF.
“Home” button
From any screen or menu level, press the middle
button for 4 seconds to always return to the default
settings of your hearing system and the Home screen
of myPilot.
Getting started
2

Selecting your preferred Home screen
To select different Home screens, enter the menu by
pressing the Center button then select Settings,
then Home screen.
The “standard”-mode gives
you the most complete
overview of volume and
program, including
iconic pictures of the
programs.
In the “direct control”-
mode each button directly
selects the indicated
program number. This
mode is for the program
and volume control only
with no menu or
ZoomControl access.
The screens of your myPilot may look different,
depending on your preferences set by your
hearing care professional.
Using myPilot
3

Using myPilot
“Standard”-mode
The "standard"-mode
gives the full overview
including program and
volume information.
Press the left or right arrow (/) to scroll
through the hearing programs
Press the up-/down arrow (/) to change the
volume. See page 6 for details
Short press middle button to access the
sub-menus
Press middle button for 2 seconds to change
to the ZoomControl screen. See page 7 for details
4

5
Using myPilot
“Direct control”-mode
In the “direct control“-mode each
key selects the indicated program
number.
The program names are shown for 10 seconds
after a new program is selected.
Press the up-/down arrow (/) to
change the volume.
Press the left and right button (/)
simultaneously for 2 seconds to skip
the direct control-mode
The available hearing programs are set by
your hearing care professional.
In the direct control-mode, the screens for volume
control, sub-menus and zoom control are not available.
Quick access however is available.
Programs
Short press
2 second press
Left

1
3
Middle
A
4
Right

2
5

6
Using myPilot
Changing the volume
In the "standard"-mode Home screen go to the Volume
screen by pressing either or . Once in the Volume
screen, you can change the volume of both hearing in-
struments simultaneously by pressing to increase and
to decrease the volume.
In a similar way you can change the volume settings
of your left (or right) hearing instrument individually.
Press  to choose the left side (or  to choose
the right side) after entering the Volume screen as
described above. Then press to increase and 
to decrease the volume.

Using myPilot
ZoomControl (optional)
This special feature
allows you to focus
your hearing system
to front, back, left
or right.
In the “standard” Home screen
press the middle button for 2 seconds to
enter the ZoomControl screen
Short press the left, up, right or down button
(///) to select left, front, right or back
hearing direction
Short press middle button to access the
sub-menus
Press the middle button for 2 seconds again
to return to the program selection screen and to
activate the last used program
Press either the up or down button for 2 seconds
to enter the volume control screen
Note: Ask your hearing care professional whether
ZoomControl is available on your hearing instruments.
7

Special functions
From the menu Settings Quick access
ON/OFF button you can select a special
function associated with a short press of the
ON/OFF button.
Quick access
Short press the ON/OFF button to activate
the stored program/volume settings even from
sleep mode.
Status readout
Short press the ON/OFF button to start the
hearing instrument status readout process.
Visit card
If set, find your hearing care professional contact
in the main menu under Contact.
Using myPilot
8

For your safety and to benefit from all the features
of your myPilot, please read the myPilot User Guide
carefully. Pay particular attention to the “Important
information” section and the following symbol
which refers to associated warnings.
Please ask your hearing care professional
for more help.
Important information
9
