pico Technology PicoScope 5000 A Series User manual

Copyright © 2013 Pico Technology Limited. All rights reserved.
PicoScope 5000 A and B Series
User's Guide
ps5000ab.en r1
Flexible Resolution Oscilloscopes

IPicoScope 5000 A and B Series PC Oscilloscopes User's Guide
Copyright © 2013 Pico Technology Limited. All rights reserved. ps5000ab.en r1
Contents
....................................................................................................................................11 Welcome
....................................................................................................................................22 Introduction
........................................................................................................................................2
1 Safety symbols
........................................................................................................................................2
2 Safety warning
........................................................................................................................................3
3 FCC notice
........................................................................................................................................3
4 CE notice
........................................................................................................................................4
5 Licence conditions
........................................................................................................................................5
6 Trademarks
........................................................................................................................................5
7 Warranty
........................................................................................................................................5
8 Company details
........................................................................................................................................6
9 Minimum system requirements
........................................................................................................................................6
10 Cleaning
....................................................................................................................................73 Pack contents
....................................................................................................................................84 Installation
....................................................................................................................................95 Product information
........................................................................................................................................10
1 Model comparison table
........................................................................................................................................11
2 Connector diagrams
........................................................................................................................................12
3 Moving to another USB port
........................................................................................................................................12
4 Compensating probes
....................................................................................................................................136 Glossary
....................................................................................................................................15
Index

PicoScope 5000 A and B Series PC Oscilloscopes User's Guide 1
Copyright © 2013 Pico Technology Limited. All rights reserved. ps5000ab.en r1
1 Welcome
Thank you for buying a PicoScope 5000 Series Flexible Resolution Oscilloscope
from PicoTechnology!
The PicoScope 5000 A and B Series of Flexible
Resolution Oscilloscopes from PicoTechnology are a
range of high-specification real-time measuring
instruments that connect to the USB port of your
computer. With the PicoScope software you can use
these devices as oscilloscopes and spectrum analyzers.
With various options of portability, resolution, deep
memory, fast sampling rates and high bandwidth,
these highly versatile oscilloscopes suit a wide range of
applications.
B
5V
A
Ext G
PicoScope
www.picotech.com
PicoScope 5000 Series
BCD
5V
A
Ext G
PicoScope
www.picotech.com
PicoScope 5000 Series
The A models are high-speed portable oscilloscopes with a function generator:
PicoScope 5242A
PicoScope 5243A
PicoScope 5244A
PicoScope 5442A
PicoScope 5443A
PicoScope 5444A
The B models are as the A models, but feature an arbitrary waveform generator and
deeper memory:
PicoScope 5242B
PicoScope 5243B
PicoScope 5244B
PicoScope 5442B
PicoScope 5443B
PicoScope 5444B
Here are some of the benefits provided by the PicoScope 5000 A and B Series
oscilloscopes:
Flexibility: Whether you want 8, 12, 14, 15 or 16-bit resolution, the PicoScope
5000 Series Oscilloscopes will suit your needs.
Portability: Take the unit with you and plug it in to any Windows PC.
Performance: Up to 1 GS/s sampling, 200 MHz bandwidth and 512 MS buffer.
Programmability: The PicoScope 5000A SDK lets you write your own programs, in
your chosen programming language, to control all the features of the scope. Using
the API functions, you can develop your own programs to collect and analyze data
from the oscilloscope. Refer to the PicoScope 5000 Series (A API) Programmer's
Guide for more information.
Long-term support: Software upgrades are available to download from our
website. You can also call our technical specialists for support. You can continue to
use both of these services free of charge for the lifetime of the product.
Value for money: You don't have to pay twice for all the features that you already
have in your PC, as the PicoScope 5000 Series oscilloscope contains the special
hardware you need and nothing more.
Convenience: The software makes full use of the full-sized display, disk storage,
user interface and networking built in to your PC.
Five-year warranty: Your oscilloscope is covered for five years from the day of
purchase against manufacturing faults. We don't charge a penny extra for this
benefit.
For further information on the PicoScope 5000 A and B Series oscilloscopes, see the
comparison table in this manual, and the specifications tables in the PicoScope
5000 Series data sheets available on our website.
10

Introduction2
Copyright © 2013 Pico Technology Limited. All rights reserved.ps5000ab.en r1
2 Introduction
2.1 Safety symbols
Warning Triangle
This symbol indicates that a safety hazard exists on the indicated
connections if correct precautions are not taken. Read all safety
documentation associated with the product before using it.
2.2 Safety warning
We strongly recommend that you read the general safety information below before
using your oscilloscope for the first time. Safety protection built in to equipment may
cease to function if the equipment is used incorrectly. This could cause damage to
your computer, or lead to injury to yourself and others.
Maximum input range
The PicoScope 5000 A and B Series Oscilloscopes are designed to measure voltages in
the range -20 V to +20 V. Attempting to measure voltages outside this range (other
than using a differential or isolating probe specifically designed for this purpose) may
expose the user to a risk of electric shock.
The analog inputs of the PicoScope 5000 A and B Series Oscilloscopes are protected
to ±100 V. Contact with voltages outside the protection range may cause permanent
damage to the unit.
Mains (line) voltages
PicoScope 5000 A and B Series oscilloscopes are not designed for use with mains
(line) voltages. To measure mains (or line) voltage, use a differential isolating probe
specifically designed for that purpose.
Safety grounding
PicoScope 5000 A and B Series Oscilloscopes connect directly to the ground of a
computer through the USB cable provided to minimize interference.
Avoid connecting the ground input to any potential other than ground. The outer
shells of the BNC connectors are all at the same potential (shorted together). If in
doubt, use a meter to check that there is no significant AC or DC voltage between the
ground input of the oscilloscope (and also, if your oscilloscope is connected to a
laptop, mains ground) and the point to which you intend to connect it, as this may
cause a large current to flow. Failure to check may cause damage to your computer
and connected equipment, or lead to injury to yourself and others.
Do not rely on the product to provide a protective safety earth.
Repairs
The oscilloscope contains no user-serviceable parts. Repair or calibration of the
oscilloscope requires specialized test equipment and must be performed by
PicoTechnology.

PicoScope 5000 A and B Series PC Oscilloscopes User's Guide 3
Copyright © 2013 Pico Technology Limited. All rights reserved. ps5000ab.en r1
2.3 FCC notice
This equipment has been tested and found to comply with the limits for a Class A
digital device, pursuant to Part 15 Subpart B of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference when the
equipment is operated in a commercial environment. This equipment generates, uses,
and can radiate radio frequency energy and, if not installed and used in accordance
with the instruction manual, may cause harmful interference to radio communications.
Operation of this equipment in a residential area is likely to cause harmful interference
in which case the user will be required to correct the interference at his or her own
expense.
For safety and maintenance information see the safety warning .
2.4 CE notice
The PicoScope 5000 A and B Series Oscilloscopes meet the intent of the EMC
directive 89/336/EEC and have been tested to EN61326-1:2006 Class A
Emissions and Immunity standard.
The product also meets the intent of the Low Voltage Directive and has been
designed to meet BS EN 61010-1:2010 Safety requirements for electrical
equipment for measurement, control, and laboratory use standard.
2

Introduction4
Copyright © 2013 Pico Technology Limited. All rights reserved.ps5000ab.en r1
2.5 Licence conditions
The software supplied with this product is licensed, not sold. Pico Technology Limited
grants a licence to the person who installs this software, subject to the conditions
listed below:
Access. The licensee agrees to allow access to this software only to persons who have
been informed of these conditions and agree to abide by them.
Usage. The software in this release is for use only with Pico Technology products or
with data collected using Pico Technology products.
Copyright. Pico Technology Limited claims the copyright of, and retains the rights to,
all material (software, documents etc.) contained in this release. You may copy and
distribute the entire release in its original state, but must not copy individual items
within the release other than for backup purposes.
Liability. Pico Technology and its agents shall not be liable for any loss, damage or
injury, howsoever caused, related to the use of Pico Technology equipment or
software, unless excluded by statute.
Fitness for purpose. Because no two applications are the same, Pico Technology
cannot guarantee that its equipment or software is suitable for a given application. It
is your responsibility, therefore, to ensure that the product is suitable for your
application.
Mission-critical applications. This software is intended for use on a computer that
may be running other software products. For this reason, one of the conditions of the
licence is that it excludes usage in mission-critical applications; for example, life-
support systems.
Viruses. This software was continuously monitored for viruses during production, but
you are responsible for virus-checking the software once it is installed.
Support. If you are dissatisfied with the performance of this software, please contact
our technical support staff, who will try to fix the problem within a reasonable time. If
you are still dissatisfied, please return the product and software to your supplier
within 14 days of purchase for a full refund.
Upgrades. We provide upgrades, free of charge, from our website at
www.picotech.com. We reserve the right to charge for updates or replacements sent
out on physical media.

PicoScope 5000 A and B Series PC Oscilloscopes User's Guide 5
Copyright © 2013 Pico Technology Limited. All rights reserved. ps5000ab.en r1
2.6 Trademarks
Windows is a registered trademark of Microsoft Corporation in the USA and other
countries.
Pico Technology Limited and PicoScope are trademarks of Pico Technology Limited
registered in the United Kingdom and other countries.
2.7 Warranty
Pico Technology warrants upon delivery, and for a period of 5 years unless otherwise
stated from the date of delivery, that the Goods will be free from defects in material
and workmanship.
Pico Technology shall not be liable for a breach of the warranty if the defect has been
caused by fair wear and tear, willful damage, negligence, abnormal working conditions
or failure to follow Pico Technology's spoken or written advice on the storage,
installation, commissioning, use or maintenance of the Goods or (if no advice has
been given) good trade practice; or if the Customer alters or repairs such Goods
without the written consent of Pico Technology.
2.8 Company details
Address:
Pico Technology
James House
Colmworth Business Park
St Neots
Cambridgeshire PE19 8YP
United Kingdom
Phone:[phone]
Fax: [phone]
Email:
Technical Support: [e-mail]
Sales: [e-mail]
Web site: www.picotech.com

Introduction6
Copyright © 2013 Pico Technology Limited. All rights reserved.ps5000ab.en r1
2.9 Minimum system requirements
To ensure that your PicoScope 5000 Series Oscilloscope operates correctly, you must
have a computer with at least the minimum system requirements as shown in the
following table. The performance of the oscilloscope will be better with a more
powerful PC, and will benefit from a multi-core processor.
Item
Absolute
minimum
Recommended
minimum
Recommended
full specification
Operating system
Windows XP SP3
Windows Vista
Windows 7
Windows 8*
32 bit and 64 bit versions supported
Processor
As required
by Windows
1 GHz
1 GHz
Memory
512 MB
512 MB
Free disk space**
32-bit: 600 MB
64-bit: 1.5 GB
32-bit: 850 MB
64-bit: 2 GB
Ports
USB 1.1 compliant port
USB 2.0 or 3.0 compliant port
* Not Windows RT.
** The PicoScope software does not use all the disk space specified in the table.
The free space is required to make Windows run efficiently.
2.10 Cleaning
Clean the oscilloscope using a soft cloth dampened with a solution of mild soap or
detergent in water.
CAUTION: Do not allow water to enter the oscilloscope casing, as this could damage
the sensitive electronic components inside.

PicoScope 5000 A and B Series PC Oscilloscopes User's Guide 7
Copyright © 2013 Pico Technology Limited. All rights reserved. ps5000ab.en r1
3 Pack contents
A PicoScope 5000 A or B Series Oscilloscope is supplied with the following items:
Standard USB cable (4-channel scopes only)
Double-headed USB cable
AC Adapter (4-channel scopes only)
Software and Reference CD
Installation Guide
2 or 4 x Probes (see Model Comparison table for probe details)
10

Installation8
Copyright © 2013 Pico Technology Limited. All rights reserved.ps5000ab.en r1
4 Installation
Important:
Do not connect your PicoScope 5000 Series Oscilloscope to the PC
until you have installed the software.
Please note the various power supply options below. Consult the appropriate section
relating to the intended use of the oscilloscope and the instructions in the Installation
Guide and the leaflet included with your product package.
Powering 2-channel scopes
Connect your 5000 Series 2-channel oscilloscope to two free, powered USB ports on
the PC or USB hub using the double-headed USB cable supplied (see image 2 below).
Powering 4-channel scopes
When using 1 or 2 channels of the 4-channel 5000 Series oscilloscopes, you have two
options for power.
1. If your computer or USB hub does not have two free, powered USB ports, connect
your 5000 Series oscilloscope to the PC or hub using the single-headed USB cable
supplied. Plug the power adapter into the mains and connect the DC cable to the
DC power socket on the rear of the oscilloscope (see image 1 below).
2. If your computer or USB hub has two free, powered USB ports, connect your 5000
Series oscilloscope to two ports on the PC or hub using the double-headed USB
cable supplied (see image 2 below).
When using 3 or 4 channels on the 4-channel 5000 Series oscilloscopes connect your
oscilloscope to the PC or hub using the single-headed USB cable supplied. Plug the
power adapter into the mains and connect the DC cable to the DC power socket on
the rear of the oscilloscope (see image 1 below).
Note: If you connect or disconnect the AC adapter while the oscilloscope is in
operation it will restart automatically and any unsaved data will be lost.
Checking the installation
Once you have installed the software and connected the oscilloscope to the PC, start
the PicoScope software. The software should now display any signal connected to the
scope inputs. If you have a probe connected to your oscilloscope, you should see a
small 50or 60 hertz signal in the oscilloscope window when you touch the probe tip
with your finger.
11
11

PicoScope 5000 A and B Series PC Oscilloscopes User's Guide 9
Copyright © 2013 Pico Technology Limited. All rights reserved. ps5000ab.en r1
5 Product information
Standard oscilloscope connectors
The PicoScope 5000 Series Flexible Resolution Oscilloscopes have input channels with
standard BNC connectors and standard input impedance. They are therefore
compatible with most oscilloscope probes including x10 and switched x1/x10 types.
The probes supplied with the PicoScope 5000 A and B Series oscilloscopes have been
trimmed specifically for use with the scopes they are supplied with. For optimum
performance, please use the probes supplied. Although other oscilloscope probes can
be used, the specified performance cannot be guaranteed. Replacement probes
matched to your PicoScope 5000 can be ordered from Pico Technology.
Signal generator (Gen) output
The Gen connector is the output of the oscilloscope's built-in signal generator, which
can generate a number of built-in waveforms as well as user-defined arbitrary
waveforms (B Models only).
If you are using the PicoScope 6 program, refer to the PicoScope 6 User's Guide for
information on how to configure the signal generator.
If you are writing your own software, refer to the PicoScope 5000 Series (A API)
Programmer's Guide.
External trigger (Ext) input
The Ext input can be used as a trigger source. It is selected using the trigger drop-
down menu in the PicoScope software, or using a function call if you are writing your
own software.
The Ext input uses dedicated circuitry with a software-configurable threshold to detect
a trigger signal. This has the advantage of freeing the analog channels for viewing
signals. The Ext input has the same characteristics as a scope channel so that a
supplied probe can be trimmed on one of the channels and then used with the Ext
input to give best vertical accuracy. If trigger timing accuracy is critical, we
recommend using one of the main input channels as the trigger source. These
channels use digital triggering (accurate to one sample period) and have a vertical
resolution of 1 LSB.

Product information10
Copyright © 2013 Pico Technology Limited. All rights reserved.ps5000ab.en r1
5.1 Model comparison table
For full specifications, refer to the 5000 Series data sheets on your Software and
Reference CD or to the 5000 Series page on www.picotech.com.
PicoScope 2-channel models overview
Model
Maximum
Bandwidth
Memory
Waveform Output
Probes
Supplied
8-bit
≥12-bit
5242A
60 MHz
16 MS
8 MS
Func. Gen.
2 x 60 MHz
5242B
60 MHz
32 MS
16 MS
Func. Gen. and AWG
2 x 60 MHz
5243A
100 MHz
64 MS
32 MS
Func. Gen.
2 x 150 MHz
5243B
100 MHz
128 MS
64 MS
Func. Gen. and AWG
2 x 150 MHz
5244A
200 MHz
256 MS
128 MS
Func. Gen.
2 x 200 MHz
5244B
200 MHz
512 MS
256 MS
Func. Gen. and AWG
2 x 200 MHz
PicoScope 4-channel models overview
Model
Maximum
Bandwidth
Memory
Waveform Output
Probes
Supplied
8-bit
≥12-bit
5442A
60 MHz
16 MS
8 MS
Func. Gen.
4 x 60 MHz
5442B
60 MHz
32 MS
16 MS
Func. Gen. and AWG
4 x 60 MHz
5443A
100 MHz
64 MS
32 MS
Func. Gen.
4 x 150 MHz
5443B
100 MHz
128 MS
64 MS
Func. Gen. and AWG
4 x 150 MHz
5444A
200 MHz
256 MS
128 MS
Func. Gen.
4 x 200 MHz
5444B
200 MHz
512 MS
256 MS
Func. Gen. and AWG
4 x 200 MHz
Resolution vs sampling rate
Resolution
Sampling rate vs. number of channels in use
Any 1 channel
Any 2 channels
Any 3 channels
All channels
8-bit
12-bit
14-bit
15-bit
16-bit
1 GS/s
500 MS/s
125 MS/s
125 MS/s
62.5 MS/s
500 MS/s
250 MS/s
125 MS/s
125 MS/s
-
250 MS/s
125 MS/s
125 MS/s
-
-
250 MS/s
125 MS/s
125 MS/s
-
-
For further information see the specifications tables in the PicoScope 5000 Series data
sheets available on our website.

PicoScope 5000 A and B Series PC Oscilloscopes User's Guide 11
Copyright © 2013 Pico Technology Limited. All rights reserved. ps5000ab.en r1
5.2 Connector diagrams
PicoScope 5000 A and B Series oscilloscopes
B
5V
A
ExtG
PicoScope
www.picotech.com
PicoScope5000 Series
A
B
34
1
2
PicoScope
ww w.picotech.com
PicoScop
e5000 Series
5VDC
5
6
7
BCD
5V
A
ExtG
PicoScope
www.picotech.com
PicoScope5000 Series
A
B
C
D
34
1
2
A. Input channel A
B. Input channel B
C. Input channel C
D. Input channel D
1. Probe compensation output
2. LED: red when scope is connected but not operating. Flashes green when the
oscilloscope is capturing data.
3. External trigger input
4. Signal generator output
5. DC power socket: for use with the AC adapter supplied. See Installation for
details.
6. USB 2.0 port: connects to your PC using the Hi-Speed USB cable supplied. See
Installation for powering options.
7. Earth terminal: Some laptop power supplies can produce electrical noise which may
interfere with your measurements. If this occurs, the earth terminal can be
connected to an external ground point (for example, on the system you are testing)
to provide a ground reference for the scope. This can help to avoid external noise
interfering with your measurements. Alternatively you can run the laptop using
battery power.
8
8

Product information12
Copyright © 2013 Pico Technology Limited. All rights reserved.ps5000ab.en r1
5.3 Moving to another USB port
The procedure for moving your PicoScope Oscilloscope to another USB port depends
on your operating system.
Windows XP
When you first installed the PicoScope 5000 Series Oscilloscope by plugging it into a
USB port, Windows associated the Pico driver with that port. If you later move the
oscilloscope to a different USB port, Windows will display the "New Hardware Found
Wizard" again. When this occurs, just click "Next" in the wizard to repeat the
installation. If Windows gives a warning about Windows Logo Testing, click "Continue
Anyway". As all the software you need is already installed on your computer, there is
no need to insert the Pico Software CD again.
Windows Vista, Windows 7 and Windows 8
The process is automatic. When you move the device from one port to another,
Windows displays an "Installing device driver software" message and then a
"PicoScope 5000 Series PC Oscilloscope" message. The Oscilloscope is then ready for
use.
5.4 Compensating probes
We recommend that you compensate each oscilloscope probe before using it with your
PicoScope. Compensation instructions specific to the probe are included in the leaflet
supplied with the probe.
Connecting a probe for compensation
1. Plug the probe's BNC connector into the appropriate input channel on the scope.
2. Fit the spring hook (supplied with the probe) on the probe tip.
3. Attach the spring hook to the probe compensation output located on the front
panel.
4. Attach the ground lead (supplied) to the probe and connect the crocodile clip to the
ground shell of one of the scope's BNC inputs.
5. Run the PicoScope software. Set the input coupling to AC and then click Auto
Setup, which ensures that the correct range and timebase are selected.
6. Follow the compensation (or 'trimming') instructions in the probe leaflet.
Note: if the probe is moved to a different scope channel, the compensation procedure
must be repeated.
11

PicoScope 5000 A and B Series PC Oscilloscopes User's Guide 13
Copyright © 2013 Pico Technology Limited. All rights reserved. ps5000ab.en r1
6 Glossary
API. Application Programming Interface. A set of function calls that give
programmers access to the PicoScope 5000 A/B Series driver.
Bandwidth. The range of input frequencies over which the measured signal amplitude
is no more than 3 decibels below its true value.
Buffer size. The size of the oscilloscope buffer memory, measured in samples. In
block mode, the buffer memory is used by the oscilloscope to store data temporarily.
This allows the oscilloscope to sample data independently of the speed at which it can
transfer data to the computer.
Device Manager. Device Manager is a Windows program that displays the current
hardware configuration of your computer. For Windows XP: Right-click on 'My
Computer,' choose 'Properties', then click the 'Hardware' tab and the 'Device Manager'
button. For Windows Vista, and Windows 7: From the Start Menu right-click on
'Computer', choose 'Properties', then click 'Device Manager' in the left panel. For
Windows 8, right-click in the bottom left corner of the screen and select 'Device
Manager' from the menu.
Driver. A program that controls a piece of hardware. The driver for the PicoScope
5000 A and B Series Oscilloscopes is supplied in the form of a 32-bit Windows DLL,
ps5000a.dll. This is used by the PicoScope software, and by user-designed
applications, to control the oscilloscopes.
External trigger. This is the BNC connector marked Ext on the PicoScope 5000 A and
B Series oscilloscopes. It can be used as a trigger source but not as a waveform input.
Flexible Resolution Oscilloscope. The instrument formed by connecting a
PicoScope 5000 A and B Series Oscilloscope to a computer running the PicoScope
software application.
Maximum sampling rate. A figure indicating the maximum number of samples the
oscilloscope can acquire per second. Maximum sample rates are usually given in MS/s
(megasamples per second) or GS/s (gigasamples per second.) The higher the
sampling rate of the oscilloscope, the more accurate the representation of the high-
frequency details in a fast signal.
MS/s. Megasamples per second. Used to quantify the sampling rate of an
oscilloscope.
PicoScope software. This is a software product that accompanies all our
oscilloscopes. It turns your PC into an oscilloscope, spectrum analyzer, and meter
display.
Signal generator. A built-in circuit that generates signals suitable for driving an
external device under test. Its output is on the BNC connector marked Gen on the
oscilloscope. If you connect a BNC cable between this and one of the channel inputs,
you can send a signal into the channel.
Timebase. A timer that controls the speed at which the scope device captures data.
At slow timebases this process is visible as PicoScope draws the trace across the scope
view from left to right, but at fast timebases PicoScope draws the whole trace in a
single operation. The timebase is measured in units of time (such as seconds) per
division. There are ten divisions across the scope view, so the total time across the
width of the view is ten times the "per division" setting.
USB 1.1. USB (Universal Serial Bus) is a standard port that enables you to connect
external devices to PCs. A typical USB 1.1 port supports a data transfer rate of 12
Mbps (12 megabits per second), much faster than an RS232 port.
USB 2.0. A typical USB 2.0 port supports a data transfer rate that is 40 times faster
than USB 1.1. USB 2.0 is backwards-compatible with USB 1.1.
Vertical resolution. A value, in bits, indicating the precision with which the
oscilloscope converts input voltages to digital values. The resolution enhancement
function in PicoScope can improve the effective vertical resolution.

Glossary14
Copyright © 2013 Pico Technology Limited. All rights reserved.ps5000ab.en r1
Voltage range.The range of input voltages that the oscilloscope can measure. For
example, a voltage range of ±20 V means that the oscilloscope can measure voltages
between —20 V and +20 V. Input voltages outside this range will not be measured
correctly, but will not damage the instrument as long as they remain within the
protection limits stated in the specifications.

PicoScope 5000 A and B Series PC Oscilloscopes User's Guide 15
Copyright © 2013 Pico Technology Limited. All rights reserved. ps5000ab.en r1
Index
A
Arbitrary waveform generator 9
B
Bandwidth 10
Buffer size 10
C
Calibration 2
Cleaning 6
Company information 5
Compliance 3
Connections
Arbitrary waveform generator 11
Compensation output 11
Earth terminal 11
Ext connector 11
External trigger 11
Function generator 11
Gen connector 11
USB port 11, 12
Contact details 5
E
Earth terminal 9
Ext connector 9
External trigger 9
F
Function generator 9
G
Gen connector 9
L
LED 11
Licence conditions 4
M
Maximum input range 2
Maximum sampling rate 10
Memory 10
Model comparison 10
O
Oscilloscope probe 8, 9, 11
compensating 12
P
Pack contents
AC Adapter 7
Installation Guide 7
Probes 7
Software and Reference CD 7
USB cable (double-headed) 7
USB cable (single-headed) 7
PicoScope 5000 Series 2, 6, 9
PicoScope software 8, 9
Probes 10
R
Repair 2
S
Safety
symbols 2
warning 2, 3
Signal generator 10
output 9
Specifications 10
System requirements 6
T
Technical support 5
Test equipment 2
Trademarks 5
U
USB 6
USB cable (double-headed) 8
USB cable (single-headed) 8
USB port connection 9
W
Warranty 5
