PICO Neo 2 User manual

A New Reality
pico neo 2
USER GUIDE
Virtual Reality All-In-One Headset
Pico Neo 2 User Guide R01-20190903.indd 39 2019/9/6 下午1:18

40
|
Warning
Please do not expose the optical lens of the helmet to the sun to prevent damage to the
helmet screen.
Permanent yellow spots may be caused to the screen in less than on minute when the lens
is exposed to the sun, both indoors and outdoors.
Please note that such physical damage is not covered by the warranty of the product.
Pico Neo 2 User Guide R01-20190903.indd 40 2019/9/6 下午1:18

41
· It is recommended that you use this product in an open and safe indoor area (at least
2m * 2m). Please confirm that you are in a safe environment without any discomfort before
using it. Remember to avoid accidents, especially when you move indoors with the helmet
on. Pleas wear the lanyard when using the handle, and make sure that there is enough
space around your head and body to stretch your arms to avoid injury to others or
yourself.
· It is recommended that you should be careful when using it and putting it back to protect
the optical lens form being scratched by sharp objects. Please use the cloth enclosed in
the package when cleaning the lens, otherwise it may be scratched and the visual eect
may be aected.
· It is recommended that you should not turn up the volume too much, otherwise it may
cause damage to your hearing.
· Long time of wearing may cause slight dizziness or eyestrain, so it is recommended that
you take a rest every 30 minutes. You can relieve eyestrain by doing some eye exercises or
watching distant objects. If your feel any discomfort, please stop using it immediately.
· Basic operations can be achieved through the buttons of the helmet. For more
interesting functions, please connect the handle.
· This product has no myopia adjustment function. For myopic users, please wear your
glasses according to the wearing instructions when using it.
· The “Eye Protection Mode” of this product has been certified by TUVRheinland, Germany.
In this mode, the picture color is yellowish. You can activate or deactivate this function in
“Settings -> Display -> Eye Protection Mode” according to your personal preference.
· Children aged 12 years old and under are not recommended to use this product. Please
keep your helmet, handles and accessories out of their reach. Children over 12 years old
should use this product under adult supervision to avoid accidents.
|
Important Notes
* This introduction is for reference only. The final appearance and functions of this
product shall be subject to the actual product.
Pico Neo 2 User Guide R01-20190903.indd 41 2019/9/6 下午1:18

42
|
Package Details
VR Headset x1
The main color of the basic version is white
the main color of the Pro version is gray
Controller x2 Controller Lanyard x2
AC Adapter x2 User Guide x1 Lens Cleaning Cloth x1
USB-C 2.0
Data Cable x1
Two-in-one USB-C
Charging Cable x1
For charging the controller only
No data transmission function
Pico Neo 2 User Guide R01-20190903.indd 42 2019/9/6 下午1:18

43
|
VR Headset Instructions
Stereo-fisheye Camera
Inside Out tracking and crossing of the VR Headset.
No block when using it.
Cooling Fan
Pico Neo 2 User Guide R01-20190903.indd 43 2019/9/6 下午1:18

44
Return Button
Can be set as other functions
in specific applications
HOME Button
· Short press to return to the
main interface.
· Long press the center of the
screen for correction.
· Short press to wake the VR
Headset up when it is in sleep
mode.
Strap Knob
OK Button
Battery Holder
3.5mm Power Jack
Maximum 5V/2A DC
power supply
Back Cushion
Removable
Side Strap
Can be rotated up to 90 degrees
for users wearing glasses
Face Cushion
Removable
Head Strap
Removable
Three lengths to adjust
USB-C Interface
Charging or USB 3.0 data
transmission
USB 3.0 OTG device extension
Status Indicator
For detailed status
please refer to the
explanation of status
indicator
Power Button
· ON: long press for 2
seconds
· OFF: long press for 5
seconds
· Reset: long press for 10
seconds
· Short press to enter
sleep mode when it is
turned on.
· Short press to wake it
up when it is sleeping.
60GHz Antenna
*For Pico Neo 2 Pro only
Secondary Mic
Pico Neo 2 User Guide R01-20190903.indd 44 2019/9/6 下午1:18

45
Left Loudspeaker Right Loudspeaker
Volume Button
Main Mic Earphone Jack
Eye Tracking
*For Pico Neo 2 Pro only.
Micro SD Card Slot
Proximity Sensor
· The system automatically wakes up when
the VR Headset is on.
· The system automatically sleeps when the
VR Headset is o.
Pico Neo 2 User Guide R01-20190903.indd 45 2019/9/6 下午1:18

46
|
Controller Instructions
Rocker
Clicking by pressing
down is available
Return Button
Can be set as other
functions in specific
applications
HOME Button
· ON: short press
· OFF: long press for 4
seconds
· Reset: long press for 10
seconds
· Return to the main
interface: short press
· Screen center
correction: press for 1
second
Status Indicator
For detailed status
please refer to the
Explanation of Status
Indicator
Pico Neo 2 User Guide R01-20190903.indd 46 2019/9/6 下午1:18

47
Trigger Button
Switch the master controller
Confirm and shot
Side Press Button
Grab
USB-C Interface
Lanyard Hole
Pico Neo 2 User Guide R01-20190903.indd 47 2019/9/6 下午1:18

48
Explanations of status indicator of the VR Headset
Explanations of status indicator of the Controller
Color of the status indicator Status of the system
The red light is always on Charging. The battery is less than 20%.
The yellow light is always on Charging. The battery is less than 90%.
The green light is always on Charging finished. The battery is more
than 90% or full.
The blue light is always on Starting up or working.
The red light flickers The battery is less than 20%.
The blue light flickers Shutting down.
The white light flickers The firmware is updating.
The indicator is off. Sleeping or power-off.
Color of the status indicator Status of the system
The blue light flickers Connecting.
The blue light is always on Connected.
The red and blue lights flicker
alternately at a slow frequency
(0.5s)
Waiting to be matched.
The red light flickers Low battery.
The red light is always on Charging.
The white light flickers The firmware is updating.
The indicator is off Power-off or full-battery.
Pico Neo 2 User Guide R01-20190903.indd 48 2019/9/6 下午1:18

49
|
Play Space
Since there is no cable constraint, your movements in the real world will be same as in the
virtual world, so it is recommended that you ensure a safe play area before you start playing.
1. Prepare a clean and safe indoor area of at least 2m * 2m;
2. Charge the helmet and handle first;
3. Wear the handle lanyard;
4. Set the security area according to the notice on the screen after starting up.
Pico Neo 2 User Guide R01-20190903.indd 49 2019/9/6 下午1:18

50
- Turn on the VR Headset
Long press the Power button for 2 seconds (until the blue light is always on) to trun on the
VR Headset.
|
Wearing Instructions
Pico Neo 2 User Guide R01-20190903.indd 50 2019/9/6 下午1:18

51
After the VR Headset is turned on and worn, press the HOME button of the controller
(until the blue light flickers) to turn it on, and the system will automatically complete the
connection.
When the connection is complete, the status indicator of the controller is blue, and the
virtual controller and rays are visible in the VR Headset.
-Connect the Controller
Pico Neo 2 User Guide R01-20190903.indd 51 2019/9/6 下午1:18

52
-Wear the VR Headset
Note: Since this device has no myopia adjustment function, please do not remove your
glasses when wearing it.
Adjust the strap knob to the maximum or appropriate size
and rotate the strap up to allow enough space for your head
1
Pico Neo 2 User Guide R01-20190903.indd 52 2019/9/6 下午1:18

53
cover your glasses with the face cushion of the VR Headset
2
Pico Neo 2 User Guide R01-20190903.indd 53 2019/9/6 下午1:18

54
Rotate the strap down
and place the back cushion over your head
3
Pico Neo 2 User Guide R01-20190903.indd 54 2019/9/6 下午1:18

55
Fine-tune the strap knob and the wearing position
until it is comfortable and clear
4
Pico Neo 2 User Guide R01-20190903.indd 55 2019/9/6 下午1:18

56
|
Operation Instructions
- Rocker operation
Shaking in four directions are available to perform page-turning operations;
Clicking by pressing down is available.
Pico Neo 2 User Guide R01-20190903.indd 56 2019/9/6 下午1:18

57
-Browse contents
You can switch to what you want to browse by moving and rotating the handle/helmet
and select the content with the Trigger button of the handle or the OK button of the
helmet.
Note: You can operate by turning your head and clicking the buttons on the VR Headset
if the controller is not connected.
Pico Neo 2 User Guide R01-20190903.indd 57 2019/9/6 下午1:18

58
- Screen center correction
Wear the VR Headset and look straight ahead, press and hold the HOME button of the VR
Headset/controller for more than 1 second to correct the center of the screen, and adjust
the interface to the current field of view.
-Switch the rays of the master controller
In the main interface, short press the Trigger button of the corresponding controller to
switch the rays of the master controller;
- Sleep / Wake up
Method 1: The system automatically sleeps a while after the VR Headset is removed and
automatically wakes up when the VR Headset is worn.
Method 2: Short press the Power button of the VR Headset to perform sleep or wake-up
operation.
- Disconnect the controller
Press and hold the HOME button until its status indicator turns red with vibration. The
controller is then turned o and disconnected from the VR Headset.
You do not need to deliberately shutdown the controller. It will automatically shut down to
save power in the following cases.
· when the VR Headset enters deep sleep (a while after the helmet is removed)
· when the Bluetooth of the VR Headset is o
· when the controller is unbound in the helmet management interface
· when the VR Headset is turned o
- Add new controller
If you need to add a new controller (the VR Headset can only connect one pair of
controllers at the same time, that is, one left controller and one right controller) or connect
the controller again after unbinding it, you can enter "Settings" -> "Controller", click "Add
Controller", press and hold the HOME button and the Trigger button at the same time until
the red and blue lights of the controller status indicator flicker alternately, and then follow
the instructions on the VR Headset screen.
-Volume adjustment
You can use the Volume Adjustment button of the VR Headset to turn up or turn
down the volume, and long press it to continuously adjust the volume.
Pico Neo 2 User Guide R01-20190903.indd 58 2019/9/6 下午1:18
