Introduction
Validity of documentation
This documentation is valid for the product PSEN ma1.3-22 M12/8 VA. It is valid until new
documentation is published.
This operating manual explains the function and operation, describes the installation and
provides guidelines on how to connect the product.
Using the documentation
This document is intended for instruction. Only install and commission the product if you
have read and understood this document. The document should be retained for future ref-
erence.
Definition of symbols
Information that is particularly important is identified as follows:
DANGER!
This warning must be heeded! It warns of a hazardous situation that poses
an immediate threat of serious injury and death and indicates preventive
measures that can be taken.
WARNING!
This warning must be heeded! It warns of a hazardous situation that could
lead to serious injury and death and indicates preventive measures that can
be taken.
CAUTION!
This refers to a hazard that can lead to a less serious or minor injury plus
material damage, and also provides information on preventive measures
that can be taken.
NOTICE
This describes a situation in which the product or devices could be dam-
aged and also provides information on preventive measures that can be
taken. It also highlights areas within the text that are of particular import-
ance.

PSEN ma1.3-22 M12/8 VA
Operating Manual PSEN ma1.3-22 M12/8 VA
1004511-EN-04 | 5
INFORMATION
This gives advice on applications and provides information on special fea-
tures.
Safety
Intended use
The safety function of the safety switch is:
}The safety contacts open when the actuator is removed beyond the assured release dis-
tance sar or when the actuator is not detected.
The safety switch meets the requirements in accordance with:
}EN 60947-5-3 in series connections: PDDB only in connection
– with the actuator PSEN ma1.3-08 VA,
– the interface PSEN ix1 and
– the suitable evaluation devices (see Requirements and connection to evaluation
devices [ 11]).
}EN 60947-5-3 in single connections: PDDB only in connection
– with the actuator PSEN ma1.3-08 VA,
– the control cabinet terminal PSEN ix0 F1 mag (see Order reference for
accessories [ 24]) and
– the suitable evaluation devices.
Improper use
The following is deemed improper use in particular
}Any component, technical or electrical modification to the product,
}Use of the product outside the areas described in this operating manual,
}Use of the product outside the technical details (see Technical details [ 20]).
NOTICE
EMC-compliant electrical installation
The product is designed for use in an industrial environment. The product
may cause interference if installed in other environments. If installed in other
environments, measures should be taken to comply with the applicable
standards and directives for the respective installation site with regard to in-
terference.

PSEN ma1.3-22 M12/8 VA
Operating Manual PSEN ma1.3-22 M12/8 VA
1004511-EN-04 | 6
Safety regulations
Safety assessment
Before using a device, a safety assessment in accordance with the Machinery Directive is
required.
The product as an individual component fulfils the functional safety requirements in accord-
ance with EN ISO 13849 and EN 62061. However, this does not guarantee the functional
safety of the overall plant/machine. To achieve the relevant safety level of the overall plant/
machine’s required safety functions, each safety function needs to be considered separ-
ately.
Use of qualified personnel
The products may only be assembled, installed, programmed, commissioned, operated,
maintained and decommissioned by persons who are competent to do so.
A competent person is a qualified and knowledgeable person who, because of their train-
ing, experience and current professional activity, has the specialist knowledge required. To
be able to inspect, assess and operate devices, systems and machines, the person has to
be informed of the state of the art and the applicable national, European and international
laws, directives and standards.
It is the company’s responsibility only to employ personnel who
}Are familiar with the basic regulations concerning health and safety / accident prevention,
}Have read and understood the information provided in the section entitled Safety
}Have a good knowledge of the generic and specialist standards applicable to the specific
application.
Warranty and liability
All claims to warranty and liability will be rendered invalid if
}The product was used contrary to the purpose for which it is intended,
}Damage can be attributed to not having followed the guidelines in the manual,
}Operating personnel are not suitably qualified,
}Any type of modification has been made (e.g. exchanging components on the PCB
boards, soldering work etc.).
Disposal
}In safety-related applications, please comply with the mission time TM in the safety-related
characteristic data.
}When decommissioning, please comply with local regulations regarding the disposal of
electronic devices (e.g. Electrical and Electronic Equipment Act).

PSEN ma1.3-22 M12/8 VA
Operating Manual PSEN ma1.3-22 M12/8 VA
1004511-EN-04 | 7
For your safety
WARNING!
Loss of safety function due to manipulation of the interlocking device
Manipulation of the interlocking device may lead to serious injury and death.
– You should prevent any possibility of the interlocking device being
manipulated through the use of a spare actuator.
– Keep the substitute actuator in a safe place and protect it from unau-
thorised access.
– If substitute actuators are used, these must be installed as described
under Installation [ 16].
– If the original actuators are replaced with substitute actuators, the ori-
ginal actuators must be destroyed before disposal.
}Do not remove the connector's protective cap until you are just about to connect the unit.
This will prevent potential contamination.
Unit features
}The actuator PSEN ma1.3-08 VA belongs to the safety switch.
}Coded actuator
}Safety switch with 8-pin M12 male connector
}Use with temperatures over 80°C
}2 safety contacts (reed contacts - N/O)
}1 auxiliary contact (N/O)
}Design: cylindrical with threaded sleeve
– Safety switch M12
– Actuator M12:PSEN ma1.3-08 VA
}Operation Magnetic
}Switching voltage 24 VDC
}Series connection via PSEN ix1 interface
}Switch and actuator from stainless steel

PSEN ma1.3-22 M12/8 VA
Operating Manual PSEN ma1.3-22 M12/8 VA
1004511-EN-04 | 8
Function description
If the actuator is within the response range (safety gate closed), the safety contacts and the
auxiliary contact on the safety switch are closed.
Application in series connections
Operate the PSEN ma1.3-22 M12/8 VA in conjunction with the following components:
}Actuator PSEN ma1.3-08 VA (see Order reference [ 24]),
}interface PSEN ix1 (see Order reference [ 24]) and
}a connected evaluation device (see Requirements and connection to evaluation
devices [ 11]).
Application in single connections
Operate the PSEN ma1.3-22 M12/8 VA in conjunction with the following components:
}Actuator PSEN ma1.3-08 VA,
}Control cabinet terminal PSENix0F1mag (see Order reference [ 24]) and
}a connected evaluation device.
Block diagram
Actuator
Safety switch
Magnet
7
1
4
26
3

PSEN ma1.3-22 M12/8 VA
Operating Manual PSEN ma1.3-22 M12/8 VA
1004511-EN-04 | 9
Operating distances
Sao SoSrSar (mm)Somin
On
Off
Legend
Sao Assured operating distance
Somin Min. operating distance
Sar Assured release distance
The offset-independent values for the switching distances are included in the Technical
details [ 20].
Lateral and vertical offset
Actuator PSEN ma1.3-08/VA
[3]
[1]
[2]
Legend
[1] Lateral offset
[2] Vertical offset
[3] Sensing faces

PSEN ma1.3-22 M12/8 VA
Operating Manual PSEN ma1.3-22 M12/8 VA
1004511-EN-04 | 10
Assured operating distance Sao in mm
Lateral offset Vertical offset
0 2 4
08.0 7.2 5.8
27.2 6.6 5.1
45.8 5.1 3.2
The stated values are valid at a temperature of 20 °C.
Wiring
}Information given in the Technical details [ 20] must be followed.
}Calculation of the max. cable length lmax:
Rlmax - Ri
Rl / km
Imax =
Rlmax = Max. overall cable resistance (see evaluation device's technical details)
Ri = Internal resistance sensor (see Technical details [ 20])
Rl/km = Cable resistance/km of the cable (seetechnical details cable)
}Ensure the wiring and EMC requirements of EN 60204-1 are met.
}Depending on which evaluation device is used, the overall cable resistance must be
checked; before commissioning it may also be necessary to check the cross circuit detec-
tion function.
}The supply voltage for the auxiliary contact must be provided via a Class III power supply.
}The safety contacts are not short circuit-proof.
}UL requirement: the supply voltage must be provided via a Class 2 power supply.
Pin assignment
NOTICE
The colour marking for the connection lead only applies for the cable that
Pilz supplies as an accessory
The safety switch is shown in an unoperated condition.

PSEN ma1.3-22 M12/8 VA
Operating Manual PSEN ma1.3-22 M12/8 VA
1004511-EN-04 | 11
Assignment of the 8-pin
M12 male connector
6
3
5
4
1
NC
2
7
8NC
Pink
Green
White
Yellow
Brown
Blue
Red
Grey
NOTICE
The auxiliary contact (pin 2, pin 7)
– can be connected in series
– maynot be used for safety circuits
Requirements and connection to evaluation devices
For use of PSEN ma1.3-22 M12/8 VA in accordance with DIN EN 60947-5-3 an evaluation
device must be connected.
Connect the PSEN ma1.3-22 M12/8 VA
}either with a certified Pilz evaluation device
}or with an evaluation device with defined properties
Certified Pilz evaluation devices are, for example:
}PNOZelog for safety gate monitoring
– PNOZ e1p, PNOZ e1.1p, PNOZ e1vp
– PNOZ e5.11p
– PNOZ e6vp, PNOZ e6.1p
}PNOZpower for safety gate monitoring
– PNOZ p1p, PNOZ p1vp
}PNOZsigma for safety gate monitoring
– PNOZ s3
– PNOZ s4
– PNOZ s5

PSEN ma1.3-22 M12/8 VA
Operating Manual PSEN ma1.3-22 M12/8 VA
1004511-EN-04 | 12
}PNOZ X for safety gate monitoring
– PNOZ X2, PNOZ X2.5P, PNOZ X2.7P, PNOZ X2.8P, PNOZ X2.9P, PNOZX2C
– PNOZ X3, PNOZ X3.1, PNOZ X3P, PNOZ X3.10P
– PNOZ X4
– PNOZ X5, PNOZ X5J
– PNOZ Ex
}PNOZmulti for safety gate monitoring
Configure the switch in the PNOZmulti Configurator with switch type 3.
}PSS for safety gate monitoring with standard function block SB064, SB066 or
FS_SafetyGate
}PSSuniversal PLC for safety gate monitoring with function block FS_SafetyGate
The correct connection to the respective evaluation device is described in the operating
manual for the evaluation device. Make sure that the connection is made in accordance
with the specifications in the operating manual for the selected evaluation device.
Defined properties of evaluation devices:
}2-channel with feasibility monitoring
}Open circuit monitoring of the safety switch is performed
}Inputs and outputs on the evaluation device must fulfil the requirements of IEC61131,
Type 3
}Technical data of the evaluation device must fulfil the requirements in the Technical
details [ 20] of PSEN ma1.3-22 M12/8 VA
– Always comply with the max. switching current safety contacts of PSEN ma1.3-22
M12/8 VA.
}Outputs at the evaluation device must only be switched on again when both reed con-
tacts at the safety switch have been opened and closed (partial operation lock)
INFORMATION
Risk time in accordance with DIN EN 60947-5-3
The risk time is made up of the reaction time of the sensor (see Technical
details [ 20]) and the processing and delay times of the evaluation
device (s. operating manual for the relevant evaluation device).

PSEN ma1.3-22 M12/8 VA
Operating Manual PSEN ma1.3-22 M12/8 VA
1004511-EN-04 | 13
Y1 Y8
A2A1
11 12
14
Y2 Y3 Y4Y5 Y6 Y9
1 2 3 4
13 23 24
21 22 31
33 34
32 41
43 44
42
A1 A2
1 2 3 4
11 12 1413
1 2 3 4
21 22 2423
1 2 3 4
31 33 3432
1 2 3 4
41 43 4442
+24 V
I0.0
I0.1
I0.2
I0.3
+24 V
0 V
PSEN ix1
PLC
PSENmag
Evaluation device
Input circuit
Input circuit
Fig.: Dual-channel connection of four PSENmag to the input circuits of an evaluation device

PSEN ma1.3-22 M12/8 VA
Operating Manual PSEN ma1.3-22 M12/8 VA
1004511-EN-04 | 14
Examples for connection to Pilz evaluation devices:
Application in series connections
S12
S22
S11
S21
1
2
3
4
5
6
7
8
PNOZ s3 PSENmag PSEN ix1
Yellow
White
Pink
Green
1
2
3
4
I1
I0
T1
T0
1
2
3
4
5
6
7
8
PNOZmulti PSENmag
PSEN ix1
Yellow
White
Pink
Green
1
2
3
4

PSEN ma1.3-22 M12/8 VA
Operating Manual PSEN ma1.3-22 M12/8 VA
1004511-EN-04 | 15
Application in single connections
S21
S22
S11
S12
1
2
3
4
5
6
7
8
PNOZ s3 PSENmag
PSEN ix0 F1 mag
12
22
11
21
Yellow
White
Pink
Green
T0
I0
T1
I1
1
2
3
4
5
6
7
8
PNOZmulti PSENmag
PSEN ix0 F1 mag
12
22
11
21
Yellow
White
Pink
Green

PSEN ma1.3-22 M12/8 VA
Operating Manual PSEN ma1.3-22 M12/8 VA
1004511-EN-04 | 16
Installation
}The unit can be installed in any position. Safety switches and actuators must be installed
so that the sensing face of the safety switch is exactly opposite the sensing face of the
actuator.
}If possible, do not install the safety switch and actuator on to ferromagnetic material.
Changes to the operating distances are to be expected.
CAUTION!
Potential loss of safety function due to changed device properties
The unit's properties may be affected if installed in an environment contain-
ing electrically or magnetically conductive material.
– Please check the operating distances and the assured release dis-
tance.
CAUTION!
Possible loss of the safety function by changing the release distance
Sar with non-flush installation
Installing the safety switch non-flush within electrically or magnetically con-
ductive material, the value for the assured release distance Sar can change.
– Check the assured release distance Sar.
}Safety switches and actuators must be positioned so that they are secured against a
change of position.
}The safety switch and actuator should only be secured using screws and nuts made of
non-magnetic material (e.g. brass or stainless steel).
}Avoid the risk of damages from foreseeable external influences by attaching the safety
switch and actuator. If necessary, safety switch and actuator have to be protected.
INFORMATION
Protect the actuator from unauthorised removal (e.g. via a screw lock or
concealed installation) and from contamination.
}Prevent self-loosening of the fastening elements of safety switch and actuator.
}The fastening of safety switch and actuator has to be sufficiently stable to ensure the
proper operation of the safety switch and the actuator.
}The distance between two safety switches must be maintained (see Technical
details [ 20]).

PSEN ma1.3-22 M12/8 VA
Operating Manual PSEN ma1.3-22 M12/8 VA
1004511-EN-04 | 17
}Safety switches and actuators
– Should be kept away from iron swarf
– Should not be exposed to strong magnetic fields
}Prevent the safety switch and actuator being exposed to heavy shock or vibration.
}Make sure that the safety switch and actuator cannot be used as an end stop.
}Circumvention of the safety switch in a reasonably foreseeable manner must be preven-
ted.
}Please note the installation measures in accordance with EN ISO 14119 for a proximity
switch type 4 with coding level Low.
}Alignment errors of the guard must not adversely affect the safety function of the guard.
}The assured operating distance Sao and the assured release distance Sar must be tested
under real conditions.
}Do not apply any installation tools (e.g. Pliers) on the surfaces of the switch.
}The protection type (see Technical details [ 20]) is only achieved when Pilz connec-
tion cables are used - these are available as an accessory - and when the connector
torque is complied with (see Technical details).
Application in series connections
}Install the interface PSEN ix1 in the control cabinet and wire the interface with the evalu-
ation device (see Wiring [ 10]).
Application in single connections
}Install the control cabinet terminal PSEN ix0 F1 mag in the control cabinet and wire the
control cabinet terminal with the evaluation device (see Wiring [ 10]).

PSEN ma1.3-22 M12/8 VA
Operating Manual PSEN ma1.3-22 M12/8 VA
1004511-EN-04 | 18
Installation of safety switch
Sensing face
Slide the switch through the hole in the
mounting surface with the sensing face to-
wards the actuator.
Attach the switch using 2 M12x1
hexagonal nuts.
The surfaces of the switch are not suitable
for applying an installation tool (e.g. pliers).
Also note the max. torque setting (see
Technical details [ 20]).
Installation with actuator PSEN ma1.3-08/VA
Sensing face
Slide the actuator through the hole in the
mounting surface with the sensing face to-
wards the safety switch.
Attach the actuator using 2 M12x1
hexagonal nuts.
Also note the max. torque setting (see
Technical details [ 20]).

PSEN ma1.3-22 M12/8 VA
Operating Manual PSEN ma1.3-22 M12/8 VA
1004511-EN-04 | 19
Adjustment
Application in series connections
}The safety switch may only be used with the corresponding actuator PSEN ma1.3-08 VA.
}Always test the function with the PSEN ix1 interface and connected evaluation device.
}The stated operating distances (see Technical details [ 20]) only apply when the
safety switch and actuator are installed according to the specifications in
Installation [ 16]. Operating distances may deviate if other arrangements are used.
Note the maximum permitted lateral and vertical offset (see Operating distances and Lat-
eral and vertical offset [ 9]).
Application in single connections
}The safety switch may only be used with the corresponding actuator PSEN ma1.3-08 VA.
}Always test the function with the control cabinet terminal PSENix0F1 mag and connec-
ted evaluation device.
}The stated operating distances (see Technical details [ 20]) only apply when the
safety switch and actuator are installed according to the specifications in
Installation [ 16]. Operating distances may deviate if other arrangements are used.
Note the maximum permitted lateral and vertical offset (see Operating distances and Lat-
eral and vertical offset [ 9]).
Periodic test
}Carry out a monthly function test on the safety switch and actuator.
}The safety function may only be checked by qualified personnel.
NOTICE
The safety functions should be checked after initial commissioning and each
time the plant/machine is changed. The safety functions may only be
checked by qualified personnel.
Application in series connections
}Always test the function with the PSEN ix1 interface and connected evaluation device.
Application in single connections
}Always test the function with the control cabinet terminal PSENix0F1 mag and connec-
ted evaluation device.

PSEN ma1.3-22 M12/8 VA
Operating Manual PSEN ma1.3-22 M12/8 VA
1004511-EN-04 | 20
Dimensions in mm
Safety switch
60
36
1
M12x1
Actuator PSEN ma1.3-08/VA
25
19
M12x1
Technical details
General
Certifications CE, EAC, ECOLAB, TÜV, UKCA, UL/cUL
Sensor's mode of operation Magnetic
Coding level in accordance with EN ISO 14119 Low
Design in accordance with EN ISO 14119 4
Classification in accordance with EN 60947-5-3 PDDB
Electrical data
Supply voltage
Voltage 24 V
Kind DC
Voltage tolerance -20 %/+20 %
Max. switching frequency 1 Hz
Lowest operating current (Im) 1 mA
Max. voltage drop (Ud) 0,5 V
Switching voltage 24 V
Internal resistance safety contacts 0 Ohm
Internal resistance auxiliary contact 0 Ohm
Max. switching current, safety contacts 0,14 A
Max. breaking capacity, safety contacts 4 W
Max. switching current, auxiliary contacts 140 mA
Utilisation category in accordance with EN 60947-1 DC-12
Conventional thermal current auxiliary contact 0,1 A
Max. continuous current safety contacts 0,1 A
Times
Reaction time (actuator removed) 2 ms
