Pima DPD743 User manual

Wireless 2-Way Outdoor DT Detector
Installation Instructions
Model: DPD743 / DPD786

2
Description
The DPD743/786 is a battery powered wireless DT detector that has been designed to provide
enhanced 24-hour outdoor protection, with Active IR Anti-mask capabilities. Integrated Dual
Technology (DT) combines two K-band microwave channels with two PIR sensors for better catch
performance and pet immunity, minimizing false alarm.
Features include
•PIR coverage: 12m, 90°
•Two channel K band - MW detection (Sway Recognition)
•Pet immunity
•Two correlated PIR Sensors
•Light sensor for reducing false alarms due to sunlight
•Active IR Anti mask
•Various mounting heights with optional swivel bracket
•Designed for outdoor installation, UV resistant, IP 65
•Cover and wall tampers
•3-axis-accelerometer for protection against vandalism
Installation
Step 1: Preliminary Considerations
Select the mounting location for best coverage of the area that is to be protected (see Step 2: Coverage
Patterns). Pay attention to the following:
Figure 1

Install the device in a location where the detector’s field
of view is clear of any static obstacle
Up to 35cm
(1.1ft)

3
Figure 2
Walking direction must cut across the beam pattern
Figure 3
Do not install the device close to any moving objects

4
Step 2: Coverage
PIR Coverage
Mounting height [m]
Distance [m]
1.8
10
2.2 (optimal)
12
Note For pet immunity, install the detector at
the optimal height of 2.2 meters.
PIR Coverage - Using Swivel
Bracket
Note The table below is relevant when using
the Swivel Bracket (Model: BRS180).
Mounting
height [m]
Swivel
Angle [°]
Distance
[m]
1.8
0
10
5
7
10
5
2.2 (optimal)
0
12
5
8
10
6
2.5 –2.7
0
N/A
5
10
10
7
NA = Avoid such installation
Figure 4 Coverage Pattern
NA = Avoid such installation
Step 3: Enrolling the Detector in the System
For complete description of the wireless configuration and device enrollments, refer to Programming
Guide for the FORCE and VISION Alarm Systems
Enrollment of the DPD detector in the system can be performed manually or automatically via the
keypad.
Auto Enrolling (using RF Communication):
1. Enter Installer menu, and select:
System Configuration > Peripherals > Wireless Peripherals > Enroll and delete > Detectors >Enroll
>Auto Enrollment
2. Insert the batteries (see step 5) and connect the detector to the mounting bracket. In 3 seconds the
detector will send an Enrollment message. The serial number should appear on the keypad.
3. Select Enroll and press .
Manual Enrolling:
1.Enter Installer menu, and select:
System Configuration > Peripherals > Wireless Peripherals > Enroll and delete > Detectors >Enroll
>Manual Enrollment

5
2. Enter the serial number and press .
3. Select Enroll and press .
Enrolling through the Force Manager Software:
You can enroll the detector using Force Manager software; For information refer to the Force
Manager Manual.
Step 4: Mount the Detector on the Wall Bracket
1
Figure 5
Unscrew and separate detector from mounting bracket.
2
Figure 6
Open the 5 knockout holes of the wall bracket and use as a template for mounting.

6
3
4
Figure 7
Figure 8
CAUTION! The detector batteries are
supplied inside of the unit, which are covered
with plastic wrapping. Remove the plastic
wrapping from the batteries before
installation.
Observing battery polarity, insert 3 CR123 3V
Lithium batteries (supplied) into the batteries
compartment.
Secure the wall bracket to the wall using
the 5 screws.
5
Figure 9
Insert and fasten the screw to lock the detector.

7
Step 6: Performing a Walk Test
1
Figure 10
The detector automatically enters walk test mode for 10 minutes following tamper
closure. Walk through the entire protected area and observe the LEDs to confirm full
coverage (see LED Status).
2
Manually initiate a walk test:
Select Installer Menu: Diagnostics > Zones Test > Select Single zone or All Zones.
The detector remains in walk test mode until any key on the panel is pressed.
Note: The LEDs switch off after Walk Test to avoid a situation of mapping the detection zone
and to extend battery life.
Step 7: MW Range Adjustment
1Over power
2Under power
3Correct adjustment
ADetector
BCorridor
Anti-Mask Calibration
Following tamper closure, the anti-mask calibration procedure begins (up to 2 minutes). For
successful calibration, make sure that there are no objects near the detector for the duration of the
procedure.
1
23
A
B

8
Detector Configuration
Being bi-directional, the detectors parameters can be modified from the keypad or from the system
configuration software according to your needs.
PIR Sensitivity:
High/Low*
MW Sensititvity:
Min. 25%, 50%, 65%*, 85%, max. **
Anti-Mask:
Yes/No*
LED:
On*/Off
Operation Mode:
Immediate: The detector transmits after each detection
Normal –every 2.5 minutes*
Disposition Sensor:
Enable/Disable*
* Default
** In maximum sensitivity sway recognition is disabled to achieve optimum sensitivity
NOTE: The Disposition Sensor sends an alarm following change in the position of the detector.
LED Status
LED
State
Description
Yellow
ON
PIR detection
Flashing
Anti-Mask detection
Red
ON
Alarm, Tamper Close/Open
Flashing (4 times)
Low battery indication
Green
ON
MW detection
Flashing (4 times)
Successful registration

9
Specifications
Electrical
Battery Type :
3 x CR 123, 3V Lithium Battery
Battery Life:
3 batteries –3 year typical lifetime
Current consumption:
48 A
Supervision Transmission:
15 minutes
RF transmitting frequencies:
433.92 MHz, 24.05GHz; 868.65 MHz, 24.05 GHz
Optical
Filtering:
White Light Protection
Pet Immunity:
Up to 45Kg (99lb) animal
Physical
Size (LxWxD):
176 x 89 x 107 mm (7 x 3.5 x 4.2 in)
Weight:
410 grams (14.5 oz.)
Environmental
RF Immunity:
According to EN50130-4
Operating Temperature:
-30C to 60C (-22F to 140F)
Storage Temperature:
-20C to 60C (-4F to 140F)
Relative Humidity
90% max
Power Output
868.65 & 433.92Mhz: 10mW Max.
MW 24.05 GHz: 39.8mW Max.
Ordering Information
Model
Frequency
P/N
DPD743
433MHz
8841242
DPD786
868MHz
8841243
BRS180
-
5000020
UKCA and CE RED Compliance Statement
Hereby, PIMA declares that this equipment is in compliance with the essential requirements and
other relevant provisions of Directive 2014/53/EU. For the CE Declaration of Conformity please refer
to our website: www.pima-alarms.com
