D P P 5 0 0 L A R I S Q U A D
PIR MOTION DETECTOR with PET IMMUNITY up to 25Kg
INSTALLATION INSTRUCTIONS
PRODUCT FEATURES
The DPP500 LARIS QUAD detector uses a special designed
optical Lens with unique Quad (four element) PIR Sensor and
ASIC based electronics optimized to eliminate false alarms,
caused by small animals and Pets.
The DPP500 LARIS QUAD provides unprecedented levels of
immunity against visible light. The Detector offers an
exceptional level of detection capability and stability for every
security installation.
The DPP500 LARIS QUAD is supplied with a wide-angle lens.
Quad Linear Imaging Technology for sharp analysis of
body dimensions, and differentiation from background
and animals.
ASIC based electronics
Immunity to animals up to 25Kg
18m Detection Range with Wide Angle Lens
Temperature compensation
Compact Design for Residential Installation
Variable pulse width adjustment
Sensitivity adjustment
Environmental immunity
Height installation calibration free (1.8m - 2.4m)
LED remote function
TYPICAL INSTALLATION
Choose a location most likely to intercept an intruder. See
detection pattern as below:
For better Pet Immunity avoid installation in area where
pets can reach upwards.
The DPP500 LARIS QUAD performs best when provided
with a constant and stable environment and background.
Avoid the following locations:
Facing direct sunlight.
Facing areas that may change temperature rapidly.
Areas where there are air ducts or substantial airflows.
WIRE SIZE REQUIREMENTS
Use #22 AWG (0.5 mm) or wires with a larger diameter. Use the
following table to determine the required wire gauge (diameter)
depending on the length of wire between the detector and the
control panel.
Wire Length m 200 300 400 800
Wire Diameter mm 0.5 0.75 1.0 1.5
Wire Length ft. 800 1200 2000 3400
Wire Gauge # 22 20 18 16
INSTALLATION
The detector can either be wall, or corner
mounted (We recommend on corner installation).
If ceiling or special wall mounting is required, use
the optional bracket base. Refer to bracket
description (See fig. 6).
1. To remove the front cover, unscrew the
holding screw and gently raise the front cover.
Fig.1
2. To remove the PC board, carefully unscrew
the holding screw located on the PC board.
3. Break out the desired holes for proper
installation.
Fig.2
4. The circular and rectangular indentations at
the bottom base are the knockout holes for
wire entry. You may also use mounting holes
that are not in use for running the wiring into
the detector. (For Bracket option - lead wire
through the bracket).
5. Mount the detector base to the wall, corner, or
ceiling. (For bracket installation option, see
fig. 6).
6. Reinstall the PC board by fully tightening the
holding screw. Connect wire to terminal block.
7. Replace the cover by inserting it back in the
appropriate closing pins and screw in the
holding screw.
CONNECTION
Terminals 1 & 6 - Marked “EOL” -Not in use.
Terminals 2 & 3 - Marked “TAMPER”
If a tamper function is required, connect these
terminals to a 24-hour normally closed protective
zone in the control unit. If the front cover of the
detector is opened, an immediate alarm signal will
be sent to the control unit.
Terminals 4 & 5 - Marked “RELAY”
These are the output relay contacts of the
detector. Connect to a normally closed zone in
the control panel.
Terminal 7 - Marked “+” (+12V)
Connect to a positive voltage output of 8.2 -16VDC
source (usually from the alarm control unit).
Terminal 8 - Marked “-”
Connect to the negative voltage output or ground
(GND) of the control panel.
TESTING
Wait one minute after applying 12VDC power for
warm up time. Conduct testing with the protected
area cleared of all people.
Walk test
1. Remove the front cover.
2. Set the LED to ON position.
3. Reassemble the front cover.
4. Start walking slowly across the detection zone.
5. Observe that the LED lights, whenever motion
is detected.
6. Allow 5 sec. between each test for the
detector to stabilize.
7. After the walk test is completed, you can set
the LED to OFF position.
NOTE:
Walk tests should be conducted, at least once a
year, to confirm proper operation and coverage of
the detector.
Fig. 3
Fig. 4
A. Wire access
holes
B. Use for flat wall
mounting
C. Corner mounting
- use all 4 holes.
Sharp left or right
angle mounting -
use 2 holes (top
and bottom)
D. For bracket
mounting
C
A
D
A
A
B
B
B
B
C
C
C

SETTING UP THE DETECTOR
PET IMMUNITYJUMPER SETTING
Use his jumper for setting the PET Immune up to
15Kg or 25Kg function, depending on the pet size.
PULSE WIDTH JUMPER SETTING
Use this jumper for setting the PULSE count function
in order to provide PIR sensitivity control according to
the environment.
LED ENABLE JUMPER SETTING
Use this jumper for setting - LED Enable/Disable.
Note: The LED switch does not affect the operation of
the relay. When an intrusion is detected, the LED will
activate and the alarm relay will switch into alarm
condition for 2 sec.
PIR SENSITIVITY ADJUSTMENT
Use the Potentiometer marked “SENS” to adjust the
detection sensitivity between 15% and 100%,
according to walk test in the protected area.
(Factory set to 57%)
Rotate the potentiometer clockwise to increase range,
counter-clockwise to decrease range.
Fig.5
BRACKET INSTALLATION OPTION
Ceiling bracket base Wall bracket base
Fig. 6
TECHNICAL SPECIFICATIONS
MODEL DPP500 LARIS QUAD
Detection Method Four element PIR
Power Input 8.2 to 16VDC
Current Draw Standby: 8mA (±5%)
Active: 10mA (±5%)
Temperature
Compensation YES
Pulse Width Adjustable
Alarm Period 2 sec (±0.5sec)
Alarm Output N.C 28VDC 0.1 A with
27Ohm series protection
resistor
Tamper Switch N.C 28VDC 0.1A with
10 Ohm series protection
resistor - open when
cover is removed
Warm Up Period 60sec (±5sec)
LED Indicator LED is ON during alarm
Operating Temperature -20  C to +60  C
RFI Protection 30V/m 10 - 1000MHz
EMI Protection 50,000V of electrical
interference from lightning
or power through
Dimensions 92mm x 59mm x 37mm
Weight 40gr
Approval: EN50131-2-2 Grade 2
(w/o swivel mount bracket)
Ordering information
DPP500 LARIS QUAD: P/N 5010124
Bracket: P/N 5000014
Limited Warranty
