Pineapple RYNO DINING TABLE User manual

REQUIRED
ITEMS
RYNO®DININGTABLE TOPASSEMBLY
a8 x M10x30 security screws
a8 x M10x60 TX security button head bolts
a8 x M10x30 washer
a8 x M10 T-nut
a16 x 4x40mm security screws
a1 x handheld power drill
a2 x drill bits (TT20 & TT45)
a1 x drill bit holder
a1 x A70 studlock (thread lock)
aPliers
aHammer
aStrong adhesive
aMastic gun
Please read all instructions carefully before attempting to assemble this product. If you have any queries or
concerns, please contact your Pineapple representative for further advice
[phone]
T
E
[e-mail]

04
01
Unpack the base and remove the central
bung using pliers (do not throw away)
02
03
If adding additional weight, pour the required
weight of kiln dried sand into the bung
hole,replacing bung and seal with strong
adhesive
In addition also seal the four openings on each
corner of the base
Remove centre section from table top and
place centre section on top of table base
ensuring that it is evenly aligned
RYNO®DININGTABLE TOPASSEMBLY
[phone]
T
E
[e-mail]

05
Holding the table top firmly in place, from the
underside of the table locate the openings
for the fixing bolts and drill through the four
corner openings using the 13mm drill bit
06
07
The drill should pierce the centre section,in the
location and at the angle, as shown in the image
Take a bolt and washer and feed it up
through the opening on the underside of the
table and attach a T-nut to secure the top to
the base
RYNO®DININGTABLE TOPASSEMBLY
08
Hammer the T-nuts into place
[phone]
T
E
[e-mail]

12
09
Once the centre section is aligned to the
base section,tighten down the four bolts
and repeat the process of drilling and fixing
bolts in the remaining four positions.The two
sections should now be firmly attached to
each other
10
11
Apply A70 studlock to each of the bolt shafts
The table top has a square recess on the
underside that should fit snuggly over the centre
section. DO NOT ATTEMPT A ONE-PERSON
LIFT.THIS COULD CAUSE PERSONAL INJURY
OR DAMAGE TO TABLE TOP
On the underside screw in the 16x 4x40mm
security screws to fix the top to the base
section
RYNO®DININGTABLE TOPASSEMBLY
[phone]
T
E
[e-mail]

DISCLAIMER
Ensure the proper and adequate hardware is used to secure furniture
Ensure fastenings are appropriate for the anchoring material
Use fastenings of an appropriate strength and consider using security fixings in
challenging environments
Consider using high strength thread-locker on fastenings in challenging
environments
Ensure all gaps are sealed with the appropriate anti-pick mastic after product
installation if necessary
Please read all instructions carefully to ensure proper installation. Failure to read and
follow instructions may result inadequate product installation and void of warranty
Pineapple shall not be held liable for any consequences caused by the improper
installation of products to the installer or the end user
