Pioneer Eclipse PE320AS User manual

Subtitle
Title
We help you shine.™
A company of the Group
Operation Manual
PE320AS

The descriptions contained in this document are not binding.
The company therefore reserves the right to make any modifications at any
time to elements, details, or accessory supply, as considered necessary for
reasons of improvement or manufacturing/commercial requirements.
The reproduction, even partial, of the text and drawings contained in this
document is prohibited by law.
2
The company reserves the right to make any technical and/or supply
modifications. The images are for reference purposes only, and are not
binding in terms of design and supply.
Symbols used in the manual
Open book symbol with an "i"
Indicates the need to consult the instruction manual.
Open book symbol
Used to tell the operator to read the manual before using
the machine.
Warning symbol
Read carefully the sections marked with this symbol, for
the safety of the operator and the machine.
Disposal symbol:
Carefully read the sections marked with this symbol, for
machine disposal.

CONTENTS
ON CONSIGNMENT OF THE MACHINE.......................................................................................................................................4
SERIAL NUMBER PLATE..............................................................................................................................................................4
INTRODUCTORY COMMENT .......................................................................................................................................................4
TECHNICAL DESCRIPTION..........................................................................................................................................................4
TECHNICAL DESCRIPTION..........................................................................................................................................................5
TECHNICAL DESCRIPTION............................................................................................. ERROR! BOOKMARK NOT DEFINED.
SYMBOLS USED ON THE MACHINE............................................................................................................................................6
GENERAL SAFETY REGULATIONS.............................................................................................................................................7
MACHINE PREPARATION.............................................................................................................................................................8
1. INTENDED USE.....................................................................................................................................................................8
2. HANDLING THE PACKED MACHINE....................................................................................................................................8
3. HOW TO UNPACK THE MACHINE........................................................................................................................................8
4. HOW TO MOVE THE MACHINE............................................................................................................................................9
5. INSERTING/CONNECTING THE BATTERIES ......................................................................................................................9
6. BATTERY TYPE...................................................................................................................................................................10
7. BATTERY MAINTENANCE AND DISPOSAL......................................................................................................................10
8. RECHARGING THE BATTERIES (VERSIONS WITH EXTERNAL BATTERY CHARGER) ................................................10
9. RECHARGING THE BATTERIES (VERSION WITH BUILT-IN BATTERY CHARGER).......................................................12
10. BATTERY INDICATOR.......................................................................................................................................................12
11. INSTRUMENT PANEL COMPONENTS.............................................................................................................................13
12. REAR COMPONENTS.......................................................................................................................................................13
13.FRONT AND SIDE COMPONENTS....................................................................................................................................13
14. ASSEMBLING THE SQUEEGEE .......................................................................................................................................14
15. ADJUSTING THE SQUEEGEE INCLINATION...................................................................................................................14
16. ADJUSTING THE SQUEEGEE HEIGHT............................................................................................................................15
17. RECOVERY TANK.............................................................................................................................................................15
18. SOLUTION TANK / DETERGENT SOLUTION (VERSIONS WITHOUT DS).....................................................................15
19. SOLUTION TANK WITH AUTOMATIC CDS DISTRIBUTION SYSTEM ...........................................................................16
20. ASSEMBLING THE SPLASHGUARD RUBBERS.............................................................................................................17
21. ASSEMBLING THE BRUSH..............................................................................................................................................18
22. ASSEMBLING THE BRUSH...............................................................................................................................................18
23. REGULATING THE SOLUTION FOR VERSIONS WITHOUT DS......................................................................................19
24. DETERGENT REGULATION WITH THE DS SYSTEM......................................................................................................19
25. POTENTIOMETER REGULATION VERSION WITH BT....................................................................................................20
WORK...........................................................................................................................................................................................21
1.PREPARING TO WORK........................................................................................................................................................21
WORK...........................................................................................................................................................................................22
2.REVERSE OPERATION VERSIONS WITH ASSISTED TRACTION....................................................................................22
3. RECOVERY TANK OVERFLOW DEVICE ...........................................................................................................................22
AT THE END OF THE WORK......................................................................................................................................................23
1. AT THE END OF THE WORK ..............................................................................................................................................23
DAILY MAINTENANCE ................................................................................................................................................................24
1. CLEANING THE RECOVERY TANK....................................................................................................................................24
2. CLEANING THE SUCTION FILTER.....................................................................................................................................24
3. CLEANING THE SUCTION TUBE FILTER ..........................................................................................................................24
4. DISASSEMBLING AND CLEANING THE SQUEEGEE........................................................................................................25
5.CLEANING THE CLEAN WATER FILTER............................................................................................................................25
2. DISASSEMBLING THE BRUSH...........................................................................................................................................25
WEEKLY MAINTENANCE............................................................................................................................................................26
1.CLEANING THE SQUEEGEE TUBE.....................................................................................................................................26
2. CHECKING THE WHEEL BRAKE........................................................................................................................................26
3. CLEANING THE SOLUTION TANK......................................................................................................................................26
TROUBLESHOOTING..................................................................................................................................................................27
1. REPLACING THE SQUEEGEE RUBBERS..........................................................................................................................27
2. INSUFFICIENT WATER ON THE BRUSH...........................................................................................................................27
3. THE MACHINE DOES NOT CLEAN WELL..........................................................................................................................28
4. THE SQUEEGEE DOES NOT DRY PERFECTLY ...............................................................................................................28
5. EXCESSIVE FOAM PRODUCTION.....................................................................................................................................28
6. ELECTRIC SYSTEM SAFETY (E versions) .........................................................................................................................28
DISPOSAL....................................................................................................................................................................................29
CHOOSING AND USING THE BRUSHES...................................................................................................................................30
Replacement Parts……………………………………………………………………………………………………………………………………………………… 31
3

On consignment of the machine
When the machine is delivered to the customer, an
immediate check must be performed to ensure all the
material mentioned in the shipping documents has been
received, and also to check the machine has not been
damaged during transportation. If this is the case, the carrier
must ascertain the extent of the damage at once, informing
our customer service office. It is only by prompt action of this
type that the missing material can be obtained, and
compensation for damage successfully claimed.
Introductory comment
This is a scrubbing machine which, via the mechanical action of
the rotating brush and the chemical action of a water/detergent
solution, can clean any type of flooring. As it advances, it also
collects the dirt removed and the detergent solution not
absorbed by the floor.
The machine must be used only for this purpose. Even the
best machines will only work well if used correctly and kept in
good working order. We therefore suggest you read this
instruction booklet carefully and read it again whenever
difficulties arise while using the machine. If necessary,
remember that our assistance service (organised in
collaboration with our dealers) is always available for advice or
direct intervention.
Serial number plate
TECHNICAL DESCRIPTION UM PE320AS
Rated power W 950
Working width mm 500
Width of rear squeegee mm 760
Work capacity, up to m
2
/h 1750
Brushes (diameter and quantity) ∅mm 500 x 1
Brush rotations rpm 140
Pressure on the brushes kg 20
Brush motor V / W 24/400
Type of advance Semiautomatic
Maximum gradient % 2
Forward speed km/h -
Suction motor V / W 24/1330
Suction vacuum mbar 188
Traction motor V / W -
Solution tank PE l 48
Recovery tank PE l 54
Total machine weight in running order (including
batteries) kg 195
Batteries (Voltage / Maximum capacity ) V / AhC5 12/105 (2)
Maximum weight of batteries kg 63
Battery charger V/A 24/9
Battery compartment dimensions (Length / Height /
Width) mm 350x290x330
Machine dimensions (Length / Height / Width) mm 1180x1005x490
Noise level (in compliance with IEC 704/1) dB (A) 62
Vibration level m/s
2
0,75
4

TECHNICAL DESCRIPTION UM PE320AS
Rated power W 1100
Working width mm 500
Width of rear squeegee mm 760
Work capacity m
2
/h 1750
Brushes (diameter and quantity) ∅mm 500 x 1
Brush rotations rpm 140
Pressure on the brushes kg 20
Brush motor V / W 24/400
Type of advance Automatic
Maximum gradient % 2
Forward speed km/h 4
Suction motor V / W 36/550
Suction vacuum mbar 188
Traction motor V / W 24/150
Solution tank PE l 48
Recovery tank PE l 54
Total machine weight in running order kg 210
Batteries V / AhC5 12/105 (2)
Battery weight kg 63
Battery charger * V/A 24/9
Battery compartment dimensions (Length / Height
/ Width) mm 350x290x330
Machine dimensions (Length / Height / Width) mm 1180x1005x490
Noise level (in compliance with IEC 704/1) dB (A) 62
Vibration level m/s
2
0,75
5

SYMBOLS USED ON THE MACHINE
Tap symbol
Used to indicate water regulation changes. (CDS versions)
Detergent symbol
Used to indicate detergent regulation changes. (CDS versions)
Indicator showing battery charge level on the upper line and hour-counter on the lower line. (B-BT
versions)
Indicator showing the type of hour-counter (total) on the upper line and the type of service (none)
on the lower line.
Indicator showing the type of technology of the batteries used (lead) (B-BT versions).
Battery symbol (B-BT versions)
Indicates the maximum temperature of the detergent solution.
Located near the solution tank inlet.
Indicates the risk of crushed hands.
Indicates the instructions for dosing the detergent in the canister. (CDS version)
Indicates the earth connection point of the electric system of the machine. (E versions)
6

GENERAL SAFETY REGULATIONS
The regulations below must be carefully followed in order to avoid harm to the operator and damage to the
machine.
 Read the labels on the machine carefully. Do not cover them for any reason and replace them immediately if they
become damaged.
 The machine must be used exclusively by authorised, trained personnel.
 During the working of the machine, pay attention to other people and especially to children.
 The machine is not suitable for cleaning carpets.
 The socket for the battery charger cable must have a prescribed earth connection.
 Avoid damaging the battery charger cable by crushing or bending it, or applying stress.
 If you notice any damage to the battery charger cable, contact a APEC technical assistance centre immediately.
 Do not mix different types of detergent as this may produce harmful gases.
 Do not place any liquid containers on the machine.
 The storage temperature must be between -25°C and +55°C; do not store outdoors in damp conditions.
 Conditions of use: room temperature between 0°C and 40°C with relative humidity between 30 and 95%.
 Do not use the machine in an explosive atmosphere.
 Do not use the machine as a means of transport.
 Do not use acid solutions, which may damage the machine.
 Avoid working with the brushes when the machine is standing still, so as not to damage the floor.
 Do not vacuum inflammable liquids.
 Do not use the device to collect dangerous powders.
 In the event of a fire, use a powder extinguisher. Do not use water.
 Do not knock against shelving or scaffolding, where there is a danger of falling objects.
 Do not use the machine on surfaces with an inclination greater than the one shown on the plate.
 The machine is designed to carry out the washing and drying operations simultaneously. Different operations should only
be carried out in areas where the passage of unauthorised persons is prohibited. Signal the presence of damp floors with
suitable signs.
 If the machine does not work properly, check this is not caused by failure to carry out routine maintenance. Otherwise,
request the intervention of a APEC technical assistance centre.
 If you need to replace any components, request the ORIGINAL spare parts from a APEC dealer and/or Authorised
Retailer.
 Before carrying out any maintenance work, switch off the machine and disconnect the battery connector.
 Do not remove any protection devices which require the use of tools in order to be removed.
 Do not wash the machine with direct water jets or with pressurised water, nor with corrosive substances.
 Send the machine to a APEC technical assistance centre for servicing at least once a year.
 To prevent the formation of scale in the solution tank filter, do not fill the tank with detergent solution many hours before
using the machine.
 Before using the machine, check that all the hatches and covers are positioned as shown in this Manual.
 When disposing of consumption materials, observe the laws and regulations in force.
 When your APEC machine has reached the end of its long working life, dispose of the materials it contains in an
appropriate manner, and bearing in mind that the machine itself was constructed using 100% recyclable materials.
 Only use the brushes supplied with the device, or those specified in the Use and Maintenance Manual (page 29). The
use of other brushes could compromise safety levels.
 The device must be disconnected from the power supply before removing the battery.
 The battery must be removed from the device before this is disposed of.
 The battery and battery charger must be disposed of in a safe manner, scrupulously respecting the laws in force.
 The machine is not suitable for use by children or people with reduced physical, mental and sensorial capacities, or
people lacking experience and knowledge, unless supervised and instructed in the use of the machine by a person
responsible for their safety.
 Children must be supervised to ensure they do not play with the device.
 The machine must be used mainly in closed environments, and never left outside, in damp areas.
 Check all covers and tanks are correctly fixed on the machine.
 The elements of the batteries used must have a cell voltage no greater than 2.7V.
7

MACHINE PREPARATION
1. INTENDED USE
The scrubbing machine is designed exclusively for the professional cleaning of
surfaces and floors in industrial, commercial and public environments. In
addition, only use the machine in closed or at least covered environments.
2. HANDLING THE PACKED MACHINE
The machine is contained in specific packaging.
It is not possible to place more than two packages on top of each other.
The overall dimensions of the package are:
PE320AS
A 1145mm
B 665mm
C 1230mm
A
CB
3. HOW TO UNPACK THE MACHINE
1. Remove the outer packaging.
2. Disengage the parking brake, by means of the lever on the left wheel of the machine (1)
3. The machine is secured to the pallet with wedges that lock the wheels, remove
these wedges (2)
4. Use a chute to get the machine down from the pallet, pushing it backwards. Do
not assemble the rear squeegee before unloading the machine, and avoid
violently jolting the brush base.
5. Keep the pallet for any future transport needs.
ATTENTION: if the product is delivered in cardboard containers,
handle the packed product with suitable lifting means that
comply with the legal requirements.
2
1
8

MACHINE PREPARATION
4. HOW TO MOVE THE MACHINE
1. To safely move the machine, you should use a pallet to support it (positioning
wooden wedges to block the wheels, as shown in the previous paragraph).
2. Lower the squeegee by means of the lever at the rear of the machine. To assemble
the squeegee, read the “ASSEMBLING THE SQUEEGEE” paragraph.
4. Lower the base allowing the brushes to rest by means of the lever on the right rear of
the machine.
5. Stop the machine by operating the brake lever located behind the left wheel of the
machine.
5. INSERTING/CONNECTING THE BATTERIES (B-BT versions)
The machine may be supplied with batteries and a built-in battery charger.
If batteries other than those supplied with the machine are used, have the battery
charger and battery control card configuration checked by a qualified, COMAC-trained
technician.
Perform a battery charging cycle before using the machine.
The batteries must be housed in the special compartment beneath the recovery tank.
To insert the batteries you must:
1. Engage the machine's parking brake.
2. Lower the squeegee and base. (see the appropriate chapter)
3. Release the hinges (1) on the handlebars.
4. Rotate the recovery tank as far as it will go, using the side handle (2).
5. Lift the batteries by means of the grips on the upper part.
6. House the batteries in the compartment, positioning the poles “+” and “-“ opposite
each other.
7. Check that the machine's master switch is in the "OFF" position.
8. Connect the batteries in series - using the supplied jumper cable (3) - to the poles “+”
and “-“.
9. Connect the battery connector cable to the terminal poles “+” and “-“ to obtain a
voltage of 24V on the terminals.
2
ATTENTION: you are advised to use airtight batteries only, to avoid
the leakage of acids!
ATTENTION: you are advised to have the electric connections
made by a qualified, APEC-trained technician.
ATTENTION: you are advised to always wear protective gloves, to
avoid the risk of serious injury to your hands.
ATTENTION: You are advised to only lift and move the batteries
with lifting and transportation means suitable for the specific weight
and size.
1
3
9

MACHINE PREPARATION
6. BATTERY TYPE (B-BT versions)
To power the machine it is necessary to use:
•ries
•hnology
O
TEI EN 60254-1:2005-
1
Every sists of DIN-type elements connected in series and supplying 6V
pctric capacity of
2
Liquid electrolyte lead traction batte
Sealed traction batteries with gasrecombination or gel tec
THER TYPES MUST NOT BE USED.
he batteries must meet the requisites laid out in standards C
2 (CEI 21-5) + CEI EN 60254-2:2008-06 (CEI 21-7).
battery con
ower to the clamps. You are advised to use batteries with an ele
00 Ah (C5).
7. BATTERY MAINTENANCE AND DISPOSAL(Versioni B-BT)
For maintenance and recharging, respect the instructions provided by the battery
manufacturer.
Particular attention
since there are iff ty of the battery.
When the battery reaches the end of its working life, it must be disconnected by
expert, trained personnel, then lifted (using the grips and suitable lifting devices) to
remove it from the
CLASSIFIED AS D
AUTHORISED BODIES FOR CORRECT DISPOSAL.
must be paid when choosing the battery charger, if not supplied,
erent kinds according to the type and capacid
battery compartment. EXHAUSTED BATTERIES ARE
ANGEROUS WASTE AND MUST BE CONSIGNED TO THE
ATTENTION: you are advised to always wear protective gloves,
to avoid the risk of serious injury to your hands.
ATTENTION: You are advised to only lift and move the batteries
with lifting and transportation means suitable for the specific
weight and size.
8. RECHARGING THE BATTERIES (VERSIONS WITH EXTERNAL BATTERY
CHARGER) (B-BT Versions)
ATTENTION: Please read carefully the use and maintenance instructions of the
battery charger that is included with the machine.
To charge the batteries you must:
1.Turn the key of the master switch anticlockwise to the “OFF” position.
2.Check that there is no water inside the recovery tank.
3.Engage the parking brake located on the left side of the machine.
4.Disconnect the hinge on the upper part of the handlebars.
5.Turn the recovery tank as far as it will go.
2
1
10

6.Disconnect the machine connector (1) of the battery connector (2).
7.Connect the battery charger connector to the battery connector (2).
8.Wait for the green LED of the battery charger to light.
ctor from the battery connector (2).
e battery connector (2)
9.Disconnect the battery charger conne
10. Connect the machine connector (1) to th
ATTENTION: If one of the three LEDs flashes refer to the
battery charger manual supplied with the machine.
ATTENTION: The machine is equipped with an automatic
system that disconnects the power supply from the electrical
system while the batteries are being recharged.
ATTENTION: In order not to cause permanent damage to the
batteries it is essential to avoid their complete discharge:
itching on of
d,
be
arrange the recharge within a few minutes of the sw
the flashing "discharged batteries" signal.
ATTENTION: Never leave the batteries completely discharge
even if the machine is not being used.
ATTENTION: For the daily recharging of the batteries, you must
fully respect the indications provided by the manufacturer or
retailer. All installation and maintenance operations must
carried out by expert personnel, trained at the APEC assistance
center.
ATTENTION: Danger of exhalation of gas and leakage of
corrosive liquids.
ATTENTION: Danger of fire: do not go near with free flames.
11

MACHINE PREPARATION
9 BUILT-IN BATTERY. RECHARGING THE BATTERIES (VERSION WITH
C
A TENTION: Please read carefully the use and maintenance instructions of the
battery charger that is included with the machine.
To charge the batte
Turn the key of the master switch anticlockwise to the “OFF” position (1).
2. Engage the parking brake (2) located on the left side of the machine.
3. Make sure that the recovery tank is empty.
4. Disconnect the hinges on the upper part of the handlebars.
rn the recovery tank anticlockwise as far as it will go.
Remover the pow
7. Connect t
8. Wait for th
9. Disconne
10. Insert the
HARGER) (B-BT versions)
T
ries you must:
1.
5. Tu
6. er outlet protection (3).
he battery charger power cable.
e green LED of the battery charger to light.
ct the battery charger power cable.
power outlet protection.
ATTENTION: The machine is equipped with an automatic system
chine is not being used.
ATTENTION: For the daily recharging of the batteries, you must fully
ained at the APEC assistance centre.
ATTENTION If one of the three LEDs flashes refer to the battery
charger manual supplied with the machine.
that disconnects the power supply from the electrical system while
the batteries are being recharged.
ATTENTION: In order not to cause permanent damage to the
batteries it is essential to avoid their complete discharge: arrange the
recharge within a few minutes of the switching on of the flashing
"discharged batteries" signal.
ATTENTION: Never leave the batteries completely discharged, even
if the ma
respect the indications provided by the manufacturer or retailer. All
installation and maintenance operations must be carried out by
expert personnel, tr
ATTENTION
liquids. : Danger of exhalation of gas and leakage of corrosive
ATTENTION: Danger of fire: do not go near with free flames.
10. BATTERY INDICATOR (B-BT versions)
On the instrument panel of the machine there is a monitor (1) indicating (amongst
other things) the battery charge status. If the upper line contains 8 light indicators,
the battery charge level is 100%. If the edges of the indicators are flashing, this
means the batteries are run down.
ATTENTION: A few seconds after the last indicator on the
monitor has flashed, the brush motor will automatically switch
off. With the remaining charge it is possible to complete the
drying process before recharging.
3
2
1
1
12

MACHINE PREPARATION
11. INSTRUMENT PANEL COMPONENTS
eneath the grip)
(DS versions)
4.
5.
6.
The instrument panel components are identified as follows:
1. Levers to activate brushes/traction (located b
2. Water outlet regulation switch
Detergent outlet regulation switch (DS versions)
Battery level / hour-counter display
Battery level hour-counter display command button
Speed level key (BT versions)
3.
12. REAR COMPONENTS
The rear components are identified as follows:
8. Wa
9. Water
Tank closure hinges
Handlebar fastening screws
Squeegee lifting lever
13.Key operated switch
7. Brush lifting pedal
ter/solution level tube
tap
10.
11.
12.
13. FRONT AND SIDE COMPONENTS
The side components are identified as follows:
12
7
8
9
10
11
13
16
14
17
13
5
4 2 3
6
1
14.Wa
15.Recovery
16.Suction unit lifting handle
17.Parking brake lever
ter/solution inlet cap
tank lifting handle
13

MACHINE PREPARATION
14. ASSEMBLING THE SQUEEGEE
The squeegee, that for reasons of packaging comes disassembled from the
ceed as follows
1. FF” position.
2f the machine.
3. he lever at the rear of the machine.
4 stud (1) in the hole in the squeegee
connection.
6 tud (2) in the slot on the squeegee connection.
7. he squeegee connection.
8. Insert the suction tube (3) in the appropriate sleeve on the squeegee, ensuring
that the suction tube lies to the right of the lifting cable.
machine, must be assembled while assembling the machine. Pro
for assembly:
Turn the key of the master switch anticlockwise to the “O
. Engage the parking brake located on the left side o
Lift the squeegee connection by means of t
. Lift the squeegee and fit the right
connection.
. Secure the stud by means of the pin on the squeegee5. Lift the squeegee and fit the left s
Secure the stud by means of the pin on t
AThese operations must be carried out using
gloves to avoid any possible contact with the edges or
tips of metal objects.
TTENTION:
protective
1 EEGEE INCLINATION
D the rear rubber is tilted slightly backwards (by about 5
m s whole length. If it is necessary to increase the bend of
the rubber in the central part, you must tilt the squeegee backwards, rotating the
adjuster (4) anticlockwise. To increase the bend of the rubber at the sides of the
squeegee, rotate the set screw clockwise.
5. ADJUSTING THE SQU
uring working operation,
m) in a uniform way for it
1
2
34
14

16. ADJUSTING THE SQUEEGEE HEIGHT
The height of the squeegee must be adjusted on the basis of
ar of the rubb do this, turn the knob (1) anticlockwise to raise the squeegee,
and clockwise to low ted to the same level, so the
e
the state of wear and
te er. To
er it.
Note: The right and left wheels must be adjus
sque gee can work parallel to the floor.
17. RECOVERY TANK
Cctly closed.
heck the cap of the drainage tube (on the rear of the machine) is corre
, put a minimum quantity
of antifoam liquid in the recovery tank before starting to clean.
ATTENTION: To avoid foam production
18. SOLUTION TANK / DETERGENT SOLUTION (VERSIONS WITHOUT DS)
Proceed as follows to fill the solution tank:
1. Turn the key of the master switch anticlockwise to the “OFF” position.
2. Engage the parking brake.
3. Remove the front inlet cap and check the solution filter (1) is correctly
assembled.
Check the filter cover (2) beneath the solution tank is correctly closed.
ceeding 50°C. You can check
4.
5. Fill it with clean water at a temperature not ex
the quantity in the tank by means of the rear tube (3).
2 2
15

MACHINE PREPARATION
The solution tank has a maximum capacity of about 48 litres. Add the liquid
detergent to the tank in the concentration and manner indicated on the detergent
s label. The formation of excess foam could damage the suction
the minimum amount of detergent necessary.
manufacturer'
motor, so use only
ATTENTION: Always use detergents whose manufacturer's
label indicates their suitability for scrubbing machines. Do not
use acid or alkaline products or solvents without this indication.
In addition, you are advised to always use low foam detergents.
Do not use pure acids.
ATTENTION: Protective gloves should always be worn before
handling detergents or acidic or alkaline solutions to avoid
serious injury to hands.
19. SOLUTION TANK WITH AUTOMATIC CDS DISTRIBUTION SYSTEM
Proceed as follows to fill the solution tank:
1. Check that the key of the master switch is in the "OFF" position.
2f the
3
4
5. Rotate the recovery
6
s
liquid leaking out while the machine is being used.
. Engage the parking brake, by means of the lever on the left side o
machine.
. Check the recovery tank is empty before you open it.
. Release the hinges (1) on the handlebars.
tank as far as it will go.
. Unscrew the cap (2) of the canister in the compartment (in front of the
batteries) and fill it with liquid detergent in the manner indicated on the label
upplied with the machine. Check the screw cap is well closed, to avoid any
1
2
16

MACHINE PREPARATION
7. Close the recovery tank, rotating it by hand. Hold the recovery tank by the
8
9
1he tank has a
To regulate the
DETERGENT W
handle only to avoid crushing your hands.
. Loosen the front cap of the solution tank.
. Check that the filter cover (3) beneath the solution tank is correctly closed.
0. Fill it with clean water at a temperature not exceeding 50°C. T
maximum capacity of about 48 litres.
water/detergent mixture, carefully read the “REGULATING THE
ITH THE CDS SYSTEM” paragraph.
ATTENTION: Protective gloves should always be worn before
handling detergents or acidic or alkaline solutions to avoid
serious injury to hands.
3
ed to always use low foam detergents.
Do not use pure acids or detergents with a stronger gradation
than that indicated on the label supplied.
ATTENTION: Always use detergents whose manufacturer's
label indicates their suitability for scrubbing machines. Do not
use acid or alkaline products or solvents without this indication.
In addition, you are advis
20.
For packaging reasons, the splash guard
the machine. To connect the rubber, remove the rubber-pressing blades and
unthread the spring hook (1) from the connection screw. Wind the rubber all
around the base, inserting the base fixing screw in the central hole. Reattach the
blades, starting from the centre of the base.
Be careful not to invert the right blade with the left one, as they are not the same.
ASSEMBLING THE SPLASHGUARD RUBBERS.
rubbers are supplied disassembled from 1
17

MACHINE PREPARATION
21. achine.
4.
5
6
7.
ASSEMBLING THE BRUSH m1.Use the parking brake handle (1) to stop the
2.Raise the base by means of the appropriate pedal.
3.Turn the key of the master switch anticlockwise to the “OFF” position.
With the base in a raised position, place the brush under the seat of the base
plate.
.Lower the base with the appropriate pedal.
.Turn the key of the master switch clockwise to the “ON” position.
Instantly engage and release the brush-traction control lever.
WARNING! During this operation, check there are no people
or objects near the brushes.
A TTENTION: This operation must be carried out wearing
gloves to protect your hands.
22. ASSEMBLING THE BRUSH
1.Use the parking
2.Raise the base
3.Turn the key of ckwise to the “OFF” position.
brake handle (1) to stop the machine.
by means of the appropriate pedal.
the master switch anticlo
4. With the base up, place the brushes into the plate housing beneath the base,
turning the brushes until the three pins enter the niches in the plate itself; rotate
until the button is pushed towards the coupling spring and is locked into place .
The figure shows the rotation direction for coupling the right-hand brush; for the
left-hand one, rotate in the opposite direction.
1
1
18

MACHINE PREPARATION
You are advised to invert the right and
are ot new however, and have deformed bristles, it is better to reassemble them
left-hand brushes every day. If the brushes
the left-hand one on the
n
in the same position (the right-hand one on the right, and
left), to prevent the different inclination of the bristles producing an overload on the
brush motor as well as excessive vibrations.
ATTENTION: This operation must be carried
gloves to protect your hands.
WARNING! During this operation, check there are no people
t wearing
or objects near the brushes. ou
23. REGULATING THE SOLUTION FOR VERSIONS WITHOUT DS
Adjust the amount of outlet water through the anticlockwise rotation of the lever (1)
on the tap, located on the rear of the machine.
24. DETERGENT REGULATION WITH THE DS SYSTEM
with the CDS:
sby rotating the upper knob
es/hour to
maximum of 75 litres/hour, with 7 set dosing points. The right solution flow
hould be proportional to the degree of dirt on the floor. In addition, remember
that the time available for continuous working depends on the quantity of water
in the tank: For example, the work autonomy with a full tank (about 48 litres) and
the selector (1) set at 30, is about 1.5 hours.
2.Regulate the percentage of liquid detergent in the solution by rotating the lower
knob (2) clockwise. The lower value is equal to 0.5% (for standard detergents)
or 0.1% (for a concentrated detergent, diluted as indicated on the label supplied
with the machine), while the higher value is equal to 3.5% or 0.7%, with 7 set
To
an
Perform the following adjustments on machine versions
1.Regulate the flow of detergent solution to the brushe
(1) clockwise. The quantity of solution varies from a minimum of 30 litr
a
s
points. Use high detergent percentages to remove very greasy dirt from the
floor.
avoid any tampering with the set regulation, you can remove the two switches
d cover the two holes with the plastic caps supplied with the machine.
1
WARNING! Check that the tap lever is fully opened, the
lever is positioned at the rear of the machine.
1
2
19
