Pioneer PRS-D4200F - Premier Amplifier User manual

. i
,'
Mode d'emploi
··'·MA,·.··;"E,~,_',·,M,',"",,",,","·,··,,",·"· ,Z",·-", -E' .''''.1t. ... ' ,.""',.',", .. ','
y.' y. - , ••
, ..' .' - - - ~, '" -.'
. -_.- ..-
.,,
':1
: ",.' , ';" : ',. ,",:,"', ,. ,,~
·P.RS~D4200.F
;:,·r=J'RII)GEABLE',FOUR-CHANNELPOWER AMPLIFIER,
:~·:/~~f - '. ~'-,: .. : _.-.: -~
1~1;~~:jr~ltijM'nliln .... .... . ...
~<.':~<;~>,;;'\;: ;,)';': ,:,;' ;" ;

Contents
Before Using This Product 2
Information to User 2
Inportant 2
After-sales service for Pioneer products 2
CAUTION 3
Visit our website 3
CAUTION 3
WARNING 4
Setting the Unit 5
Power Indicator 5
Top Cover 5
Cut
Off Frequency Control 5
BFC (Beat Frequency Control) Switch 5
LPF (Low-Pass Filter)IHPF (High-Pass Filter)
Select Switch 6
Gain Control 6
Input Select Switch 6
Input Switch 6
Setting the Gain properly 7
Connecting the Unit 8
Connection Diagram 9
Solderless Terminal Connections
10
Connecting the Power Terminal 10
Connecting the Speaker Output Terminals 11
Using the Speaker Input 11
Connecting the Speakers and Input Wires 12
Installation 14
Example of installation on the floor mat
or on the chassis
15
Replacing the top cover 15
Specifications 16
•

Before Using This Product
Thank you for purchasing this PIONEER
product. It
is designed to give you many
years
of enjoyment.
PIONEER SUGGESTS USING APRO-
FESSIONAL INSTALLER DUE TO THE
COMPLEXITY OF THIS PRODUCT.
Please read
aU instructions and WARN-
INGS in this manual before attempting
operation. Should you have any questions,
contact your nearest Pioneer authorized
dealer or installation specialist.
Information to User
Alteration or modifications carried out
without appropriate authorization may
invalidate the user's right
to operate the
equipment.
Important
The serial number of this amplifier is writ-
ten on the bottom
of the unit. For your
own security and convenience, write it
down on the enclosed warranty card. Keep
the card handy for future reference.
After-sales service for Pioneer
products
Please contact the dealer or distributor from where
you purchased the product for its after-sales ser-
vice (including warranty conditions) or any other
information. In case the necessary information is
not available, please contact the companies listed
below:
Please do not ship your product to the companies
at the addresses listed below for repair without
advance contact.
• U.S.A.
Pioneer Electronics (USA) Inc.
CUSTOMER SUPPORT DIVISION
P.O. Box 1760
Long Beach, CA 90801-1760
800-421-1404
• CANADA
Pioneer Electronics of Canada, Inc.
CUSTOMER SATISFACTION
DEPARTMENT
300 Allstate Parkway
Markham, Ontario L3R
OP2
1-877-283-5901
905-479-4411
For warranty information please see the Limited
Warranty sheet included with your product.
•

Before Using This Product
4 Ohm Bridged Mode
2 Ohm Bridged Mode
Diagram B- Improper
R-
Pioneer
Amplifier
L+
IACAUTION
I Diagram A- Proper
•Never replace the fuse with one of greater
value or rating than the original fuse. Use
of
an improper fuse could result in overheating
and smoke and could cause damage to the
product and injury including bums.
•Use the supplied hexagonal wrench to tight-
en screws when fastening wires to the termi-
nal. The use
of along, commercially avail-
able hexagonal wrench can cause excessive
torque to be applied possibly resulting in
damage to terminals and wires.
Visit our website
A CAUTION
Visit us at the following site:
http://www.pioneerelectronics.com
Register your product. We will keep the details of
your purchase on file to help you refer to this
information in the event
of an insurance claim
such as loss or theft.
2Receive updates on the latest products and tech-
nologies.
3Download owner's manuals, order product cata-
logues, research new products, and much more.
Do NOT install or use your Pioneer ampli-
fier by wiring speakers rated at 4Ohm (or
lower) in parallel to achieve a 2
Ohm (or
lower) bridged mode (Diagram B).
Amplifier damage, smoke, and overheat-
ing could result from improper bridging.
The amplifier surface could also become
hot to the touch and minor bums could
result.
To properly install or use abridged mode
for atwo-channel amplifier and achieve a
4Qload, wire two 8Qspeakers in parallel
with Left +and Right -(Diagram A)
or
use asingle 4Qspeaker. For afour-chan-
nel amplifier, follow the speaker output
connection diagram for bridging as shown
on the back
of your amplifier, and wire
two 8Qspeakers in parallel to achieve a 4
Qload or use asingle 4Qspeaker per
channel.
If you have any questions or concerns,
please contact your local authorized
Pioneer dealer or call Pioneer customer
service.
•

WARNING
•Handling the cord on this product or cords associ-
ated with accessories sold with the product will
expose you to lead, achemical known to the State
of California and other governmental entities to
cause cancer and birth defects or other reproduc-
tive harm. Wash hands after handling.
• We recommend that you use the special red bat-
tery and ground wire [RD-228], which
is sold sep-
arately. Connect the battery wire directly to the
car battery positive terminal (+) and the ground
wire to the car body.
•Do not touch the amplifier with wet hands.
Otherwise you may get an electric shock. Also, do
not touch the amplifier when it
is wet.
•For traffic safety and to maintain safe driving
conditions, keep the volume low enough so that
you can still hear normal traffic sound.
•Check the connections
of the power supply and
speakers if the fuse of the separately sold battery
wire or the amplifier fuse blows. Detect the cause
and solve the problem, then replace the fuse with
another one
of the same size and rating.
•To prevent malfunction
of the amplifier and
speakers, the protective circuit will cut the power
supply to the amplifier (sound will stop) when an
abnormal condition occurs. In such acase, switch
the power to the system OFF and check the
connection
of the power supply and speakers.
Detect the cause and solve the problem.
•Contact the dealer
if you cannot detect the cause.
•To prevent an electric shock or short-circuit
during connection and installation, be sure to
disconnect the negative (-) terminal of the battery
beforehand.
•Confirm that no parts are behind the panel when
drilling ahole for installation of the amplifier. Be
sure
to protect all cables and important equipment
such as fuel lines, brake lines and the electrical
wiring from damage.
•DO NOT allow amplifier
to come into contact
with liquids due to, for example, the location
where the amplifier is installed. Electrical shock
could result. Also, amplifier and speaker damage,
smoke, and overheating could result from contact
with liquids. In addition, the amplifier surface and
the surface
of any attached speakers could
become hot to the touch and minor bums could
result.
•

Setting the Unit
•To adjust the switch, use standard tip screwdriver ifneeded.
Power Indicator
The power indicator lights
when the power
is switched
on.
Top Cover
Before setting up the unit, unfasten the
screws with a 4 mm hexagonal wrench
and remove the top cover.
•
Cut Off Frequency Control
If the LPFIHPF select switch is set to
LPF or HPF, you can select acut
off
frequency from 40 Hz to 500 Hz.
BFC (Beat Frequency Control)
Switch
BFC switch is on the bottom of the unit.
If you hear abeat while listening to an
AM broadcast with your car stereo,
change the BFC switch using asmall
standard tip screwdriver.

LPF (Low-Pass Filter)/HPF (High-Pass Filter) Select Switch
Set the LPFIHPF select switch as follows according to the type of speaker that is connected
to the speaker output connector and the car stereo system:
LPFIBPF Select
Switch
LPF (Left)
OFF (Center)
HPF (Right)
Audio frequency range
to be output
*- 40 Hz to 500 Hz
Full range
*40 Hz to 500 Hz -
Speaker
Type
Subwoofer
Full range
Full range
Remarks-
Connect asubwoofer.
Use
if you want to cut the
very low frequency range*
because it is not necessary
for the speakers you are
usmg.
*See the "Cut Off Frequency Control" section.
Gain Control
Adjusting the gain controls Aand Bwill help match the output of the car stereo to the
Pioneer amplifier. Normally, set the gain controls to the NORMAL position.
If the output is
low, even when the volume
of the car stereo is turned up, tum these controls clockwise. If
there is distortion when the volume of the car stereo is turned up, tum these controls
counter-clockwise.
• If you only use one input plug, set the gain controls for speaker outputs Aand Bto the same position.
•When using with an RCA equipped car stereo (standard output
of 500 mV), set to the NORMAL
position. When using with an RCA equipped Pioneer car stereo with max. output
of 4 V or more,
adjust level to match the car stereo output level.
Input Select Switch
For two-channel input, slide this switch
to the left. For four-channel input, slide
this switch to the right.
Input Switch
It is possible to input from acar stereo external output (subwoofer output) or acar stereo
speaker output. When using an external output (subwoofer output), slide the switch to the
left. For connection instructions, see the "Connection Diagram" section. When using a
speaker output, slide the switch to the right. In this case, it is necessary to use the supplied
speaker input wire with RCA pin cord. For details, see the "Using the Speaker Input" sec-
tion. .
•

Setting the Unit
Head unit volume steps Head unit volume steps
Amplifier gain
-----.~~ Amplifier gain
(normal) (maximum)
Signal
waveform
I Maximum gain I
.--
I Normal gain
Signal
waveform
Power Power ---;
INormal gain I IMaximum gain I
._---- ..
Relationship between the gain of the
amplifier and the output power of the
head unit
• If you raise the gain of the amplifier to an improp-
er level, only distortion is increased and the power
increases only slightly.
Signal waveform when outputting at high
volume by the gain control of the amplifier
Setting the Gain properly
•This unit is equipped with aprotective function to
prevent malfunction
of the unit itselfand speakers
from too much output, improper use
or improper
connection.
•When outputting sound at high volume etc., this
function will cut offthe sound output in afew
seconds. But this is not amalfunction. When you
tum down the volume
of the head unit the sound
output·will be restored.
•
If sound output is cut, the gain control of this unit
may be improperly set. To ensure continuous
sound output at increased volume
of the head unit,
set the gain control
of the amplifier to aproper
position according to the preout maximum output
level
of the head unit. There is no need to
decrease the volume
of the head unit and too
much output is controlled.
•
If you decrease the volume of the head unit and
set the gain control
of the amplifier to the proper
position but still the sound cuts out from time to
time, contact the nearest authorized PIONEER
Service Station.
Gain Control of This Unit
Preout level: 4 V --......
~
NORMAL
Preout level: 6.5 V-/"'· ~ ~ level: 2 V
~ (Standard: 500 mV)
6.5V O.4V
GAIN
Amplifier gain ---- .... ~ Amplifier gain
(normal) (maximum)
•With high output the signal waveform is distorted,
if you raise the gain of the amplifier the power
changes only slightly.
•The above illustration shows the gain set to
NORMAL.
•

Connecting the Unit
A CAUTION
•Disconnect the negative (-) tenninal of the bat-
tery to avoid the risk
of short-circuit and damage
to the unit.
•Secure the wiring with cable clamps or adhesive
tape. To protect the wiring, wrap adhesive tape
around it where they lie against metal parts.
•Do not route wires where they will get hot, for
example where the heater will blow over them.
If
the insulation heats up, it may become damaged,
resulting in ashort-circuit through the vehicle
body.
A CAUTION:
To prevent damage and/or injury
•Do not ground the speaker wire directly or con-
nect anegative
(-) lead wire for several speakers.
•This unit is for vehicles with a12-volt battery and
negative grounding. Before installing it
in arecre-
ational vehicle, truck
or bus, check the battery
voltage.
• If the car stereo is kept on for along time while
the engine is at rest
or idling, the battery may go
dead.
Tum the car stereo off when the engine is at
rest or idling.
• If the system remote control wire of the amplifier
is connected to the power terminal through the
ignition switch (12 VDC), the amplifier will
always be on when the ignition is
on- regardless
of whether the car stereo is on or off. Because of
this, the battery could go dead if the engine is at
rest or idling.
•Make sure that wires will not interfere with mov-
ing parts
of the vehicle, such as the gearshift,
handbrake or seat sliding mechanism.
•Do not shorten any wires. Otherwise the protec-
tion circuit may fail to work when
it should.
•Never feed power to other equipment by cutting
the insulation
of the power supply wire to tap
from the wire. The current capacity
of the wire
will be exceeded, causing overheating.
•Never replace the fuse with one
of greater value
or rating than the original fuse. Use
of an improp-
er fuse could result in overheating and smoke and
could cause damage to the product and injury
including burns.
•Speakers to be connected to the amplifier should
conform with the standards listed below.
If they
do not conform, they may catch fire, emit smoke
or become damaged. The speaker impedance
must be 2to 8ohms. But in case
of two-channel
and other bridge connections, the speaker
impedance must be 4to 8ohms.
•Install and route the separately sold battery wire
as far away as possible from the speaker wires.
Install and route the separately sold battery wire,
ground wire, speaker wires and the amplifier as
far away as possible from the antenna, antenna
cable and tuner.
Speaker Cha~el
SpeakerType
Power
Four-channel Subwoofer Nominal input: Min. 70 W
Other than subwoofer Max. input: Min. 150 W
Two-channel Subwoofer Nominal input: Min. 200 W
Other than subwoofer Max. input: Min. 600 W
Three-channel Subwoofer Nominal input: Min. 70 W
Speaker output AOther than subwoofer Max. input: Min. 150 W
Three-channel Subwoofer Nominal input: Min. 200 W
Speaker output BOther than subwoofer Max. input: Min. 600 W•

Connecting the Unit
Connection Diagram
•This diagram shows connections using external output (subwoofer output). Slide the input switch to the left
(RCA).
•When you connect with speaker output, connections defers from the diagram. For details, see the "Using
the Speaker Input" section. In either case, you need to set the input switch. For details, see the "Setting the
Unit" section.
Grommet
Fuse (40 A) x 2
Special red battery wire [RD-228] (sold separately)
After making all other connections at the amplifier,
connect the battery wire terminal
of the amplifier to
the positive (+) terminal
of the battery.
~-----------e:o
Ground wire (Black) [RD-228] (sold separately)
Connect to metal body or chassis.
Car stereo with
RCA output
jacks
Connecting wire with
RCA pin plugs (sold
separately).
~
,~ .
RCA input
Amplifier with
RCA input jacks
Speaker
output tenninal
See the "Connecting the Speakers
and Input Wires" section for
speaker connection instructions.
Fuse (30 A) x 2
RCA output jack RCA input
jack Br-- ....,
...... _~""---,,= = = == RCA input jack A
~...,
•
/
System remote control wire (sold separately)
Connect the male terminal
of this wire to the system remote control terminal of the car
siereo (SYSTEM REMOTE CONTROL). The female terminal can be connected to the
auto-antenna relay control terminal. If the car stereo does not have asystem remote control
terminal, connect the male terminal to the power terminal through the ignition switch.

Interior of
the vehicle
Engine
compartment
FUSe(40A)X2/
Drill a 13 mm
Insert the O-ring rubber hole into the
grommet into the vehicle vehicle body.
body.
Positive (+)
tenninal
oL
1. Pass the battery wire from the
engine compartment to the interior
of the vehicle.
•After making all other connections to the
amplifier, connect the battery wire tenninal
of the amplifier to the positive (+) tenninal of
the battery.
2. Connect the wires to the terminal.
•Fix the wires securely with the tenninal
screws.
•Do not connect acord having an exposed core
wire to the power tenninals
of this amplifier
(Power tenninal, GND tenninal, System remote
control tenninal). Disconnection
or breakage of
the core wire can cause afire or short-circuit.
•Since the wire will become loose over time, it
must be periodically inspected and tightened as
necessary.
•Do not solder
or bind the ends of the twisted
wires.
•Fasten while making sure to not to clamp the
insulating sheath
of the wire.
•Use the supplied hexagonal wrench to tighten and
loosen the tenninal screw
of the amplifier.
Securely fasten the wire with the tenninal screw.
However, since excessively tightening
the tenni-
nal screw
of the System remote control has the
risk of damaging the wire, be careful not to tight-
en excessively by observing the status
of the wire
when tightening.
Connecting the Power Terminal
Solderless Terminal Connections
• We recommend that you use the special red bat-
tery and ground wire [RD-228], which is sold
separately. Connect the battery wire directly to
the car battery positive tenninal (+) and the
ground wire to the car body.
•Recommended wires size (AWG: American Wire
Gauge)
is as follows. The battery wire and the
ground wire must be same size.
•Use a10 AWG to 20 AWG wire for the system
remote control wire.
Battery Wire and Ground Wire Size
less than less than less than
4.5 m
7.2m 11.4 m
(14
f1. 9in.) (23 f1. 7in.) (37 f1. 5in.)
8AWG 6AWG 4AWG
System remote Tenninal screws
control tenninal
~~~ GND tenninal
powertenninal~~ ~
'l:t~~und wire
Battery wir~"",
System remote
control wire
A WARNING
Failure to securely fasten the battery wire to the ter-
minal using the tenninal screws could cause the ter-
minal area to overheat and could result in damage
and injury including minor bums.
•

(lonnecting the Unit
Connecting the Speaker Output
Terminals
Connections when using the speaker
input
•Use a10 AWG to 16 AWG wire for the speaker
wire.
1. Expose the end of the speaker wires
using nippers oracutter
by about 10
mm (3/8 inch) to 12 mm (1/2 inch).
--------~
I- -I
10 rom (3/8 inch) to 12 mm (1/2 nch)
Car Stereo
r------
Sp
r1
eaker output
2. Connect the speaker wires to the
speaker output terminals.
•Fix the speaker wires securely with the termi-
nal screws.
White: Black:
Left ffi Left eBlack: Red: Right eRight ffi
Terminal screws
Speakeroutput
~
tenmnal ~
~" Speaker wire
~~
Using the Speaker Input
Connect the car stereo speaker output
wires to the amplifier using the supplied
speaker input wire with RCA pin cord.
•Slide the input switch to the right (SP).
ID
Speaker input
wire with RCA
pin cord
To RCA input
jack of this unit.
•As aresult
of connecting the car stereo speaker
output wire to the amplifier, the power
of the
amplifier is turned on automatically when the car
stereo is turned on. It is not necessary to connect
the system remote control wire in this case.
•In the case the amplifier and head unit are con-
nected using aspeaker input wire with
RCA pin
cord, the amplifier power is only turned on when
one amplifier is being used.
If two or more ampli-
fiers are synchronously connected
in combina-
tion, connect the head unit and all
of the ampli-
fiers with the system remote control wire.
Note:
•Connect the system remote control wire when the
power
of the amplifier is not to be turned on
when the car stereo is turned on.

Connecting the Speakers and Input Wires
The speaker output mode can be four-channel, three-channel (stereo +mono)
or two-channel (stereo, mono). Connect the speaker leads to suit the mode
according
to the figures shown below.
Four-channel
Input select switch is on the top of the unit. For two-
channel input, slide this switch to the left. For four-
channel input, slide this switch to the right.
RCA input
jack B
RCA input jack A
~
;:::::.-=::::::=~ M ~;;; -;;- ;;- ~
~o~ ,
~~ ,
t=~-
Q
iii 6 :~~n:~~~~~:s
,'fi (sold separately)
vvr
From car stereo (RCA output)
If only one input plug is used, such as
when the car stereo has only one output
(RCA output), connect the plug to
RCA
input jack A, but do not connect aplug to
RCA input jack B.
·rrfJ
ED88ED
--
~~
---
-- -.
---
sa
n- -
I
... a .... ~ .. G:JAlao It
.. D. D ••
•••• 'Ill
lie
Ille
lie III
(Left)
Speaker out B
(Right)
(Right)
Speaker
out A
(Left)
Three-channel
•
(Right)
Speaker
out A
(Left)
rrFCC1 Speaker out B
I II 'J (Mono)
8 ED
_CIlII"II .. hQWf'Wf -
IiG.II.GE)MGDllIa 0 Ita_ D_._ II
.""".'0'
jr~'~ =~
RCA input jack B
RCA input
jack A
~
;:::::. _=::::::=~ - ~;;; -;;- ;;- ~
~(i) ,
!IiJ ~ ,
t=~-
O
t ~ Connecting wires
~ with RCA plugs
...l[ (sold separately)
Input select switch
is on the top of the unit. For two-
channel input, slide this switch to the left. For four-
channel input, slide this switch to the right.
_L
From car stereo (RCA output)
If only one input plug is used, such as
when the car stereo has only one output
(RCA output), connect the plug to
RCA
input jack A, but do not connect aplug to
RCA input
jack B.

Connecting the Unit
Two-channel (Stereo)
Input select switch is on
the top of the unit. Slide
this switch to the left.
-1-----11,
rr=e:J Speaker (Right)
(±)
r
e
(±)
~Ll·===~=:::c(] Speaker (Left)
RCA input jack A
In the case of two-channel mode
connect RCA plugs to the RCA
input jack A.
/
Two-channel (Mono)
RCA input jack A
In the case of two-channel mode
connect RCA plugs to the RCA
input jack A.
Input select switch is on
the top of the unit. Slide
this switch to the left.
L
From car stereo (RCA output)
r-r:d Speaker (Mono)
e (±)
-----1
-RAllIIIOVJl'VT -. CEtllU1'PUf--
M.DoIlGElutc=:JMD 0 .. a_ D_cm_ a
~~I." .,.,, .,
(±) e
II c(] Speaker (Mono)
D

Installation
A CAUTION
•Do not install in:
-Places where it could injure the driver or pas-
sengers
if the vehicle stops suddenly. .
-Places where it may interfere with the driver,
such as on lhe floor in front of the driver's
seat.
•Make sure that wires are not caught in the sliding
mechanism
of the seats, resulting in ashort-cir-
cuit.
•Confirm that no parts are behind the panel when
drilling ahole for installation
of the amplifier.
Protect all cables and important equipment such
as fuel lines, brake lines and electrical wiring
from damage.
•Install tapping screws in such away that the
screw tip does not touch any wire. This is impor-
tant to prevent wires from being cut by vibration
of the car, which can result in fire.
•DO NOT allow amplifier to come into contact
with liquids due to, for example, the location
where the amplifier is installed. Electrical shock
could result. Also, amplifier and speaker damage,
smoke, and overheating could result from contact
with liquids. In addition, the amplifier surface and
the surface
of any attached speakers could
become hot to the touch and minor bums could
result.
•To ensure proper installation, use the supplied
parts in the manner specified. If any parts other
than the supplied ones are used, they may damage
internal parts
of the amplifier, or they may
become loose causing the amplifier to shut down.
•Never replace the fuse with one
of greater value
or rating than the original fuse. Use
of an improp-
er fuse could result in overheating and smoke and
could cause damage to the product and injury
including bums.
A CAUTION:
To prevent malfunction and/or injury
•To ensure proper heat dissipation of the amplifier,
be sure
of the following during installation.
-Allow adequate space above the amplifier for
proper ventilation.
-Do not cover the amplifier with afloor mat or
carpet.
•DO NOT allow amplifier to come into contact
with liquids due to, for example, the location
where the amplifier is installed. Electrical shock
could result. Also, amplifier and speaker damage,
smoke, and overheating could result from contact
with liquids. In addition, the amplifier surface and
the surface of any attached speakers could
become hot to the touch and minor bums could
result.
•Do not install the amplifier on unstable places
such as the spare tire board.
•The best location for installation differs with the
car model and installation location. Secure the
amplifier at asufficiently rigid location.
•Make temporary connections first and check that
the amplifier and the system operate properly.
•After installing the amplifier, confirm that the
spare tire, jack and tools can be easily removed.

D
Installation
Example of installation on the
floor mat or on the chassis
1. Place the amplifier where it is to be
installed. Insertthe supplied tap-
ping screws
(4 mm x30 mm) into
the screw holes. Push on the screws
with ascrewdriver so they make
marks where the installation holes
are to be located.
2. Drill 2.5 mm (1/8 inch) diameter
holes
at the point marked, and
install the amplifier, either on the
carpet
or directly to the chassis.
Replacing the top cover
1. Align the unit and top cover, and
insert the screw.
•The cover can be installed in the desired
direction to match to the amplifier.
2. Tighten the screw with a 4 mm
hexagonal wrench.
Tapping-screws (4 mm x30 nun)
,
-\ i
\Drill a2.5 mm diameter hole
Floor mat or chassis

Specifications
Power source 14.4 V DC (10.8 V to 15.1 V allowable)
Grounding system Negative type
Current consumption 28 A (at continuous power, 4 n)
Average current drawn* 10 A (4 n for four channels)
20 A (4 n for two channels)
20 A (2 n for four channels)
l:'.~,..... ')" A .. ~"
rU1>1; .JV t"\ A ..
Dimensions 301 (W) mm x 57 (H) mm x 213 (D) mm
[12 (W) in x 2-1/4 (H) in x 8-3/8 (D) in]
Weight 3.5 kg (7.71bs.) (Leads for wiring not included)
Maximum power output 150 Wx 4 (4 n) / 600 Wx 2 (4 n)
Continuous power output 75 Wx 4 (at 14.4 V, 4 n, 20 Hz to 20 kHz 1.0% THD)
300 Wx 2 (at 14.4 V, 4 n, 1 kHz 1.0% THO)
150 Wx 4 (at 14.4 V, 2 n, 1 kHz 1.0% THO)
Load impedance 4n (2 n to 8n allowable)
Frequency response 10 Hz to 50 kHz (+0 dB, -3 dB)
Signal-to-noise ratio 100 dB (IHF-A network)
Distortion 0.005 % (10 W, 1 kHz)
Separation 70 dB (1 kHz)
60 dB (100 Hz to 10 kHz)
Low pass filter Cut off frequency: 40 Hz to 500 Hz
Cut off slope: -12 dB/oct
High pass filter Cut off frequency: 40 Hz to 500 Hz
Cut off slope: -12 dB/oct
Gain control RCA: 400 mV to 6.5 V
Speaker: 1.6 V to 26 V
Maximum input level/impedance RCA: 6.5 V/ 22 ill
Speaker: 26 V/90 kn
Power output 75 W RMS x4 channels
(4 n and ~ I % THD+N)
300 W RMS x 2 channels
(4 n and ~ 1% THD+N)
150 W RMS x4 channels
(2 n and ~ I % THD+N)
Signal-lo-noise ratio 80 dBA (Reference: 1W into 4 n)
Note:
•Specifications and the design are subject to possible modification without notice
due
to improvements.
*Average current drawn
•The average current drawn is nearly the maximum current drawn by this unit
when an audio signal
is input. Use this value when working out total current
drawn
by multiple power amplifiers.
•

Published by Pioneer Corporation.
Copyright ©2008
by Pioneer Corporation.
All rights reserved.
Publication de Pioneer Corporation.
Copyright ©2008 Pioneer Corporation.
Tous droits de reproduction et de traduction
reserves.
Registeryourproduct at
Enregistrez votre produit au
Registre su producto en
http://www.pioneerelectronics.com
See "Visit our website"page
Voir fa page "Visitez notre site Web"
Consulte
fa pagina sobre "Visite nuestro sitio Web"
PIONEER CORPORATION
4-1, MEGURO 1-CHOME, MEGURO-KU, TOKYO 153-8654, JAPAN
KOpnOpau.MA naMOHMp
4-1, Merypo 1-LJoMe, Merypo-Ky, TOK~o 153-8654, AnoH~A
PIONEER ELECTRONICS (USA) INC.
P.O. Box 1540, Long Beach, California 90801-1540, U.S.A.
TEL: [phone]
PIONEER
EUROPE NV
Haven 1087, Keetberglaan 1, B-9120 Melsele, Belgium
TEL: [phone]
PIONEER
ELECTRONICS ASIA CENTRE PTE. LTD.
253 Alexandra Road, #04-01, Singapore 159936
TEL: [phone]
PIONEER
ELECTRONICS AUSTRALIA PTY. LTD.
178-184 Boundary Road, Braeside, Victoria 3195, Australia
TEL: [phone]
PIONEER
ELECTRONICS OF CANADA, INC.
300 Allstate Parkway, Markham, Ontario L3R
OP2, Canada
TEL: [phone]
TEL: [phone]
PIONEER
ELECTRONICS DE MEXICO, S.A. de C.V.
Blvd.Manuel Avila
Camacho 138 10 piso
Col.Lomas
de Chapultepec, Mexico, D.F. 11000
TEL: [phone]
<KSNNX> <08AOOOOO> BA098765432
Printed in China
Imprime en Chine
<YRD5202-A/S> UC

PIONEER ELECTRONICS (USA) INC.
R{EMIEI{
PIONEER ELECTRONIQUES DU CANADA, INC.
GARANTIE L1MITEE . . .
GARANTIE VALIDE SEULEMENT DANS LE PAYS OU LE PRODUIT A ETE ACHETE
GARANTIE
Pioneer Electronics (USA) Inc. (PUSA) et Pioneer Electronique du Canada. Inc. (POC) garantissent que les produits distribues par PUSA aux Etats-Unis et par POC au Canada qui,
apres avoir
ete installes et utilises conformement au manuel de I'utilisateur inclus avec I'unite, ne fonctionnent pas de fac;:on appropriee dans des conditions d'utilisation normales en
raison d'un vice de fabrication, seront repares ou remplaces par une unite de valeur comparable, au choix de
PUSA ou de POC, sans que vous deviez payer pour les pieces ou les
travaux
de reparation. Les pieces incluses en vertu de la presente garantie peuvent etre neuves ou remises aneuf, au choix de PUSA ou de POCo
LA PRESENTE GARANTIE L1MITEE S' APPLIQUE AU PROPRIETAIRE INITIAL AINSI QU' A TOUT PROPRIETAIRE SUBSEQUENT DU PRESENT PRODUIT PIONEER PENDANT LA PERIODE DE GARANTIE,
A CONDITION QUE LE PRODUIT AIT ETE ACHETE CHEZ UN DISTRIBUTEUR OU DETAILLANT PIONEER AUTORISE AUX ETATS-UNIS OU AU CANADA. VOUS DEVREZ FOURNIR UN RELEVE DE
CAISSE OU UNE AUTRE PREUVE 0' ACHAT VALIDE INDIQUANT LA DATE DE L' ACHAT INITIAL OU, Sl VOUS LOUEZ LE PRODUIT, VOTRE CONTRA T DE LOCATION INDIQUANT L'ENDROIT ET LA DATE
DE LA PREMIERE LOCATION. SI JAMAIS UN SERVICE DE REPARATION EST REQUIS, LE PRODUIT DOlT ETRE EXPEDIE PENDANT LA PERIODE DE GARANTIE, EN PORT PREPAYE, A L'INTERIEUR
DU PAYS OU L'ACHAT A ETE EFFECTUE SEULEMENT, TEL QU'IL EST EXPLIQUE DANS LE PRESENT DOCUMENT. VOUS litES RESPONSABLE DU DEMONTAGE ET DE L'INSTALLATION DU
PRODUIT. PUSA OU POC, LE CAS ECHEANT, PAIERA POUR VOUS RETOURNER LE PRODUIT REPARE OU REMPLACE, A L'INTERIEUR DU PAYS OU L'ACHAT A ETE EFFECTUE.
PERIODE DE GARANTIE DES PROOUITS
Appareil audio central pour automobile a marque PREMIER .
Amplificateurs de puissance, Lecteurs de CD "Multi-Play" et Reseau actif de separation amarque PREMIER .
Haut-Parleurs a marque PREMIER .
Pieces
2ans
2ans
1an
Main-d'ceuvre
2 ans
2 ans
1 an
< CRY1070-D/U >
La periode de garantie pour lesclientsqui louent Ie produit commence Ie jourou Ie produitest utilise pour lapremierefois (a) pendant laperiode de location ou (b) apres la vente au detail. selonce qui se produiten premier.
ELEMENTS NON COUVERTS PAR LA GARANTIE
UN PRODUIT ACHETE CHEZ UN DISTRIBUTEUR NON AUTORISE N'EST COUVERT PAR AUCUNE GARANTIE EXPRESSE OU IMPLICITE, YCOMPRIS QUELQUE GARANTIE
IMPLICITE
DE QUALITE MARCH AN DE OU D'ADAPTATION A UN USAGE PARTICULIER QUE CE SOIT. DE PLUS, CE PRODUIT EST STRICTEMENT VENDU 00 TEL QUEL "
ET 00 AVEC TOUS SES DEFAUTS EVENTUELS ".
PIONEER N'EST PAS RESPONSABLE DE QUELQUE DOMMAGE CONSECUTIF ET(OU) INDIRECT QUE CE SOIT.
PIONEER NE GARANTIT PAS LES PRODUITS ENUMERES CI-DESSUS LORSQU'ILS SONT UTILISES ADES FINS COMMERCIALES
OU PROFESSIONNELLES, OU AU SEIN
DE TOUTE APPLICATION INDUSTRIELLE OU COMMERCIALE QUE CE SOIT.
LA PRESENTE GARANTIE NE S'APPLIQUE PAS
SI LE PRODUIT A ETE SOUMIS AUNE PUISSANCE NOMINALE EXCEDANT CELLE QUI AETE ETABLIE DANS LES
DOCUMENTS S'Y APPLIQUANT.
LA PRESENTE GARANTIE
NE COUVRE PAS LES TELEVISEURS OU LES ECRANS ENDOMMAGES EN RAISON DE L'APPLICATION D'IMAGES STATIQUES ET IMMOBILES
PENDANT
DE LONGUES PERIODES (IMAGES REMANENTES).
LA PRESENTE GARANTIE
NE COUVRE PAS LE COFFRAGE OU LES ELEMENTS ESTHETIQUES, LES ANTENNES INSTALLEES PAR L'UTILISATEUR, LES DOMMAGES AUX DISQUES
OU AUX RUBANS OU DISQUES D'ENREGISTREMENT, LES DOMMAGES AU PRODUIT DECOULANT D'UNE RETOUCHE, D'UNE MODIFICATION NON AUTORISEE PAR ECRIT
PAR PIONEER, D'UN ACCIDENT, D'UN USAGE INAPPROPRIE
OU D'UN USAGE ABUSIF, LES DOMMAGES PRODUITS PAR LA FOUDRE OU LA SURTENSION, LES DOMMAGES
SUBSEQUENTS DECOULANT
DE FUITES, LES DOMMAGES DECOULANT DE PILES DEFECTUEUSES OU DE L'UTILISATION DE PILES NON CON FORMES ACELLES QUI SONT
SPECIFIEES DANS LE MANUEL
DE L'UTILISATEUR.
LA PRESENTE GARANTIE
NE COUVRE PAS LE COUT DES PIECES OU DE LA MAIN-D'CEUVRE QUI SERAIENT AUTREMENT OFFERTES SANS FRAIS EN VERTU DE LA PRESENTE
GARANTlE,
SI ELLES SONT OBTENUES AUPRES D'UNE SOURCE AUTRE QU'UNE SOCIETE DE SERVICE OU AUTRE AUTORISEE OU DESIGNEE PAR PIONEER. LA PRESENTE
GARANTIE NE COUVRE PAS LES DEFECTUOSITES
OU LES DOMMAGES CAUSES PAR L'UTILISATION D'UNE MAIN-D'CEUVRE OU DE PIECES NON AUTORISEES, NI D'UN
ENTRETIEN INADEQUAT.
LES NUMEROS
DE SERlE MODIFIES, OBLITERES OU ENLEVES ANNULENT LA PRESENTE GARANTIE DANS SA TOTALITE.
INVALADITE DE TOUTE AUTRE GARANTIE
AUX ETATS-UNIS -PIONEER LIMITE SES OBLIGATIONS EN VERTU DE TOUTE GARANTIE IMPLICITE QUE CE SOIT, YCOMPRIS ENTRE AUTRES LES GARANTIES IMPLICITES DE
QUALITE MARCHANDE ou D'ADAPTATION A UN USAGE PARTICULlER, A UNE PERIODE N'EXCEDANT PAS LA PERIODE DE GARANTIE. AUCUNE GARANTIE NE S'APPLIQUE APRES
LA PERIODE DE GARANTIE. CERTAINS ETATS NE PERMETIENT PAS LA LIMITATION DE LA DUREE D'UNE GARANTIE IMPLICITE, ET CERTAINS NE PERMETIENT PAS L'EXCLUSION
OU LA LIMITATION DES DOMMAGES CONSECUTIFS OU INDIRECTS. LES LIMITATIONS ET EXCLUSIONS ETABLIES CI-DESSUS PEUVENT DONC NE PAS S'APPLIQUER A VOUS.
LA PRESENTE GARANTIE VOUS DONNE DES DROITS LEGAUX SPECIFIQUES. VOUS POUVEZ JOUIR D'AUTRES DROITS, QUI PEUVENT VARIER D'UN ETAT AL'AUTRE.
AU CANADA -SOUS RESERVE DE CE QUI EST EXPRESSEMENT STIPVLE DANS LES PRESENTES, AUCUNE REPRESENTATION, GARANTIE, OBLIGATION OU CONDITION,
QU'ELLE SOIT IMPLICITE, OBLIGATOIRE
OU AUTRE, NE S'APPLIQUE A CE PRODUIT.
SERVICE (A L'EXCEPTION DES HAUT-PARLEURS D'AUTO VENOUS SEULEMENT AUX ETATS-UNIS)
PUSA et POC ont designe un certain nombre de societes de service autorisees partout aux Etats-Unis et au Canada si jamais vous avez besoin de services de reparation pour
votre produi!.
Pour profiter du service en vertu de la garantie, vous devez presenter votre releve de caisse ou, si vous louez Ie produit, votre contrat de location indiquant I'endroit
et
la date de la transaction par Ie premier proprietaire. Si vous expediez I'unite, vous devez I'emballer soigneusement et I'envoyer aune societe de service autorisee, en port prepaye
et selon
une methode de transport pouvant etre suivie et assuree. Emballez Ie produit au moyen de materiaux coussines adequats pour eviter les dommages pendant Ie transport.
La
boite d'origine est ideale a celie fin. Incluez votre nom, votre adresse et un numero de telephone ou nous pouvons vous joindre pendant les heures de bureau.
SERVICE (POUR LES HAUT-PARLEURS D'AUTO VENOUS AUX ETATS-UNIS)
Si votre produit necessite une reparation. veuillez Ie retourner avotre marchand pour I'echanger. Pour profiter du service en vertu de la garantie, vous devez presenter votre releve
decaisse indiquant I'endroit et la date de I'achat parIe premierproprietaire. Si, pourune raison ou une autre, vous ne pouvez echanger
Ie produitaupres de votre marchand, communiquez
avec Ie service de Soutien ala clientele au numero ci-dessous.
Pour to utes les plaintes et problemes aux Etats-Unis, communiquez avec Ie service de Soutien ala clientele au 1-800-421-1404. Au Canada, communiquez avec Ie groupe de
Satisfaction de la clientele au 1-877-283-5901.
Pour Ie raccordement ou Ie fonctionnement de votre unite, ou pour trouver une societe de service autorisee, appelez ou ecrivez a:
AUX ETATS-UNIS AU CANADA
CUSTOMER SUPPORT DIVISION DEPARTEMENT DE SERVICE AU CONSOMMATEUR
PIONEER ELECTRONICS (USA) INC. PIONEER ELECTRONIQUES DU CANADA, INC.
P.O. BOX 1760 300 ALLSTATE PARKWAY
LONG BEACH CALIFORNIA 90801 MARKHAM, ON L3R OP2
1-800-421-1404 [phone]
. . 1-877-283-5901
.
hUp:llwww.ploneerelectronlcs.com hUp:llwww.pioneerelectronics.ca
REGLEMENT DES CONFLITS
AUX ET ATS·UNIS -Si un conflit se produit entre vous et Pioneerapres la reponse aune demande initiale faite au service de Soutien alaclientele, vous pouvez avoir recours au Programme
de resolution des plaintes de Pioneer pour resoudre Ie confli!. Ce programme vous est offert sans frais. Vous devez avoir recours au Programme de resolution des plaintes avant
de vous prevaloir de vos droits ou de chercher reparation en vertu du Titre Ide la loi Magnuson-Moss Warranty-Federal Trade Commission Improvement Act, 15 U.S.C. 2301 et
S.S.
Pour avoir recours au Programme de resolution des plaintes, appelez au 1-800-421-1404 et expliquez au representant du service ala clientele qui vous rep'ondra Ie probleme auquel
vous faites face et les demarches
que vous avez entreprises pour faire reparer Ie produit pendant la periode de garantie, puis donnez-Iui Ie nom du distrlbuteurIdetaillant autorise
aupres duquel vous vous €ltes procure Ie produit Pioneer. Une fois que votre plainte a €lIe expliquee au representant, un numero de resolution vous sera communique. Pioneer
etudiera Ie conflit et, dans un delai de quarante (40) jours apres la reception de votre plainte, (1) repondra avotre plainte par ecrit pourvous aviser des demarches qu'elle entreprendra
pourres0l!dre
Ie conflit, etindiqueracombien detemps ces demarches prendront; ou (2) repondra avotre plainte par ecritpour vous indiquerles raisons pourlesquelles elle n'entreprendra
aucune demarche.
AU CANADA - Communiquez avec Ie directeur de la Satisfaction de la clientele au [phone] pour discuter de votre plainte et resoudre rapidement Ie probleme.
ENREGISTREZ LE LIEU ET LA DATE D'ACHAT POUR REFERENCE ULTERIEURE
No. du modele :No. deSerte: _
Dated'achat: Achetede: _
PRENEZ SOIN
DE GARDER CETTE INFORMATION ET VOTRE REl;U D'ACHAT DANS UN ENDROIT SUR POUR REFERENCE FUTURE Imprime
en Chine

PIONEER ELECTRONICS (USA) INC.
R{EMIEI{
PIONEER ELECTRONICS OF CANADA, INC.
LIMITED WARRANTY
WARRANTY VALID ONLY IN COUNTRY OF PRODUCT PURCHASE
WARRANTY
Pioneer Electronics (USA) Inc. (PUSA), and Pioneer Electronics OfCanada, Inc. (POC), warrant that products distributed by PUSA in the U.S.A., and by POC in Canada that fail to function
property undernormal use due
to amanufacturing defectwhen installed and operated a=rding to the owner's manual enclosed with the unit will be repaired or replaced with aunitof comparable
value, at the option of PUSA or POC, without charge
to you for parts or actual repair work. Parts supplied under this warranty may be new or rebuilt at the option of PUSA or POCo
THIS LIMITED WARRANTY APPLIES TO THE ORIGINAL OR ANY SUBSEQUENT OWNER OF THIS PIONEER PRODUCT DURING THE WARRANTY PERIOD PROVIDED THE
PRODUCT WAS PURCHASED FROM AN AUTHORIZED PIONEER DISTRIBUTORIDEALER
IN THE U.S.A. OR CANADA. YOU WILL BE REQUIRED TO PROVIDE ASALES
RECEIPT OR OTHER VALID PROOF OF PURCHASE SHOWING THE DATE OF ORIGINAL PURCHASE OR, IF RENTED, YOUR RENTAL CONTRACT SHOWING THE PLACE
AND DATE OF FIRST RENTAL
IN THE EVENT SERVICE IS REQUIRED, THE PRODUCT MUST BE DELIVERED WITHIN THE WARRANTY PERIOD, TRANSPORTATION PREPAID,
ONLY FROM WITHIN THE COUNTRY OF PURCHASE AS EXPLAINED
IN THIS DOCUMENT. YOU WILL BE RESPONSIBLE FOR REMOVAL AND INSTALLATION OF THE
PRODUCT. PUSA OR POC, AS APPROPRIATE, WILL PAY TO RETURN THE REPAIRED OR REPLACEMENT PRODUCT TO
YOU WITHIN THE COUNTRY OF PURCHASE.
PRODUCT WARRANTY PERIOD
PREMIER Brand Car Electronics Head Units, Amplifiers, CD Changers and Active Crossovers .
PREMIER Brand Loudspeakers ..
parts
2 Years
1 Year
Labor
2 Years
1 Year
The warranty period for retail customers who rent the product commences upon the date product is first put into use (a) during the rental period or (b) retail sale, whichever occurs first.
WHAT IS NOT COVERED
IF THIS PRODUCT WAS PURCHASED FROM AN UNAUTHORIZED DISTRIBUTOR, THERE ARE NO WARRANTIES, EXPRESS OR IMPLIED, INCLUDING THE IMPLIED WARRANTY
OF MERCHANTABILITY AND THE IMPLIED WARRANTY OF FITNESS FOR APARTICULAR PURPOSE AND THIS PRODUCT IS SOLD STRICTLY "AS IS" AND "WITH ALL FAULTS".
PIONEER SHALL NOT BE LIABLE FOR ANY CONSEQUENTIAL AND/OR INCIDENTAL DAMAGES.
PIONEER DOES NOT WARRANT ANY PRODUCT LISTED ABOVE WHEN IT IS USED IN ATRADE OR BUSINESS OR IN ANY INDUSTRIAL OR COMMERCIAL APPLICATION.
THIS WARRANTY
DOES NOT APPLY IFTHE PRODUCT HAS BEEN SUBJECTED TO POWER IN EXCESS OF ITS PUBLISHED POWER RATING.
THIS WARRANTY DOES NOT COVER DISPLAY SCREENS DAMAGED BY STATIC, NON-MOVING, IMAGES APPLIED FOR LENGTHY PERIODS (BURN-IN).
THIS WARRANTY DOES NOT COVER THE CABINET OR ANY APPEARANCE ITEM, USER ATTACHED ANTENNA, ANY DAMAGETO RECORDS OR RECORDING TAPES OR DISCS, ANY
DAMAGE TO THE PRODUCT RESULTING FROM ALTERATIONS, MODlACATIONS NOT AUTHORIZED IN WRmNG BY PIONEER, ACCIDENT, MISUSE OR ABUSE, DAMAGE DUE TO
LIGHTNING OR TO POWER SURGES, SUBSEQUENT DAMAGE FROM LEAKING, DAMAGE FROM INOPERATIVE BATTERIES, OR THE USE OF BATTERIES NOT CONFORMING TO THOSE
SPECIAED IN THE OWNER'S MANUAL.
THIS WARRANTY DOES NOT COVER THE COST OF PARTS OR LABOR WHICH WOULD BE OTHERWISE PROVIDED WITHOUT CHARGE UNDER THIS WARRANTY OBTAINED FROM
ANY SOURCE OTHER THAN A PIONEER AUTHORIZED SERVICE COMPANY OR OTHER DESIGNATED LOCATION. THIS WARRANTY DOES NOT COVER DEFECTS OR DAMAGE CAUSED
BY THE USE OF UNAUTHORIZED PARTS OR LABOR OR FROM IMPROPER MAINTENANCE.
ALTERED, DEFACED,
OR REMOVED SERIAL NUMBERS VOID THIS ENTIRE WARRANTY
NO OTHER WARRANTIES
IN THE U.S.A. - PIONEER LIMITS ITS OBLIGATIONS UNDER ANY IMPLIED WARRANTIES INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF
MERCHANTABILITY AND FITNESS FOR APARTICULAR PURPOSE, TO APERIOD NOT TO EXCEED THE WARRANTY PERIOD. NO WARRANTIES SHALL APPLY AFTER THE
WARRANTY PERIOD. SOME STATES
DO NOT ALLOW LIMITATIONS ON HOW LONG AN IMPLIED WARRANTY LASTS AND SOME STATES DO NOT ALLOW THE EXCLUSIONS
OR LIMITATIONS OF INCIDENTAL OR CONSEQUENTIAL DAMAGES, SO THE ABOVE LIMITATIONS OR EXCLUSIONS MAY NOT APPLY TO YOU. THIS WARRANTY GIVES
YOU SPECIFIC LEGAL RIGHTS AND YOU MAY HAVE OTHER RIGHTS WHICH MAY VARY FROM STATE TO STATE.
IN CANADA-EXCEPT AS EXPRESSLY PROVIDED HEREIN, THERE ARE NO REPRESENTATIONS, WARRANTIES, OBLIGATIONS OR CONDITIONS, IMPLIED, STATUTORY
OR OTHERWISE,
APPLICABLE TO THIS PRODUCT.
TO OBTAIN SERVICE (EXCEPT CAR SPEAKERS SOLD IN THE U.S.A. ONLY)
PUSA and POC have appointed anumber of Authorized Service Companies throughout the U.S.A. and Canada should your product require service. To receive warranty service
you need to present your sales receipt or, if rented, your rental contract showing place and date
of original owner's transaction. If shipping the unit you will need to package
it carefully and send it, transportation prepaid by atraceable, insured method, to an Authorized Service Company. Package the product using adequate padding material to
prevent damage in transit. The original container is ideal for this purpose. Include your name, address and telephone number where you can
be reached during business hours.
TO OBTAIN SERVICE ON CAR SPEAKERS SOLD IN THE U.S.A.
Should your car speaker require service please return it to your retail dealer for exchange. To receive warranty service you will need to present your sales receipt showing
place and date
of original owner's retail purchase. If, for any reason, you can not exchange speakers at the selling dealer call Customer Support at the number below.
On all complaints and concerns in the U.S.A. call Customer Support at 1-800-421-1404, or, in Canada, call Customer Satisfaction at 1-877-283-5901.
IN THE U.S.A. IN CANADA
For hook-up and operation of your unit or to locate an For additional information on this warranty,
Authorized Service Company, please call or write: please call or write:
CUSTOMERSUPPORTDIVISION CUSTOMER SATISFACTION GROUP
PIONEER ELECTRONICS (USA) INC. PIONEER ELECTRONICS OF CANADA, INC.
POBOX 1760 300 ALLSTATE PARKWAY
LONG BEACH' CALIFORNIA 90801 MARKHAM, ON L3R OP2
1-800-421-1404 [phone]
1-877 -283-5901
http://www . pionee rei ectro nics .com http://www.pioneerelectronics.ca
DISPUTE RESOLUTION
IN THE U.S.A. -Following our response to any initial request to Customer Support, should adispute arise between you and Pioneer, Pioneer makes available its Complaint
Resolution Program to resolve the dispute. The Complaint Resolution Program is available to you without charge. You are required to use the Complaint Resolution Program
before you exercise any rights under, or seek any remedies, created by Title Iof the Magnuson-Moss Warranty·Federal Trade Commission Improvement
Act, 15 U.S.C. 2301 et seq.
To use the Complaint Resolution Program call 1-800-421-1404 and explain to the customer service representative the problem you are experiencing, steps you have taken
to have the product repaired during the warranty period and the name of the authorized Distributor/Dealer from whom the Pioneer product was purchased. After the complaint
has been explained to the representative, aresolution number will be issued. Within 40 days of receiving your complaint, Pioneer will investigate the dispute and will either:
(1) respond to your complaint in writing informing you what action Pioneer will take, and in what time period, to resolve the dispute; or (2) respond to your complaint in writing
informing you why it will not take any action.
IN
CANADA -Call the Customer Satisfaction Manager at [phone] to discuss your complaint and to obtain aprompt resolution.
RECORD THE PLACE AND DATE OF PURCHASE FOR FUTURE REFERENCE
Model No.
Purchased From
.Serial No. Purchase Date . _
KEEP THIS INFORMATION AND YOUR SALES RECEIPT IN ASAFE PLACE <
CRY1070-D/U >
Printed in China
