Pioneer AVIC-D3 - Navigation System With DVD Player User manual

Hardware buttons
(1) Disc loading slot
(2) EJECT button
(3) MENU button
(4) MAP button
(5) VOLUME knob
Turn to adjust the AV (Audio
and Video) volume or press
to change the AV source.
Press and hold the VOLUME
knob to switch the source to
mute.
DVD MULTIMEDIA AV NAVIGATION SERVER
AVIC-D3
AVIC-D3
Quick Start Guide
This guide is intended to guide you through the basic
functions of this navigation system. For details, please
refer to the Operation Manual provided with the product.
Published by Pioneer Corporation.
Copyright © 2007 by Pioneer Corporation. <CRB2327-A/U> UC
All rights reserved. MAN-AVIC-D3-QSG-EN
<KMZZX> <06K00001> Printed in China
(6)
(2)
(3)
(4)
(5)
Search function overview
This navigation system has multiple methods for entering your des-
tination.
(1) (4) (5)
(6) (7) (8) (9)
(3)
(2)
Switching the screen
Press the following buttons and touch keys to display the respective
screens.
(1)
(6) /
Pressing this button when
the AV source is selected
skips a track, file or chapter.
Press and hold to fast for-
ward/fast reverse a track,
file or chapter.
1Display the [NAVI MENU].
2Touch the Destination tab
and then touch Address
Search.
3Input the house number
and then touch OK.
4Input the street name.
5Select the street name
from the list.
If the list screen for city or
area is displayed, touch the
city or area where your desti-
nation is located.
When route calculation is com-
pleted, navigation guidance
begins.
6Begin driving in accor-
dance with navigation
guidance.
This navigation systems gives
you route guidance both visually
and by voice.
Searching for your destination by
address
(1) Search by address
(2) Shortcut key for home
address
(3) Shortcut key for favorite des-
tination
(4)
Search for stores, restaurants,
and other businesses in the
points of interest database
(5) Search for stores, restaurants,
and other businesses in your
vicinity
Search result list for vicinity
search
(6) Select a destination from
your address book
(7) Select a previously routed
destination
(8) Select a route to a freeway
entrance or exit
(9) Search for a destination by
business telephone number
[AV operation screen] [AV MENU]
[NAVI MENU][MAP screen]

Selecting the AV source
Touch the AV source icon to select the desired AV source.
Basic operation on the map screen
Switching the view mode
Scrolling the map
Zoom in or zoom out
Touch or .
(1)Direct scale change
(2)Gradual scale change
Touch and hold where you would
like to scroll to on the map
screen. After a few seconds, the
scrolling will begin.
Press the MAP button on the
map screen.
This navigation system allows
you to select different view
modes depending on your pref-
erence.
(2)(1)
Operation of AV operation screens
(2)
(1)
Playing your Apple iPod
®
You can control an iPod by connecting the iPod cable (CD-I200)
(sold separately) to the navigation system.
Playback of music sources
1Display the [AV MENU].
2Touch the iPod icon to display the iPod source screen.
(1)Touch one of the categories
in which you want to search
for a song.
(2)Touch to display the video
screen.
(3)Touch keys to operate the
music source.
Playback of video sources
Change the video setting on the iPod so that the iPod can output
the video to an external device, before you display the video screen.
For details concerning setting and operation, refer to the iPod’s
owner’s manual.
1Display the iPod source screen.
2Touch VIDEO to display the video screen.
In the video screen, control operations with the iPod’s buttons.
(1)Touch keys to operate the
video source.
(2)Touch to display the music
screen.
(1)
(2)
(1) (2)
(3)
CD source screen Touch keys

Playback and Pause
/
CD:Skip the track forward or
backward
DVD:Skip the chapter forward or
backward

DVD:Stop playback
DVD-V source screen
Touch the screen to display touch
keys, when you play the DVD-Video.
RADIO source screen
Up/Down
Switch the radio station
Seek/Seek
Seek tuning (keep touching for
about one second and release).
Band
Switch between bands:
FM1–FM2–FM3–AM
Detail
Switch to the Detail information
display.
Setting the voice guidance volume
Touch the Settings tab in
[NAVI MENU] and then touch
Volume.
(1)AV source icon
• DISC [CD, ROM, DVD-V,
DivX]
• RADIO [Tuner]
• iPod [iPod]
• XM [XM tuner]
• SIRIUS [SIRIUS tuner]
• BT-TEL [Bluetooth-Telephone]
• BT-AUDIO [Bluetooth-Audio]
• M-CD [Multi-CD player]
(2)OFF [Switch the source off]
In the AV operation screen or the source off screen, press the
MENU button to display [AV MENU].
