Operation Manual
Vehicle Dynamics Processor
AVG-VDP1
English DeutschEspañol

Thank you for buying this Pioneer product.
Please read through these operating instructions so you will know how to operate
your model properly. After you have finished reading the instructions, keep this man-
ual in a safe place for future reference.
Precautions
IMPORTANT SAFE UARDS 3
To ensure safe driving 4
Before You Start
About this unit 5
About this manual 5
In case of trouble 5
Resetting the microprocessor 6
Basic Operations
Displaying the V.D.P. image 7
Demonstration mode 7
Touch panel key basic operation 8
Selecting a mode 9
Selecting gauges 12
Using a peak hold function 13
Customizing the ppearance
Introduction of appearance settings 14
Selecting the background display 14
Selecting the colors 14
Switching the indicators on or off 15
Setting the level indicator 16
Setting the distance alert 17
Selecting the vehicle type 17
Customizing the graph 17
Performing a Run
Introduction of the running record
functions 18
Recording your runs 18
Replaying stored running records 19
Editing the list names 19
Deleting a stored running record 19
Deleting all stored running records 20
GPS Locator
Introduction of PS locator operation 21
Setting the destination 21
Registering locations 22
Checking the Vehicle Dynamics
Processor Status
Introduction of information functions 25
Checking your records 25
Checking the connections of cables and the
installation positions 26
Checking the sensor learning status and the
driving status 26
Setup adjustments
Introduction of setup adjustments 28
Setting the volume level 28
Calibrating the RPMs 28
Setting your vehicle weight 28
Setting units and scales 29
Selecting your area 29
Selecting language 29
Setting the clock 30
Setting RPM alert 30
Setting speed alert 30
Selecting the video format 30
dditional Information
Troubleshooting 31
Error messages 31
Positioning technology 32
Handling large errors 33
Terms 34
Specifications 34
Contents
En
2

IMPORTANT SAFEGUARDS
Before using your Vehicle Dynamics Pro-
cessor, be sure to read and fully understand
the following safety information.
1Read this manual fully and carefully be-
fore operating your Vehicle Dynamics
Processor.
2Keep this manual handy as a reference for
operating procedures and safety informa-
tion.
3Pay close attention to all warnings in this
manual and follow the instructions care-
fully.
4Do not allow other persons to use this sys-
tem until they have read and understood
the operating instructions.
5Do not install the display where it may (i)
obstruct the drivers vision, (ii) impair the
performance of any of the vehicles oper-
ating systems or safety features, includ-
ing air bags, hazard lamp buttons or (iii)
impair the drivers ability to safely oper-
ate the vehicle.
6s with any accessory in your vehicles in-
terior, the display should not divert your
attention from the safe operation of your
vehicle. If you experience difficulty in op-
erating the system or reading the display,
please park safely before making adjust-
ments.
7Do not attempt to install or service your
Vehicle Dynamics Processor by yourself.
Installation or servicing of the Vehicle Dy-
namics Processor by persons without
training and experience in electronic
equipment and automotive accessories
may be dangerous and could expose you
to the risk of electric shock or other ha-
zards and can cause damage to the sys-
tem that is not covered by warranty.
8Please remember to wear your seat belt at
all times while operating your vehicle. If
you are ever in an accident, your injuries
can be considerably more severe if your
seat belt is not properly buckled.
9To promote safety, certain functions are
disabled unless the parking brake is ap-
plied.
10 The Data Recording functionality of this
product is intended to capture vehicle in-
formation into its internal memory to be
reviewed at a later time when the vehicle
is not in motion, and parked in a safe
place. Only use the Data Recording func-
tionality if it is safe to do so. Do not use
this feature if doing so in any way will di-
vert your attention from the safe operation
of your vehicle. lways observe safe driv-
ing rules and follow all existing traffic reg-
ulations.
11 The GPS Locator functionality utilizes the
GPS and Gyrosensor in the VG-VDP1 to
provide information about your current lo-
cation. It is not intended to be any kind of
guidance or navigation device.
Precautions
En 3
English
Section
01

To ensure safe driving
W RNING
!LIGHT GREEN LE D T POWER CON-
NECTOR IS DESIGNED TO DETECT
P RKED ST TUS ND MUST BE CON-
NECTED TO THE POWER SUPPLY SIDE
OF THE P RKING BR KE SWITCH. IM-
PROPER CONNECTION OR USE OF
THIS LE D M Y VIOL TE PPLIC BLE
L W ND M Y RESULT IN SERIOUS IN-
JURY OR D M GE.
!Always observe safe driving rules and follow
all applicable traffic laws. Do not use the fea-
tures of this unit if conditions are unsafe. Al-
ways use proper care, judgment and
attentiveness when driving.
!To avoid the risk of accident and the potential
violation of applicable laws, certain functions
of this unit should never be used while the ve-
hicle is being driven. Also, rear displays
should not be in a location where it is a visible
distraction to the driver.
!In some countries or states the viewing of
images on a display inside a vehicle even by
persons other than the driver may be illegal.
Where such regulations apply, they must be
obeyed.
When using a video recorder
connected to VIDEO OUT
Through this unitsVIDEO OUT enables you to
record on a video recorder.
!In the following cases, images may not be
displayed properly on the display/VCR:
When not displaying the V.D.P. image
outputted from this unit on the front dis-
play. (Refer to Displaying the V.D.P.
image on page 7.)
When connecting the display/VCR
which has incompatible video output
format with this unitsVIDEO OUT.
(Refer to Selecting the video format on
page 30.)
Precautions
En
4
Section
01

A out this unit
This Vehicle Dynamics Processor features a
variety of entertainment functions enabling
you to maximize your enjoyment while driving.
W RNING
!Indications of this unit may be different
from the actual value, so never use this
unit instead of the meters of your vehicle.
!For safety reasons, certain functions of
this unit are not available while driving.
To enable these functions, you must park
the vehicle in a safe place and apply the
parking brake before operating these
functions.
C UTION
Do not allow this unit to come into contact with li-
quids. Electrical shock could result. Also, this
unit damage, smoke, and overheat could result
from contact with liquids.
Features
Touch panel key operation
It is possible to operate this unit by using
touch panel key.
Vehicle dynamics displays
It is possible to display five enhanced modes
from analog to vehicle status.
GPS Locator
It is possible to show the current location of
your vehicle and also register your favorite lo-
cations.
Replay memory
It is possible to record your runs and replay it.
Cause of incorrect indications
!Tachometer and torque meter of this unit
cannot work if you do not perform the RPM
calibration. And also, the other meters can-
not work properly.
!In the following cases, the indications of
this unit are different from the actual value:
Speedometer, accelerometer and horse-
power meter do not work properly while
the vehicle is wheel-spinning.
Tiltmeter does not work properly when
the vehicle is accelerating with the
wheel-spinning.
Lateral accelerometer does not work
properly while the vehicle is donut-turn-
ing or power-sliding.
Speedometer and tiltmeter do not work
properly while the brake is locked.
A out this manual
This unit features a number of sophisticated
functions ensuring superior reception and op-
eration. All the functions have been designed
for the easiest possible use, but many are not
self-explanatory. This operation manual will
help you benefit fully from this units potential
and to maximize your listening enjoyment.
We recommend that you familiarize yourself
with the functions and their operation by read-
ing through the manual before you begin
using this unit. It is especially important that
you read and observe W RNINGs and C U-
TIONs in this manual.
In case of trou le
Should this product fail to operate properly,
contact your dealer or nearest authorized Pio-
neer Service Station.
Before You Start
En 5
English
Section
02

Resetting the microprocessor
Pressing RESET lets you reset the micropro-
cessor to its initial settings without changing
memory except session records.
The microprocessor must be reset under the
following conditions:
!Prior to using this unit for the first time
after installation
!If the unit fails to operate properly
!When strange or incorrect messages ap-
pear on the display
%Press RESET with a pen tip or other
pointed instrument.
RESET button
Note
When you want to erase all memorized settings
or return the unit to its factory settings, discon-
nect the yellow and red leads for a few days.
Before You Start
En
6
Section
02

Displaying the V.D.P. image
You can display the V.D.P. (Vehicle Dynamics
Processor) image on the display.
%Press V.ADJ on the display unit to
switch the display to the V.D.P. image.
#If the C UTION screen is displayed, be sure
to read though the caution. And then touch O
to confirm it.
#You can select a language for the C UTION
screen and keyboard. (Refer to Selecting language
on page 29.)
#To return to the video of sources, press V.ADJ
again.
#Depending on the display unit, this function is
operable with NAVI/AV or MENU button instead
of V.ADJ button.
When using this unit for the
first time
When using this unit for the first time or after
resetting it, the following modes may appear:
1 Operation setting mode
2 Area setting mode
3 Language setting mode
4C UTION screen
1 Touch Normal to use this unit normally.
Refer to Demonstration mode on this page.
#To turn the demonstration mode on, touch
Demo.
2 Select your area.
Refer to Selecting your area on page 29.
3 Select a desired language.
Refer to Selecting language on page 29.
4 Touch O after confirming the caution.
Sensor Learning.... appears on the display
and means that sensor initialization is not
complete. Until sensor initialization is finished
completely, all of the recording functions of
this unit cannot be used.
!The C UTION screen is the important in-
formation for using this unit safely and
properly. Be sure to read through the cau-
tion before using this unit.
!Perform the RPM calibration before using
this unit. (Refer to Calibrating the RP s on
page 28.)
Demonstration mode
If you do not perform an operation within
about five minutes, the animations start auto-
matically.
!Because demonstration mode is the func-
tion for displaying at stores, do not use this
function while driving.
%To turn demonstration mode off, turn
the ignition switch OFF and ON and then
touch Normal in operation setting mode.
Basic Operations
En 7
English
Section
03

Touch panel key asic
operation
Activating the touch panel keys
1
3
4
2
5
6
7
8
9
1Mode key
Touch to select a desired mode. (Refer to Se-
lecting a mode on the next page.)
2Select Gauge key
Touch to select desired gauges. (Refer to Se-
lecting gauges on page 12.)
3Peak Hold key
Touch to control a peak hold function.
(Refer to Using a peak hold function on page
13.)
4Save Loc. key
Touch to register the current location of
your vehicle. (Refer to Registering the cur-
rent location on page 22.)
5REC key
Touch to record your runs. (Refer to Record-
ing your runs on page 18.)
6Replay key
Touch to replay the stored runs. (Refer to Re-
playing stored running records on page 19.)
7Display key
Touch to select functions for each mode.
8Menu key
Touch to select various setup functions.
9ESC key
Touch to hide the touch panel keys.
1 Touch the screen to activate the touch
panel keys corresponding to each mode.
The touch panel keys appear on the display.
2 Touch ESC to hide the touch panel keys.
Operating the menu
1
3
2
5
6
4
1LOC key
Touch to display PS locator functions
quickly.
2INFO key
Touch to display information functions
quickly.
3SETUP key
Touch to display setup functions quickly.
4/keys
Touch to cycle through all of the functions.
5Back key
Touch to return to the previous display.
Basic Operations
En
8
Section
03

6ESC key
Touch to cancel the control mode of func-
tions.
1 Touch Menu to display Menu.
Menu appears on the display.
#When Menu is not displayed, you can display
it by touching the screen.
2 Touch the desired key to display the
function names you want to operate.
#Touch or to switch between the lists of
names.
3 Touch ESC to return to the normal dis-
play of each mode.
Selecting a mode
You can select a mode you want to display.
%Touch Mode and then touch the desired
mode name.
There are the following five modes:
!Analog Analog mode
!Digital Digital mode
!Cyber Cyber mode
!Virtual Virtual mode
!V.Status Vehicle status mode
Analog mode
1
2
3
You can customize the gauges and the back-
ground.
!To select the different types of gauges, refer
to Selecting gauges on page 12.
!To control a peak hold function, refer to
Using a peak hold function on page 13.
!To customize the colors of gauge, refer to
Selecting the colors on page 14.
!To select the background, refer to Selecting
the background display on page 14.
1Accelerometer (ACC.G)
Shows the acceleration in a forward direc-
tion. The + sign indicates acceleration
while the sign indicates deceleration
(braking).
2Speedometer (SPEED)
Shows your vehicle speed.
3Tachometer (TACH)
Shows the engine speed in revolutions per
minute (rpm).
Digital mode
1
3
4
2
5
b
c
8
6
a
9
7
You can customize the gauges and the back-
ground.
!To control a peak hold function, refer to
Using a peak hold function on page 13.
!To customize the colors of gauge, refer to
Selecting the colors on page 14.
Basic Operations
En 9
English
Section
03

!To select the background, refer to Selecting
the background display on page 14.
!To turn the various indicators on or off,
refer to Switching the indicators on or off on
page 15.
1Horsepower (POWER)
Shows the horsepower calculated minus all
possible losses such as drivetrain, rolling re-
sistance, and aerodynamic drag. Therefore,
this horsepower value becomes lower than
engine horsepower or wheel horsepower.
2Slope (SLOPE)
Shows the slope of your vehicle.
3Tachometer (TACH)
Shows the engine speed in revolutions per
minute (rpm).
4Speedometer (SPEED)
Shows your vehicle speed.
5Acceleration (ACC.G)
Shows the acceleration in a forward direc-
tion. The + sign indicates acceleration
while the sign indicates deceleration
(braking).
6Torque (TORQUE)
Shows the torque, the twisting force pro-
duced at the heart of the engine.
7Voltage (BATT.)
Shows the battery voltage.
8Angular velocity (ANG.V)
Shows the turning speed of your vehicle.
9Longitude and latitude (LON./LAT.)
Shows the longitude and latitude of the cur-
rent location of your vehicle.
aCompass
Shows the direction your vehicle is travel-
ling.
bLateral acceleration (LAT.G)
Shows the acceleration in the lateral direc-
tion.
cTime (TIME)
Shows the current time.
Cy er mode
1
7
3
c
6
a
8
2
4
5
b
9
9
You can turn the various indicators on or off.
(Refer to Switching the indicators on or off on
page 15.)
1Distance to the destination
Shows the straight distance between the
destination and the current location.
2Slope (SLOPE)
Shows the slope of your vehicle.
3Direction line
Shows the direction towards the destina-
tion.
4Destination name
Shows the name of the destination stored in
this unit.
Basic Operations
En
10
Section
03

!If the destination name is not stored, the
longitude and latitude of the destination
is displayed.
5Compass
Shows the direction your vehicle is travel-
ling.
6Time (TIME)
Shows the current time.
7Voltage (BATT.)
Shows the battery voltage.
8Tachometer (TACH)
Shows the engine speed in revolutions per
minute (rpm).
9Lateral acceleration (LAT.G)
Shows the acceleration in the lateral direc-
tion.
aLongitude and latitude (LON./LAT.)
Shows the longitude and latitude of the cur-
rent location of your vehicle.
bAcceleration (ACC.G)
Shows the acceleration in a forward direc-
tion. The + sign indicates acceleration
while the sign indicates deceleration
(braking).
cSpeedometer (SPEED)
Shows your vehicle speed.
Virtual mode
1
5
2
8
4
7
6
3
In the virtual mode, there are three different
types of display: Virtual country, virtual desert
and virtual city.
You can turn the various indicators on or off.
(Refer to Switching the indicators on or off on
page 15.)
1Distance to the destination
Shows the straight distance between the
destination and the current location.
2Direction arrow
Shows the direction towards the destina-
tion.
3Destination name
Shows the name of the destination stored in
this unit.
!If the destination name is not stored, the
longitude and latitude of the destination
is displayed.
4Time (TIME)
Shows the current time.
5Altitude (ALTI.)
Shows the altitude of the current location.
!The altitude can be indicated from 0 to
4000 m.
Basic Operations
En 11
English
Section
03

6Compass
Shows the direction your vehicle is travel-
ling.
7Longitude and latitude (LON./LAT.)
Shows the longitude and latitude of the cur-
rent location of your vehicle.
8Speedometer (SPEED)
Shows your vehicle speed.
Vehicle status mode
1
3
5
2
4
You can customize the graph and the back-
ground.
!To customize the graph, refer to Customiz-
ing the graph on page 17.
!To select the background, refer to Selecting
the background display on page 14.
1Graph
Shows the graph of speed vs time.
2Time (TIME)
Shows the current time.
3Speedometer (SPEED)
Shows your vehicle speed.
4Tachometer (TACH)
Shows the engine speed in revolutions per
minute (rpm).
5Acceleration (ACC.G)
Shows the acceleration in a forward direc-
tion. The + sign indicates acceleration
while the sign indicates deceleration
(braking).
Selecting gauges
You can change the combination of gauges.
!This function can be operated only when
selecting the analog mode.
1 Touch Select Gauge.
The touch panel keys for selecting the gauges
are displayed.
#When Select Gauge is not displayed, you can
display it by touching the screen.
2 Touch the middle of a gauge that you
want to change.
The cursor moves to the selected gauge.
3 Touch ior jto select the gauge type.
Each time you touch ior jselects the
gauge types in the following order:
TACH (tachometer)BATT. (voltmeter)
ACC.G (accelerometer)LAT.G (lateral ac-
celerometer)POWER (horsepower meter)
TORQUE (torque meter)tiltmeterSPEED
(speedometer)
4 Touch kor lto switch among the po-
sition of the gauges.
Basic Operations
En
12
Section
03

5 Touch ESC to return to the normal dis-
play of each mode.
#To return to the previous display, touch
Back.
Using a peak hold function
With this unit, the peak hold value will be auto-
matically stored in memory. And you can re-
call the maximum value reached for each
parameter in memory.
!This function can be operated when select-
ing the analog and the digital modes.
1 Touch Peak Hold.
The maximum value reached for each para-
meter will be displayed.
#When Peak Hold is not displayed, you can
display it by touching the screen.
2 Touch the screen to display the touch
panel keys.
The touch panel keys appear in the display.
#To reset the peak hold value, touch Reset.
#To hide the touch panel keys, touch Hide ey.
3 Touch ESC to return to the normal dis-
play of each mode.
#To return to the previous display, touch Back.
Note
In the analog mode, you can also change the
combination of gauges by touching i/j/k/
l.
Basic Operations
En 13
English
Section
03

Introduction of appearance
settings
1
Appearance settings lets you customize the
appearance of each mode.
1Function display
Shows the function names.
%Touch Display to display the function
names.
The function names are displayed.
#When Display is not displayed, you can dis-
play it by touching the screen.
#To cycle through all of the functions, touch
or .
#To return to the previous display, touch Back.
#To return to the normal display of each mode,
touch ESC.
Selecting the ackground
display
You can select the background display sepa-
rately for each mode.
!This function cannot be operated when se-
lecting the cyber mode.
1 Touch Display and then touch
Background.
2 Touch Background to select the desired
background display.
Each time you touch Background it selects
background displays in the following order:
nalog, digital and vehicle status modes
Movie1 (movie 1)Movie2 (movie 2)
Picture1 (picture 1)Picture2 (picture 2)
Picture3 (picture 3)
Virtual mode
Desert (desert)Country (country)City
(city)
Selecting the colors
You can select the color of the gauges; gauge
ring and gauge face, etc.
!These functions can be operated when se-
lecting the analog and the digital modes.
Selecting the gauge ring color
1 Touch Display and then touch
Gauge Ring.
2 Touch Gauge Ring to select the desired
color.
Each time you touch Gauge Ring it selects
colors in the following order:
Red (red)Blue (blue)Yellow (yellow)
White (white)Orange (orange)
Selecting the gauge face color
1 Touch Display and then touch
Gauge Face.
2 Touch Gauge Face to select the desired
color.
Each time you touch Gauge Face it selects
colors in the following order:
Customizing the
Appearance
En
14
Section
04

Black (black)White (white)Blue (blue)
Carbon (carbon)Titanium (titanium)
Twilight (twilight)
Selecting the gauge text color
1 Touch Display and then touch
Gauge Text.
2 Touch Gauge Text to select the desired
color.
Each time you touch Gauge Text it selects
colors in the following order:
Red (red)Black (black)Blue (blue)
Orange (orange)Yellow (yellow)White
(white)
Selecting the gauge needle color
!This function can be operated only when
selecting the analog mode.
1 Touch Display and then touch
Gauge Needle.
2 Touch Gauge Needle to select the de-
sired color.
Each time you touch Gauge Needle it selects
colors in the following order:
Red (red)White (white)Black (black)
Blue (blue)Orange (orange)Yellow
(yellow)
Setting the graph properties
You can select the visual-effect method of the
graph bar.
!This function can be operated only when
selecting the digital mode.
1 Touch Display and then touch
Graph Properties.
2 Touch Graph Properties to select the
graph properties.
Touch Graph Properties to switch between
Indicator and Colorful.
!Indicator Indicate graph bars with the
same color as the gauge text
!Colorful Indicate graph bars with the
multiple color
Switching the indicators on
or off
You can turn on or off the various indicators;
the longitude/latitude and the compass, etc.
Turning the longitude and
latitude indicator on or off
This unit can display the longitude and lati-
tude of the current location of your vehicle
using PS locator. You can turn the longitude
and latitude indicator on or off.
!This function can be operated when select-
ing the digital, cyber and the virtual modes.
!This unit uses W S 84 of the world geode-
tic system. (Refer to page 34.)
1 Touch Display.
2 Touch LON./LAT. to turn the longitude
and latitude indicator on or off.
Turning the compass indicator
on or off
This unit can display the compass showing
the direction your vehicle is travelling. You can
turn the compass indicator on or off.
!This function can be operated when select-
ing the digital, cyber and the virtual modes.
1 Touch Display.
Customizing the
Appearance
En 15
English
Section
04

2 Touch Compass to turn the compass in-
dicator on or off.
#When Compass is not displayed, you can dis-
play it by touching or .
Turning the time indicator on
or off
The current time is displayed based on the
time difference between the time originally set
in this unit and the current location of your ve-
hicle.
!This function can be operated when select-
ing the cyber and the virtual modes.
!To adjust the time difference, refer to Set-
ting the clock on page 30.
1 Touch Display.
2 Touch Clock to turn the clock indicator
on or off.
Turning the destination
indicators on or off
You can turn on or off the following indicators:
Distance to the destination, Destination name
and Direction line. These indicators are dis-
played only when the destination has been
set.
!This function can be operated when select-
ing the cyber and the virtual modes.
1 Touch Display.
2 Touch Destination to turn the destina-
tion indicators on or off.
Turning the altitude indicator
on or off
This unit can display the altitude of the current
location of your vehicle using PS locator. You
can turn the altitude indicator on or off.
!This function can be operated only when
selecting the virtual mode.
1 Touch Display and then touch twice.
2 Touch Altitude to turn the altitude indi-
cator on or off.
Setting the level indicator
The level indicator is the motion display inter-
locked with music signal level. You can turn
the motion display on or off. In addition, you
can select the level indicator color.
!These functions can be operated only when
selecting the cyber mode.
Setting the level indicator color
1 Touch Display and then touch Indicator.
2 Touch Indicator to select the desired
color.
Each time you touch Indicator it selects col-
ors in the following order:
Blue (blue)Colorful (colorful)Off (off)
Setting the motion of the level
indicator
1 Touch Display.
2 Touch Sound Motion to turn the motion
display on or off.
Customizing the
Appearance
En
16
Section
04

Setting the distance alert
When you pass the intervals you set, this unit
sounds a beep and displays your travel dis-
tance.
!This function can be operated only when
selecting the virtual mode.
1 Touch Display.
2 Touch Distance Alert to select the de-
sired interval.
Each time you touch Distance Alert it selects
intervals in the following order:
Off (off)2km5km10km50km
100km
Note
The unit of distance can be switched between
miles and kilometers. (Refer to Setting units and
scales on page 29.)
Selecting the vehicle type
You can select the vehicle type displayed in
the virtual mode.
!This function can be operated only when
selecting the virtual mode.
1 Touch Display and and then touch
Vehicle Type.
2 Touch Vehicle Type to select the desired
vehicle type.
Each time you touch Vehicle Type it selects
vehicle types in the following order:
Vehicle A (vehicle A)Vehicle B (vehicle B)
Vehicle C (vehicle C)Vehicle D (vehicle D)
Vehicle E (vehicle E)Vehicle F (vehicle F)
Vehicle G (vehicle )
Customizing the graph
You can customize the graph as desired.
!These functions can be operated only when
selecting the vehicle status mode.
Selecting the graph pattern
You can switch the graph pattern between line
graph and area graph.
1 Touch Display.
2 Touch Pattern to select the desired
graph pattern.
Each time you touch Pattern it selects graph
patterns in the following order:
Line (line)Area (area)
Selecting the graph data
1 Touch Display.
2 Touch Data to select the desired graph
data.
Each time you touch Data it selects graph
data in the following order:
Speed (speed)R"P"M(RPM)ACC.G (ac-
celeration)LAT.G (lateral acceleration)
Power (power)Torque (torque)
Selecting the scale of graph
1 Touch Display.
2 Touch Scale to select the desired scale.
Each time you touch Scale it selects scales of
graph in the following order:
30sec (30 sec.)60sec (60 sec.)2.5min (2.5
min.)5.0min (5.0 min.)
Customizing the
Appearance
En 17
English
Section
04

Introduction of the running
record functions
4
2
1
3
W RNING
The Data Recording functionality of this pro-
duct is intended to capture vehicle informa-
tion into its internal memory to be reviewed
at a later time when the vehicle is not in mo-
tion, and parked in a safe place. Only use the
Data Recording functionality if it is safe to
do so. Do not use this feature if doing so in
any way will divert your attention from the
safe operation of your vehicle. lways ob-
serve safe driving rules and follow all exist-
ing traffic regulations.
You can record throughout your runs (vehicles
behaviour). After you have recorded your runs
you can replay the desired running record.
1Time
Shows the recording time of the selected
running record.
2Name
Shows the name of the selected running re-
cord.
3Record number
Shows the number of the selected running
record.
4Function display
Shows the function names.
%Touch Replay and then touch your fa-
vorite list name.
The function names are displayed.
#When Replay is not displayed, you can dis-
play it by touching the screen.
#To return to the previous display, touch Back.
#To return to the normal display of each mode,
touch ESC.
Recording your runs
Your running records can be memorized in
this unit. Up to five minutes each and up to 12
records can be stored.
!While Sensor Learning.... appears, this
function cannot be used. If your vehicle is
driven for a little while, Sensor Learning....
will disappear.
1 Touch REC and then touch Yes to start
recording your run.
The recording time is displayed, the recording
begins.
#When REC is not displayed, you can display it
by touching the screen.
#When 12 records have been already stored,
MEMORY FULL is displayed.
#To cancel the recording, touch No.
2 Touch the screen and then touch Stop
to stop the recording.
Recording Complete is displayed briefly and
your running record is memorized in this unit.
#If the recording time exceeds five minutes, a
message is displayed. Touch O and end the re-
cording.
#To cancel the recording, touch Cancel.
Performing a Run
En
18
Section
05

Replaying stored running
records
You can replay your running records. In addi-
tion, you can control playbacks; play and
pause, etc.
1 Touch Replay and your favorite list
name and then touch Replay.
Replay of the selected records begins.
#If there are no records in the memory,
MEMORY EMPTY is displayed.
2 Touch the screen to display the touch
panel keys.
Touch panel keys for playback control are dis-
played.
!gTouch to stop playback and to return to
the start of the record
!mKeep touching to rewind
!qTouch to move back one frame at a
time
!fTouch to switch sequentially be-
tween playback and pause play
!rTouch to move ahead one frame at a
time
!nKeep touching to perform fast for-
ward playback
#To hide the touch panel keys, touch ESC.
3 Touch Exit to exit the replay mode.
Note
Vehicle status mode graphs the consecutive
changes of data. Therefore, do not operate the
display switching such as the mode switching
and the graph scale switching while replaying a
running record in the vehicle status mode. If you
perform these operations and return to the vehi-
cle status mode, the graph may not appear dis-
play properly.
Editing the list names
You can edit list names. This function lets you
input the list names up to 20 letters long.
1 Touch Replay and then touch the list
name that you want to edit the name.
2 Touch Edit Information.
3 Enter a new name.
Touch the letter you want to enter.
#To delete the entered text, touch .
#To switch the character type, use Symbol,0-9
and Other.
!Symbol Touch to display symbols such as
& and +
!0-9 Touch to display numbers
!Other Touch to display European letters,
such as those with accents (e.g. á, à, ä, ç)
#Other appears only when selecting the lan-
guage including European letters. (Refer to Se-
lecting language on page 29.)
4 Touch Save to store the entered name
in memory.
Registration Complete is displayed briefly
and return to the previous display.
Deleting a stored running
record
1 Touch Replay and then touch the list
name that you want to delete the record.
Performing a Run
En 19
English
Section
05

2 Touch Delete This Item.
3 Touch Yes to delete a record from mem-
ory.
Deleting.... is displayed briefly and the se-
lected record is deleted from memory.
#To cancel halfway this operation, touch No.
Deleting all stored running
records
1 Touch Replay and then touch
Delete All.
2 Touch Yes to delete all records from
memory.
Deleting.... is displayed briefly and all records
are deleted from memory.
#To cancel halfway this operation, touch No.
Performing a Run
En
20
Section
05
