Pioneer VSX-416-K User manual

ORDER NO.
PIONEER CORPORATION 4-1, Meguro 1-chome, Meguro-ku, Tokyo 153-8654, Japan
PIONEER ELECTRONICS (USA) INC. P.O. Box 1760, Long Beach, CA 90801-1760, U.S.A.
PIONEER EUROPE NV Haven 1087, Keetberglaan 1, 9120 Melsele, Belgium
PIONEER ELECTRONICS ASIACENTRE PTE. LTD. 253 Alexandra Road, #04-01, Singapore 159936
PIONEER CORPORATION 2006
Model Type Power Requirement The voltage can be converted by
the following method.
VSX-416-K SPWXJ AC 110 V/120 to 127 V/220 V/240 V With the voltage selector
VSX-416-S SFLXJ AC 110 V/120 to 127 V/220 V/240 V With the voltage selector
VSX-416-S YPWXJ AC 240 V –––––––
VSX-416-S NAXJ5 AC 220 V –––––––
RRV3491
T – ZZK SEPT. 2006 Printed in Japan
AUDIO/VIDEO MULTI-CHANNEL RECEIVER
VSX-416-K
VSX-416-S
CONTENTS
1. CONTRAST OF MISCELLANEOUS PARTS ........ 2
2. SCHEMATIC DIAGRAM ....................................... 8
Model No. Order No. Remarks
VSX-516-K/KUCXJ RRV3329
¶This service manual should be used together with the following manual(s):
THIS MANUAL IS APPLICABLE TO THE FOLLOWING MODEL(S) AND TYPE(S).
¶For SPECIFICATIONS and PANEL FACILITIES, refer to the operating instructions.

2
1234
1234
C
D
F
A
B
E
VSX-416-K
1. CONTRAST OF MISCELLANEOUS PARTS
jpfy
For the applying amount of lubricants or glue, follow the instructions in this manual.
(In the case of no amount instructions, apply as you think it appropriate.)
Parts marked by "NSP" are generally unavailable because they are not in our Master Spare Parts List.
The mark found on some component parts indicates the importance of the safety factor of the part.
Therefore, when replacing, be sure to use parts of identical designation.
Screws adjacent to mark on product are used for disassembly.
Reference Nos. indicate the pages and Nos. in the service manual for the base model.
NOTES:
•When ordering resistors, first convert resistance values into code form as shown in the following examples.
Ex.1 When there are 2 effective digits (any digit apart from 0), such as 560 ohm and 47k ohm (tolerance is shown by J=5%,
and K=10%).
560 Ω→56 × 101→561 ........................................................ RD1/4PU 56
1
J
47k Ω→47 × 103→473 ........................................................ RD1/4PU 47
3
J
0.5 Ω→R50 ..................................................................................... RN2H R5
0
K
1 Ω→1R0 ..................................................................................... RS1P 1
R 0
K
Ex.2 When there are 3 effective digits (such as in high precision metal film resistors).
5.62k Ω→ 562 × 101→5621 ...................................................... RN1/4PC
5 6
2
1
F
CONTRAST TABLE
Ref. Part No.
No. Mark Symbol and Description VSX-516-K VSX-416-K VSX-416-S VSX-416-S VSX-416-S Remarks
/MYXJ5 /SPWXJ /SFLXJ /YPWXJ /NAXJ5
PCB ASSEMBLIES
P9-1 DSP ASSY AWX8572 AWX8573 AWX8573 AWX8573 AWX8573
P9- 4 MAIN ASSY XWK3230 XWK3246 XWK3246 XWK3246 XWK3246
NSP COMPLEX ASSY XWK3210 XWK3239 XWK3239 XWK3240 XWK3240
P11-1 FRONT DISPLAY ASSY XWZ4052 XWZ4051 XWZ4051 XWZ4051 XWZ4051
P9-10 PRIMARY ASSY XWZ4073 XWZ4074 XWZ4074 XWZ4075 XWZ4075
P9-11 REGULATOR ASSY XWZ4116 XWZ4077 XWZ4077 XWZ4077 XWZ4077
NSP AMP ASSY XWK3220 XWK3243 XWK3243 XWK3243 XWK3243
P9-3 POWER PACK ASSY XWZ4083 XWZ4119 XWZ4119 XWZ4119 XWZ4119
P9-13 TRAMS2 ASSY XWZ4092 XWZ4091 XWZ4091 XWZ4091 XWZ4091
P11-4 USB IN ASSY XWK3247 Not used Not used Not used Not used
P9-5 USB ASSY AWX8704 Not used Not used Not used Not used
PACKING SECTION
P7-1 FM Antenna ADH7030 Not used Not used Not used Not used
P7-3 Microphone ASSY APM7008 Not used Not used Not used Not used
P7-5 NSP Battery (R6) 2P (JE) XEX3002 Not used Not used Not used Not used
P7-7 Operating Instructions XRE3121 Not used Not used Not used Not used
(English/Italian)
P7-7 Operating Instructions Not used XRB3058 XRB3058 XRB3058 Not used
(English)
P7-8 Operating Instructions XRC3223 Not used Not used Not used Not used
(Dutch/Spanish)
P7-8 Operating Instructions Not used Not used Not used Not used XRC3229
(Chinese)
P7-9 Operating Instructions XRC3224 Not used Not used Not used Not used
(French/German)
P7-9 Operating Instructions Not used Not used XRC3228 Not used Not used
(Chinese/Spanish)
P7-10 Remote Control XXD3102 XXD3101 XXD3101 XXD3101 XXD3101
P7-14 Packing Case XHD3589 XHD3600 XHD3601 XHD3601 XHD3602
P7-15 Battery Cover XZN3139 Not used XZN3139 Not used Not used
P7-16 Label (WEEE) ARW7322 Not used Not used Not used Not used
P7-17 NSP Warranty Card ARY7065 Not used Not used Not used ARY7046
>AC power Cord Not used ADG7100 ADG7104 Not used Not used
>AC power Cord Not used Not used XDG3034 Not used Not used
>AC power Cord Not used ADG7062 ADG7062 Not used Not used
J-Shape Plug Not used AKX7008 AKX7008 AKX7008 AKX7008
VSX-416-K/SPWXJ, VSX-416-S/SFLXJ, YPWXJ, NAXJ5 and VSX-516-K/MYXJ5 are constructed the same except for the
following :

3
1234
1234
C
D
F
A
B
E
VSX-416-K
Ref. Part No.
No. Mark Symbol and Description VSX-516-K VSX-416-K VSX-416-S VSX-416-S VSX-416-S Remarks
/MYXJ5 /SPWXJ /SFLXJ /YPWXJ /NAXJ5
Power Plug Adapter Not used AKX7022 Not used Not used Not used
Caution Card 220V Not used XRR3001 XRR3001 Not used Not used
Caution Card SD SB Not used Not used ARM7063 Not used Not used
Caution Ccard SB Not used Not used ARM7064 Not used Not used
NSP Polyethylene Bag Z21-038 Not used Z21-038 Not used Not used
EXTERIOR SECTION
P9-2 FM/AM Tuner Unit AXX7170 AXX7211 AXX7211 AXX7211 AXX7211
P9-18 >Transformer XTS3102 XTS3090 XTS3090 XTS3090 XTS3090
P9-19 >Fuse (6.3 A) REK1027 REK1030 REK1030 REK1030 REK1030
>Fuse (3.15A) Not used REK1027 REK1027 REK1027 REK1027 FU2, FU3
P9-20 Fuse Card AAX7493 Not used Not used AAX7493 Not used
P9-20 NSP Fuse Card Not used XAX3218 XAX3218 Not used Not used
P9-21 >AC Power Cord VDG1080 Not used Not used XDG3017 VDG1088
P9-33 NSP H/Sink (MTL) XNH3044 XNH3043 XNH3043 XNH3043 XNH3043
P9-27 17P F.F.C/30V Not used XDD3203 XDD3203 XDD3203 XDD3203
P9-28 25P F.F.C/30V XDD3201 Not used Not used Not used Not used
P9-31 R Panel XNC3414 XNC3418 XNC3435 XNC3436 XNC3419
P9-36 >Cord Stopper CM-22B Not used Not used CM-22B CM-22B
P9-37 Insulator PNW2766 AMR7198 AMR7198 AMR7198 AMR7198
P9-39 Bonnet XZN3183 Not used XZN3184 XZN3184 XZN3184
P9-40 NSP Label VRW1629 VRW1629 VRW1629 VRW1629 Not used
P9-41 ICP Label (PAP) XAX3121 Not used Not used Not used Not used
P9-46 Screw BBZ30P080FTB BBZ30P080FTB BBZ30P080FNI BBZ30P080FNI BBZ30P080FNI
>Voltage Selector Not used AKX-507 AKX-507 Not used Not used No.1
>AC Inlet ASSY Not used ADX7395 ADX7395 Not used Not used No.2
NSP CCC S&E Label Not used Not used Not used Not used DRW2310 Rear Panel
NSP SISIR Label 516SF Not used Not used XAX3579 Not used Not used Rear Panel
NSP DF Label Not used Not used AAX7960 Not used Not used Rear Panel
FRONT PANEL SECTION
P11-9 D Panel XAK3535 XAK3529 XAK3529 XAK3529 XAK3529
P11-10 NSP Gold Foil Label XAX3487 Not used Not used Not used Not used
P11-11 NSP F Panel ASSY XXG3249 XXG3255 XXG3256 XXG3256 XXG3256
P11-12 TUNER BTN XAD3230 Not used XAD3248 XAD3248 XAD3248
P11-13 SUB BTN XAD3231 Not used XAD3249 XAD3249 XAD3249
P11-14 FUNC BTN XAD3232 Not used XAD3250 XAD3250 XAD3250
P11-15 LISTEN BTN XAD3233 Not used Not used Not used Not used
P11-16 JOG Button XAD3240 Not used XAD3251 XAD3251 XAD3251
P11-16 JOG Button Not used Not used XAD3252 XAD3252 XAD3252
P11-17 Pioneer badge B XAM3006 Not used VAM1129 VAM1129 VAM1129
P11-18 FRT Panel XMB3227 XMB3234 XMB3235 XMB3235 XMB3235
P11-20 Earth Plate XNG3144 Not used Not used Not used Not used
P11-21 4P Shielded Cable XDX3028 Not used Not used Not used Not used
P11-22 5P F.F.C/30V XDD3199 Not used Not used Not used Not used
JOG Knob XAB3046 Not used XAB3048 XAB3048 XAB3048
VOL Knob XAB3049 Not used XAB3051 XAB3051 XAB3051
Standby BTN XAD3202 Not used XAD3203 XAD3203 XAD3203
Notes : ÷The numbers in the remarks column correspond to the numbers on the “ EXPLODED VIEWS ”.
÷For PCB ASSEMBLIES, Refer to “CONTRAST OF PCB ASSEMBLIES” and “2. SCHEMATIC DIAGRAM”.

4
1234
1234
C
D
F
A
B
E
VSX-416-K
Rear Panel
Screw BBZ30P80FNI
2
1
CONTRAST OF PCB ASSEMBLIES
Mark Symbol and Description Part No. Remarks
XWK3230 XWK3246
D253 UDZS13(B) UDZS27(B)
D255 UDZS13(B) Not used
IC106 HA17558AF Not used
IC315 BA4560RF Not used
IC5001 LC72725M Not used
Q251 Not used 2SD2704K
Q255 2SC4081(QR) RT1N241M
Q259 RT1P241M Not used
Q260 2SC4081(QR) Not used
R279 RS1/16S104J Not used
R280 Not used RS1/16S0R0J
R282 RS1/16S473J Not used
R286, 288, 290 RS1/16S332J Not used
R291 RS1/16S0R0J Not used
R292 RS1/16S182J Not used
R434 RS1/16S104J Not used
R437 Not used RS1/16S164J
R463, 465, 466 RS1/16S223J Not used
R464 RS1/16S223J RS1/16S0R0J
R504 RS1/16S222J Not used
R507 RS1/16S104J Not used
R512 RS1/16S362J Not used
R514 RS1/16S153J Not used
R515 RS1/16S0R0J Not used
R516 RS1/16S103J Not used
R5010, 5011 RS1/16S473J Not used
R5012, 5013 RS1/16S102J Not used
R9023 RS1/16S472J RS1/16S0R0J
R9024 Not used RS1/16S472J
R9026 RS1/16S0R0J RS1/16S622J
R9042-9044 RS1/16S103J Not used
C103-114 CCSRCH101J50 Not used
C148, 152, 264 CKSRYB223K25 CKSRYB223K50
C170, 171 CEAT100M50 Not used
C181, 182, 185-192, 197, 198 CCSRCH101J50 Not used
MAIN ASSY
F
A
XWK3246 and XWK3230 are constructed the same except for the following :
EXPLODED VIEWS
EXTERIOR SECTION (SPWXJ and SFLXJ types)

5
1234
1234
C
D
F
A
B
E
VSX-416-K
Mark Symbol and Description Part No. Remarks
XWK3230 XWK3246
C282 CEAT2R2M50 Not used
C286, 288 CCSRCH331J50 Not used
C290 CEAT100M50 Not used
C291, 292 CKSRYB103K50 Not used
C386, 387 CCSRCH101J50 Not used
C388 CEAT220M50 Not used
C390, 393 CKSRYB103K50 Not used
C5011 CEJQ100M50 Not used
C5013, 5014 CCSRCH270J50 Not used
C5015 CEJQ470M16 Not used
C5016 CKSRYB103K50 Not used
C5017 CCSRCH561J50 Not used
C5020 CKSRYB472K50 Not used
C9011, 9014 CKSRYB473K16 CKSRYB473K25
X5001 ASS7004 Not used
CN108 CKS3370 Not used
CN109 XKP3055 XKP3054
CN112 CKS3390 CKS3382
PRIMARY ASSY
XWZ4074, XWZ4075 and XWZ4073 are constructed the same except for the following :
Mark Symbol and Description Part No. Remarks
XWZ4073 XWZ4074 XWZ4075
D58 MTZJ5.1B MTZJ5R1(B) MTZJ5R1(B)
T51 ATT7040 XTT3006 XTT3006
NSP J8807 ZWX-STD.JW-0R58 Not used Not used
NSP J8808 Not used ZWX-STD.JW-0R58 ZWX-STD.JW-0R58
H53-56 Not used AKR7001 Not used
S51 Not used XKX3005 Not used
FRONT DISPLAY ASSY
XWZ4051 and XWZ4052 are constructed the same except for the following :
Mark Symbol and Description Part No. Remarks
XWZ4052 XWZ4051
D500 SLI-343DCW(STU) Not used
R550 RS1/16S181J Not used
V401 XAV3025 XAV3033
F
REGULATOR ASSY
XWZ4077 and XWZ4116 are constructed the same except for the following :
Mark Symbol and Description Part No. Remarks
XWZ4116 XWZ4077
IC807 TA7805S Not used
D813 MTZJ6.2B Not used
R802 RS2LMF221J Not used
R819 RS1/16S0R0J Not used
C816 CEAT101M10 Not used
C817 CKSRYB103K25 Not used
F
K
F
U
P

6
1234
1234
C
D
F
A
B
E
VSX-416-K
POWER PACK ASSY
XWZ4119 and XWZ4083 are constructed the same except for the following :
Mark Symbol and Description Part No. Remarks
XWZ4083 XWZ4119
IC600, 602 STK412-230C Not used
IC603 Not used STK413-230C
Q631 2SD2704K Not used
Q633 2SC2240(GRBL) Not used
Q651 2SD2704K Not used
Q655 2SC2240(GRBL) Not used
Q681 Not used 2SD2704K
Q683 Not used 2SC2240(GRBL)
Q804 RT1N431M RT1N241M
D631, 632, 651, 653 1SS133 Not used
D647, 648 MTZJ15A Not used
D757, 758 1SS355 Not used
D683, 684 Not used 1SS133-T
L501 ATH1004 Not used
CN751 XKE3042 Not used
CN753 XKE3044 Not used
CN754 Not used XKE3050
CN755 Not used XKE3049
CN812 XKP3067 Not used
CN813 CKS3390 Not used
CN815 XKM3006 XKM3005
CN817 Not used CKS3382
RY501 XSR3012 Not used
NSP J602 DB919NB0 Not used
NSP J604 Not used DB211NB0
NSP J605 Not used DB410NB0
NSP J8806 ZWX-STD.JW-0R58 ZWX-STD.JW-0R58
R631 RD1/4PU222J Not used
R632 RS1/16S103J Not used
R635 RD1/4PU273J Not used
R636 RD1/4PU821J Not used
R637 RD1/4PU273J Not used
R638 RD1/4PU331J Not used
R639 ACN7094 Not used
R640 RD1/4PU182J Not used
R641 RD1/4PU821J Not used
R642 RD1/4PU223J Not used
R647, 648 RD1/4PU562J Not used
R651 RD1/4PU222J Not used
R653 RS1/16S103J Not used
R659 RD1/4PU273J Not used
R661 RD1/4PU821J Not used
R663 RD1/4PU273J Not used
R665 RD1/4PU331J Not used
R667 ACN7094 Not used
R669 RD1/4PU182J Not used
R671 RD1/4PU821J Not used
R673 RD1/4PU223J Not used
R680 RS1/16S0R0J Not used
R681 Not used RD1/4PU222J
R682 Not used RS1/16S103J
R685 Not used RD1/4PU273J
R686 Not used RD1/4PU821J
R687 Not used RD1/4PU273J
R690 Not used RD1/4PU331J
F
C

7
1234
1234
C
D
F
A
B
E
VSX-416-K
TRANS2 ASSY
XWZ4091 and XWZ4092 are constructed the same except for the following :
Mark Symbol and Description Part No. Remarks
XWZ4092 XWZ4091
>IC853 IC Protector AEK7021 AEK7018
F
Mark Symbol and Description Part No. Remarks
XWZ4083 XWZ4119
R691 Not used ACN7094
R692 Not used RD1/4PU182J
R693 Not used RD1/4PU821J
R694 Not used RD1/4PU223J
R699 RD1/4PU333J Not used
R707, R708 RD1/4PU124J RD1/4PU104J
R709, R710 Not used RS1LMF472J
R789 RD1/4PUF101J Not used
R790 RS1LMF4R7J Not used
R811 RS1/16S0R0J Not used
C517 CQMBA224J50 Not used
C630 CEANP2R2M50 No tused
C632 CKSRYB331K50 Not used
C633 CEAT4R7M50 Not used
C634 CCSRCH470J50 Not used
C635 CEAT101M16 Not used
C636, 637 CCSRCH470J50 Not used
C653 CKSRYB331K50 Not used
C655 CEAT4R7M50 Not used
C657 CCSRCH470J50 Not used
C659 CEAT101M16 Not used
C661, 663 CCSRCH470J50 Not used
C665 CEANP2R2M50 Not used
C682 Not used CKSRYB331K50
C683 Notu sed CEAT4R7M50
C684 Not used CCSRCH470J50
C685 Not used CEAT101M16
C686, 687 Not used CCSRCH470J50
C688 Not used CEANP2R2M50
C766 CQMBA123J50 Not used
C785 CQMBA224J50 Not used
D

8
1234
1234
C
D
F
A
B
E
VSX-416-K
2. SCHEMATIC DIAGRAM
2.1 MAIN ASSY (1/3)
FR
FL
SR
SL
SW
C
SBR
SBL
CIN1
SLIN1
FRIN1
SRIN1
FLIN1
SWIN1
C9018
C9019
CN105
C9020
C166
C165
R158 R161
CN109
C114 R114 C192
C138
CN118
C113
R113
L112
C191
C137
C118
C136
CN118
R156
C112 C111
L111
R157
R112
C117
R111
R134
CN117
C110
R110
C109
R109
C190
C134
C189
R133
C133
C179
C107C108
R108
C132
R132
C188 C187
C131
R131
CN117
R107
C106
R106
C105
R128
C186
C128
C185
R127
R105
C199
L104
R104
C127
C104
C1041
C126
R154
L103
C102
R155
C103
C1031
R103
R124
C125
R140 R139
R159
R162
R180
R138 R137 R136 R135
C135
R182
R181
R149
IC108
C162
C160
C161
C159
C158
R126
R183
C147
C145
R125
C146
C157
C156
C155
C148 C150 C149 C152 C153 C154
C101
R102
R101
C183C184
C124
R123
C123
R122
C180
100P100P
100P100P
100P 100P100P
100P
100P
100P100P
100P
100P
100P100P
100P
100P100P
100P
100P100P
100P 100P100P
R121
R146
R145
D332
D312
R312
C334
D331
C332 C331
C333
R311
R142 R141
D311
R147 R148
C151
2
1
5
6
3
4
7
17 15
16
13
14
19
18 12
9
8
711 5
4
3
10 6 2
1
68 69 66 67 65
6364 6162 60 59 58 57 55 5456 53 52
71 72 70 74 75 73 78 77 76 80 79
213465 78910111213
5051 4849 47 46 4445 4243 41
40 39 38 36 37
1514 1716 1918
33 35 34 30 32 31 29 28 27
20 21 22 23 24
25 26
CHASSIS
YB
0.1
STBY
GNDA GNDA1 GNDA0
GNDA
STBY
CK533172-
GNDA
1/50
1/50
STBY
STBY
XKP3054
GNDA
330
CH
GNDA
10/50
GNDA
CH
CH
330
STBY
10/50
CH
GNDA
2.2K
CH
10/50
0
STBY
0
330
CH
22p22p
GNDA
2.2K
CH
CH
10/50
10/50
CH
330
CH
0.01
YB
CH GNDA
CH
10/50
GNDA
330
CH CH
330
10/50
CH
GNDA
CH
10/50
330
CH CH
10/50
GNDA
STBY
CH CH
GNDA
STBY
0.01
330
YB
STBY
0
10/50
2.2K
CH
22p CH
10/50
STBY
0
330
CH
22p CH
10/50
2.2K GNDA
STBY
10/50
STBY STBY
STBY
STBY
STBY
0
STBY STBY
DSPOL
GNDA
STBY
0
STBY
GNDA
STBY
0
STBY
STBY
100k
R2S15205FP
100/16
100/16
100/16
100/16
100/16
GNDA
STBY
0
YB
0.01
100p
GNDD
CH CH
GNDA
STBY
1K
100p
V-12
100/16
100/16
100/16
0.022
YB
0.15
YB
0.15
0.047
0.022
0.047
CH CH
0.01
YB
CH
GNDA
STBY
330 10/50
CH
TR
TL
GNDA
STBY
VLDT
1K
VLCK
UDZS6R8(B)
1SS355
100/1W
V-7
100/10
GNDA
STBY
GNDA
UDZS6R8(B)
0.01
YB
0.01 YB
100/10
100/1W
STBY
GNDA
STBY
1SS355
V+12
V+7
YB
4.7K
YB YB YB
4.7K
0.01
YB
V+7
( ) (SQ):CKSQ.CCSQ
NOTES: NO INDICATED PARTS IS....
RESISTOR: RS1/16S***J-T, RS1/10S***J-T
CHEMICAL CAPACITOR: CEAT***M**-T,-TS
CERAMIC CAPACITOR: CCSRCH****50-T
CKSRYB****50-T
J48
GNDA(DAG) GNDA(DAG)
VCOMG
GNDA(DAG) GNDA(DAG) GNDA(DAG) GNDA(DAG) GNDA(DAG)
AG
C
SL
AG
SW
SR
AG
RIN
FLO
FRO
LIN
RCMUT/OVF
SLO
SRO
SWO
SBRO
CO
SBLO
R
PLAY
(CHASSIS)
GNDGND
MD
CN118
L
CD-R/TAPE
R
L
REC
(R)
TV
L
R
(CHASSIS)
GND
CN117
L
R
DVD/LD
(CHASSIS)
R
PLAY
VCR/DVR
CN125
R
L
GND
R
L
REC
TR
CDRREC(L)
CDRREC(R)
VCRREC(R)
VCRREC(L)
FRONT(L)
FRONT(R)
AUX(L)
AUX(R)
DVD/LD(L)
DVD/LD(R)
VCR(L)
VCR(R)
TV(R)
TV(L)
CDR(L)
TL
C
SR
SL
SW
LIN LIN
REC
ATT
TONE
TONE
CDR(R)
CD(L)
CD(R)
(R)
AVEE
CLOCK
DATA
DGND
RIN LIN SRIN1 CIN1 SWIN1 SLIN1
AVCC
FRIN1 FLIN1
0.047
0.047
0.15
0.15
L
GND
(CHASSIS)
AKB3055
AKB7114
AKB7114
AUX
STBY
CN815
C2/2F
CN307
I
A1/3F
MAIN ASSY(XWK3246)
A1/3F
A3/3F
A3/3F
A3/3F
A3/3F
A3/3F
(SL)
(SL)
(FL)
(SL)
(SW)
(C)
(C)
(C)
(C)
(SW)
(SW)
(SW)
(SL)
(L)
(L)
(L)
(L)
(L)
(M)
(FL)
(SL)
(C)
(SW)
(L)
(L)
(L)
(L)
(L)
(L)
(L)
(L)
(L)
(L)
(L)
(L)
(L)
(L)
(L)
(L)
(L)
(L)

9
1234
1234
C
D
F
A
B
E
VSX-416-K
-
+
-
+
-
+
-
+
+
-
+
-
-
+
-
+
IN1
SWIN1
FR
FRIN1
FLIN1
CIN1
SR
MP
SLIN1
SRIN1
R270
R262 C264
C262 R264 R266
C266
R272 R274
R268
R276
C278
C270 R278
IC104
C268
R202
C202
R201
C204 C206
R210
R212 R214
C210
R216
C218
R204 R206 R208
IC105
C208
R240
C217
C203 C205
R209
R211 R213
C209
R215
Q232
C201
C261
R261 R242
R205 R207R203
IC105 R239
C207
R269
C263
C265
R263 R265 R267
R271 R273
C269
R275
C277
C272
R277
C271
IC104
C244
C246
R236
C267
R250
R252 R254
C258
R256
R218
R220
C212
R222
IC107
R234
C216
C214 R228
R224
C221
R238 R226
R231
C222
IC110
Q231
R217
R219
R223
C211
R237
C220
R221
R233
C215
C213 R227
IC107
C219
R225
D107
D103
D105
C242
R241
C241
R244 R246 R248
IC103
C250
R235
C248
R258
C243
C245
R249
R251 R253
C249
R255
C252
C257
R257
C251
R243 R245 R247
IC103 R232
C247
8
2
34
1
8
2
1
34
8
6
54
7
8
6
5
7
4
3
1
4
28
7
6
5
8
10
9
4
3
2
1
12
11
13
14
5
7
4
68
8
2
1
34
68
7
54
GDAC
GDAC
1.2K
47K
0.022u
YB
TS
2.2/50 3.3K 6.8K
0.01u
2.7K 270
YB
39K
STBY
10/50TS 100
5600p
YB
4700p
GDAC
V-12
TS
2.2/50
(COUT)
47K
LSSN
(SLOUT)
(SWOUT)
2.2/50
TS
47K
470p
330p
3.9K 3.9K
CH
3.9K
CH
3.9K
683.3K
STBY
STBY YB
0.01
GDAC
330p
STBY
YB
0.01
GNDU
CH V+12
RT1N241M
470p 330p
CH
CH
3.9K 3.9K 3.9K
3.9K
3.3K 68
STBY
STBY
RT1P241M
(SROUT)
(FROUT)
(FLOUT)
TS
2.2/50
GDAC
STBY
330p
3.3K
1.8K 0
V-12
CH
47K
100p
330p
3.3K
CH
3.3K 3.3K
CH 10/50
STBY
STBY
4700p
YB0.01
TS 100
0.01 YB
GDAC
47K
100p
330p
330p
3.3K
1.8K 0
CH
STBY
V+12
4700p
GDAC
STBY
0
V-7
4.7K
STBY
4.7K YB
1.2K
470K
YB
0.01
10/50 100
TS
GDAC
0.01
3.9K
TC4066BFN
V-7
100K
GDAC 4.7K V-12
V+7
0.01
0
STBY
V+7
1.2K
0.1
4.7K
STBY
YB
YB
470K
0.01
YB
10/50 100
YB
0.1
TS
3.9K
V+12
GNDA
GNDA
GDAC
DAN217U
GNDU
DAN217U
DAN217U
GDAC GNDU
TS
2.2/50
2.2/50
TS
3.3K
CH
3.3K
CH
3.3K
GDAC
10/50
STBY
330p
100
TS
V-12
CH
100p
47K
CH
CH
330p
3.3K 3.3K 3.3K
3.3K
1.8K 0
10/50
STBY
0.01
4700p
YB
100
TS
0.01
STBY
HA17558AF-TBB
330p
V+12
YB
CH
(2/2)
(2/2)
(FR)
(1/2)
(1/2)
(1/2)
(FR)
LFE MIX
(1/2)
Low Pass Filter
(2/2)
(SR)
(1/2)
VEF1040-A
For Wire Styling
101
A1/3F
A2/3F
A3/3F
HA17558AF-TBB
HA17558AF-TBB
HA17558AF-TBB
HA17558AF-TBB
HA17558AF-TBB
HA17558AF-TBB
HA17558AF-TBB
(L) : Audio Signal Route (L ch)
(FL) : Audio Signal Route (Front L ch)
(SL) : Audio Signal Route (Surround L ch)
(C) : Audio Signal Route (Center ch)
(SW) : Audio Signal Route (SubWoofer ch)
(C)
(C) (C)
(C)
(SW)
(SW) (SW)
(FL)
(FL)
(FL)
(FL)
(FL)
(SL)
(SL)
(SL) (SL)

10
1234
1234
C
D
F
A
B
E
VSX-416-K
2.2 MAIN ASSY (2/3)
+
-
-
+
+
-
-
+
+
-
-
+
R300 C300
R485
R484
C362
R488
R489
IC312
C368
R490
Q362
R486
C370
R502
R494
R498
C364
R496
C366
R500
C367
Q361
R483
C361
R495
C363
R493
R497
R499
C365
IC311
IC312
C342
R482
R474 R476
C348
C346
R478 C347
R481
C343
R475 R473
C344
R477
R479
C345
C341
IC310
IC311
C328
R480
R308
R307
R306
R305
R304
R303
R462
C322
R454
R458 R456
C324
C326
C327
C321
R461
R455
C323
R453
R457
IC310
C325
R460 R459
V-12
STBY
V+5U
STBY
10/50 TS
100K
4.7K
SWPR
V-12
0
STBY
4.7/50
BA4560
0.01 YB
4.7/50
STBY
STBY
STBY
200K
910 2.7K
TS
0.01
YB
4700p
YB
V+12
2SD2704K
100K
10/50
TS
2.7K 1K
100p
CH
22/50
BA4560
BA4560
V-12
YB
0.01
10k 10k
GNDA
TS 10/50
100K
1K 2.7K
22/50
YB0.01
CH
V+12
100K
TS 10/50
2.7K 1K
100p
CH
100p
TS
22/50
TS 10/50
BA4560
BA4560
V-12
YB
0.01
10k 10k
(SROUT)
(SWOUT)
(COUT)
100
100
100
(SLOUT)
(FLOUT)
(FROUT)
100
100
100
100K
1K 2.7K
TS 22/50
0.01
YB
100p
CH
CH
V+12
100K
TS 10/50
2.7K 1K
15K
15K
15K
15K
15K
15K
100p
22/50
BA4560
TS
10k 10k
MVRATT
(2/2)
SW
C
(1/2)
(1/2)
SR
SL
(1/2)
(2/2)
FR
FL
(2/2)
PRE-AMP
A1/3F
A3/3F
A3/3
A2/3F
MAIN ASSY(XWK3246)
A2/3F
(FL) (FL)
(FL)
(SL)
(SL)
(SL)
(C)
(C)
(C)
(SW)
(SW)
(SW)

11
1234
1234
C
D
F
A
B
E
VSX-416-K
DCDT
OLDT
XPROTECT
NECK
AMUTE
CONTROL
+
+
-
-
3
1
2
3
1
2
211715
16 2018
19
10
913
14
12
11
4
3
82
7
6
51
R280 D253
Q255
R464
R443
Q252
Q254
C256
R447
R442
R436
IC251
R439
IC253
C253
R441
D251
R435
R432 R437
R433
R431
R440
Q251
R438
R445
C255
R444
Q253
R448
D254
Q257
R449
R446
C392
Q256
C254
CN251
CN252
C320
CN114
GNDU
0
0
RT1N241M
470 4.7K
(QR)
2SD1858X RT1P241M
HA17558AF
0.01 CKPU
2SD2704K
0.01 CKPU
100K
100K
(2/2)
100K
HA17558AF
750K
2.2K
DAN217U
100K
(1/2)
100K
100K
160K
100K
100K
2SD2704K
4.7/25
NP
STBY
RT1N241M
22k
100K
UDZS5R1(B)
1K
2SA1576A (QR)
100k
GNDA
GNDU
YB
1000p GNDU
100/25
52147-0310
B3B-EH
GNDCH
YB
1000p
6 OHM
GNDU
FL
GNDA
SR
GNDA
FR
GNDA
SBL
GNDA
SBR/SW
GNDA
SL
GNDA
XKP3091-
C
6_OHM
FAN CONTROL
SR
FL
SL
FR
C
+12V
GNDU
-12V
J22
FAN+
FAN-
FAN STOP
ATT
DCDT
XPROTECT
OLDT
NECK
AMUTE
JA:CEJA
Ratings: Capacity(µF)/Voltage(V) unless otherwise noted.
Rated Voltage: 50V expect for electrolytic capacitors.
Unit: k-kΩ, M-MΩor Ωunless otherwise noted.
2.CAPACITORS
1.RESISTORS
Tolerance: (J) 5% unless otherwise noted.
Unit: p-pF or µF unless otherwise noted.
Rated power: 1/16W unless otherwise noted.
NOTE
+
-
CN705
FAN
C1/2F
891
O
A3/3F
A3/3F
A2/3F
UDZS27(B)
(FL) : Audio Signal Route (Front L ch)
(SL) : Audio Signal Route (Surround L ch)
(C) : Audio Signal Route (Center ch)
(FL) (FL)
(SL) (SL)
(C) (C)
(SW) : Audio Signal Route (SubWoofer ch)

12
1234
1234
C
D
F
A
B
E
VSX-416-K
2.3 MAIN ASSY (3/3)
HPDET
SPA_RY
R/C_RY
SPB_RY
AC_WP
AC_RY
SRTX
SW2
SRRX
SW1
MUTE
SROUT
V3
SRIN
RMC
SWDET
OSD_CLK
OSD_RST
OSD_CS
OSD_DT
INH
V1
V2
V4
T_DO
T_CLK
T_CE
T_DI
CONTROL
CN111
L9001
L9002
L102
L101
R5007
CN104
R5005
R5016
C5008
R5009 Q5009
R5006
L5002
D9003
D9002
D101
C116 C115
D9001
IC9002
C5028 C5027 C5025
C5026
CN103
R5004
R5003
C5002
R5002
R5001
C5001 C5003
C5005
C5004
20 1618
21 19 17
14 1012 8
15 13 11 9 7
462
531
15
16
19
18
17 13
14
11
10
9
8
12
7
2
5
64
31
10
11
9
4
1
3
2
5
6
8
7
8
7
6
5
4
3
1
2
GNDTGNDU
XKP3091-
ATL7002
ATL7002
GNDU
GAV
QTL1013
QTL1013
GNDA
0
STBY
GNDT
CKS3384-
GNDT 0STBY STBY
STBY
QTL1013
VT+9
DAN202U
SM+5V
DAP202U
V-12
D+5.6
STBY
0.010.01
V+12
V+5U
YBYB
DAP202U
ST+5.6
GNDU
STBY
BR24L16FV
TR
TL
1000p 1000p
1000p
52044-1145
STBY
STBY
22p 1000p
VT+9
CHASSIS
STBY
STBY
YB YB
0.01
YB
STBY
1u STBY
+
-
Ratings: Capacity(µF)/Voltage(V) unless otherwise noted.
2.CAPACITORS
Unit: k-kΩ, M-MΩor Ωunless otherwise noted.
Rated power: 1/16W unless otherwise noted.
Tolerance: (J) 5% unless otherwise noted.
Unit: p-pF or µF unless otherwise noted.
Rated Voltage: 50V expect for electrolytic capacitors.
1.RESISTORS
NOTE
GNDT
T+12V
HP. SW
SP-A RY
R/C RY
SP-B RY
-12V
FL AC1 FL AC2
-VF
AC WP
AC RY
D+5.6V
GNDU
ST5.6V
GNDA
SWOUT
+12V
GAV
GNDA
NC
SRTXD
SRRXD
SW1
SW2
NC
SRIN
RMC
SWDET
AMUTE
SROUT
VIDEO2
VIDEO3
INH
OSD CLK
OSD CS
OSD RST
VIDEO1
OSD DT
J33 VIDEO4
GNDT
RDS
VSM
A0
A1
A2
GND
SCL
SDA
Vcc
WP
E2PROM
TUNER CLK
+9V
TR
GNDT
TL
TUNER DO
TUNER CE
TUNER DI
J34
(RCA Jack)
CN816
C2/2F
Y
CN303
Q
A1/3F
A1/3F
A2/3F
A3/3F
MAIN ASSY (XWK3246)
A3/3F
(L)
(SW)
(SW)

13
1234
1234
C
D
F
A
B
E
VSX-416-K
36 35 37
46 42
41
39
40
45
38
29
30
26
28
27
24
25
23
22
1W_WP
UART2
19
AC_WP
EE_DT
EE_CLK
OSD_CLK
OSD_DT
IPOD_POW
OSD_CS
OSD_RST
26 46 45 42 41 38 39 40 35 37 36 50 21 48 49
49
48
50
MUTE
XM_ERR
52
SPA_RY
R/C_RY
SPB_RY
NECK
V4
AC_RY
SWDET
V3
V2
INH
SW2
DCDT
V1
OLDT
RDS_CLK
RDS_DT
SW1
78
77
80
79
T_CLK
28 SRIN RMC SROUT 1W_WP
1
2
100
HPDET
91
93
21
GCTRL
T_CE
T_DO
T_DI
CN102
R9065 R9064 R9067 R9066
D9065
D9064 D9068
Q9065
CN112
R9080
Q9064 Q9065
R9010
R9031
C9005
R9013
R9037
Q9001
C9001
C9004
C9002
R9002
C9006
D9010
R9033
L9003
R9046
R9039
R9004
C9009
C9010
X9001
R9041
R9062
C9015
R9005
C9019
IC9001
R9045
R9048
R9047
R9016
R9018
R9017
R9014
R9015
C9008
C9007
R9038
C9012
R9026
R9060
R9024
R9082
C9081
R9081
R9009
D9011
R9011
C9000
R9012
Q9003
R9032
C9013
Q9002
R9030
Q9007
C9018
R9068
R9008
R9036
R9028
R9021
R9020 R9019
R9022
R9034
CN101
C9017
R9007
C9014
R9006 C9011
R9063
Q9004
D9007 D9006
1
2
3
4 6
7 5
10
8
9
16
17
14 12 10 8
1315 11 9 7
462
531
31 33 34 32 36 35 37
30
40 39 38 42 43 41 46 44 45
292827262523 241817 19 2120 2210 11 12 13 14 15 1665 94 87321
100
97 98 99 95 96 94 91 92 93 89 88 90 86 85 87
47 48 49 50
5153 525455565758596062 6164 6366 6569 68 6771 7073 72747577 76787980
83 82 84 81
4
3
2
1
12
9
10
1311
68
7515
16
17
14
GNDU
SWPR
STBY
10K 10K 10K 10K
DAP202U
GNDU
UMD2N
DAP202U 1SS355
RT1P241M UMD2N
CKS3382
V+5U
10K
V+5U
100K
LSSN
5.1k
JQ
2.2/50
100K
RT1N431M
STBY
0.01
STBY
YB
YB
1u/10
100K
1SS355
47K
LFCA2R2J
470
100K
STBY
*
XSS3004- STBY
100K
470
470
1000p
YB
0
STBY
470
10k
10k
330/6.3
YB
0.01
470
470
470
470
470
STBY
STBY
47K
270K
0.01
220
STBY
V-12
1K
0
RT1P241M
47K
100K
V+5U
DAN202U
RT1P241M
V+12 GNDU
STBY
DTC143TK
47
VLDT
VLCK
SM+5V
STBY
0
220
220 DSPOL
100K
STBY
470
470
470
470
V+5U
6_OHM
4.7K
3.3K
CKS3382-
ST+5.6
D+5.6 SM+5V
V+5U
STBY
STBY
0.047/25
470K
YB
470K
GNDU
0.047/25
YB
STBY
DAN217U
V+5U
DAN217U
MVRATT
SR_TXD
NC
T_BUSY
VSS
T_RST
T_PGM/OE/MD
T_SCLK
T_VDD
VSS
SR_RXD
1
5
4
2
MUTE_OUT
3
DIR CS
USB XRST
DSP DO
DSP DI
DIR DO
DSP MODE
DSP HREQ
BUSY
DSP SS
DSP RST
DSP CLK
DEC MUTE
DIR RST
DIR ERR
XTLO
GNDD GNDD
J45
DMUTE
XMTX
232C CTS CLK DSP CLK DSP DO DSP DI BUSY DSP SS DSP RST DSP MUTE DSP MODE DSP HREQ DIR CS DIR DO ADMODE
STBY
15.7MHZ
XM RX
DISP RST 32.RX(SR+/IPOD)
USCS
USB XRST
31.TX(SR+/IPOD)
XFLAG
IPOD SENSE
51.NECK SELECT
USB CTL
USB HREQ
1W WUP
USB TREQ
UART SW2
ACIN(WAKEUP)
PEG217-K
LOW_CONSUMPTION
MAIN µ-COM
12C DT EEPROM
NMI
+5V
XIN
GND
XOUT
XRESET
12C CLK EEPROM
CNVSS
GND
DISP CLK/OSD CLK
DISP DO
DISP DI/OSD DT 3.DISP EN
2.USCLK
RDS CLK/XM LOW SPD
RDS DT/XM LINK ACTIVE
DISP RDY
1.USDAI
USDAO
HPDET
AVCC
VREF
AVSS
SIMUKE2 SIMUKE1
IPOD POW
DECO MUTE
XPROTECT
XM POW
XM Fs
MVRATT
OSD RST
OSD CS
6 OHM
A
DIR ERR DIR CDC RST LSSN XTLO
AMUTE
XMDCS
RY_C/R
RY_B
XM ERR
RY_A
VIDEO4
RY-AC
EVR CLK
EVR DT
+5V
COMP VIDEO B
COMP VIDEO INH
GND
COMP VIDEO A
SW DET
VIDEO2
VIDEO3
DC PROT
VIDEO1
DSP OVERLOAD
OL DET
WAKE_UPB(XM)
RDS FM+/XM RST
XM SIGNAL SW
T_CE
T_DI
T_CLK
T_DO
XM CS
J31
FLAC 2 FLAC 1 -VF DISP RST DISP DI DISP CLK DISP DO SRIN SROUT RMC 1W WP DISP EN DISP RDY GNDU ST5.6V D+5.6V MIC DET
FLASH U-COM
CN817
C2/2F
CN401
K
A2/3F
A2/3F
A2/3F
A1/3F
A1/3F
A1/3F
A3/3F
R9023 4.7K
(L)
: Audio Signal Route (L ch)
(V)
: Video Signal Route
(SW)
: Audio Signal Route (SubWoofer ch)
(SW)

14
1234
1234
C
D
F
A
B
E
VSX-416-K
11
3
11
412
910 78563412
123456
7610 8 593412
D752 D751
RY752(3/3)
RY751(3/3)
RY753(3/3)
D754 D753
R755
L753
R756 C755
RY753(1/3)
C756 C763
C764
C761 C762
C753
C754
C751
C752
L761
R761
R762
L762
L751
R751
R752
Q705(2/2)
L752
C709
R716
R1110
R763 R764 R753
R754
RY752(2/3)
RY751(1/3)
RY751(2/3)
RY752(1/3)
Q705(1/2)
R714 R715
Q707(1/2)
D703
IC608
IC609
IC606
C704
IC607
IC604
IC605
C703
Q707(2/2) W201
R712 R711
D712
C712
D711
C711
C702
D702
H701
C708
H702
C701
C707
CN1201
C759 C521 C773 C757 C758
CN701
851
C1250
R1250
CN702
C1251 R1251
R1252
IC853
IC853
AEK7018 (4A)
IC851
IC852
IC702
R707
C706
Q702
R702
R704
R706
R705
R708
C705
D713 R713
Q703 Q704
R703
R722
R721
IC701
ICP-N10(400mA)
ICP-N10(400mA)
R701 6.8K
68K
68K
10 0K
100K
8.2K
6.8K
Q721
Q701
D701
J6
R724
J4 J3 J5 J7
R881
Q722
R882
C882 C883
C881
R723
C1252
OL
P13
P12
SBLO
SBRO/SBO/SWO
600/3_5
600/3_2
SBLO
OL
SBRO/SBO/SWO
CO
DC_DET
P6
CO
P1
OL
SRO
FRO
602_5
602_2
XPROTECT
P6
602_5
P12 602_2
P13 600/3_5
OL 601_5
600/3_2
601_2
SRO
601_2 P12
XPROTECT
NECK
( ) DC OUTPUT DETECTOR
GNDU
Q696,697:
Q605,606,633,655,656,683,
Q505: OVERLOAD DETECTOR
FR/FL RY
+12V 1SS355
1SS355
R/C RY
Indicated in 1SS133-T
Rated Voltage:50V except for
electrolytic capacitors.
3.DIODES
Unit: p-pF or µF unless otherwise
noted.
Ratings:Capacity(µF)/Voltage(V)
unless otherwise noted.
Tolerance:(J) 5% unless otherwise
noted.
2.CAPACITORS
1.RESISTORS
Unit:k-kΩ,M-MΩor unless otherwise
noted.
Rated power:1/4W unless otherwise
noted.
NOTE
DB917NB0
WHITEJ603
DC DET.
J601 WHITE
DB923NB0
DB118NB0
J607 BROWN
DB621NB0
J606 BLUE
(FR)
2.2K (MYXJ5, MVXJ5)
-29.7V
D
STANDBY
C
B
MTZJ
6.8B
-22.9V
D20PYY1130E
J21J21
STBY5V
Stby 5V
AC WUP
STBY
AKR7001-A-T
A
GNDU
AC RY
0.012 0.012 0.012 0.012 0.012
NO SIGNAL
/KU Others
C.D
A.B
39.538.6
61.467.0
C
+
-
SITUATION
A-D
POINT VOLTAGE (V)
-
+
-
+
SR
SL
XKE3050
CN754
XKE3049
CN755
-
FL
+
-
+
FR
FL AC1 FL AC2
REG B
GNDU
AC WUP
AC RY
REG G
REG B
DREG DREG
-VF
HP.SW
A.MUTE
GNDU AC WUP FL AC1 AC RY FL AC2 REG B
52147-1110
REG B REG G DREG DREG
GNDU HP.SW A.MUTE HP G HP R HP L
51048-1100
STANDBY
52147-0610
J47
1237
ACH
DB230NB0
DB232NB0
DB932NB0
DB025NB0
DB927NB0
STBY
6ohm
STANDBY
STANDBY
XSR3012
XSR3012
XSR3012
PUF 100 1/4W
ATH1004
1W
4.7
PUF 100 1/4W
ATH1004
PUF 100 1/4W
PUF
ATH1004
100 1/4W
ATH1004
PUF 100 1/4w
RN4903
ATH1004
1/50
10k
1W
4.7
0.22
0.22
0.22
0.22
0.22
1W
4.7 4.7
1W
4.7
1W
CHASSIS
0
stby
RN4903
D+5V
1k
10k 1SS355
RN4903
D+5V
XCH3012--F
3300u/42
(10A)
(10A)
(10A)
XCH3012--F
3300u/42
2SA2005(E)
(10A)
(10A)
(10A)
D5SBA20(B)
RN4903
100/10 100/35
MTZJ22D
XCH3026
5600/71 5600/71
XCH3026
0.01/250
D5SBA20(B)
0.01/250
52147-0410
CHASSIS
1/4W
4.7
NP
4.7
1/4W
NP
STBY
STBY
GNDU
10/100
47k
47k
1SS133 1k
2SC2240
(GRBL)
2SA1145
10/100
(GRBL)
2SA1145
2SC5511(E)
47k
1/4W
4.7
2SC2240
(GBRL)
NP
NP
47k
NP
ACH
1237
1/4W
4.7
NP
+-
~
~
+-
~
~
C1/2F DF
55
U
1551
G
TRANS 3 ASSY
(XWZ4079)
E
TRANS 2 ASSY
(XWZ4091)
E C1/2F DF E
C2/2F
C2/2F
∗1∗1
∗1
∗1
CAUTION : FOR CONTINUED PROTECTION AGAINST
RISK OF FIRE. REPLACE ONLY WITH
SAME TYPE NO. ICP-N10, MFD BY ROHM
CO., LTD. FOR IC701 and IC702.
CAUTION : FOR CONTINUED PROTECTION
AGAINST RISK OF FIRE.
REPLACE ONLY WITH SAME
TYPE NO. AEK7018
MFD, BY LITTELFUSE INK. FOR
IC853.
DF
DB211NBO
J604
J605
DB410NBO
∗1
C751, C752, C755,
C761, C762
0.22
ST +5.6V
XPROTECT
XPROTECT
R709 2.7K
2.7K
MYXJ5, MVXJ5
ONLY
W175
R710
(FL) : Audio Signal Route (Front L ch)
(SL) : Audio Signal Route (Surround L ch)
(C) : Audio Signal Route (Center ch)
(SW) : Audio Signal Route (SubWoofer ch)
(FL)
(FL)
(FL) (FL)
(FL)(FL)
(FL)
(SL)
(SL)
(SL)
(C)
(C) (C)
(C)
(SL)
2.4 POWER PACK ASSY (1/2)

15
1234
1234
C
D
F
A
B
E
VSX-416-K
REK1027
(3.15 A)
REK1027
(3.15 A)
YP, NA / REK1027 (3.15 A)
SP, SF / REK1030 (6.3 A)
PRIMARY ASSY
(SPWXJ, SFLXJ : XWZ4074)
(YPWXJ, NAXJ5 : XWZ4075)
UF
CN1201
D
• NOTE FOR FUSE REPLACEMENT
FOR CONTINUED PROTECTION AGAINST RISK OF FIRE.
REPLACE WITH SAME TYPE AND RATINGS ONLY.
CAUTION -
UFUF
2.5 PRIMARY ASSY
