ORDER NO.
PIONEER CORPORATION 4-1, Meguro 1-chome, Meguro-ku, Tokyo 153-8654, Japan
PIONEER ELECTRONICS SERVICE, INC. P.O. Box 1760, Long Beach, CA 90801-1760, U.S.A.
PIONEER EUROPE NV Haven 1087, Keetberglaan 1, 9120 Melsele, Belgium
PIONEER ELECTRONICS ASIACENTRE PTE. LTD. 253 Alexandra Road, #04-01, Singapore 159936
PIONEER CORPORATION 2000
c
XC-F10
RRV2319
1. SAFETY INFORMATION...................................... 2
2. EXPLODED VIEWS AND PARTS LIST ............... 3
3. BLOCK DIAGRAM AND SCHEMATIC DIAGRAM..... 6
4. PCB CONNECTION DIAGRAM ......................... 18
5. PCB PARTS LIST............................................... 25
6. ADJUSTMENT.................................................... 29
CONTENTS 7. GENERAL INFORMATION ................................ 32
7.1 DIAGNOSIS.................................................. 32
7.1.1 DISASSEMBLY ...................................... 32
7.1.2 SINGLE OPERATION METHOD............ 35
7.2 PARTS .......................................................... 36
7.2.1 IC ............................................................ 36
7.2.2 DISPLAY................................................. 40
8. PANEL FACILITIES AND SPECIFICATIONS....... 41
T – ZZK JUNE 2000 Printed in Japan
STEREO CDTUNER
Type Model Power Requirement Remarks
XC-F10
ZVYXJ DC power supplied from other system component
THIS MANUAL IS APPLICABLE TO THE FOLLOWING MODEL(S) AND TYPE(S).
¶This product is a system(s) component.
This product does not function properly independently ; to avoid malfunctions, be
sure to connect it to the prescribed system component(s), otherwise damage may
result.
¶Please connect it to the STEREO POWER AMPLIFIER M-F10, for adjustment and
operation inspection.
¶This product’s instructions are contained within the instruction manual of the related
system component(s).
The manual is packed with those component(s).
This product’s accessories etc. are packed with its related component(s).
Component Model Service manual Remarks
STEREO CD TUNER XC-F10 RRV2319 This manual.
STEREO POWER AMPLIFIER M-F10 RRV2321
SPEAKER SYSTEM S-F10-LRW RRV2330
STEREO CASSETTE DECK CT-F10 RRV2308
STANDBY

2
XC-F10
WARNING!
Lithium batteries. Danger of explo-
sion. Replacement must be done by
qualified personnel and only by fol-
lowing the instructions given in the
service manual.
This
warning is stated on the product or
in the operating instructions. When replac-
ing the lithium batteries, follow the note
below.
Dispose
of the used battery promptly.
Keep away from children. Do not disas-
semble and do not dispose of in fire.
The
battery used in this device may present
a fire or chemical hazard if mistreated. Do
not recharge,
disassemble, heat above
100°C or incinerate. Replace only with the
same Part Number. Use of another battery
may
present a risk of fire or explosion.
Note: The
lithium battery installation po-
sition is shown in the exploded views.
ADVARSEL!
Lithiumbatteri −Eksplosionsfare ved
fejlagtig håndtering. Udskiftning må kun
ske med batteri af samme fabrikat og
type. Levér det brugte batteri tilbage til
leverandøren.
Denne advarsel or angivet på produktet
eller i brugsvejledningen. Ved udskiftning
af lithium batterierne følges nedenstående
anveisning.
Batterierne
må kun udskiftes med batteri-
er af samme type og mærke.
1. SAFETY INFORMATION
LITHIUM BATTERY NOTICE
LABEL CHECK
1. Laser Interlock Mechanism
The position of the switch (S5907) for detecting loading
state is detected by the system microprocessor, and the
design prevents laser diode oscillation when the switch
(S5907) is not on CLOSE terminal side (CDO/C signal is
high level).
Thus, the interlock will no longer function if the switch
(S5907) deliberately set to CLOSE terminal side (low
level).
The interlock also does not function in the test mode∗.
Laser diode oscillation will continue, if pin 9 of TA2150FN
(IC1101) on the SELF-CHACK CD ASSY is connected to
GND, or pin 10 is connected to low level (ON), or else the
terminals of Q1101 are shorted to each other (fault
condition).
2. When the DOOR WINDOW is removed, close viewing of
the objective lens with the naked eye will cause exposure
to a Class 1 laser beam.
∗: Refer to page 29.
Additional Laser Caution
IMPORTANT
THIS PIONEER APPARATUS CONTAINS
LASER OF CLASS 1.
SERVICING OPERATION OF THE APPARATUS
SHOULD BE DONE BY A SPECIALLY
INSTRUCTED PERSON.
LASER DIODE CHARACTERISTICS
MAXIMUM OUTPUT POWER: 5 mW
WAVELENGTH: 780 – 785 nm

3
XC-F10
2.1 PACKING
2. EXPLODED VIEWS AND PARTS LIST
NOTES: •Parts marked by "NSP" are generally unavailable because they are not in our Master Spare Parts List.
•The mark found on some component parts indicates the importance of the safety factor of the part.
Therefore, when replacing, be sure to use parts of identical designation.
•Screws adjacent to mark on the product are used for disassembly.
•PACKING PARTS LIST
Mark No. Description Part No.
1 Front Pad M AHA7295
2 Rear Pad M AHA7296
3 Packing Case CD/ZVY AHD7894
4 Sheet Z23-026
5 Stand Note ARM7044
4
3
2 (1/2) 2 (2/2)
5
1
FRONT

4
XC-F10
2.2 EXTERIOR
A
A
C
B
B
D
D
C
56
62
56
52
32
60 6
69
69
8
2
69
69
13
69
20
61
54
72
69
6969
72
30
30
69
69
29 69
5
69
68 1
69
69
69
69
69
69
51
63
64
25
25 66 65
67
34(2/2)
47(1/4)
47(2/4)
47(4/4)
47(3/4)
34(1/2)
11
12
70
4958
58 57
9
3
50 55
43
35
69
42
4
24
22
38
18
15 19 26 2626
3627
69
33
69
69
69
69
69
69
53
69
69
17
23
21
37 39 40
41
69
69
69
10
28
16
59
45
14
44
69 71 46
7
48
31(1/2)
31(2/2)

5
XC-F10
•EXTERIOR PARTS LIST
Mark No. Description Part No. Mark No. Description Part No.
1 MAIN UNIT AWU7564
2 DISP UNIT AWU7565
3 MOTOR UNIT AWU7566
4 CD SW UNIT AWU7567
5 AUX UNIT AWU7568
6 KEY L UNIT AWU7569
7 LED UNIT AWU7570
8 KEY R UNIT AWU7625
9 SENS UNIT AWU7657
NSP 10 SELF-CHACK CD ASSY AWP7027
11 FM/AM TUNER MODULE AXQ7229
12 13P FFC/30V (J1) ADD7225
13 22P FFC/30V (J2) ADD7226
14 24P FFC/30V (J5) ADD7227
15 16P FFC/30V (J1101) ADD7245
16 CONNECTOR ASSY (J111) PF02PP2R05
17 Slider Motor VXM1033
18 CD Mecha KSM-770ABA
19 Float Spring ABH7191
NSP 20 Bottom Chassis CD ANA7107
21 Door Angle AL ANG7306
22 Door Angle AR ANG7307
23 Door Angle BL ANG7308
24 Door Angle BR ANG7309
25 Leg AEB7090
26 Float Rubber AEB7129
27 Belt AEB7171
NSP 28 Leg AEB7200
29 Barrier AEC7288
30 Chassis Sheet AEC7290
31 Mecha Holder AMR7311
32 FL Holder AMR7312
33 Reflector AMR7313
34 FFC Barrier AMR7314
35 Gear A ANW7063
36 Gear Pulley A ANW7066
37 Cam Base L ANW7196
38 Cam Base R ANW7197
39 Slide Cam A ANW7198
40 Slide Cam B ANW7199
41 Slide Cam C ANW7200
42 Slide Cam D ANW7201
43 Gear N ANW7203
44 Gear Holder ANW7205
45 Shaft Assy AXG7095
46 Motor Pulley PNW1634
47 Button CD AAD7581
48 Door Window A AAK7748
49 Door Window B AAK7749
50 Sub Panel CD AAK7755
51 Rear Cap CD AAK7758
52 FL Window CD AAK7773
53 Lens AAK7806
54 FL Cover AAK7841
55 Disc Lens AAK7847
56 Side Line AAP7074
57 Rear Line CD AAP7075
58 Screw ABA7061
59 PCB Spacer AEB7206
60 FL Filter AEC7273
61 Bottom Base CDMD AMA7017
62 Top Panel CD AMB7699
NSP 63 Name Label(Pap)CD/ZY AAL7250
64 Connector Label CD/E ARW7093
65 Caution Label PRW1018
66 Caution Label PRW1233
67 Caution Label VRW1094
68 Screw BBZ30P080FMC
69 Screw BPZ30P080FZK
70 Screw BPZ30P120FMC
71 Screw PMZ26P040FMC
72 Screw VBZ30P100FZK

XC-F10
6
A
B
C
D
1234
1234
SELF-CHACK
CD ASSY
(AWP7027)
B
FM/AM
TUNER MODULE
(AXQ7229)
A
C1/2, C2/2
MAIN UNIT (AWU7564)
C
AUX UNIT
(AWU7568)
D
IC1101
(TA2150FN)
IC1201
(TC9495F)
IC1301
(M56788FP)
RF AMP.
SERVO
DSP
D/A
DRIVER 25
85 9
38
IC3502
(BA4558F)
IC3503
(BA4558F)
IC3501
(BU4052BCF)
BALANCED
BUFFER(+)
BALANCED
AMP
FUNCTION
SW
VOLTAGE SUPPLY
for FL
BALANCED
BUFFER(-)
75
75
IC3504
(BA4558F)
3
1
IC5701
(BU1923F)
IC5501
(PDC061A)
RDS
µ-COM
13
15 14
11 12
Q3503
CD MUTE
IC502
V-9
V+9
V+9
V-9
V-5
FLAC
V-40
V+5
V+10
IC501 Q501
V+12
VE+5BU
VE+5
Q5501
D5503
IC551
Q551, Q552
D551-D556
4
2
6
3. BLOCK DIAGRAM AND SCHEMATIC DIAGRAM
3.1 BLOCK DIAGRAM

XC-F10
7
A
B
C
D
5678
5678
MOTOR UNIT
(AWU7566)
K
KEY R UNIT
(AWU7625)
H
KEY L UNIT
(AWU7569)
G
DISP UNIT
(AWU7565)
E
SENS UNIT
(AWU7657)
I
CD SW UNIT
(AWU7567)
J
LED UNIT
(AWU7570)
F
IC5652
(PDA5601A)
X5901
(GP1U27X)
D5912
(SIR-56ST3F)
DOOR OPEN CODE
INFRARED
SENSOR
V5651
(AAV7077)
IC5651
(MSM9202-01)
FL
DRIVER
FL
Note :When ordering service parts, be sure to refer to "EXPLODEDVIEWS and PARTS LIST" or "PCB PARTS LIST".

XC-F10
8
A
B
C
D
1234
1234
A
3.2 FM/AM TUNER MODULE
FM FRONT END
MW RF TUNING BLOCK
FM/AM TUNER MODULE (AXQ7229)
A
OSC : 981 - 2052kHz 9k step
(AM)
(AM)
(AM)
(AM) (AM) (AM)
(FM)
(FM) (FM)
(FM)
(FM)
(FM)
(FM) (FM)
(FM)
(FM)

XC-F10
9
A
B
C
D
5678
5678
A
1/2
C
CN1
L201
ATE7003
: AUDIO SIGNAL ROUTE (TUNER)
(TX)
: AM SIGNAL ROUTE
(AM)
: FM SIGNAL ROUTE
(FM)
(AM)
(AM)
(FM)
(AM) (AM)
(AM)
(AM)
(AM)
(AM)
(FM)
(AM)
(FM)
(TX)
(TX) (TX)
(TX)
(TX)
(FM)
: The power supply is shown with the marked box.

XC-F10
10
A
B
C
D
1234
1234
1
2
VC
SELF-CHACK
CD ASSY
(AWP7027)
B
To CD PICK UP To CD MECHA CN111
K
(T)
(T)
(F)
(F)
(L)
(L)
(S)
(S)
(C)
(C)
(F)
(T)
(T)
(T)
(F)
(T)
(T)
(L)
(C)
(L)
(S)
(S)
(C)
(F)
(T)
(C)
(L)
(T)
(S)
(S)
(F)
(F)
(T)
(F)
(C)
DRIVER
RF AMP
3.3 SELF-CHACK CD ASSY
B
