Hatco GR2A-18 User manual

Hatco Glo-Ray Designer Infrared
Foodwarmers safely keep all hot foods
at optimum serving temperatures longer.
Foods do not dry out or become
discolored; even delicate dishes hold
that “just-prepared” look. The Glo-Ray
pre-focused heat pattern directs heat
from a tubular element to bathe the
entire holding surface.
FLEXIBILITY
The continuous aluminum housings, up to
88" (2235 mm) in width, are very strong
and eliminate the danger of sagging.
Optional breath protectors that meet
NSF standards can be ordered for
display areas and buffet lines. Made of
shatterproof, easy-to-clean acrylic, they
provide a safe food-serving environment.
The advanced Glo-Ray Dual Mounting
feature allows side-by-side mounting
of two warmers to provide a deeper
holding area. A 3" or 6" (76 or 152 mm)
spacer is available, as well as
shatter-resistant incandescent lights
that illuminate the warming area.
Remote control installation is mandatory
on all Designer foodwarmers.
Remote control enclosures are available
in several sizes, built in accordance
with UL standards to accommodate
switches, indicator lights and wiring,
ready for installation.
Designer color foodwarmer and inset
panels allow the unit to match the
surrounding décor. The powdercoated
surfaces provide durability and are easy
to clean.
QUALITY
The following features assure the finest
performance for years to come:
• Available in widths from 22" to 88"
(559-2235 mm).
• Sturdy continuous aluminum housings
eliminate sagging.
• Pre-focused heat maintains safe
serving temperatures longer without
continuing to cook the food.
• Variety of models, configurations,
colors and accessories provide
unlimited flexibility.
• Optional coated shatter-resistant
incandescent lights enhance brilliant
product display while safeguarding
food from bulb breakage.
METAL SHEATHED ELEMENTS GUARANTEED AGAINST
BURNOUT AND BREAKAGE FOR TWO YEARS.
Model GR2AH-24
Model GR2AHL-24D with
optional breath protectors
ITEM#
GLO-RAY ® DESIGNER INFRARED FOODWARMERS
Models GR2A-18, -24, -30, -36, -42, -48, -54, -60, -66, -72, -84 GR2AH-18, -24, -30, -36, -42, -48, -54, -60, -66, -72, -84
GR2A-18D, -24D, -30D, -36D, -42D, -48D, -54D, -60D, -66D, -72D, -84D GR2AH-18D, -24D, -30D, -36D, -42D, -48D, -54D, -60D, -66D, -72D, -84D
Model GR2AL-36 with Designer
legs for hanging installations
Model RMB-14D
with infinite controls
Model RMB-3F
with toggle
switch and
indicator light
Remote Control Enclosures
HATCO CORPORATION P.O. Box 340500 Milwaukee, WI 53234-0500 U.S.A.
[phone] • [phone] • Fax [phone] • Int’l. Fax [phone]
www.hatcocorp.com • E-mail: [email protected]
Form No. GR2A Spec Sheet
Printed in U.S.A.
April 2007
Model RMB-7D with
optional Designer color

DIMENSIONS
GR2A & GR2AH: 22"-88"W x 9"D•x 31⁄2"H without legs
(559-2235 x 229 x 89 mm).
GR2A-XXD & GR2AH-XXD: 22"-88"W x 18" or 21"D x 31⁄2"H
without legs (559-2235 x 457 or 533 x 89 mm).
• Add 3" (76 mm) to depth for models with lights.
VOLTAGE
120, 208 and 240 volts, single phase.
Models with Lights: 120, (3-wire),120/208 and 120/240 volts,
single phase, (4-wire). Export voltages available.
PRODUCT SPECS
Designer Infrared Foodwarmer
The Designer Infrared Foodwarmer shall be a Glo-Ray®,
manufactured by the Hatco Corporation, Milwaukee, WI
53234 U.S.A.
With 24/7 service (U.S. and Canada only), the Foodwarmer shall
be a Glo-Ray Model ...., rated at ....watts, ....volts, single phase
and be ....inches (millimeters) in overall width.
The Glo-Ray shall consist of an aluminum housing and include
as standard equipment 14" (356 mm) Designer legs.
HATCO CORPORATION P.O. Box 340500 Milwaukee, WI 53234-0500 U.S.A. • [phone] • [phone]
Fax [phone] • Int’l. Fax [phone] • www.hatcocorp.com • E-mail: [email protected]
Printed in U.S.A.
Form No. GR2A Spec Sheet April 2007
OPTIONS (NOT FOR RETROFIT)
❑Unit and Inset Panel Designer Colors: Warm Red, Black,
Gray Granite, White Granite, Navy Blue, Hunter Green
❑Dark Gray Designer Corner Caps (Black is standard)
❑Breath Protectors – 71⁄2" or 14" (191 or 356 mm)
High Watt Standard Watt
Model Watt Model Watt Width Shipping Weight
■
GR2AH-18 350 GR2A-18 250 22" ( 559 mm) 28 lbs. (12 kg)
GR2AH-24 500 GR2A-24 350 28" ( 711 mm) 32 lbs. (15 kg)
GR2AH-30 660 GR2A-30 450 34" ( 864 mm) 35 lbs. (16 kg)
GR2AH-36 800 GR2A-36 575 40" (1016 mm) 37 lbs. (17 kg)
GR2AH-42 950 GR2A-42 675 46" (1168 mm) 53 lbs. (25 kg)
GR2AH-48 1100 GR2A-48 800 52" (1321 mm) 64 lbs. (29 kg)
GR2AH-54 1250 GR2A-54 925 58" (1473 mm) 74 lbs. (34 kg)
GR2AH-60 1400 GR2A-60 1050 64" (1626 mm) 82 lbs. (37 kg)
GR2AH-66* 1560 GR2A-66 1160 70" (1778 mm) 91 lbs. (41 kg)
GR2AH-72* 1725 GR2A-72 1275 76" (1930 mm) 100 lbs. (45 kg)
GR2AH-84*
▲
2050 GR2A-84 1500 88" (2235 mm) 120 lbs. (54 kg)
The infrared heating element shall be tubular metal sheathed.
The foodwarmer shall be factory assembled ready for
electrical installation.
Options shall include Designer non-adjustable tubular legs in
various sizes, hanger legs, dark gray Designer corner caps,
breath protectors, lights, and remote control enclosure.
SPECIFICATIONS
High Watt Dual Standard Watt Dual
Model Watt Model Watt Width Shipping Weight
■
GR2AH-18D 700 GR2A-18D 500 22" ( 559 mm) 44 lbs. (20 kg)
GR2AH-24D 1000 GR2A-24D 700 28" ( 711 mm) 48 lbs. (22 kg)
GR2AH-30D 1320 GR2A-30D 900 34" ( 864 mm) 52 lbs. (24 kg)
GR2AH-36D 1600 GR2A-36D 1150 40" (1016 mm) 57 lbs. (26 kg)
GR2AH-42D 1900 GR2A-42D 1350 46" (1168 mm) 66 lbs. (30 kg)
GR2AH-48D 2200 GR2A-48D 1600 52" (1321 mm) 77 lbs. (35 kg)
GR2AH-54D 2500 GR2A-54D 1850 58" (1473 mm) 88 lbs. (40 kg)
GR2AH-60D 2800 GR2A-60D 2100 64" (1626 mm) 97 lbs. (44 kg)
GR2AH-66D* 3120 GR2A-66D 2320 70" (1778 mm) 107 lbs. (49 kg)
GR2AH-72D* 3450 GR2A-72D 2550 76" (1930 mm) 117 lbs. (53 kg)
GR2AH-84D*
▲
4100 GR2A-84D 3000 88" (2235 mm) 138 lbs. (63 kg)
REMOTE CONTROL ENCLOSURES
Model Width Toggle Switches
RMB-3 51⁄2" (140 mm) 2 Maximum
RMB-7 9" (229 mm) 4 Maximum
RMB-14 14" (356 mm) 6 Maximum
RMB-16 16" (406 mm) 3 Maximum
RMB-20 20" (508 mm) 3 Maximum
NOTE: ONE CONTROL BOX PER FOODWARMER.
ITEM#
GLO-RAY ® DESIGNER INFRARED FOODWARMERS
Models GR2A-18, -24, -30, -36, -42, -48, -54, -60, -66, -72, -84 GR2AH-18, -24, -30, -36, -42, -48, -54, -60, -66, -72, -84
GR2A-18D, -24D, -30D, -36D, -42D, -48D, -54D, -60D, -66D, -72D, -84D GR2AH-18D, -24D, -30D, -36D, -42D, -48D, -54D, -60D, -66D, -72D, -84D
18" or 21"
(457-533 mm)
SIDE VIEW
22" to 88"
(559 to 2235 mm)
18" to 84"
(457 to 2134 mm)
(Width minus 4" (102 mm))
131⁄4", 151⁄4",
171⁄4" or 191⁄4"
(337, 387,
438, 489 mm)
9"
(229 mm)
31⁄2" (89 mm)
FRONT VIEW SIDE VIEW
60" (1524 mm)
flexible metal
conduit through
post
❑Designer Non-Adjustable Stands 10", 12", 16" (254, 305,
406 mm) Height in lieu of Standard 14" (356 mm) Stands
❑4" (102 mm) Designer Overhead Mounts
❑Halogen Bulbs in lieu of Standard Display Lights
* 120 volt models with infinite switch require tandem (end-to-end) elements.
▲120 volt models of GR2AH-84 and GR2AH-84D contain tandem elements
individually controlled.
■Does not include RMB.
Dual ModelsStandard Models
MOUNTING REQUIREMENTS
Recommended Mounting Height –
Single Infrared Foodwarmer Models
Standard Watt: 10"-12" (254-305 mm)
High Watt: 12"-14" (305-356 mm)
Dual Infrared Foodwarmer Models
Standard Watt: 10"-14" (254-356 mm)
High Watt: 14"-16" (356-406 mm)
MINIMUM SPACING –
May not be installed in combustible surroundings.
Must be installed no closer than 6" (152 mm) from a non-
combustible back wall and above a non-combustible surface.
