Pitco SSHLV Series User manual

Solstice Gas ROV Fryers
SSHLV Series
Service Manual
RETAIN AND STORE THIS MANUAL IN A SAFE PLACE FOR FUTURE USE
L22-392 R1 (10/14)

Pitco SSHLV (ROV) Gas Fryers
!
DANGER
!
Improper installation, operation, adjustment, maintenance, all alterations or service, and unauthorized
alterations or modifications can cause property damage, injury or death. Read the installation, operating
and service manuals thoroughly before installing or servicing this equipment.
!WARNING !
DO NOT supply the appliance with a gas that is not indicated on the data plate. If conversion of the
appliance is required, contact your dealer or authorized service agent.
!DANGER !
Only qualified service personnel may service or convert this appliance to use a gas other than that for
which it was originally manufactured. Improper conversion can lead to property damage, injury or death.
!DANGER !
Prior to moving, testing, maintaining or repairing your appliance, ensure it is emptied of all oil, cool,
disconnected from gas and all electrical power. Failure to do so may result in property damage, damage
to your fryer, injury or death.
!
DANGER
!
No structural material on the fryer should be altered or removed to accommodate placement of the fryer
under a hood, or any other reason. Unauthorized modifications could cause improper combustion and
excess heat, causing property damage, injury and death.
!
DANGER
!
Adequate means must be provided to limit the movement of this appliance without depending on the gas
line. Single fryers equipped with legs must be stabilized by installing anchor straps. All fryers equipped
with casters must be stabilized by installing restraining lanyards. If a flexible gas line is in use, an
additional restraining lanyard must be connected at all times when the fryer is in use. The restraining
cable must NOT exceed 80% of the length of the flexible gas line. Failure to do so may result in ruptured
gas lines and property damage, injury and death.
!DANGER !
DO NOT sit or stand on this appliance. The appliance’s top deck, door, front panel, tank, splash
back, tank cover, workshelf, drain board are not steps. Serious injury will result from slipping,
falling or contact with hot liquids causing property damage, injurious severe burns and/or death.
!
DANGER
!
NEVER use the appliance as a step for cleaning or accessing the ventilation hood. Serious
injury will result from slipping, falling or contact with hot liquids causing property damage,
injurious severe burns and/or death.
!
DANGER
!
Do not store or use gasoline, store or spray aerosols or other flammable liquids or vapors in the vicinity
of this or any other appliance. Appliances incorporate open flames and/or high heat that will ignite
flammable vapors causing property damage, injury and death.
L22-392 R1 2

Pitco SSHLV (ROV) Gas Fryers
!
DANGER
!
Instructions to be followed, in the event an operator smells/detects a gas leak, must be posted in a
prominent location. This information can be obtained from your local gas company or supplier. Failure to
post the instructions could leave an active gas leak unresolved, leading to fire, property damage, injury
and death.
!
DANGER
!
The contents of the crumb catch and/or filter pan of any filter system must be emptied into a
fireproof container at the end of the frying operation each day. Some food particles can
spontaneously combust into flames if left soaking in certain oil/shortening materials,causing
fire, property damage, injury and death.
!DANGER !
Any and all spilled oil, water or other liquids that occurs as a result of operation, cleaning, maintenance
or repair of this fryer should immediately be cleaned and dried. Failure to do so can create a slippery
surface resulting in falling/impact injury or death.
!
DANGER
!
Check for gas leaks after installation or servicing of a gas fryer. Apply a leak detection solution to all
connections and joints to ensure there are no bubbles or leaks. Failure to check for and correct any leaks
could lead to fire and/or explosion, property damage, injury and death.
!WARNING !
DO NOT use the filter pan to transport oil, hot or cold. The filter pan is not designed to transport oil.
Serious injury will result from slipping, falling or contact with hot liquids causing property
damage, injurious severe burns and/or death.
!
WARNING
!
DO NOT remove frypot fittings before all oil is drained from the tank. Serious injury will result from
slipping, falling or contact with hot liquids causing property damage, injurious severe burns and/or
death.
!
WARNING
!
For appliances equipped with manual (opposed to automated) filtration, shut down the appliance
completely when the shortening, fat or oil is being drained from the appliance. This will prevent the
appliance inadvertently heating up during the draining and filtering process.
!
WARNING
!
This appliance must be installed and used in such a way that any water cannot contact the fat or oil.
Water will react violently with hot fat or oil causing severe burns, injury or death.
!
WARNING
!
Keep all items and hands out of drains. Automated actuators may close without notice causing damage to
the fryer and personal injury.
!
WARNING
!
This appliance is NOT jet stream approved. Do not clean the appliance with a water jet. Use of any
pressurized water jet will cause damage to the fryer and personal injury.
L22-392 R1 3

Pitco SSHLV (ROV) Gas Fryers
!
WARNING
!
This appliance is intended for indoor use only. Do NOT use outdoors.
!
WARNING
!
This appliance is not intended for use by persons (including children) with reduced physical, sensory or
mental capabilities, or lack of experience and knowledge. Property damage, personal injury or death can
result from unqualified operators.
!CAUTION !
Use caution and wear appropriate safety equipment to avoid contact with hot oil or surfaces. Hot oil and
surfaces can cause severe burns and injury.
!
CAUTION
!
Do not bang fry baskets or other utensils on the joining strips between batteried fry pots. Banging
frybaskets or any other utensil on the joining strip will distort and promote oil migration inside the fryer.
!
CAUTION
!
NEVER run water through the filter pump. Water will damage the pump seals and render the pump
inoperable/ It will also void the warranty on the filter pump.
NOTE
Some US states require any gas appliance to be installed by a state licensed plumber or pipe fitter. Check
with your local municipality prior to installation.
NOTE
This equipment must be installed in accordance with appropriate local and national codes in the state,
country and/or region in the appliance is to be operated. Contact your local gas authority for guidance.
NOTE
This equipment is to be installed in compliance with the basic plumbing code of the Building Officials and
Code Administration International (BOCA) and the Food Service Sanitation Manual of the U.S Food and
Drug Administration.
NOTE
Photos and drawings used in this manual are intended to illustrate operational, cleaning and technical
procedures and may not conform to onsite management operational procedures.
NOTE
This appliance is intended to be used for commercial applications: For example in kitchens of
restaurants, canteens, hospitals and in commercial enterprises such as bakeries, butcheries, etc. but
NOT for continuous mass production of food.
NOTE
This appliance is intended for professional use only and is to be operated by qualified, trained personnel
only. A Pitco Authorized Service Agent (ASA) or other qualified professional must perform installation,
maintenance and repairs. Installation or repairs by unqualified personnel will void the manufacturer’s
warranty. See chapter one for descriptions of qualified personnel.
L22-392 R1 4

Pitco SSHLV (ROV) Gas Fryers
NOTE
If, during the warranty period, the end user uses a part for this Pitco appliance other than an UNMODIFIED
new part purchased directly from Pitco or any of Pitco’s authorized service agents, and/or the part being
used is modified from its original configuration, THE WARRANTY WILL BE VOID. Further, Pitco Frialator
and its affiliates will not be liable for any claims, damages or expenses incurred by the customer which
arise directly or indirectly, in whole or in part, due to the installation of any modified part and/or part
received from an unauthorized servicer/supplier.
1 Notice
In the event of problems or questions about your order, contact the Pitco Frialator factory at
[phone].
For non-routine maintenance or repairs, or for service information, contact your local Pitco Frialator
Authorized Service and Parts representative (ASAP). In order to assist you quickly,your Pitco Frialator
ASAP or Service Department representative requires certain information about your equipment. Most of
this information is printed on a data plate affixed to the inside of the fryer door. Part numbers are found
in the Service and Parts Manual. Parts orders may be placed directly with your local ASAP or
distributor. A list of Pitco Factory Authorized Service and Parts is located on the Pitco Frialator website
at www.pitco.com. If you do not have access to this list, contact the Pitco Frialator Service Department
at [phone] or by email at:
Literature Fulfillment (brochures, spec sheets, manuals)
[email protected]
Non-urgent service parts inquires. i.e. (part numbers or reference information)
[email protected]
Non-urgent technical service questions
[email protected]
Non-urgent warranty questions
[email protected]
MAILING ADDRESS
Pitco Frialator
P.O. Box 501
Concord, NH 03302-0501
SHIPPING ADDRESS
Pitco Frialator
10 Ferry Street
Concord, NH 03301
EQUIPMENT REFERENECE INFORMATION
Model #: __________________________
Serial #: __________________________
Date Purchased: ___________________
L22-392 R1 5

Pitco SSHLV (ROV) Gas Fryers
TABLE OF CONTENTS
1Notice ...........................................................................................................................................5
2General.........................................................................................................................................8
2.1 Serial Numbers......................................................................................................................9
2.2 Safety Information...............................................................................................................10
2.2.1 Installation, Operating, and Service Personnel ...............................................................10
2.3 Definitions............................................................................................................................10
2.3.1 Qualified and/or Authorized Operating Personnel...........................................................10
2.3.2 Qualified Installation Personnel.......................................................................................10
2.4 Shipping Damage Claim Procedure....................................................................................11
3Theory of Operation..................................................................................................................11
3.1 The Matchless Ignition System ...........................................................................................11
3.2 Auto Filtration Boards..........................................................................................................12
3.3 Thermostats ........................................................................................................................14
3.4 Fryer Sequence Operation..................................................................................................14
3.5 Heating System...................................................................................................................14
3.6 Safety System.....................................................................................................................15
3.7 Filter System (Manual Filtration Only).................................................................................15
3.8 Basket Lift (Optional)...........................................................................................................16
3.9 Auto Top Off – ATO (Optional)............................................................................................16
3.10 Automated Filtration (Optional) ...........................................................................................17
4Accessing Fryer for Servicing .................................................................................................18
5Replacing the Controllers ........................................................................................................19
5.1 Removing the Controller Front Panel Bezel........................................................................19
6Manual Operation of Drain and Return (Auto Filter Only).....................................................20
7Blocked Drain (Auto Filter Only)..............................................................................................21
7.1 Replacing the Relay Board and Paper................................................................................22
8Checking Resistance................................................................................................................23
8.1 Checking the Resistance of the Transformer......................................................................23
8.2 Diagram Identifying Terminals for Second Resistance .......................................................24
8.3 Checking the Resistance of the DVI Switch........................................................................24
8.4 Checking the Resistance of the Hi-Limit .............................................................................25
8.5 Checking the Resistance of the Temperature Probe ..........................................................26
9Replacing Temperature Probe.................................................................................................27
10 Replacing the Ignition Module and Hi-Limit ...........................................................................29
11 Replacing an Igniter/Pilot Assembly.......................................................................................30
12 Replacing Drain Valve with Actuator (Auto Filter Only)........................................................31
13 Replacing the DC Power Supply..............................................................................................33
14 Replacing Transformer/Power Box .........................................................................................34
15 Changing Filter Pump Actuator...............................................................................................35
16 Testing the Auto Top Off Probe (if equipped) ........................................................................36
17 Replacing the Auto Top Off Probe (If equipped)....................................................................38
18 Gas Conversion.........................................................................................................................40
19 Replacing the Return Valve......................................................................................................41
20 Replacing the Optional Flush Hose Assembly and Valve.....................................................42
21 Replacing the Waste Oil and Components.............................................................................45
21.1 Removing Rear Mounting Bracket ......................................................................................45
21.2 Removing the Check Valve.................................................................................................46
22 Removing the Filter Pump from the Motor .............................................................................48
22.1 Replacing Seal Kit...............................................................................................................48
23 Replacing the Drain Line or Gasket ........................................................................................49
L22-392 R1 6

Pitco SSHLV (ROV) Gas Fryers
24 Replacing the Pump Relay and Circuit Breaker.....................................................................50
24.1 Replacing the Circuit Breaker..............................................................................................50
24.2 Replacing the Pump Relay..................................................................................................51
25 Cleaning the Gas Valve Vent Tube..........................................................................................52
26 Checking the Gas Pressure .....................................................................................................53
26.1 Taking a Supply Gas Pressure Reading.............................................................................53
26.2 Taking a Manifold Gas Pressure Reading...........................................................................55
26.3 Adjusting Manifold Gas Pressure........................................................................................56
26.4 Adjusting Pilot Flame...........................................................................................................56
27 Replacing the Self-Cleaning Burner Solenoid........................................................................57
28 Replacing the Gas Valve ..........................................................................................................58
29 Replacing the DVI Switch (Manual Filter Only).......................................................................60
30 Replacing the Burner Assembly..............................................................................................61
30.1 Replacing the Burner(s) ......................................................................................................61
30.2 Replacing the Burner Assembly..........................................................................................63
31 Replacing the Frypot ................................................................................................................64
32 Replacing the Basket Lift Components ..................................................................................68
32.1 Removing the Basket Lift Cover..........................................................................................68
32.2 Replacing the Basket Lift Transformer................................................................................68
32.3 Replacing the Basket Lift Driver Board ...............................................................................69
32.4 Adjusting the Magnetic Sensor............................................................................................70
32.5 Replacing the Basket Lift Actuator......................................................................................70
33 Replacing the Filter Pump and Motor......................................................................................72
33.1 Removing the Filter Pump and Motor..................................................................................72
34 Information Charts/Tables........................................................................................................75
34.1 Temperature Probe Resistance Chart.................................................................................76
34.2 Orifice Size Chart................................................................................................................77
34.3 Orifice Size at Sea Level Chart...........................................................................................78
35 Simplified Wiring Diagrams .....................................................................................................79
35.1 Wiring Diagram – Heat Control Wiring Left & Right (ROV) .................................................79
35.2 Wiring Diagram – Auto Filter Board (AFB2) Wiring (ROV)..................................................80
35.3 Wiring Diagram – Connector Locations Detail AFB2 W/Jib & No Bulk Oil Option (ROV) ...81
35.4 Wiring Diagram – Calibration Test Points and Indicators (ROV).........................................82
35.5 Wiring Diagram – AC & DC Control Voltage Supplies (ROV) ............................................83
35.6 Wiring Diagram – Basket Lift Option & Connector Locations (ROV)..................................84
35.7 Wiring Diagram – Filter Pump Options 208V-240V (ROV).................................................85
35.8 Wiring Diagram – Full Vat with SCB....................................................................................86
35.9 Wiring Diagram – Basket Lifts.............................................................................................87
35.10 Wiring Diagram – Filter Motor 115V-60Hz.......................................................................88
35.11 Wiring Diagrams – Filter Motor 208-240V.......................................................................89
L22-392 R1 7

Pitco SSHLV (ROV) Gas Fryers
2 General
Read the instructions in this manual thoroughly before attempting to operate this equipment. This
manual covers all configurations of Pitco SSHLV gas models. The fryers in this model family have most
parts in common, and when discussed as a group, will be referred to as SSHLV fryers.
The SSHLV fryers feature a low oil volume frying vat, optional automatic oil top off and optional
automated filtration unit. The Solstice design features a large round drain, which ensures that fries and
other debris will be washed into the filter pan. The SSHLV fryers are controlled with an I12 + Controller.
Fryers in this series come in full- or split-vat arrangements, and can be purchased in batteries of up to
five fryers.
L22-392 R1 8

Pitco SSHLV (ROV) Gas Fryers
2.1 Serial Numbers
NOTE
If, parts returned to the factory under warranty are found to be a functional/serviceable, Pitco may, at its
discretion, decline warranty reimbursement and may charge for replacement parts.
L22-392 R1 9

Pitco SSHLV (ROV) Gas Fryers
2.2 Safety Information
Before attempting to install, operate or service your unit, read the instructions in this manual thoroughly.
Throughout this manual, you will find notations enclosed in shaded boxes similar to the one below.
Clean up any spilled oil or shortening immediately. Oil or shortening left on the floor creates a
slipping hazard that will result in personal injury sustained from falling.
NOTE boxes contain especially important information.
CAUTION boxes contain information about actions or conditions that may cause or result in a
malfunction of your system and/or minor personal injury.
WARNING boxes contain information about actions or conditions that may cause or result in damage
to your system and/or moderate personal injury, and which may cause your system to malfunction.
DANGER boxes contain information about actions or conditions that may cause or result in serious
injury or death to personnel, and which may cause damage to your system and/or cause your system
to malfunction.
2.2.1 Installation, Operating, and Service Personnel
Operating information for Pitco equipment has been prepared for use by qualified and/or authorized
personnel only, as defined in Section 2.3. All installation and service on Pitco equipment must be
performed by qualified, certified, licensed, and/or authorized installation or service personnel,
as defined in Section 2.3.2.
2.3 Definitions
2.3.1 Qualified and/or Authorized Operating Personnel
Qualified/authorized operating personnel are those who have carefully read the information in this
manual and have familiarized them themselves with the equipment functions, or who have had previous
experience and/or training with the operation of the equipment covered in this manual.
2.3.2 Qualified Installation Personnel
Qualified installation personnel are individuals, firms, corporations, and/or companies which, either in
person or through a representative, are engaged in and are responsible for the installation of electrical
appliances. Qualified personnel must be experienced in such work, be familiar with all electrical
!DANGER !
!
CAUTION
!
!WARNING !
!DANGER !
NOTE
L22-392 R1 10
