INSTALLATION, OPERATION & MAINTENANCE
INSTRUCTIONS
ELECTRIC HEATING UNITS
MODEL: ETA / EKI

Operating
Instructions for
Electrical Heater Units
PITSAN
Page 2 / 16
PİTSAN MAK. SAN. VE TİC. LTD ŞTİ, Esenyurt Yolu Üzeri No: 66 - 68 Bağlar Mevkii, TR – 34850 Avcılar - İSTANBUL
Tel.: [phone], Fax: [phone], Email:[e-mail], http: //www.pitsan.com
CONTENTS
1 GENERAL..........................................................................................................3
2 SAFETY .............................................................................................................3
2.1 Safety instructions ...................................................................................3
2.2 Correct use..............................................................................................3
3 DESCRIPTION OF THE UNIT..............................................................................5
4 OPERATING PRINCIPLE.....................................................................................7
5 APPLICATION AND INTENDED USE..................................................................7
6 PACKAGING, HANDLING, STORAGE................................................................8
7 COMMISSIONING................................................................................................8
7.1 Installation................................................................................................8
7.2 Wiring and electric diagrams....................................................................9
7.3 Start up and controls..............................................................................12
7.4 Operation...............................................................................................12
8 SPARE PARTS....................................................................................................12
9 MAINTENANCE AND REPAIRS.........................................................................13
10 POSSIBLE PROBLEM CAUSES AND SOLUTIONS.........................................14
11 WARRANTY........................................................................................................15
12 APPENDIX...........................................................................................................16

Operating
Instructions for
Electrical Heater Units
PITSAN
Page 3 / 16
PİTSAN MAK. SAN. VE TİC. LTD ŞTİ, Esenyurt Yolu Üzeri No: 66 - 68 Bağlar Mevkii, TR – 34850 Avcılar - İSTANBUL
Tel.: [phone], Fax: [phone], Email:[e-mail], http: //www.pitsan.com
1 GENERAL
Always read the Safety Instructions chapter of these operating instructions before putting the
heater into operation.
Even loss of life and loss of property can result from nonobserving the following instructions or
the valid national and international safety regulations.
Installation, electrical connection, commissioning and maintenance are only to be carried out
by authorised personnel and in accordance with requirements and current legislation. There
should be enough space provided for a safe working on service and maintenance.
2 SAFETY
2.1 Safety instructions
Caution: To avoid possible electrical shock, ensure the power is turned off before attempting
to wire. All wiring must be in accordance with local electrical codes. This equipment requires a
ground as precaution against electrical shock.
Basic precautions should always be followed to reduce the risk of fire, electric shock, and
injury to persons.
- Disconnect all power supplies before working on circuit.
- Do not heat air containing combustible materials.
- Mount heater out of reach.
- Install at least 2ft. (61 cm) from fl oor except 40 - 60 kW at least 8 ft. (2.4 m) from fl oor.
- Do not use outdoors.
- Do not insert or allow foreign objects to enter any ventilation or exhaust opening as this may
cause an electric shock or fire, or damage the heater.
- Do not block air intakes or exhaust in any manner.
- Heater contains arcing and sparking parts. Do not use it in areas where gasoline, paint, or fl
ammable liquids are used or stored.
- Use this heater only as described in this manual. Any other use not recommended by the
manufacturer may cause fire, electric shock, or injury to persons.
- Connect only to the voltage and frequency specified on the nameplate.
- Wire used to connect to the heater should have insulation rated to at least 75°C.
- Connections are to be made as shown on the wiring diagram

Operating
Instructions for
Electrical Heater Units
PITSAN
Page 4 / 16
PİTSAN MAK. SAN. VE TİC. LTD ŞTİ, Esenyurt Yolu Üzeri No: 66 - 68 Bağlar Mevkii, TR – 34850 Avcılar - İSTANBUL
Tel.: [phone], Fax: [phone], Email:[e-mail], http: //www.pitsan.com
- Check out the fuses carefully. Beware of the sufficient power and amperage.
- A disconnecting means and ground must be provided in accordance with the National
Electrical Code.
- An optional integral thermostat may be installed to control heating element and fan. If so
equipped, the thermostat range is approximately 55°F to 105°F.
- Check out the contactor if it is working properly in threephase models.
Hot Furface: The surface temperature of the heater may rise up to temperatures which will
cause inquiry. Do not touch the surface while the heater is operating. In case of maintenance
or contact must, wait at least 2 hours after the unit is disconnected for the unit cool down .
2.2. Correct use
Heater will not operate.
• Make sure installation instructions and wiring diagram were followed.
• Disconnect switch or main circuit breaker may be in off position.
• Check for proper control voltage.
• Automatic or manual reset thermal cutout(s) may have opened due to overheating. Let unit
cool before resetting manual cutouts. Determine and correct the cause for overheating.
The unit is designed for heating air in closed areas. Do not intent to use the unit for other
applications.

Operating
Instructions for
Electrical Heater Units
PITSAN
Page 5 / 16
PİTSAN MAK. SAN. VE TİC. LTD ŞTİ, Esenyurt Yolu Üzeri No: 66 - 68 Bağlar Mevkii, TR – 34850 Avcılar - İSTANBUL
Tel.: [phone], Fax: [phone], Email:[e-mail], http: //www.pitsan.com
3 DESCRIPTION OF THE UNIT
ETA- ELECTRICAL UNIT HEATERS MODELS

Operating
Instructions for
Electrical Heater Units
PITSAN
Page 6 / 16
PİTSAN MAK. SAN. VE TİC. LTD ŞTİ, Esenyurt Yolu Üzeri No: 66 - 68 Bağlar Mevkii, TR – 34850 Avcılar - İSTANBUL
Tel.: [phone], Fax: [phone], Email:[e-mail], http: //www.pitsan.com
EKI - DUCT TYPE ELECTRICAL HEATER MODELS

Operating
Instructions for
Electrical Heater Units
PITSAN
Page 7 / 16
PİTSAN MAK. SAN. VE TİC. LTD ŞTİ, Esenyurt Yolu Üzeri No: 66 - 68 Bağlar Mevkii, TR – 34850 Avcılar - İSTANBUL
Tel.: [phone], Fax: [phone], Email:[e-mail], http: //www.pitsan.com
4 OPERATING PRINCIPLE
COMPONENTS
• LOUVERS: Louvers are discharge air deflectors, either adjustable or nonadjustable, that
change or route the air flow
• HEATING COIL: convert electrical energy to heat by passing electrical current through a
specifically designed resistance wire. Constructed of spiral wound resistance wire, surrounded
by an insulating power , encased in a metal enclosure. Either Monophase or Threephase
types can be provided upon by request.
• FAN (FAN BLADE): is a propeller type device, used to move the air through the unit heater.
Unit heaters discussed in this manual are directly coupled to an electric motor. They are not
belt driven.
• MOTOR:are permanently lubricated electrical devices that rotate the fan to move the heated
air from the heater to the space. When the unit heater wattage is over loaded one or more
CONTACTORS are employed to switch the electrical current to the elements and / or
the motor. Usually a thermostat or fan delay will control when the contactor is energized.
• OVER TEMPERATURE LIMIT: is a normally closed temperature sensing device, located on
or in close proximity to the element, designed into the heater to open f an abnormally hot
condition occurs. Abnormally hot conditions are usually the result of a loss of moving air
across the element. Frequent causes of over temperature limit opening are; blocked inlet or
discharge, motor stoppage and loose fan.
5 APPLICATION AND INTENDED USE
The units are designed for heating air in closed areas. Heaters can be mounted for horizontal
or vertical air flow.
Typical Application Areas:
Factories
Warehouses
Garages
Stores
Power Stations and Aircraft Hangers
Agricultural Barns
Green Houses
Industrial assembly areas
Enclosed outside smoking areas.
Wall type or ceiling mounting bracket for horizontal or vertical air flow or any position
between.

Operating
Instructions for
Electrical Heater Units
PITSAN
Page 8 / 16
PİTSAN MAK. SAN. VE TİC. LTD ŞTİ, Esenyurt Yolu Üzeri No: 66 - 68 Bağlar Mevkii, TR – 34850 Avcılar - İSTANBUL
Tel.: [phone], Fax: [phone], Email:[e-mail], http: //www.pitsan.com
- Do not heat air containing combustible materials
- Do not use outdoors
- Heater contains arcing and sparking parts. Do not use it in areas where
gasoline, paint, or fl ammable liquids are used or stored.
- Use this heater only as described in this manual. Any other use not
recommended by the manufacturer may cause fire, electric shock, or injury to persons.
6 PACKAGING, HANDLING, STORAGE
The units are packed in carton boxes and made ready for shipments on pallets. It is
essential that great care is exercised when handling the unit. When handling the equipment,
care should be taken with corners and edges and that the weight distribution within the unit is
considered.
The units should be stored indoors away from humidity.
7 COMMISSIONING
For the first-commissioning it is recommended to use our specialist personnel
7.1. Installation
HEATER LOCATION: Unit heaters should be located along outside walls to provide
perimeter air circulation. The discharge air should wipe the walls without blowing directly on
them.
a. Small rooms - can be heated by one or two units. Locate the unit heater(s) to provide
circular air movement within the space.
b. Large rooms - requiring multiple unit installations. Units should be located so that the
discharge air from one unit supports the discharge from another unit and provides a circular
air movement.

Operating
Instructions for
Electrical Heater Units
PITSAN
Page 9 / 16
PİTSAN MAK. SAN. VE TİC. LTD ŞTİ, Esenyurt Yolu Üzeri No: 66 - 68 Bağlar Mevkii, TR – 34850 Avcılar - İSTANBUL
Tel.: [phone], Fax: [phone], Email:[e-mail], http: //www.pitsan.com
HORIZONTAL DISCHARGE:
To ensure proper heating of floor surfaces, observe the following recommended mounting
limitations
Minimum recommended mounting height (to bottom of heater):
2meters
Maximum recommended mounting height (to bottom of heater):
4,5meters
Minimum clearance from walls and ceiling are (Z) :
250mm
VERTICAL DISCHARGE:
To ensure proper heating of floor surfaces, observe the following
recommended mounting limitations
X: 250mm
Y: 250mm
Z: 250mm
KANALA MONTAJ YAZILABİLİR
7.2. Wiring and Electric Diagrams
Connect the heater only to the voltage and frequency specifi ed on the nameplate.
Rough-in branch circuit wiring to the heater using wire rated for 75 degrees C. Wire heater
supply according to diagram in manual
The unit is supplied with plugs, all wiring to be in accordance with local and national
electric codes.

Operating
Instructions for
Electrical Heater Units
PITSAN
Page 10 / 16
PİTSAN MAK. SAN. VE TİC. LTD ŞTİ, Esenyurt Yolu Üzeri No: 66 - 68 Bağlar Mevkii, TR – 34850 Avcılar - İSTANBUL
Tel.: [phone], Fax: [phone], Email:[e-mail], http: //www.pitsan.com
Monophase Diagram

Operating
Instructions for
Electrical Heater Units
PITSAN
Page 11 / 16
PİTSAN MAK. SAN. VE TİC. LTD ŞTİ, Esenyurt Yolu Üzeri No: 66 - 68 Bağlar Mevkii, TR – 34850 Avcılar - İSTANBUL
Tel.: [phone], Fax: [phone], Email:[e-mail], http: //www.pitsan.com
Threephase Diagram

Operating
Instructions for
Electrical Heater Units
PITSAN
Page 12 / 16
PİTSAN MAK. SAN. VE TİC. LTD ŞTİ, Esenyurt Yolu Üzeri No: 66 - 68 Bağlar Mevkii, TR – 34850 Avcılar - İSTANBUL
Tel.: [phone], Fax: [phone], Email:[e-mail], http: //www.pitsan.com
7.3. First Start up and controls
1- Place the fan switch to ON position
2- Set the temperature control thermostat to a setting below the temperature
3- Energize the heater electrical supply circuit
4- The heater fan should come on but the heater should remain off
5- Place the fan switch to OFF position
6- The fan should go off
7- Set the temperature control thermostat to a setting above the current room temperature
8- The heater should come on and the fan should energize approx. 1-2 minutes. If the room
temperature is high or the heater is mounted too close to ceieling or walls the unitmay cycle
on the thermal high limits of the motor and/or heater
9- Check out and repost any unusual or questionable operating characteristics, such as noise,
vibration ..etc
10- Set the fan switch and temperature control on desired operating positions
7.4. Operation
1- Before the unit is energized, the discharge louvers should be be adjusted for desired air
deflection
2- Perform the operation steps for the applicable temperature control option
2- Place all switches in their normal operating position and place the unit heater in service.
8 SPARE PARTS
All replacements must be factory supplied to ensure safe heater operation. PITSAN assumes
no liability for and provides no warranty against damage arising from the use of non-original
spare parts and accessories.
Reference heater model numbers for ordering
SERVICE AND SPARE PART CONTACT:
PİTSAN MAK. SAN. VE TİC. LTD ŞTİ, Esenyurt Yolu Üzeri No: 66 - 68 Bağlar Mevkii, TR –
34850 Avcılar - İSTANBUL Tel.: [phone], Fax: [phone],
Email:[e-mail], http: //www.pitsan.com
Spare parts provided:
- Fan
- Motor
- Resistance
- On/Off Switch
- Thermostat
- Louvers

Operating
Instructions for
Electrical Heater Units
PITSAN
Page 13 / 16
PİTSAN MAK. SAN. VE TİC. LTD ŞTİ, Esenyurt Yolu Üzeri No: 66 - 68 Bağlar Mevkii, TR – 34850 Avcılar - İSTANBUL
Tel.: [phone], Fax: [phone], Email:[e-mail], http: //www.pitsan.com
9 MAINTENANCE AND REPAIRS
Maintenance and repair must be carried out by qualified personnel only. Before
any maintenance or repair activity heater must be DISCONNECTED from supply
circuit
Once a year remove the dust accumulation inside the heater using a vacuum cleaner
or compressed air. Be careful not to bend the fan blades
The electric motors are permanently lubricated and thermally protected . There is no
need for lubrication.
Check periodically motor and fan for smooth running operation
Annually check for tightness of visible bolts and nuts
Periodically inspect electrical cable insulations, contactors to avoid any short circuits
Be sure that all clearances for air intake are kept as installation
10 POSSIBLE PROBLEM CAUSES AND SOLUTIONS
PROBLEM
POSSIBLE CAUSE
SOLUTION
Fan is not operating
The fan is not plugged
Plug in the fan control wiring
The fan switch is OFF
Switch the button ON position
The motor is defected
Replace the motor
Heater is not operating
Set thermostat temperature
is higher than room
temperature
Set thermostat temperature to
higher position
There is abnormal heating
fan is not working
Check fan connections
There is abnormal heating
air inlet is not sufficient
Increase the clearance between
wall/ceiling and the fan
Not sufficient air is
blowing
The clearance is not right
Check the clearance between
wall/ceiling and the fan
Heating output is reduced
The inlet air temperature is
low
Perform mechanical checks to
see if heating elements are
working properly. If yes it's OK
If one or more heating
elements are burned
Replace the heating elements

Operating
Instructions for
Electrical Heater Units
PITSAN
Page 14 / 16
PİTSAN MAK. SAN. VE TİC. LTD ŞTİ, Esenyurt Yolu Üzeri No: 66 - 68 Bağlar Mevkii, TR – 34850 Avcılar - İSTANBUL
Tel.: [phone], Fax: [phone], Email:[e-mail], http: //www.pitsan.com
11 WARRANTY
PITSAN warrants to the original purchaser of Electrical Heater Units that they are free from
defects in material and workmanship for one year (following the invoice date) of normal
service when installed and operated in accordance with the instructions provided by the
Company and subject to the following conditions:
1. Since the paint finish may be damaged in use, no warranty applies to such paint finish
except for manufacturing defects which become apparent within 30 days from date of
installation.
2. Labour costs for removal and re-installation of parts which may be repaired or replaced
under this warranty are the sole responsibility of the purchaser.
3. The warranty will not apply to parts which have been subject to accident, misuse, abuse or
operation on an incorrect power supply.

Operating
Instructions for
Electrical Heater Units
PITSAN
Page 15 / 16
PİTSAN MAK. SAN. VE TİC. LTD ŞTİ, Esenyurt Yolu Üzeri No: 66 - 68 Bağlar Mevkii, TR – 34850 Avcılar - İSTANBUL
Tel.: [phone], Fax: [phone], Email:[e-mail], http: //www.pitsan.com
12 APPENDIX
The customers confirm by their signatures that they have received , read and understood the
operating and maintenance instructions. Personnel undertake to follow the instructions
conscientiously (Nonobservance leads to forfeiture of the manufacturers warranty)
Date:
Company:
Name:
Signature

Operating
Instructions for
Electrical Heater Units
PITSAN
Page 16 / 16
PİTSAN MAK. SAN. VE TİC. LTD ŞTİ, Esenyurt Yolu Üzeri No: 66 - 68 Bağlar Mevkii, TR – 34850 Avcılar - İSTANBUL
Tel.: [phone], Fax: [phone], Email:[e-mail], http: //www.pitsan.com
EC DECLARATION OF CONFORMITY
MANUFACTURER
NAME : PITSAN MAKINA SAN. VE TIC. LTD.STI.
ADDRESS : ESENYURT YOLU, BAGLAR MEVKII, NO:66/68 AVCILAR- ISTANBUL
TEL : [phone] FAX : [phone] WEB: [e-mail]
The undersigned declares that the described products meet the essential requirements of the
below mentioned standards as based on EN 60335-1; EN 60335-2-33
The item of equipments which identified below has been subject to internal manufacturing
checks with monitoring of the final assesment by PITSAN
MACHINE MODEL LIST : ETA /EKI series electrical heating units
APPLICABLE DIRECTIVES :
2006/ 42 / EC MACHINERY SAFETY DIRECTIVE
2006 / 95 / EC LOW VOLTAGE DIRECTIVE
2004 / 108/ EC ELECTROMAGNETIC COMPATIBILITY DIRECTIVE
APPLICABLE REGULATIONS :
EN 614-1:2006 ; EN 894-2:1997+A1:2008 ; EN 953:1997 ; EN 983:1996 + A1:2008 ;
EN 1037: 1995 + A1:2008 ; EN 1088: 1995 + A2:2008 ; EN 11200:1995 ; EN 12100-1:2003 ;
EN 12100-2:2003 ; EN ISO 13849-1:2008 ; EN ISO 13850:2008 ; EN ISO 14121-1:2007 ;
EN 60204-1:2006 ; EN 13985:2003 ; EN 999:1998 +A1:2008 ; EN 982:1996 +A1:2008 ;
EN 894-3:2000+A1:2008 ; EN 894-1:1997+A1:2008 ; EN 349+A1:2008 ; EN ISO 13857:2008
;
EN 12622:2001 ; EN 61000-6-2:2005 ; EN 61000-6-4:2007
EC CERTIFICATE NO/ NOTIFIED BODY: Sertifika Numarası Verilebilir.
SIGNED ON BE HALF OF THE MANUFACTURER
NAME :
POSITION :
PLACE/ DATE : .......... / …….
SIGNATURE :
