Pixio PX277 Prime User manual

The color and the appearance may differ depending on the product, and the specifications are subject to change without prior
notice to improve the performance.
The contents of this manual are subject to change without notice to improve quality.
Copyright © 2019 Pixio USA Inc. I Pixio is a registered trademark of Pixio USA Inc. I All Rights Reserved.
Use or reproduction of this manual in parts or entirety without the authorization of Pixio USA Inc is prohibited.
All other trademarks are owned by their respective owners. Rev.1.01Copyright © 2019 Pixio USA Inc. I Pixio is a registered trademark of Pixio USA Inc.
All Rights Reserved.
PX277 Prime

27in IIPS WQHD 165Hz Gaming Monitor
PX277P
200526006EMC-1

RISK OF ELECTRIC SHOCK DO NOT OPEN THE MONITOR.
OPENING MONITOR BACK COVER WILL VOID YOUR WARRANTY.
This symbol indicates that high voltage is present inside.
It is dangerous to make any kind of contact with any internal part of
this product.
This symbol alerts you that important literature concerning operation
and maintenance has been included with this product.

Before Using the Product.
Do not place the monitor near heat sources, such as radiators, and do not expose the monitor to direct sunlight
for an extended period of time.
Make sure to keep the original packaging material. If there are any needs to transport the monitor, the packaging
material will be the best method for successful delivery.
Make sure to use a soft, non-abrasive cloth when cleaning the monitor. Do not use corrosive or strong detergents
to clean the monitor. They may result in permanent damage to the panel and will void the warranty.
Always check to make sure the power cord is unplugged before cleaning the monitor.
Be careful when handling liquids while cleaning as it may cause irreparable damage to the electrical components
in the monitor.
Installation Space
Ensure some space around the product for ventilation. An internal temperature rise may cause fire and damage the product.
Make sure to allow some space. Do not install near heater or any other high temperature product or humidifier.

Make sure the monitor is not placed near any source of water, such as the bathroom, kitchen, or humid areas.
Do not place the monitor on an unstable, or uneven surface. If dropped, the monitor may cause bodily injuries.
When transporting the monitor, make sure it is secured in an upright position or preferably in its original packaging
for best results. When mounting the monitor, make sure to follow the instructions of the respective mounting provider
for best results.
The openings in the monitor are for ventilation. For best results, make sure the ventilation holes are not covered up.
Avoid confined spaces like a bookcase for proper functionality.
If the monitor will not be used for an extended period of time, make sure to unplug the power cord to prevent the risk
of damage from lighting strikes or other abnormal voltage incidents.
Do not overburden any socket to prevent risk of fire or shock.
Do not stick any foreign objects into the monitor to prevent risk of fire or shock.
Please do not try to take off the back panel to repair the monitor yourself. You may run the risk of shock and void the
warranty as well. Contract Pixio directly for all RMA issues.
Take note of elevation and temperature zone warnings on the adapters.
The icon indicates that the adapter is suited for areas under 2000 meters.
The icon indicates that the adapter is suited for non-tropical areas.

Take the following steps when cleaning.
1 Power off the product and computer.
2 Disconnect the power cord from the product.
Hold the power cable by the plug and do not touch the cable with wet hands. Otherwise, an electric shock
may result.
3 Wipe the monitor with a clean, soft and dry cloth.
Do not apply a cleaning agent that contains alcohol, solvent, or surfactant to the monitor.
Do not spray water or detergent directly on the product.
4 Wet a soft and dry cloth in water and wring thoroughly to clean the exterior of the product.
5 Connect the power cord to the product when cleaning is finished.
6 Power on the product and computer.
Cleaning the Product.

Notice.

Product Includes:
Preperation.

Product Assembly:
1. Assemble the base to the stand with sets of M4 x 16mm screws as pictured.

Product Disassembly:
To remove the whole base, do as above:
Push the Slider on the back cover. Take it out in the arrow pointed direction.
Lift the base.

Net Weight: 4.6kg (10.14lb)
Dimension & Weight.
464.8mm
364.3mm
616mm
410.3mm 251.8mm
57.5mm
100mm
100mm

Monitor Inputs.
DC
HDMI1 HDMI 2.0, 144Hz, FreeSync, HDR
HDMI2 HDMI 2.0, 144Hz, HDR
DP DisplayPort 1.2, 165Hz, FreeSync, HDR
AUDIO OUT
*WARNING:
Always use the appropriate power cord.

Control Panel.
UP
DOWN
RIGHTLEFT
Jog Button
Multi directional
button that helps
navigate.
Menu Short Cut
Up Input selection Short Key / Exit Short Key Menu
Brightness Adjustment Short Key Menu
Game Assist selection Short Key Menu
Preset selection Short Key Menu
Down
Left
Right
MOVE BACK ENTER
Input
DP
Auto Select
HDMI1 [2.0]
HDMI2 [1.4]
Up
MOVE BACK ENTER
Game Assist
Timer
Crosshair(LoS)
FPS Counter
Left
MOVE BACK ENTER
Preset
Standard
User
Movie
RTS
FPS1
FPS2
Right
MOVE BACK ENTER
Brightness
50
Down

Main OSD Navigation
Rocker Press Move the OSD Menu FPS
MOVE BACK ENTER
2560x1440 165Hz FreeSync
144
Contrast
Black Equalizer
Preset
Aspect Ratio
Sharpness
Ultra Vivid
Brightness
50
50
User
Full
50
Off
90
Color
Gaming Setup
Input
System Set
User Data
V1.0
DP
Display
How to Reconfigure
To turn ON/OFF the OSD Menu, Press Jog Button.
Up
Down
Left
Right
Press
Move up the OSD Menu / Increase
Move down the OSD Menu / decrease
Move left on the OSD Menu / Back
Move right on the OSD Menu / Enter
Turn ON / OFF the OSD Menu
BACK
ENTER

Display
OSD Menu.
FPS
MOVE BACK ENTER
2560x1440 165Hz FreeSync
144
Contrast
Black Equalizer
Preset
Aspect Ratio
Sharpness
Ultra Vivid
Brightness
50
50
User
Full
50
Off
90
•Brightness: Adjust the display brightness value from 0 to 100.
•Contrast: Adjust the display contrast value from 0 to 100.
•Black Equalizer: Adjust the Black Equalizer value from 0 to 100.
•Preset: Select Preset from Standard, User, Movie, Photo, RTS,
FPS1, and FPS2.
•Aspect Ratio: Select Aspect Ratio from Full, 16:9, and 4:3.
[disabled when turn on the FreeSync]
•Sharpness: Adjust the Sharpness value from 0 to 100.
•Ultra Vivid: Turn Ultra vivid On or Off.
Color
Gaming Setup
Input
System Set
User Data
V1.0
DP
Display

FPS
MOVE BACK ENTER
2560x1440 165Hz FreeSync
144
Gamma
Hue
Saturation
Low Blue Light
Color Temperature
2.2
50
70
0
User
Color
•Color Temperature: Select Color Temperature from Warm,
Normal, Cool, sRGB, and User.
•Gamma: Select Gamma from Off, 1.8, 2.0, 2.2, and 2.4.
•Hue: Adjust the Hue value from 0 to 100.
•Saturation: Adjust the Saturation value from 0 to 100.
•Low Blue Light: Adjust the Blue light Filter value from 0 to 100.
Color
Gaming Setup
Input
System Set
User Data
V1.0
DP
Display

FPS
MOVE BACK ENTER
2560x1440 165Hz FreeSync
144
Overdrive
Game Assist
HDR
DCR
MPRT
Off
Off
Off
Freesync
Off
Off
Gaming Setup
•FreeSync: Turn FreeSync On or Off.
•Overdrive: Select Overdrive from Off, Low, Middle, and High.
•Game Assist: Select Game Assist from Time, Crosshair(LoS),
and FPS Counter.
•HDR: Turn HDR On or Off.
•DCR: Turn DCR On or Off.
•MPRT: Turn MPRT On or Off.
Timer: Select Timer from Off, 15:00, 30:00, 45:00, 60:00
and 90:00
Crosshair(LoS): Select Crosshair type.
FPS Counter: Turn FPS Counter On or Off.
Color
Gaming Setup
Input
System Set
User Data
V1.0
DP
Display

FPS
MOVE BACK ENTER
2560x1440 165Hz FreeSync
144
HDMI1 [2.0]
HDMI2 [1.4]
DP
Auto Select
Input
•Switch the signal input to Auto Select, DP, HDMI1 [2.0],
or HDMI2 [1.4].
Color
Gaming Setup
Input
System Set
User Data
V1.0
DP
Display

FPS
MOVE BACK ENTER
2560x1440 165Hz FreeSync
144
OSD Setup
Audio
Reset
Firmware Update
Language English
System Set
•Language: Change the OSD menu display language
•OSD Setup: Select OSD Setup from H Position, V Position,
OSD Timeout, Transparency.
H Position: Adjust 0-100
V-Position: Adjust 0-100
OSD Timeout: Adjust 15-60
Transparency: Adjust 0-100
•Audio: Select Audio from Volume or Mute.
Mute: turn On or Off
Volume: Adjust 0-100
•Reset: Select Reset from Cancel or Confirm.
•Firmware Update: Firmware Update from Cancel or Confirm.
