Pixsys ATR 243 User manual

ATR 243
Controller / Regolatore
User manual / Manuale d’uso

ATR243 - User manual - 3
Summary
1 Model identication..................................................................................................................................5
2 Technical Data............................................................................................................................................5
2.1 General data......................................................................................................................................5
2.2 Hardware data..................................................................................................................................6
2.3 Software data ...................................................................................................................................6
3 Dimensions and Installation...................................................................................................................7
3.1 Panel Assembly.................................................................................................................................8
3.2 Electronics Removal ........................................................................................................................8
4 Electrical wirings........................................................................................................................................9
4.1 Wiring diagram ................................................................................................................................9
5 Conguration EASY-UP ................................................................................................. 16
6 Display and Key Functions.................................................................................................................... 17
6.1 Numeric Indicators (Display)...................................................................................................... 17
6.2 Meaning of Status Lights (Led) .................................................................................................. 17
6.3 Keys ................................................................................................................................................ 18
7 Controller Functions....................................................................................................... 18
7.1 Modofying Main Setpoint and Alarm Setpoint Values ........................................................ 18
7.2 Auto-Tuning.................................................................................................................................... 19
7.3 Manual Tuning............................................................................................................................... 19
7.4 Automatic Tuning ......................................................................................................................... 19
7.5 Soft-Start......................................................................................................................................... 20
7.6 Automatic / Manual Regulation for % Output Control ....................................................... 20
7.7 Pre-Programmed Cycle................................................................................................................ 21
7.8 Memory Card (optional)...................................................................................... 21
7.9 Loading default values ................................................................................................................ 23
7.10 Latch on functions ........................................................................................................................ 23
7.11 Loop Break Alarm On Amperometric Trasformer.................................................................. 24
7.12 Digital Imput Functions............................................................................................................... 25
7.13 Dual Action Heating-Cooling..................................................................................................... 26
8 Serial Communication........................................................................................................................... 28
9 Conguration .......................................................................................................................................... 34
9.1 Modify Conguration Parameter.............................................................................................. 34
10 Table of Conguration Parameters .................................................................................................... 35
11 Alarm Intervention Modes............................................................................................ 52
12 Table of Anomaly Signals ..................................................................................................................... 56
13 Summary of Conguration parameters............................................................................................ 57

4 - ATR243 - Manuale d’uso
Sommario
1 Identicazione del modello.................................................................................................................. 60
2 Dati tecnici ............................................................................................................................................... 60
2.1 Caratteristiche generali ............................................................................................................... 60
2.2 Caratteristiche Hardware............................................................................................................ 61
2.3 Caratteristiche Software.............................................................................................................. 61
3 Dimensioni ed installazione................................................................................................................. 62
3.1 Montaggio a pannello................................................................................................................. 63
3.2 Estrazione dell’elettronica ........................................................................................................... 63
4 Collegamenti elettrici ............................................................................................................................ 64
4.1 Schema di collegamento............................................................................................................. 64
5 Congurazione EASY-UP............................................................................................... 71
6 Funzione dei visualizzatori e tasti....................................................................................................... 72
6.1 Indicatori numerici (Display) ..................................................................................................... 72
6.2 Signicato delle spie di stato (Led) ........................................................................................... 72
6.3 Tastenfunktionen .......................................................................................................................... 73
7 Funzioni del regolatore ................................................................................................. 73
7.1 Modica valore setpoint principale e setpoint di allarme................................................... 73
7.2 Auto-Tuning.................................................................................................................................... 74
7.3 Lancio del Tuning Manuale ........................................................................................................ 74
7.4 Tuning Automatico....................................................................................................................... 74
7.5 Soft-Start......................................................................................................................................... 74
7.6 Regolazione automatico / manuale per controllo % uscita............................................... 75
7.7 Ciclo pre-programmato............................................................................................................... 76
7.8 Memory Card (opzionale) ................................................................................... 76
7.9 Caricamento valori di default .................................................................................................... 78
7.10 Funzione Latch on......................................................................................................................... 78
7.11 Loop Break Alarm da ingresso T.A. (Trasformatore Amp.) .................................................. 79
7.12 Funzioni da Ingresso digitale ..................................................................................................... 80
7.13 Funzionamento in doppia azione (caldo / freddo)............................................................... 81
8 Comunicazione Seriale.......................................................................................................................... 83
9 Congurazione........................................................................................................................................ 88
9.1 Modica parametro di congurazione.................................................................................... 88
10 Tabella parametri di congurazione.................................................................................................. 89
11 Modi d’intervento allarme........................................................................................... 106
12 Tabella segnalazioni anomalie ......................................................................................................... 110
13 Promemoria congurazione.............................................................................................................. 111

ATR243 - User manual - 5
Introduction
Thank you for choosing a Pixsys controller.
With ATR243 model Pixsys integrates in a single device all options for sensor
reading and actuators command, beside extended supply range 24…230 Vac/
Vdc. Thanks to 18 selectable sensors and outputs congurable as relay, SSR
command, 4…20 mA and 0…10 Volt the user or retailer can reduce stock needs.
The series includes also a model with serial communication RS485 Modbus
RTU and with a loading control function via the amperometric transformer. The
possibility to repeat parametrization is simplied by the Memory Cards with
internal battery that do not require power supply for the controller.
1 Model identication
ATR243 series includes three versions. Looking at the table here below it is pos-
sible to nd the required model.
Power supply 24…230 Vac/Vdc +/-15% 50/60 Hz – 5,5 VA
ATR243-20-ABC 2 relays 5 A or 1 relay + 1 Ssr/V/mA
ATR243-21-ABC-T 2 relays 5 A + 1 Ssr/V/mA + RS485 + amperometric transformer*
ATR243-31-ABC 3 relays 5 A + 1 Ssr/V/mA + amperometric transformer*
* Models with amperometric transformer input for “Loop Break Alarm” fun-
ction.
2 Technical Data
2.1 General data
Indicators 4x0.40 inch displays
4x0.30 inch displays
Operating
temperature
Temperature 0-45 °C
Humidity 35..95 uR%
Sealing IP65 front panel (with gasket)
IP20 casing and terminals
Material PC ABS UL94VO self-extinguishing
Weight 165 g (-20ABC) / 185 g (-21/31ABC)

6 - ATR243 - User manual
2.2 Hardware data
Analogue
imput
1: AN1 congurable via
software. Input: Thermocou-
ple type K, S, R, J. Automatic
compensation of cold junction
from 0°C to 50°C.
Thermoresistance:
PT100, PT500, PT1000, Ni100,
PTC1K, NTC10K (β 3435K).
Linear: 0-10 V, 0-20 or 4-20
mA, 0-40 mV.
Amperometric transformer:
50 mA, 1024 points on version
ATR243-21/-31. Potentiome-
ters: 6 KΩ, 150 KΩ.
Tolerance (25 °C) +/-0.2% ±1
digit for thermocouple input,
thermo resistance and V / mA.
Cold junction accuracy 0.1
°C/°C.
Impedance:
0-10 V: Ri>110 KΩ
0-20 mA: Ri<5 Ω
4-20 mA: Ri<5 Ω
0-40 mV: Ri>1 MΩ
Relay
output
2Relays (Atr243-20...21…).
3Relays (Atr243-31...).
Congurable as command
and / or alarm output.
Contacts
5 A - 250 V~.
Resistive load.
SSR/V/mA
output
1 Linear 0/4…20 mA /
SSR/0…10 Volt.
• Deselecting OUT2 relay on
ATR243-20… Congurable
as command output or
retransmission of setpoint
or process.
Congurable:
• 0/4…20 mA (Resolution 6000
points, Rmax 500 Ω);
• 0…10 Volt (Resolution 9500
points, Rmin 300 Ω).
2.3 Software data
Regulation
algorithms
ON - OFF with hysteresis.
P, P.I., P.I.D., P.D. with proportional time.
Proportional
band 0...9999 °C or °F
Integral time 0,0...999,9 sec. (0 excludes integral function)
Derivative time 0,0...999,9 sec. (0 excludes derivative function)
Controller
functions
Manual or automatic Tuning, congurable alarms, pro-
tection of command and alarm setpoints, activation of
functions via digital input, preset cycle with Start / Stop.

ATR243 - User manual - 7
3 Dimensions and Installation
CN1
1 6
MEMORY C.241
15
1116
234
12131415
16
Memory Card
12
3
4
5
11 13 14 15 1612
6 7 8 9 10
CN1
1 6
PIXSYS
FRONTAL PANEL
CUT-OUT
46 X 46 mm
48 mm
48 mm 125 mm10
SUGGESTED THICKNESS 2 ÷ 6 mm
MEMORY CARD (OPTIONAL)
WITH BATTERY
Cod. MEMORY C243
MEMORY CARD (OPTIONAL)
Cod. MEMORY C241 INSERT MEMORY CARD 42 mm

8 - ATR243 - User manual
3.1 Panel Assembly
1
1
2
2
Method of panel assembly and xing
of anchorage hooks.
12
To dismantle, use a screwdriver and
slightly force the xing hooks to re-
move them from the xing guide.
3.2 Electronics Removal
To remove the electronics, grip the front part using the two specic side ridges.
1
1
2
Disconnect the device from the mains before starting to congura-
tion or service it.

ATR243 - User manual - 9
4 Electrical wirings
WARNING
Although this controller has been designed to resist noises in
an industrial environments, please notice the following safety
guidelines:
• Separate control lines from the power wires.
• Avoid the proximity of remote control switches, electroma-
gnetic meters, powerful engines.
• Avoid the proximity of power groups, especially those with
phase control.
4.1 Wiring diagram
The connections are reported below for the three models available.
ATR243-20-ABC
ATR243-21-ABC ATR243-31-ABC
V/I

10 - ATR243 - User manual
Power
10 24...230V
AC/DC
SUPPLY
9
Switching power supply with extended range
24…230 Vac/dc ±15% 50/60 Hz – 5,5 VA (with galva-
nic isolation).
AN1 Analogue Imput
For thermocouples K, S, R, J.
• Comply with polarity.
• For possible extensions, use a compensated
wire and terminals suitable for the thermocou-
ples used (compensated).
• When shielded cable is used, it should be
grounded at one side only.
Rosso
Red
Bianco
White
Rosso
Red
For thermoresistances PT100, NI100.
• For the three-wire connection use wires with the
same section.
• For the two-wire connection short-circuit termi-
nals 1 and 3.
• When shielded cable is used, it should be
grounded at one side only.
• Select internal jumper JP3 as in the gure.
Rot
Rot
:HLȕ
For thermoresistances NTC, PTC, PT500, PT1000 e
potentiometers.
When shielded cable is used, it should be grounded
at one side only to avoid ground loop currents.

ATR243 - User manual - 11
For linear signals V / mA.
• Comply with polarity.
• When shielded cable is used, it should be
grounded at one side only.
• Select internal jumper JP3 as in the gure.
If jumpers are not properly selected,
12 Vdc / 30 mA are not available on ter-
minal 3 to power the sensor.
Example of Connection for linear input Volt and mA
+12 V
30 mA For signals 0….10 V.
Comply with polarity.
+12 V
30 mA
For signals 0/4….20 mA with three-wire sensor.
Comply with polarity:
A= Sensor output
B= Sensor ground
C= Sensor power
For signals 0/4….20 mA with external power of
sensor.
Comply with polarity:
A= Sensor output
B= Sensor ground
+12 V
30 mA
For signals 0/4….20 mA with two-wire sensor.
Comply with polarity:
A= Sensor output
C= Sensor power supply

12 - ATR243 - User manual
Serial Input
RS485 Modbus RTU communication.
Relay Q1 Output
Capacity 5 A / 250 V~ for resistive loads.
NB: see graphic next page.
Uscita Relè Q2 per ATR243-20ABC
Capacity 5 A / 250 V~ for resistive loads.
To select Q2 as relay output, remove jumpers JP5 and
JP7 as indicated in the gure (in the gure is shown
default conguration).
NB: see graphic next page.
Connecting a load without removing the
jumpers will permanently damage the
controller.
Relay Q2 output for ATR243-20ABC
Capacity 5 A / 250 V~ for resistive loads.
NB: see graphic.

ATR243 - User manual - 13
Uscita Relè Q3 su ATR243-31ABC
Q3 Relay Output on ATR243-31ABC.
NB: see graphic.
Electrical endurance Q1 / Q2 / Q3:
5 A, 250 Vac, resistite loads, 105operations.
20/2 A, 250 Vac, cosφ = 0.3, 105operations.
SSR output
SSR/V/mA
5
+
4
-
SSR command output 12 V / 30 mA.
Insert JP5 and JP7 and select JP9 as in
the gure to use the SSR output.

14 - ATR243 - User manual
mA / Volt output
SSR/V/mA
5
+
4
-
Linear output in mA congurable using parameters
as command (parameter c.out ) or retransmission of
process-setpoint (parameter rEtr. ).
Insert JP5 and JP7 and select JP9 as in
gure to use the output in mA.
SSR/V/mA
5
+
4
-
Linear output in Volt congurable using parameters
as command (parameter c.out ) or retransmission of
process-setpoint (parameter rEtr. ).
Insert JP5 and JP7 and select JP9 as in
gure to use the linear output in Volt.
Amperometric Transformer Input on ATR243-21ABC-T
and ATR243-31ABC
• Input 50 mA for amperometric transformer.
• Sampling time 80 ms.
• Congurable by parameters.
Insert JP4 and JP6 as in gure to select
the amperometric transformer input.

ATR243 - User manual - 15
Digital Input on ATR243-20ABC
+ 12V
GND
I D
3
2Digital input using parameter
dGti .
The use of digital input in this version is possible only
with TC sensors, 0…10 V, 0/4…20 mA and 0…40 mV.
Select internal jumper JP3 as in gure.
Digital Input on ATR243-21ABC-T and ATR243-31ABC
+ 12V
GND
I D
16
15
Digital input using parameter dGti .
Insert JP4 as in gure to select the digital
input.

16 - ATR243 - User manual
5 Conguration EASY-UP
To simplify the setting of parameters and the integration of the dierent com-
ponents involved in the control system, Pixsys introduces the EASY-UP coding
which allows to set sensors and/or command outputs in one single step.
By means of the code listed in the data sheet enclosed to the sensor or actuator
(SSR, motorized valve, etc.) the EASY-UP coding will set the relevant main pa-
rameters on the controllers (ex. selection of PT100 on parameter “Sensor” and
the corresponding measuring range on parameters “Lower and Upper limits
of the setpoint”).
Dierent codes may be entered on the controllers in sequence to congure
inputs, control output or retransmission of signal.

ATR243 - User manual - 17
6 Display and Key Functions
A1
C2
C1
ATR243
PIXSYS
A2
1
3
4
89
10 5
6
7
2
6.1 Numeric Indicators (Display)
1
1234
Normally displays the process. During the conguration phase,
it displays the parameter being inserted.
2
1234
Normally displays the setpoint. During the conguration pha-
se, it displays the parameter value being inserted.
6.2 Meaning of Status Lights (Led)
3
C1 C2
ON when the output command is on.
C1 with relay/SSR/mA/Volt command or C1 (open) and C2
(close) for a motorised valve command.
4
A1 A2 A3
ON when the corresponding alarm is on.
5
MAN
ON when the“Manual”function is on.
6
TUN
ON when the controller is running an“Autotune”cycle.
7
REM
ON when the controller communicates via serial port.

18 - ATR243 - User manual
6.3 Keys
8
• Allows to increase the main setpoint.
• During the conguration phase, allows to slide through
parameters. Together with the key it modies them.
• Pressed after the key it allows to increase the alarm
setpoint.
9
• Allows to decrease the main setpoint.
• During the conguration phase, allows to slide through
parameters. Together with the key it modies them.
• Pressed after the key it allows to decrease the alarm
setpoint.
10
• Allows to display the alarm setpoint and runs the autotu-
ning function.
• Allows to vary the conguration parameters.
7 Controller Functions
7.1 Modofying Main Setpoint and Alarm Setpoint
Values
The setpoint value can be changed from the keyboard as follows:
Press Display Do
1or
Value on display 2
changes.
Increases or decreases the
main setpoint.
2
Visualize alarm setpoint
on display 1 value being
inserted.
3or
Value on display 2
changes.
Increases or decreases the
alarm setpoint value.

ATR243 - User manual - 19
7.2 Auto-Tuning
The Tuning procedure calculates the controller parameters and can be manual or
automatic according to selection on parameter 57 ( tunE ).
7.3 Manual Tuning
The manual procedure allows the user greater exibility to decide when to
update P.I.D. algorithm work parameters. The procedure can be activated in
two ways.
• By running Tuning by keyboard:
Press the key until display 1 shows the writing
tunE with display 2 show-
ing off , press , display 2 shows on .
The TUN led switches on and the procedure begins.
• By running Tuning by digital input:
Select tune on parameter 61 dGt.i. On rst activation of digital input (com-
mutation on front panel) the TUN led switches on and on second activation
switches o.
7.4 Automatic Tuning
Automatic tuning activates when the controller is switched on or when the
setpoint is modied to a value over 35%.
To avoid an overshoot, the treshold where the controller calculates the new
P.I.D. parameters is determined by the setpoint value minus the “Set Deviation
Tune” (see parameter 58 S.D.tu. ).
To exit Tuning and leave the P.I.D. values unchanged, just press the key until
display 1 shows the writing tune with the display showing on , press , display
2 shows off . The TUN led switches o and the procedure nishes.

20 - ATR243 - User manual
7.5 Soft-Start
To reach the setpoint the controller can follow a gradient expressed in units
(example: Degree/Hours).
Set the increase value in parameter 62 GrAd. with the desired Units/Hours; only
on subsequent activation the controller uses the Soft-Start function.
If parameter 59 op.mo. is set on cont. and parameter 63 ma.ti. is dierent from
0, after switch-on and elapsing of the time set on parameter 63, setpoint does
not follow the gradient anymore, but it reaches nal setpoint with maximum
power.
Autotuning does not work when Soft-Start is activated: otherwise if parameter
63
ma.ti. is dierent from 0 and parameter 57 tune is set on auto , Autotuning
starts when Soft-Start time is nished.
If parameter 57 tune is set on man. , the Autotuning can be started only when
Soft-Start nishes.
7.6 Automatic / Manual Regulation for % Output
Control
This function allows to select automatic functioning or manual command of
the output percentage.
With parameter 60 Au.ma. , you can select two methods.
1 The rst selection ( en. ) allows you to enable the key with the writing p.-
--
on display 1, while display two shows Auto .
Press the key to show Man. ; it is now possible, during the process display,
to change the output percentage using the keys and . To return to au-
tomatic mode, using the same procedure, select Auto on display 2: the led
MAN switches o and functioning returns to automatic mode.
2 The second selection ( EN.ST, ) enables the same functioning, but with two
important variants:
• If there is a temporary lack of voltage or after switch-o, the manual fun-
ctioning will be maintained as well as the previously set output percentage
value.
• If the sensor breaks during automatic functioning, the controller moves to
manual mode while maintaining the output percentage command unchan-
ged as generated by the P.I.D. immediately before breakage.
