Planar LC08 User manual

997-2584-00
Full Color TFT AMLCD
SVGA (800 x 600) native.
Supports VGA and XGA as well.
246 mm x 184.5 mm (12.1-inch diagonal)
Analog; 15-pin D-sub connector
>1500 cd/m2
40% min. (compared to center brightness)
300:1
-
120° Horizontal, +45°/-55° Vertical
45msec (rise + fall)
54 W
+12VDC
13.4” x 12.2” x 4.1” (340mm x 310mm x 105mm)
10.7 lbs (5.0 kg)
0° to +60° C
-20° to +60° C
< 95% RH non-condensing
FCC Class A, CE, UL/cUL, TUV
Internal cooling w/cowling
-
Custom touch screens & Vandal Glass w/Contrast
Enhancement Technology available
997-2799-00 (with dimming sensor)
Full Color TFT AMLCD
XGA (1024 x 768), SVGA,VGA
304mm x 228mm (15-inch diagonal)
Analog; 15-pin D-sub connector. VGA cable included.
1000 cd/m2
78% min.
(compared to center brightness at full luminance)
350:1
4:1 (typical)
160° Horizontal/ 109° Vertical
16msec (rise + fall)
48 W
+12VDC
13.1” x 10.3” x 3.1” (333mm x 262mm x 78mm)
6.7 lbs (3.0 kg)
0 to +50 C
-20 to +60 C
< 85% RH non-condensing
CE, UL/cUL, TUV
FCC Class B
Internal fan w/thermostat.
Optional 3-fan cooling kit for solar loading
Optional 80W power supply.
Available with US or European power cord.
Vandal Glass w/Contrast Enhancement
Technology available (CET)
Optional 3M Capacitive or 3M NFI touch screen
models available.The LC1502R with NFI comes
standard with a cooling kit.
LC15
LC12
LC08
Planar Part Number
Display Type
Video Modes
Image Area
Video Input
Luminance (typical)
Luminance (uniformity)
Contrast Ratio (typical)
Dimming Range
Viewing angle (typical)
Response Time (typical)
Power Consumption (typical)
Supply Voltage & Current (typical)
Dimensions (WxHxD)
Weight
Operating Temperature
Storage & Transport Temperature
Humidity (operating)
Regulatory and Safety
Cooling kit
Power Supply
Vandal Glass and Enhancements
SPECIFICATIONS
997-2566-00
Full Color TFT AMLCD
SVGA (800 x 600), VGA
170.9mm x 129.6mm (8.4-inch diagonal)
Analog; 15-pin D-sub connector
1000 cd/m2
70% min. (compared to center brightness)
250:1
-
100° Horizontal, +20°/-45° Vertical
100msec max. (rise + fall)
40W
+12VDC
9.6” x 7.1” x 4.3” (245mm x 180mm x 110mm)
5.7 lbs (2.5 kg)
0° to +60° C
-20° to +60° C
< 95% RH non-condensing
FCC Class A, CE, UL/cUL, TUV
Internal cooling w/thermostat & cowling
-
Custom touch screens & Vandal Glass w/Contrast
Enhancement Technology available
PLANAR AMLCD MONITORS
Display Innovation You Depend On
Contrast Enhancement Technology (CET)
Features:
• Rugged vandal glass with integrated Contrast
Enhancement Technology (CET): protects you
and your display system from impact and con-
taminants
• Increases display contrast ratio by as much as
75% in high ambient light and high glare,
improving readability and user satisfaction
• Reduces need for a brighter backlight lamp,
increasing overall system reliability and reducing
maintenance costs
• Improves display system’s thermal performance
in direct sunlight
• Based on patent-pending technology invented
by Planar’s optics experts
Dimensions (15” version)
333 x 262 x 7.3mm (13.1”x10.3”x.29”)
Weight (15” version)
3.0 lbs (1.4 kg) typical. (Custom sizes avail. Consult Factory.)
Contrast Ratio (15” version)
With Planar’s vandal glass with CET mounted in
front of the LC15 (typically 1000 nit brightness) the
resulting contrast ratios (CR) will be as follows:
Dark ambient: CR=420 typical
7800fL specular ambient: CR=41.4 typical
2000 fC diffuse ambient: CR=22.2 typical
Both specular and diffuse: CR=16.2 typical
(For the purposes of mechanical design, use 1.6 gr./cm2,
0.02 lb/in2 as the mass per unit area.)
© 2004, Planar Systems, Inc. Planar is a trademark
of Planar Systems, Inc. Technical information in
this document is subject to change without notice.
Please consult your account manager for up to date
and/or custom configurations.
(before) (after)
Planar is the western world's
largest and most experienced
flat-panel display company,
with over 20 years' expertise in
flat-panel technology. We
provide innovative,
dependable display solutions
for demanding applications in
industrial, medical, commercial,
and consumer markets. Our
products span a broad range,
from ruggedized displays used
in ATMs, kiosks and gas pumps
to award-winning desktop
monitors, from diagnostic
medical imaging monitors to
LCD TVs and high-performance
large-screen displays.
For a proven, cost-effective
solution that will help you get
to market faster, choose a
Planar standard AMLCD
embedded solution.These
quick-turn solutions help you
minimize development time
and costs while you maximize
supply chain efficiency.
Effective November 15, 2004 Display Innovation You Depend Onwww.planar.com
PLANAR AMLCD COMPONENTS
Display Innovation You Depend On
Planar Part Number
Display Type
Video Modes
Image Area
Video Input
Luminance (typical)
Luminance (uniformity)
Contrast Ratio (typical)
Viewing angle (typical)
Response Time (typical)
Power Consumption (typical)
Supply Voltage & Current (typical)
Dimensions (WxHxD)
Weight
Operating Temperature
Storage & Transport Temperature
Humidity (operating)
Vibration (operating)
Shock
Regulatory and Safety
SPECIFICATIONS LC640.480.33-AC
996-0403-02
Full Color TFT AMLCD
VGA (640x480)
211.2 x 158.4 mm (10.4'' diag)
18 bit interface on 34-pin connector
1000 cd/m2
70% min. (compared to center brightness)
150:1
+70° Horizontal, +40°/-60° Vertical
Rise 25 ms, Fall 45 ms
32W max (with backlight)
+5VDC, Backlight: +12VDC
10.7” x 7.9” x 1.1” (272.3mm x 199.9mm x 27.0mm)
2.0 lbs (0.9 kg)
-10° to +70° C
-25° to +85° C
< 95% RH non-condensing
.02 g /Hz (5 to 500 Hz)
100g, 6msec
The LC640.480.33-AC will not inhibit the end prod-
uct from obtaining the following certifications:
Safety - UL1950, IEC950,
EMC - EN55022, FCC Class B
Corporate Headquarters
PLANAR SYSTEMS, INC.
1195 NW Compton Dr
Beaverton, OR 97006-1992, USA
Toll-Free +1.866.475.2627
(United States & Canada)
Phone: +1.503.748.1100
Fax: +1.503.748.1493
Email: [email protected]
European Headquarters
PLANAR SYSTEMS, INC.
Olarinluoma 9, P.O. Box 46
FIN-02201 Espoo, Finland
Phone: +358.9.42.001
Fax: +358.9.420.0200
Email: [email protected]
Regional Sales Offices
CHINA
PLANAR SYSTEMS, SHANGHAI
388 Nan Jing West Road, Suite 3905
Shanghai, Peoples Republic of China
Phone: +86`21`6334`5050
Fax: +86`21`6334`6339
Email: [email protected]
FRANCE
PLANAR SYSTEMS SARL
68, rue du Faubourg St-Honoré
75008 Paris, France
Phone: +33 1 4250 0264
Fax: +33 1 4250 0053
Email: [email protected]
GERMANY
PLANAR SYSTEMS GMBH
Airport Business Center
Am Soeldnermoos 17
85399 Hallbergmoos, Germany
Phone:+49 811 550 5850
Fax: +49 811 555 3780
Email: [email protected]
Effective November 15, 2004 Display Innovation You Depend Onwww.planar.com
© 2004, Planar Systems, Inc. Planar is a trademark of Planar Systems, Inc. Technical information in this document is subject to change without notice.Please consult your account manager for up to date and/or custom configurations.
