Planar UR8450-MX
Professional 4K 84" Display
Planar® UltraRes Series UR8450-MX is an 84" Ultra
HD (3840 x 2160) professional LCD display that
produces resolution and picture quality not before
seen in large format LCD displays. With a native 4K
resolution, Planar UR8450-MX has four times the
resolution and pixel density of comparably-sized full
HD displays. When displaying ultra HD content,
Planar UltraRes Series UR8450-MXdelivers clarity
and detail that appears sharp even at close viewing
distances - no detail is missed. The Planar UR8450-
MX features 500 nits brightness and supports
landscapes or portrait installations.
SPECIFICATION DETAIL
Product Name UR8450-MX
Planar Part Number 997-7109-00
Screen Size 84 in. (diagonal)
Orientation Landscape/Portrait
Recommended Usage Up to 24/7 mission critical operation
Aspect Ratio 16:9
Brightness (typ) 500 nits
Backlight LED
Contrast Ratio (typ) 500,000:1 (dynamic)
Response Time (typ) 5 ms
Frame Rate 120Hz
Viewing Angle (typ) 178°
Native Resolution 3840 x 2160
Display Color >1 billion colors. Full 10 bit data path
Display Active Area 73.2" (1860.5mm) wide x 41.2" (1046.5mm) tall
Surface Treatment Low-reflectance/matte
Control and Monitoring IR, RS-232, USB, LAN
Line Voltage 100-240V; 50/60Hz
Power Consumption (typ) 460W

External Connections 4 x DisplayPort 1.1a; 4 x HDMI with Deep Color and 4K support; 1 x RS-232;
1 x LAN 10/100BaseT; 1 x USB 2.0; 1 x IR
Operating Temperature 0C to +40C
Storage and Transport
Temperature -20° to +60°C (-4° to 140°F)
Humidity up to 85% RH (non-condensing)
Display dimensions 75.5" W x 43.7" H x 3.05" D (1918.7mm W x 1110.7mm H x 77.5mm D)
Bezel Width 1.14" (29.1mm) left/right; 1.26" (32.1mm) top/bottom
Dimensions, including wall
mount 75.5" W x 43.7" H x 3.17" D (1918.7mm W x 1110.7mm H x 80.5mm D)
Weight 180 lbs. (82 kg)
Weight, including mount 210 lbs (95.25 kg)
Weight (Shipping) 265 lbs. (120 kg)
HD format 4K UHD 2160p
Fanless Yes
Approvals FCC Class A, EN55022/CISPR22, ICES-003, EN55024, CNS 13438, EN60950-1,
CE, cTUVus, EU RoHS
Options / Features Free standing pedestal (single or double sided) in Portrait.
Warranty 3 years Advance Exchange
UPC 8 10689 07109 9
Touch Technology N/A
OS Compatibility N/A
Modes 1x 3840x2160 @ 24/25/30Hz; 1x3840x2160 @ 60Hz (HDMI 2.0), 4x 1920x1080
@ 24/25/30/50/60Hz; 4x 960x2160 @ 60Hz; 2x 1920x2160 @ 60Hz; 480p, 576p,
720p @ 50/60 Hz; 1080p @ 24/25/30/50/60Hz; 1080i @ 50/60 Hz
Scaling Upscaling to 1080 quadrant and to 4K full screen.
Downscaling 4K @ 24/25/30 Hz to 1080 quadrant
For more information, please visit www.planar.com
Specifications are subject to change without notice.
Specification Report Date: 5/28/2014
