1. Package Contents
Thank you for purchasing PLANET IEEE 802.3at High
Power over Ethernet Injector, POE-163/POE-164.
Model LAN Port Speed PoE Standard PoE Budget
POE-163 10/100/1000Mbps 802.3at /
802.3af 30 watts
POE-164 10/100Mbps
“802.3at PoE Injector” used in this user’s manual
refers to the POE-163/POE-164.
Unpack the box of the IEEE 802.3at High Power
over Ethernet Injector carefully and the box should
contain the following items:
The IEEE 802.3at High Power over Ethernet
Injector x 1
User’s Manual x 1
AC Power Cord x 1
If any of these are missing or damaged, please
contact your dealer immediately. If possible, retain
the carton including the original packing material,
and use them again to repack the product in case
there is a need to return it to us for repair.
2. Product Features
Interface
2-port RJ45 interfaces
1-port Data + Power output
1-port Data input
1 AC 100-240V input power socket
Power over Ethernet
High Power over Ethernet Mid-span PSE
IEEE 802.3at PoE Plus compliant
Backward compatible with IEEE 802.3af PD
device
Supports PoE Power up to 30 watts for PoE port
Auto-detects PoE IEEE 802.3at / 802.3af equip-
ment and devices for preventing damage from
incorrect installation
Remote power feeding up to 100m
Hardware
Plastic case
LED indicators for Power LED and Active LED
(PoE ready-in-use)
Standard Compliance
IEEE 802.3 10BASE-T
IEEE 802.3u 100BASE-TX
IEEE 802.3ab 1000BASE-T (POE-163 only)
IEEE 802.3af Power over Ethernet (802.3at
Type 1)
IEEE 802.3at Power over Ethernet (802.3at
Type 2)
FCC Part 15 Class B, CE
Note
PSE (Power Sourcing Equipment) is
a device (switch, or hub for instance)
that will provide power in a PoE setup.
The maximum continuous output power
allowed for each IEEE 802.3at/IEEE
802.3af device is 30W/15.4W.
PDs (Powered Devices) like IP
phones, network cameras and wireless
access points, etc. are PoE-enabled
terminals and thus they are power
sourcing equipment (PSE).
3. Product Specications
Product POE-163 POE-164
Hardware Specications
Interface
“Data” Input
Port 1 x RJ45 STP
“PoE (Data
+ Power)”
Output Port
1 x RJ45 STP
AC Input
Power Socket 1
LED Indicator
System: Power x 1 (Green)
PoE Port: Active, PoE ready / In
Use x 1 (Green)
Network Cable
10BASE-T: 2-pair UTP Cat. 3, 4,
5, up to 100m (328ft)
100BASE-TX: 2-pair UTP Cat. 3,
4, 5, up to 100m (328ft)
1000BASE-T: 2-pair UTP Cat. 5,
5e, 6 up to 100m (328ft)
(POE-163 only)
EIA/TIA-568 100-ohm STP
(100m)
Data Rate 10/100/1000Mbps 10/100Mbps
Dimensions (W x D x H) 115 x 62.5 x 31 mm
Weight 177g
Unit Output Voltage DC 53V, 0.6A
Power Requirements 100-240V AC, 50/60Hz, 0.75A
Power Consumption 30 Watts max.
Number of devices that
can be powered 1
Operating Temperature
0 ~ 50 degrees C
Storage Temperature -10 ~ 70 degrees C
Operating Humidity 5 ~ 95%, relative humidity, non-
condensing
Storage Humidity 5 ~ 95%, relative humidity, non-
condensing
Power over Ethernet
PoE Standard IEEE 802.3at Power over Ethernet
Plus / Mid-span PSE
PoE Power Output DC 53V / 30 Watts
PoE Power Supply Type Mid-span
Power Pin Assignment 4/5(+), 7/8(-)
Standards Conformance
Standards Compliance
IEEE 802.3 10BASE-T Ethernet
IEEE 802.3u 100BASE-TX Fast
Ethernet
IEEE 802.3ab 1000BASE-T Gigabit
Ethernet (POE-163 only)
IEEE 802.3af Power over Ethernet
(802.3at Type 1)
IEEE 802.3at Power over Ethernet
(802.3at Type 2)
Regulation Compliance FCC Part 15 Class B, CE
4. Product Outlook
Figure 1: shows an overview of the 802.3at PoE
Injector.
Rear Panel
Front Panel
Top Panel
Botton
Rear Panel
Front Panel
Top Panel
Botton
Figure 1: POE-163 / POE-164 Outlook
LED Indicators
LED Color Function
POWER Green Lights to indicate that the 802.3at PoE
Injector has power.
ACTIVE Green
Lights off to indicate the port is not
providing 53V DC in-line power.
Lights to indicate the port is providing
53V DC in-line power.
5. Hardware Installation
The following section describes the hardware
features of the 802.3at PoE Injector. Before
connecting any network device to the 802.3at PoE
Injector, read this chapter carefully.
This POE-163 provides three different running
speeds – 10Mbps / 100Mbps / 1000Mbps and the
POE-164 provides two different running speeds
– 10Mbps / 100Mbps in the same device for
automatically distinguishes the speed of incoming
connection. Please refer to following sections for
detailed information about the IEEE 802.3at Power
over Ethernet Injector.
5-1 Before Installation
Before your installation, it is recommended to check
your network environment. If there is any IEEE
802.3at devices that need higher power to power
on and work normally, the 802.3at PoE Injector
can provide you with power for this Ethernet device
easily. The 802.3at PoE Injector is equipped with an
AC power cord with 100-240V AC input and injects
DC 53V power into the pin of the twisted-pair cable
(pair 4, 5 [+] and pair 7, 8 [-] ).
If a power socket for the AC-DC adapter of your non
IEEE 802.3at networked device is not available, the
802.3at PoE Injector and POE-162S can provide you
with DC power for this Ethernet device easily.
Note
The 802.3at PoE Injector and POE-162S
can be installed in pair. However, the
use of third-party device is allowed if
the device complied with IEEE 802.3at
Power over Ethernet.
The 802.3at PoE Injector Installation
1. Connect the AC power cord to the “AC slot” of the
802.3at PoE Injector; the “POWER” LED will be
steadily on.
2. Connect a standard network cable from a switch /
workstation to the “LAN” port of the 802.3at PoE
Injector.
3. And connect the Injector to a remote device like a
PoE PTZ IP camera over the UTP cable.
** The 802.3at PoE Injector can directly connect
with any IEEE 802.3at / 802.3af end-nodes, such
as PTZ IP and speed dome cameras, color touch-
screen Voice over IP (VoIP) telephones, multi-
channel wireless LAN access points, etc. The
installation is shown in Figure 2 below.

- 9 -
- 10 -
- 11 -
- 12 - - 13 -
Switch
100 meters
PoE
Power
Data
PoE PTZ
IP Camera
802.3at PoE Injector
Power
Data
AC
1000BASE-T UTP
PoE
1000BASE-T UTP with PoE
Power Line (AC)
AC
Figure 2: Connection to IEEE 802.3at / 802.3af Devices
When the ACTIVE LED blinks slowly, it indicates the
port is not providing 53V DC in-line power. Once
the 802.3at PoE Injector detects the existence of
an IEEE 802.3at / 802.3af device, the ACTIVE LED
indicator will be steadily on to show it is providing
power.
Note
1. Since the 802.3at PoE Injector PoE
port supports 53V DC PoE power
output, please check and assure the
powered device’s (PD) acceptable DC
power range is 53V DC. Otherwise, it
will damage the PD.
2. If the connected device is not fully
complying with IEEE 802.3at /
802.3af Power over Ethernet or in-
line power device, the LED indicator
of the 802.3at PoE Injector will not
be steadily on.
The 802.3at PoE Injector and POE-162S, the
IEEE 802.3at Injector Splitter Installation
1. Connect the AC power cord to “AC slot” of the
802.3at PoE Injector; the “POWER” LED will be
steadily on.
2. Connect a standard network cable from the
“POE” port of the 802.3at PoE Injector to the
“PoE In” port of the POE-162S. The “ACTIVE”
LED of the 802.3at PoE Injector and PoE-in-use
LED of the POE-162S will continue to be lit.
3. Connect a standard network cable from a switch /
workstation to the “LAN” port of the 802.3at PoE
Injector.
4. Connect the UTP cable in the package from the
“Ethernet” port of the POE-162S to the RJ45
port of a remote device.
5. Adjust the proper DC power output and connect
the DC plug from the “DC OUT” of the POE-162S
to a remote device.
6. Power on the remote device and its power LED
indicator will remain on.
Switch
Power 12V/24V
POE-162S
100 meters
Power
Data
Power
Data
PoE
Power
Data
AC DC
Non-PoE PTZ
IP Camera
1000BASE-T UTP
PoE
1000BASE-T UTP with PoE
Power Line (AC)
AC
DC
Power Line (DC)
802.3at PoE Injector 802.3at PoE
Splitter
Figure 3: Connection architecture over 802.3at PoE
Injector / POE-162S
Note
1. Owing to IEEE 802.3at / 802.3af
Power over Ethernet standards, the
802.3at PoE Injector will not inject
power over the cable if not connected
to IEEE 802.3at / 802.3af devices.
2. Please ensure the POE-162S output
voltage is correct before applying
power to remote devices.
The 802.3at PoE Injector and POE-E201 IEEE
802.3at PoE Extender Installation
1. Connect the AC power cord to the “AC slot” of
the 802.3at PoE Injector; the “POWER” LED will
be steadily on.
2. Connect a standard network cable from the
“POE” port of the 802.3at PoE Injector to the
“IN” port of the POE-E201.
3. The 802.3at PoE Injector delivers both Ethernet
Data and PoE power over UTP cable to the
POE-E201 and the “ACTIVE” LED of the 802.3at
PoE Injector and the “PoE IN” LED of the
POE-E201 will continue to be lit.
4. Connect an additional standard network cable that
will be used to connect from the “OUT” port of
the POE-E201 to a remote Powered Device
(PD).
5. The "OUT" port of the power injector transmits
DC voltage over the standard network cable and
transfers data and power simultaneously between
the 802.3at PoE Injector and the PD.
6. Once the POE-E201 detects the existence of an
IEEE 802.3at / 802.3af device, the “PoE OUT”
LED indicator will be steadily on to show it is
providing power.
802.3at
PoE Extender
Data
PoE PoE
+Power
Power
Data +Power Data
100 meters100 meters
200 meters
Power Line (AC)
AC
1000BASE-T UTP
PoE
1000BASE-T UTP with PoE
PoE IP Camera
802.3at PoE Injector
Figure 4: Connection architecture over 802.3at PoE
Injector / POE-E201
Note
1. If the connected device is not fully
complying with IEEE 802.3at /
802.3af standards or in-line power
device, the PoE OUT LED indicator of
the POE-E201 will not be steadily on.
2. Owing to IEEE 802.3at / 802.3af
standards, the POE-E201 will not
inject power over the cable if a
standard IEEE 802.3at / 802.3af
device is not connected.
Customer Support
Thank you for purchasing PLANET products. You
can browse our online FAQ resource at the PLANET
Web site rst to check if it could solve you issue. If
you need more support information, please contact
PLANET switch support team.
PLANET online FAQ :
http://www.planet.com.tw/en/support/faq.php?type=2
Switch support team mail address :
[email protected]
Copyright ©PLANET Technology Corp. 2015.
Contents are subject to revision without prior notice.
PLANET is a registered trademark of PLANET Technology Corp.
All other trademarks belong to their respective owners.
EC Declaration of Conformity
For the following equipment:
*Type of Product : Single-Port 10/100/1000Mbps IEEE 802.3at PoE+ Injector (30Watts)
Single-Port 10/100Mbps IEEE 802.3at PoE+ Injector (30Watts)
*Model Number :POE-163, POE-164
* Produced by:
Manufacturer‘s Name : Planet Technology Corp.
Manufacturer‘s Address : 10F., No.96, Minquan Rd., Xindian Dist.,
New Taipei City 231, Taiwan (R.O.C.).
is herewith confirmed to comply with the requirements set out in the Council Directive on the
Approximation of the Laws of the Member States relating to Electromagnetic Compatibility
Directive on (2004/108/EC).
For the evaluation regarding the EMC, the following standards were applied:
EN55022 (2006 + A1:2007 + A2:2010)
EN 61000-3-2 (2006 + A1:2009 + A2:2009)
EN 61000-3-3 (2008)
EN55024 (2010)
IEC 61000-4-2 (2008)
IEC 61000-4-3 (2006+A1: 2007 + A2:2010)
IEC 61000-4-4 (2004 + A1:2010)
IEC 61000-4-5 (2005)
IEC 61000-4-6 (2008)
IEC 61000-4-8 (2009)
IEC 61000-4-11 (2004)
Responsible for marking this declaration if the:
Manufacturer Authorized representative established within the EU
Authorized representative established within the EU (if applicable):
Company Name: Planet Technology Corp.
Company Address: 10F., No.96, Minquan Rd., Xindian Dist., New Taipei City 231, Taiwan (R.O.C.)
Person responsible for making this declaration
Name, Surname Kent Kang
Position / Title : Product Manager
Taiwan 29th March, 2013
Place Date Legal Signature
PLANET TECHNOLOGY CORPORATION
e-mail: [email protected] http://www.planet.com.tw
10F., No.96, Minquan Rd., Xindian Dist., New Taipei City, Taiwan, R.O.C. Tel:[phone] Fax:[phone]
