Planet Networking & Communication IPX-2000 User manual

Internet Telephony PBX System
IPX-2000
User’s Manual

Copyright
Copyright (C) 2008 PLANET Technology Corp.All rights reserved.
The products and programs described in this User’s Manual are licensed products of PLANET
Technology, This User’s Manual contains proprietary information protected by copyright, and this
User’s Manual and all accompanying hardware, software, and documentation are copyrighted.
No part of this User’s Manual may be copied, photocopied, reproduced, translated, or reduced to any
electronic medium or machine-readable form by any means by electronic or mechanical. Including
photocopying, recording, or information storage and retrieval systems, for any purpose other than the
purchaser's personal use, and without the prior express written permission of PLANET Technology.
Disclaimer
PLANET Technology does not warrant that the hardware will work properly in all environments and
applications, and makes no warranty and representation, either implied or expressed, with respect to
the quality, performance, merchantability, or fitness for a particular purpose.
PLANET has made every effort to ensure that this User’s Manual is accurate; PLANET disclaims
liability for any inaccuracies or omissions that may have occurred.
Information in this User’s Manual is subject to change without notice and does not represent a
commitment on the part of PLANET. PLANET assumes no responsibility for any inaccuracies that may
be contained in this User’s Manual. PLANET makes no commitment to update or keep current the
information in this User’s Manual, and reserves the right to make improvements to this User’s Manual
and/or to the products described in this User’s Manual, at any time without notice.
If you find information in this manual that is incorrect, misleading, or incomplete, we would appreciate
your comments and suggestions.
CE Declaration of conformity
This equipment complies with the requirements relating to electromagnetic compatibility, EN 55022
class Afor ITE and EN 50082-1. This meets the essential protection requirements of the European
Council Directive 89/336/EEC on the approximation of the laws of the Member States relating to
electromagnetic compatibility.
The is a class B device, In a domestic environment, this product may cause radio interference, in which
case the user may be required to take adequate measures.
ii

FCC Notice
This equipment has been tested and found to comply with the limits for a Class A digital device,
pursuant to Part 15 of FCC Rules. These limits are designed to provide reasonable protection against
harmful interference when the equipment is operated in a commercial environment. This equipment
generates, uses, and can radiate radio frequency energy and, if not installed in accordance with the
instruction manual, may cause harmful interference to radio communication. Operation of this
equipment in a residential area is likely to cause harmful interference in which case the user will be
required to correct the interference at the user’s own expense.
WEEE Warning
To avoid the potential effects on the environment and human health as a result of the
presence of hazardous substances in electrical and electronic equipment, end users of
electrical and electronic equipment should understand the meaning of the crossed-out
wheeled bin symbol. Do not dispose of WEEE as unsorted municipal waste and have to
collect such WEEE separately.
Trademarks
The PLANET logo is a trademark of PLANET Technology. This documentation may refer to numerous
hardware and software products by their trade names. In most, if not all cases, their respective
companies claim these designations as trademarks or registered trademarks.
Revision
PLAENT IP PBX User’s Manual
Revision: 1.0 (June. 2008)
iii

TABLE OF CONTENTS
1Introduction.......................................................................................................................................1
1.1 Overview.......................................................................................................................1
1.2 Physical Interfaces........................................................................................................1
2Managing with Web Interface...........................................................................................................3
3Wizard Configuration........................................................................................................................4
3.1 Add Account Wizard......................................................................................................4
Step 1: Add User Group............................................................................................................4
Setp 2: Add User.......................................................................................................................6
Step 3: Choose Device.............................................................................................................6
Step 4: Add Device ...................................................................................................................7
Setp 5: Add Extension..............................................................................................................7
3.1.5.1 Add Extension of IP Phone..........................................................................7
3.1.5.2 Add Analog Phone.....................................................................................10
3.2 Add Route & Trunk......................................................................................................11
Step 1: Add Route...................................................................................................................11
Setp 2: Add Route Group .......................................................................................................12
Setp 3: Choose Trunk.............................................................................................................13
Setp 4: Add Trunk...................................................................................................................13
3.2.4.1 Add SIP Trunks..........................................................................................13
3.2.4.2 Add Analog PSTN Trunks..........................................................................16
3.2.4.3 Add ISDN PSTN Trunks............................................................................18
Setp 5: Assign Trunk...............................................................................................................20
3.3 Mass Extension Adding...............................................................................................21
Step 1: Add User & Extension ................................................................................................21
4System Configuration.....................................................................................................................22
4.1 PBX System................................................................................................................22
4.2 Time Setup..................................................................................................................22
4.2.1 System Time Zone .............................................................................................22
4.2.2 Real Time Clock (RTC) Setup............................................................................22
4.3 On-board WAN Setup.................................................................................................22
4.3.1 Static IP ..............................................................................................................23
4.3.2 DHCP .................................................................................................................23
iv

4.3.3 PPPoE................................................................................................................23
4.3.4 Allow WAN to Respond PING............................................................................23
4.3.5 LAN Only............................................................................................................23
4.3.6 MAC Clone.........................................................................................................24
4.4 On-board LAN Setup...................................................................................................24
4.5 LAN Routing................................................................................................................24
4.5.1 Add a Route .......................................................................................................24
4.5.2 Edit a Route........................................................................................................25
4.5.3 Delete a Route ...................................................................................................25
4.6 Dynamic DNS Setup...................................................................................................25
4.6.1 Enable Dynamic DNS.........................................................................................25
4.6.2 Disable Dynamic DNS........................................................................................25
4.7 QoS Setup...................................................................................................................26
4.7.1 Enable QoS........................................................................................................26
4.7.2 Disable QoS .......................................................................................................26
4.8 Virtual Server ..............................................................................................................26
4.8.1 Add a Service.....................................................................................................27
4.8.2 Edit a Service .....................................................................................................27
4.8.3 Delete a Service.................................................................................................27
4.9 Maintenance................................................................................................................27
4.9.1 Storage Backup..................................................................................................27
4.9.1.1 Back up to USB Mass Storage..................................................................28
4.9.1.2 Back up to NFS Server..............................................................................28
4.9.2 SIP UA................................................................................................................28
4.9.3 CDR Log.............................................................................................................29
4.9.4 System Events....................................................................................................29
4.9.5 Active Calls.........................................................................................................29
4.10 Firmware Upgrade ......................................................................................................30
4.11 Stackable Management...............................................................................................30
4.11.1 Operation Modes................................................................................................30
4.11.2 Consolidated Management ................................................................................30
4.11.3 Configuration Procedure ....................................................................................31
4.11.3.1 Case I: Stack multiple IP PBX boxes from scratch....................................31
v

4.11.3.2 Case II: Stack a new IP PBX box with an existing running box.................32
4.11.3.3 Case III: Add new slave boxes to an existing stack...................................32
4.11.3.4 Remove slave boxes from stack................................................................32
4.12 Shutdown....................................................................................................................33
4.13 Logout.........................................................................................................................33
5Service Configuration.....................................................................................................................34
5.1 NTP Service................................................................................................................34
5.1.1 Enable NTP Service...........................................................................................34
5.1.2 Disable NTP Service ..........................................................................................34
5.2 SNMP Service.............................................................................................................34
5.2.1 Enable SNMP Service........................................................................................34
5.2.2 Disable SNMP Service.......................................................................................34
5.3 STUN Service .............................................................................................................35
5.3.1 Enable STUN Service ........................................................................................35
5.3.2 Disable STUN Service........................................................................................35
5.4 TFTP Service..............................................................................................................35
5.4.1 Enable TFTP Service .........................................................................................35
5.4.1.1 Change Directory.......................................................................................35
5.4.1.2 Add a Folder..............................................................................................36
5.4.1.3 Delete a Folder..........................................................................................36
5.4.1.4 Download a File.........................................................................................36
5.4.1.5 Delete a File...............................................................................................36
5.4.1.6 Upload a File..............................................................................................36
5.4.2 Disable TFTP Service.........................................................................................36
5.5 DHCP Service.............................................................................................................37
5.5.1 DHCP Service ....................................................................................................37
5.5.1.1 Enable DHCP Service ...............................................................................37
5.5.1.2 Disable DHCP Service...............................................................................37
5.5.2 Add New.............................................................................................................37
5.5.2.1 Add DHCP Range......................................................................................37
5.5.2.2 Edit DHCP Range......................................................................................37
5.5.2.3 Delete DHCP Range..................................................................................38
5.5.3 Show Leased Clients..........................................................................................38
vi

5.6 IP PBX Service............................................................................................................38
5.6.1 Operations..........................................................................................................38
5.6.1.1 Reload IP PBX Configuration....................................................................38
5.6.1.2 Backup IP PBX Configuration....................................................................38
5.6.1.3 Restore IP PBX Configuration...................................................................38
5.6.1.4 Restart IP PBX Configuration....................................................................39
5.6.1.5 Revert IP PBX Configuration.....................................................................39
5.6.2 Settings...............................................................................................................39
6IP PBX Configuration......................................................................................................................41
6.1 User Group Configuration...........................................................................................41
6.1.1 Add a User Group ..............................................................................................41
6.1.2 Edit a User Group...............................................................................................41
6.1.3 Delete a User Group ..........................................................................................41
6.1.4 Search a User Group .........................................................................................42
6.2 User Configuration......................................................................................................43
6.2.1 Add a User..........................................................................................................43
6.2.2 Edit a User..........................................................................................................44
6.2.3 Clone a User ......................................................................................................44
6.2.4 Delete a User .....................................................................................................44
6.2.5 Search a User ....................................................................................................44
6.3 Device Configuration...................................................................................................45
6.3.1 IP Phone.............................................................................................................45
6.3.1.1 Add a Device .............................................................................................45
6.3.1.2 Edit a Device..............................................................................................45
6.3.1.3 Delete a Device .........................................................................................46
6.3.1.4 Search a Device ........................................................................................46
6.3.2 Extension of IP Phone........................................................................................47
6.3.2.1 Add an Extension.......................................................................................47
6.3.2.2 Edit an Extension.......................................................................................48
6.3.2.3 Clone an Extension....................................................................................48
6.3.2.4 Delete an Extension...................................................................................48
6.3.2.5 Search an Extension..................................................................................48
6.3.3 Analog Phone.....................................................................................................51
vii

6.3.3.1 Add an Analog Phone................................................................................52
6.3.3.2 Edit an Analog Phone................................................................................52
6.3.3.3 Delete an Analog Phone............................................................................52
6.3.4 IP Phone Firmware.............................................................................................54
6.3.4.1 Add IP Phone Firmware.............................................................................54
6.3.4.2 Delete IP Phone Firmware.........................................................................55
6.4 Route Configuration....................................................................................................55
6.4.1 Add a Route .......................................................................................................56
6.4.2 Edit a Route........................................................................................................56
6.4.3 Delete a Route ...................................................................................................56
6.4.4 Search a Route ..................................................................................................56
6.5 Route Group Configuration.........................................................................................57
6.5.1 Add a Route Group ............................................................................................57
6.5.2 Edit a Route Group.............................................................................................57
6.5.3 Delete a Route Group ........................................................................................58
6.5.4 Search a Route Group .......................................................................................58
6.6 SIP Trunk Configuration..............................................................................................58
6.6.1 Add a SIP Trunk.................................................................................................59
6.6.2 Edit a SIP Trunk..................................................................................................59
6.6.3 Clone a SIP Trunk..............................................................................................59
6.6.4 Delete a SIP Trunk.............................................................................................59
6.6.5 Search a SIP Trunk............................................................................................59
6.7 Analog PSTN Trunk configuration...............................................................................63
6.7.1 Add an Analog PSTN Trunk ...............................................................................63
6.7.2 Edit an Analog PSTN Trunk................................................................................64
6.7.3 Delete an Analog PSTN Trunk...........................................................................64
6.8 ISDN PSTN Trunk Configuration ................................................................................66
6.8.1 Add an ISDN PSTN Trunk..................................................................................66
6.8.2 Edit an ISDN PSTN Trunk..................................................................................67
6.8.3 Delete an ISDN PSTN Trunk..............................................................................68
6.9 POTS Setting..............................................................................................................70
6.9.1 FXO Port Configuration Settings........................................................................71
6.9.2 FXS Port Configuration Settings........................................................................72
viii

6.9.3 ISDN Port Configuration Settings.......................................................................73
6.10 Digitmap Configuration ...............................................................................................73
6.10.1 Add a Digitmap...................................................................................................73
6.10.2 Edit a Digitmap...................................................................................................74
6.10.3 Delete a Digitmap...............................................................................................74
7Feature Configuration.....................................................................................................................75
7.1 Call Park......................................................................................................................75
7.2 Life Line.......................................................................................................................75
7.2.1 Add a Life Line Pattern.......................................................................................76
7.2.2 Edit a Life Line Pattern.......................................................................................76
7.2.3 Delete a Life Line Pattern...................................................................................76
7.3 Meet-me Conference..................................................................................................76
7.3.1 Add a Meet-me Conference...............................................................................77
7.3.2 Edit a Meet-me Conference ...............................................................................77
7.3.3 Delete a Meet-me Conference...........................................................................77
7.4 Music On Hold.............................................................................................................78
7.4.1 Music on Hold Management...............................................................................78
7.4.1.1 Add a MOH File.........................................................................................78
7.4.2 Media File Management.....................................................................................78
7.4.2.1 Edit a MOH File .........................................................................................78
7.4.3 MOH ID List........................................................................................................78
7.4.3.1 Edit a MOH ID............................................................................................78
7.4.3.2 Delete a MOH File.....................................................................................78
7.5 Voicemail.....................................................................................................................79
7.6 Meet-me Prompts........................................................................................................80
7.7 Voicemail Prompts ......................................................................................................81
7.8 Broadcast....................................................................................................................82
7.8.1 Add a Broadcast.................................................................................................82
7.8.2 Edit a Broadcast.................................................................................................82
7.8.3 Delete a Broadcast.............................................................................................82
7.9 Worktime.....................................................................................................................83
7.9.1 Add a Worktime..................................................................................................83
7.9.2 Edit a Worktime..................................................................................................84
ix

7.9.3 Delete a Worktime..............................................................................................84
7.10 Memo Call...................................................................................................................84
7.10.1 Add a Memo Call................................................................................................85
7.10.2 Edit a Memo Call................................................................................................85
7.10.3 Delete Memo Call...............................................................................................85
7.11 Automatic Call Distribution..........................................................................................86
7.11.1 Set Agent Login and Logout...............................................................................86
7.11.2 Add an Agent......................................................................................................86
7.11.3 Edit an Agent......................................................................................................86
7.11.4 Delete an Agent..................................................................................................87
7.11.5 Add a Queue......................................................................................................87
7.11.6 Edit a Queue ......................................................................................................87
7.11.7 Delete a Queue..................................................................................................87
7.12 Interactive Voice Response (IVR)...............................................................................88
7.12.1 Add a new IVR Menu .........................................................................................89
7.12.2 Edit an IVR Menu...............................................................................................89
7.12.3 Clone an IVR Menu............................................................................................89
7.12.4 Delete an IVR Menu...........................................................................................90
7.12.5 IVR Prompts Management.................................................................................92
7.12.5.1 Add an IVR Prompt...........................................................................92
7.12.5.2 Delete an IVR Prompt.......................................................................92
7.12.6 IVR Parameters..................................................................................................93
7.12.7 Auto Attendant Prompts .....................................................................................93
8Example Provisioning.....................................................................................................................94
8.1 Internal Extension Configuration.................................................................................94
8.2 Case I: Singe-site Configuration.................................................................................94
8.3 Case II: Two-site configuration....................................................................................96
9Appendix.........................................................................................................................................99
9.1 Keypad Default Settings for IP PBX............................................................................99
9.2 Managing with CLI Commands...................................................................................99
9.2.1 Introduction.........................................................................................................99
9.2.2 Console Interface...............................................................................................99
9.2.2.1 Connection...............................................................................................100
x

9.2.2.2 Login........................................................................................................100
9.2.2.3 Basic Commands.....................................................................................100
CLI Command:....................................................................................................................................100
CLI Command:....................................................................................................................................100
CLI Command:....................................................................................................................................101
CLI Command:....................................................................................................................................101
9.2.2.4 Admin Commands...................................................................................101
CLI Command:....................................................................................................................................101
CLI Command:....................................................................................................................................101
9.2.2.5 PBX Commands......................................................................................102
Import CLI Command:.........................................................................................................................103
Export CLI Command:.........................................................................................................................103
9.3 IP PBX Voicemail System Menu Tree.......................................................................106
xi

1 Introduction
1.1 Overview
PLANET IPX-2000 series IP PBX system are designed and optimized for the enterprise, and SMB
daily communications. The IPX-2000 is the next generation voice communication platform for the small
to medium enterprise. Designed as an open, scalable, and highly reliable telephony solution, the
IPX-2000 series are able to accept 200 extension registrations, and effectively meeting scales from
various enterprises. Designed to run on a variety of VoIP applications, the IPX-1800 and IPX-2000
provides centralized call control, auto-attendant, voice conferencing, PSTN, and IP-based
communications.
The IPX-2000 integrates up to 8 FXO to become a feature-rich PBX system that supports seamless
communications between existing PSTN calls, analog, IP phones and SIP-based endpoints
The IPX-2000 system integrates telephony call processing, call control, voice mail, and a widely PBX
application programming interface into a highly scalable architecture designed to support both
traditional circuit-based and the Internet telephony service within a distributed enterprise
communications network.
With IPX-2000 system, standard SIP phones can be easily integrated in your office; plus the
auto-config feature, you may integrate our IP Phone series - VIP-254T/VIP-254T, and the ATA (analog
telephone adapter) series - VIP-156/VIP-157 to build up the VoIP network deployment in minutes.
Allowing distributed IP technology to meet traditional voice services, with proactive management
interface, the IPX-2000 system in the daily business processes, enterprises can make people more
productive, more intelligent tasks, and more customer satisfaction.
1.2 Physical Interfaces
Figure 7. Front Panel of IPX-2000
Figure 8. Rear Panel of IPX-2000

Power cord 100-240 Volt, 50-60 Hz
IPX-2000 2 x slots integrates up 8 FXO
Telephony interface ports FXO module
4 ports per daughter card, numbered from right to
the left. The rightmost port at slot 0 is port 1 and
the leftmost port at slot 1 (if installed) is port 8. FXO
ports are to be connected to FXS jacks on wall or
analog PBX using RJ-11 cables.
USB ports 1 external port with compliance to USB 1.1/2.0. Plug in a USB
hard drive for voicemail backup from the internal one
WAN Connect to a broadband modem or a WAN router
LAN Connect to a LAN switch
Table 1. Physical interfaces description of IP PBX
2

2 Managing with Web Interface
The factory default of LAN IP address is 192.168.1.1. Connect to LAN port and the configuration Web
interface is at https://192.168.1.1/. Once connected, the browser will ask for accepting a certificate.
Click Yes to see the home page. Type in the default administrator ID and password (both are admin) to
log in for administration. The administrator password can be changed in the User Management ->
User.
1. Click admin in the Login ID.
2. Change the password in Password.
3. Click Apply to change the password.
Note: For the system security, please change the password after the first log-in.
After login, you will see four icons, Add Account Wizard, Add Route & Trunk, Mass Extensions
Adding and Customize Setup. The first three icons can lead you step by step to configure some basic
settings of IP PBX. Click the Customize Setup icon to see all the PBX configurations into detail.
Administrator can click on the top-left side of the webpage to go back to the home page of IP PBX
Web Interface.
3

3 Wizard Configuration
With IP PBX Wizard configuration, the administrator can set basic configurations for IP PBX easily.
With basic setup, IP PBX can function, and connect to the relevant devices and trunks. The Wizard
Configuration including Add Account Wizard, Add Route & Trunk and Mass Extension Adding.
When entering Wizard configuration, you will see at the bottom of each page that helps
you to configure with Wizard.Any configuration change in Wizard requires clicking at the
bottom of the homepage.
3.1 Add Account Wizard
In Add User & Device page, the administrator can setup usergroups, users and devices. You can
follow the following steps to finish configuration. After finishing configuration, click at the
bottom of the homepage to take the configuration effect.
Step 1: Add User Group
1. Enter a group ID and then click ADD.
2. The name will show in the table of the webpage.
3. Click the name to view the edit page.
4. Enter settings shown in Table 3-1.
5. Click Back to return to the ADD USER GROUP page.
For deleting a usergroup, select a group ID and click DEL.
Note: Make sure there is no user associate with the usergroup, or it cannot be deleted.
Click Next to add a user.
Table 3-1Add Usergroup Settings
Field Description
Description Arbitrary description information. Click SET to add/update
4

the information.
Associated Trunks1 Select routegroups and outbound trunks accessible by this
usergroup. Note the order matters the hunting sequence in
run-time.
Routegroup: display available routegroups.
Trunk: Display available trunks.
Group ID: The default number is “0”. A trunk with Group ID
“0” does not form a balance group with any other trunks in
Group 0. If Group ID is 1~9, trunks with the same Group ID
form a usage balance group.
Weight: the weight of a trunk to be selected in a trunk
balance group for an outgoing call.
Click or to add or delete the associate trunks.
After add all trunks, click APPLY.
)If there is not any appropriate SIP trunk and PSTN
trunks to select, you may assign trunks at Setp 5:
Assign Trunk in Add Route & Trunk wizard
configuration after trunks are created in the previous
step.
Reachable User Groups Select a usergroup and click ADD that is reachable from this
usergroup. By default, only users in the same usergroup can
reach one another.
)If there is not any appropriate usergroup to select,
come back later to revise this selection, once more
usergroups have been created.
Associated PBX Features2Select PBX features enabled to this usergroup.
Member List Show the users associated with this usergroup.
Auth. Dial Passcode Select and enter a password in number for caller to have the
same privilege as this usergroup to dial out.
1Please refer to 6.6, 6.7, and 6.8 for details.
2Please refer to 7 for details.
5

Setp 2: Add User
1. Enter settings shown in Table 3-2.
2. Click ADD to see the user information in the table of the webpage.
For deleting a user, select a Login ID and click DEL.
Click Next to choose a device.
Table 3-2 Add User Settings
Field Description
Login ID A unique ID containing alphabets, numbers, and underscore
only without spaces; 20 characters maximum. This is the ID
for personal configuration through IP PBX Web
management.
Name Name of the user, either a real or a virtual one, e.g.Alice Lee
or Conference Room.
Password Password for the user to access IP PBX Web management.
Description Arbitrary description information.
E-mail Address E-mail address of the user for voicemail notification.
Attach Voicemail in E-mail Notification Select to enclose the message received in the notification
e-mail as an attachment.
Usergroup Select the usergroup this user belongs to.
)If there is not any appropriate usergroup to select,
come back later to revise this selection if no
appropriate usergroup could be chosen for now.
Step 3: Choose Device
Based on the devices you have, click ADD IP PHONE or ADD ANALOG PHONE, and Next to add/set
the device.
Note: If selecting ADD ANALOG PHONE, the wizard will skip to Step 5.
6

Step 4: Add Device
1. Enter a device name in the Device ID box.
2. Select Auto Provision if you want to enable Automatic Client Configuration.
3. Click ADD to see the newly added device in the table of the webpage, or to see the Enable
Automatic Client Configuration (ACC) page if Auto Provision is selected.
Enter settings shown in Table 3-3 ACC (Automatic Client Configuration) Settings and click ENABLE.
Note: Consult with your vendor to make sure your SIP phone supportAuto Provision function.
For deleting a device, select a device ID and click DEL.
Note: Make sure there is no extension associate with the device, or it cannot be deleted.
Click Next to set a device.
Table 3-3 ACC (Automatic Client Configuration) Settings
Field Description
Vendor Prefix Ask your IP Phone vendor for the Prefix. e.g. eip7012.
MAC Address MAC address of the device.
Supplementary Configuration Supplementary configuration files for IP Phone. The file name
must start with “psc-“.
Codec Preference Preference order of supported codec and packet times of the
phone.
Enable Voice Activity Detection
(VAD)
VAD is a technique that detects absence of audio and conserves
bandwidth by preventing the transmission of "silent packets" over
the network.
)Select if your IP Phone supports VAD.
DTMF mode Choose a DTMF mode used by the phone.
Setp 5: Add Extension
3.1.5.1 Add Extension of IP Phone
1. Enter settings shown in Table 3-4.
2. Click ADD to see the newly added extension in the table of the webpage.
7

For deleting an extension, select an extension number and click DEL.
Click Finish to finalize all the settings, and go back to the homepage.
Table 3-4 Add Extension of IP Phone Settings
Field Description
Extension Number A unique line number composed of digits only, e.g. 101; 20
digits maximum. This is the login ID on the device
configuration side.
Associated Device Select the Device this extension associates with.
User3Select the user this extension associates with.
)If there is not any appropriate users to select, one can
come back later once the expected user has been
added.
Password Password of this extension. Same password must be
configured on the device side as well.
Pickup Group The usergroup that the extension can pick up. The
extension can set a usergroup that when any extension in
the usergroup rings, the extension can press *8 to pick up
the call in ringing state.
Select Include Reachables check box to be able to pickup
calls that belong to other usergroups which is configured in
Reachable User Groups of the selected usergroup.
Language Preferred language for system instructions heard from the
extension.
Voicemail Select enable to allocate voicemail account for the
extension.
Voicemail PIN PIN to access voicemails. This is mandatory if above
voicemail option is enabled.
Max Voicemail Space Enter maximum space in KBytes for voicemail. Enter 0 or
leave it as blank for not limiting the voicemail space. The
3Please refer to 6.1 for details.
8

voicemail will be recorded until the storage is full.
Disable Fast Bridging Select to disable express media forwarding.
)With Fast Bridging feature enabled, if the two parties
involved in a call (for example, one IP extension and
one SIP trunk) use different DTMF modes
(RFC2833/SIP INFO/Inband), inline transfer (*#) or
2nd-dialing might fail. To avoid such problem, it is
recommended to set the same DTMF mode for all IP
extensions and SIP trunks in the IPBX, as well as for
all IP phones registered to the IPBX. If it is not
feasible to set the same DTMF mode for some IP
extensions or SIP trunks, and inline transfer or
2nd-dialing is necessary for those IP extensions or
SIP trunks, the Fast Bridging feature can be disabled
on a per IP extension and per SIP trunk basis. Note
that Fast Bridging is enabled by default.
Try Peer-to-peer RTP If click YES, IP PBX will attempt to notify the two peers in a
conversation to try peer-to-peer RTP transmission. This is
suggested as long as phones support INVITE or UPDATE
method during a connected call to save the resource of IP
PBX. However, only SIP INFO DTMF mode phones should
enable this since other DTMF modes require IP PBX being
RTP relay server to support in-line transfer.
DTMF Mode Choose preferred DTMF mode for this extension. Currently
supported types include RFC2833, SIP INFO, and in-band
tone. It must match configuration on the device side.
)In-band DTMF mode consumes the limited DSP
resource when using a highly compressed codec,
such as G.729 or G.723.1. Therefore, calls will not
connect with such setting if DSP is not installed.
Although using a low-complexity codec such as G.711
does not require DSP, DTMF detection still takes
considerable CPU resource and impacts several
system specs. Be cautious when configuring an
extension with in-band DTMF mode.
9
