Planet Networking & Communication WGSD-1022 User manual

User's Manual
WGSD-1022
8-Port 10/100Mbps
+ 2-Port Gigabit TP/SFP Combo
Managed Ethernet Switch

Trademarks
Copyright © PLANET Technology Corp. 2007.
Contents subject to which revision without prior notice.
PLANET is a registered trademark of PLANET Technology Corp. All other trademarks belong to their
respective owners.
Disclaimer
PLANET Technology does not warrant that the hardware will work properly in all environments and
applications, and makes no warranty and representation, either implied or expressed, with respect to the
quality, performance, merchantability, or fitness for a particular purpose.
PLANET has made every effort to ensure that this User's Manual is accurate; PLANET disclaims liability
for any inaccuracies or omissions that may have occurred.
Information in this User's Manual is subject to change without notice and does not represent a
commitment on the part of PLANET. PLANET assumes no responsibility for any inaccuracies that may be
contained in this User's Manual. PLANET makes no commitment to update or keep current the
information in this User's Manual, and reserves the right to make improvements to this User's Manual
and/or to the products described in this User's Manual, at any time without notice.
If you find information in this manual that is incorrect, misleading, or incomplete, we would appreciate
your comments and suggestions.
FCC Warning
This equipment has been tested and found to comply with the limits for a ClassA digital device, pursuant
to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful
interference when the equipment is operated in a commercial environment. This equipment generates,
uses, and can radiate radio frequency energy and, if not installed and used in accordance with the
Instruction manual, may cause harmful interference to radio communications. Operation of this
equipment in a residential area is likely to cause harmful interference in which case the user will be
required to correct the interference at whose own expense.
CE Mark Warning
This is a Class A product. In a domestic environment, this product may cause radio interference, in which
case the user may be required to take adequate measures.
WEEE Warning
To avoid the potential effects on the environment and human health as a result of the
presence of hazardous substances in electrical and electronic equipment, end users
of electrical and electronic equipment should understand the meaning of the
crossed-out wheeled bin symbol. Do not dispose of WEEE as unsorted municipal
waste and have to collect such WEEE separately.

Revision
PLANET 8-Port 10/100Mbps + 2 Gigabit TP/SFP combo Managed Ethernet Switch User's Manual
FOR MODEL: WGSD-1022
REVISION: 1.2(November.2007)
Part No. 2081-A34030-002

TABLE OF CONTENTS
1. INTRODUCTION ................................................................................................................................15
Packet Contents...............................................................................................................................15
How to Use This Manual..................................................................................................................15
Product Feature...............................................................................................................................16
Product Specification .......................................................................................................................17
2. INSTALLATION...................................................................................................................................19
2.1 Product Description....................................................................................................................19
2.1.1 Product Overview ............................................................................................................19
2.1.2 Switch Front Panel...........................................................................................................20
2.1.3 LED Indications................................................................................................................20
2.1.4 Switch Rear Panel...........................................................................................................20
2.2 Install the Switch........................................................................................................................21
2.2.1 Desktop Installation .........................................................................................................21
2.2.2 Rack Mounting.................................................................................................................22
2.2.3 Installing the SFP transceiver..........................................................................................23
3. CONFIGURATION..............................................................................................................................25
3.1 Management Access Overview..................................................................................................25
3.1.1 Administration Console....................................................................................................26
3.1.2 Direct Access...................................................................................................................26
3.2 Web Management......................................................................................................................27
3.3 SNMP-Based Network Management.........................................................................................27
3.4 Protocols....................................................................................................................................27
3.4.1 Virtual Terminal Protocols ................................................................................................27
3.4.2 SNMP Protocol................................................................................................................28
3.4.3 Management Architecture................................................................................................28
4. Web Configuration ..............................................................................................................................29
4.1 Main Screen...............................................................................................................................31
4.2 System.......................................................................................................................................32
4.2.1 Information.......................................................................................................................32
4.2.2 IP Config..........................................................................................................................33
4.2.3 SNTP...............................................................................................................................34
4.3 Port Configuration......................................................................................................................37
4.3.1 Port Settings....................................................................................................................37
4.3.2 Link Aggregation..............................................................................................................41
4.3.3 LACP Config....................................................................................................................43
4.4 VLAN Configuration...................................................................................................................44
4.4.1 Create VLAN....................................................................................................................45

4.4.2 Port Config.......................................................................................................................46
4.4.3 VLAN Group ....................................................................................................................47
4.4.4 GVRP Config ...................................................................................................................48
4.5. Spanning Tree...........................................................................................................................50
4.5.1 STP Config ......................................................................................................................50
4.5.2 STP Port Config...............................................................................................................52
4.5.3 RSTP Port Config............................................................................................................54
4.5.4 MSTP Config ...................................................................................................................56
4.5.5 MSTP Instance Config.....................................................................................................57
4.5.6 MSTP Interface Settings..................................................................................................59
4.6 Multicast.....................................................................................................................................62
4.6.1 IGMP Snooping ...............................................................................................................62
4.6.2 Bridge Multicast...............................................................................................................63
4.7 QoS............................................................................................................................................66
4.7.1 Queue Scheduling ...........................................................................................................66
4.7.2 802.1p Settings................................................................................................................67
4.7.3 DSCP Settings.................................................................................................................69
4.7.4 Rate Limit ........................................................................................................................70
4.7.5 Port Qos ..........................................................................................................................71
4.7.6 Policy Qos........................................................................................................................72
4.8 Access Control...........................................................................................................................78
4.8.1 Layer3 Based ACL...........................................................................................................78
4.8.2 Layer2 Based ACL...........................................................................................................81
4.9 Security......................................................................................................................................83
4.9.1 ACL Binding.....................................................................................................................83
4.9.2 Radius Config..................................................................................................................84
4.9.3 TACACS+ Config.............................................................................................................86
4.9.4 802.1x settings.................................................................................................................88
4.9.5 Port Security....................................................................................................................89
4.9.6 Multiple Hosts..................................................................................................................91
4.9.7 Storm control....................................................................................................................92
4.10 SNMP ......................................................................................................................................93
4.10.1 Parameters....................................................................................................................93
4.10.2 Group Profile..................................................................................................................95
4.10.3 Group Membership........................................................................................................96
4.10.4 Communities..................................................................................................................98
4.10.5 Notification Recipient...................................................................................................100
4.11 Manage..................................................................................................................................102

4.11.1 User Authentication......................................................................................................103
4.11.2 Dynamic Address.........................................................................................................104
4.11.3 Mirroring.......................................................................................................................105
4.11.4 Firmware Upgrade .......................................................................................................106
4.11.5 Save Configuration ......................................................................................................108
4.11.6 Warm Startup...............................................................................................................110
4.11.7 Factory Default............................................................................................................. 111
4.12 Statistics.................................................................................................................................112
4.12.1 RMON Statistic ............................................................................................................112
4.12.2 EAP Statistic ................................................................................................................114
4.12.3 GVRP Statistics ...........................................................................................................115
5. COMMAND STRUCTURE................................................................................................................117
5.1 Connect to PC’s RS-232 serial port.........................................................................................117
5.2 Using the CLI...........................................................................................................................118
5.2.1 CLI Command Modes....................................................................................................118
5.2.2 Starting the CLI..............................................................................................................121
5.2.3 Editing Features.............................................................................................................122
5.3 AAA Commands.......................................................................................................................125
5.3.1 aaa authentication login.................................................................................................125
5.3.2 aaa authentication enable..............................................................................................126
5.3.3 login authentication........................................................................................................128
5.3.4 enable authentication.....................................................................................................128
5.3.5 ip http authentication......................................................................................................129
5.3.6 ip https authentication....................................................................................................130
5.3.7 show authentication methods ........................................................................................131
5.3.8 password .......................................................................................................................132
5.3.9 enable password............................................................................................................132
5.3.10 username.....................................................................................................................133
5.3.11 show users accounts....................................................................................................134
5.4 Address Table Commands.......................................................................................................134
5.4.1 bridge address...............................................................................................................134
5.4.2 bridge multicast filtering.................................................................................................135
5.4.3 bridge multicast address................................................................................................136
5.4.4 bridge multicast forbidden address................................................................................137
5.4.5 bridge multicast forward-unregistered............................................................................138
5.4.6 bridge multicast forbidden forward-unregistered............................................................139
5.4.7 bridge multicast forward-all............................................................................................140
5.4.8 bridge multicast forbidden forward-all............................................................................140

5.4.9 bridge aging-time...........................................................................................................141
5.4.10 clear bridge..................................................................................................................142
5.4.11 port security .................................................................................................................143
5.4.12 port security routed secure-address ............................................................................143
5.4.13 show bridge address-table...........................................................................................144
5.4.14 show bridge address-table static .................................................................................145
5.4.15 show bridge address-table count.................................................................................146
5.4.16 show bridge multicast address-table............................................................................146
5.4.17 show bridge multicast filtering......................................................................................148
5.4.18 show ports security......................................................................................................148
5.5 Clock Commands.....................................................................................................................149
5.5.1 clock set.........................................................................................................................149
5.5.2 clock source...................................................................................................................150
5.5.3 clock timezone...............................................................................................................151
5.5.4 clock summer-time.........................................................................................................151
5.5.5 sntp authentication-key..................................................................................................153
5.5.6 sntp authenticate ...........................................................................................................154
5.5.7 sntp trusted-key.............................................................................................................154
5.5.8 sntp client poll timer.......................................................................................................155
5.5.9 sntp broadcast client enable..........................................................................................156
5.5.10 sntp anycast client enable ...........................................................................................156
5.5.11 sntp client enable (interface)........................................................................................157
5.5.12 sntp unicast client enable ............................................................................................158
5.5.13 sntp unicast client poll..................................................................................................158
5.5.14 sntp server...................................................................................................................159
5.5.15 show clock...................................................................................................................160
5.5.16 show sntp configuration...............................................................................................161
5.5.17 show sntp status..........................................................................................................162
5.6 Configuration and Image Files.................................................................................................163
5.6.1 copy...............................................................................................................................163
5.6.2 show startup-config........................................................................................................167
5.7 Ethernet Configuration Commands..........................................................................................168
5.7.1 interface ethernet...........................................................................................................168
5.7.2 interface range ethernet.................................................................................................168
5.7.3 shutdown .......................................................................................................................169
5.7.4 description .....................................................................................................................170
5.7.5 speed.............................................................................................................................170
5.7.6 duplex............................................................................................................................171

5.7.7 negotiation.....................................................................................................................172
5.7.8 flowcontrol......................................................................................................................172
5.7.9 mdix...............................................................................................................................173
5.7.10 back-pressure..............................................................................................................174
5.7.11 port jumbo-frame..........................................................................................................175
5.7.12 clear counters..............................................................................................................175
5.7.13 set interface active.......................................................................................................176
5.7.14 show interfaces configuration ......................................................................................176
5.7.15 show interfaces status .................................................................................................178
5.7.16 show interfaces description..........................................................................................179
5.7.17 show interfaces counters.............................................................................................180
5.7.18 show ports jumbo-frame ..............................................................................................183
5.7.19 port storm-control broadcast enable............................................................................183
5.7.20 port storm-control broadcast rate.................................................................................184
5.7.21 show ports storm-control..............................................................................................185
5.8 GVRP Commands ...................................................................................................................185
5.8.1 gvrp enable (global).......................................................................................................185
5.8.2 gvrp enable (interface)...................................................................................................186
5.8.3 garp timer ......................................................................................................................187
5.8.4 gvrp vlan-creation-forbid................................................................................................188
5.8.5 gvrp registration-forbid...................................................................................................188
5.8.6 clear gvrp statistics........................................................................................................189
5.8.7 show gvrp configuration.................................................................................................190
5.8.8 show gvrp statistics........................................................................................................191
5.8.9 show gvrp error-statistics...............................................................................................192
5.9 IGMP Snooping Commands ....................................................................................................193
5.9.1 ip igmp snooping (Global)..............................................................................................193
5.9.2 ip igmp snooping (Interface) ..........................................................................................193
5.9.3 ip igmp snooping mrouter ..............................................................................................194
5.9.4 ip igmp snooping host-time-out......................................................................................195
5.9.5 ip igmp snooping mrouter-time-out................................................................................195
5.9.6 ip igmp snooping leave-time-out....................................................................................196
5.9.7 show ip igmp snooping mrouter.....................................................................................197
5.9.8 show ip igmp snooping interface....................................................................................197
5.9.9 show ip igmp snooping groups ......................................................................................198
5.10 IPAddressing Commands .....................................................................................................199
5.10.1 ip address....................................................................................................................199
5.10.2 ip address dhcp ...........................................................................................................200

5.10.3 ip default-gateway........................................................................................................201
5.10.4 show ip interface..........................................................................................................202
5.10.5 arp ...............................................................................................................................202
5.10.6 arp timeout...................................................................................................................203
5.10.7 clear arp-cache............................................................................................................204
5.10.8 show arp......................................................................................................................204
5.11 LACP Commands ..................................................................................................................205
5.11.1 lacp system-priority......................................................................................................205
5.11.2 lacp port-priority...........................................................................................................205
5.11.3 lacp timeout..................................................................................................................206
5.11.4 show lacp ethernet.......................................................................................................207
5.11.5 show lacp port-channel................................................................................................207
5.12 Line Commands.....................................................................................................................209
5.12.1 line...............................................................................................................................209
5.12.2 speed...........................................................................................................................209
5.12.3 exec-timeout................................................................................................................210
5.12.4 show line......................................................................................................................211
5.13 Management ACL Commands...............................................................................................212
5.13.1 management access-list..............................................................................................212
5.13.2 permit (management) ..................................................................................................213
5.13.3 deny (management).....................................................................................................214
5.13.4 management access-class ..........................................................................................215
5.13.5 show management access-list.....................................................................................215
5.13.6 show management access-class.................................................................................216
5.14 PHY Diagnostics Commands.................................................................................................217
5.14.1 test copper-port tdr ......................................................................................................217
5.14.2 show copper-ports tdr..................................................................................................217
5.14.3 show copper-ports cable-length...................................................................................218
5.14.4 show fiber-ports optical-transceiver .............................................................................219
5.15 Port Channel Commands.......................................................................................................221
5.15.1 interface port-channel..................................................................................................221
5.15.2 interface range port-channel........................................................................................221
5.15.3 channel-group..............................................................................................................222
5.15.4 show interfaces port-channel.......................................................................................223
5.16 Port Monitor Commands........................................................................................................224
5.16.1 port monitor..................................................................................................................224
5.16.2 show ports monitor ......................................................................................................225
5.17 QoS Commands ....................................................................................................................226

5.17.1 qos...............................................................................................................................226
5.17.2 show qos......................................................................................................................226
5.17.3 wrr-queue cos-map......................................................................................................227
5.17.4 wrr-queue bandwidth ...................................................................................................228
5.17.5 priority-queue out num-of-queues................................................................................229
5.17.6 show qos interface.......................................................................................................230
5.17.7 qos map dscp-queue ...................................................................................................233
5.17.8 qos trust (Global).........................................................................................................233
5.17.9 qos trust (Interface)......................................................................................................234
5.17.10 qos cos ......................................................................................................................235
5.17.11 qos cos override.........................................................................................................236
5.17.12 show qos map............................................................................................................236
5.18 Radius Commands ................................................................................................................238
5.18.1 radius-server host........................................................................................................238
5.18.2 radius-server key.........................................................................................................239
5.18.3 radius-server retransmit...............................................................................................240
5.18.4 radius-server source-ip................................................................................................240
5.18.5 radius-server timeout...................................................................................................241
5.18.6 radius-server deadtime................................................................................................242
5.18.7 show radius-servers.....................................................................................................242
5.19 RMON Commands.................................................................................................................243
5.19.1 show rmon statistics.....................................................................................................243
5.19.2 rmon collection history.................................................................................................245
5.19.3 show rmon collection history........................................................................................246
5.19.4 show rmon history........................................................................................................247
5.19.5 rmon alarm...................................................................................................................250
5.19.6 show rmon alarm-table ................................................................................................252
5.19.7 show rmon alarm.........................................................................................................253
5.19.8 rmon event...................................................................................................................255
5.19.9 show rmon events........................................................................................................255
5.19.10 show rmon log ...........................................................................................................257
5.19.11 rmon table-size...........................................................................................................258
5.20 SNMP Commands.................................................................................................................258
5.20.1 snmp-server community ..............................................................................................258
5.20.2 snmp-server contact ....................................................................................................260
5.20.3 snmp-server location ...................................................................................................260
5.20.4 snmp-server enable traps............................................................................................261
5.20.5 snmp-server trap authentication ..................................................................................262

5.20.6 snmp-server host.........................................................................................................262
5.20.7 snmp-server set...........................................................................................................263
5.20.8 show snmp...................................................................................................................264
5.21 Spanning-Tree Commands....................................................................................................266
5.21.1 spanning-tree...............................................................................................................266
5.21.2 spanning-tree mode.....................................................................................................266
5.21.3 spanning-tree forward-time..........................................................................................267
5.21.4 spanning-tree hello-time ..............................................................................................267
5.21.5 spanning-tree max-age................................................................................................268
5.21.6 spanning-tree priority...................................................................................................269
5.21.7 spanning-tree disable ..................................................................................................269
5.21.8 spanning-tree cost .......................................................................................................270
5.21.9 spanning-tree port-priority............................................................................................271
5.21.10 spanning-tree portfast................................................................................................271
5.21.11 spanning-tree link-type...............................................................................................272
5.21.12 spanning-tree pathcost method .................................................................................273
5.21.13 spanning-tree bpdu....................................................................................................273
5.21.14 clear spanning-tree detected-protocols......................................................................274
5.21.15 show spanning-tree ...................................................................................................275
5.22 SSH and SLOGIN Commands...............................................................................................277
5.22.1 ip ssh port....................................................................................................................277
5.22.2 ip ssh server ................................................................................................................277
5.22.3 crypto key generate dsa ..............................................................................................278
5.22.4 crypto key generate rsa ...............................................................................................279
5.22.5 ip ssh pubkey-auth.......................................................................................................279
5.22.6 crypto key pubkey-chain ssh........................................................................................280
5.22.7 user-key.......................................................................................................................280
5.22.8 key-string.....................................................................................................................281
5.22.9 show ip ssh..................................................................................................................282
5.22.10 show crypto key mypubkey........................................................................................283
5.22.11 show crypto key pubkey-chain ssh ............................................................................284
5.23 System Management.............................................................................................................285
5.23.1 ping..............................................................................................................................285
5.23.2 traceroute.....................................................................................................................286
5.23.3 telnet............................................................................................................................288
5.23.4 resume.........................................................................................................................291
5.23.5 reload...........................................................................................................................292
5.23.6 hostname.....................................................................................................................292

5.23.7 show users...................................................................................................................293
5.23.8 show sessions .............................................................................................................294
5.23.9 show system................................................................................................................294
5.23.10 show version..............................................................................................................296
5.24 Syslog Commands.................................................................................................................296
5.24.1 logging on....................................................................................................................296
5.24.2 logging.........................................................................................................................297
5.24.3 logging console............................................................................................................298
5.24.4 logging buffered...........................................................................................................299
5.24.5 logging buffered size....................................................................................................299
5.24.6 clear logging ................................................................................................................300
5.24.7 logging file....................................................................................................................300
5.24.8 clear logging file...........................................................................................................301
5.24.9 show logging................................................................................................................302
5.24.10 show logging file ........................................................................................................303
5.24.11 show syslog-servers...................................................................................................304
5.25 TACACS Commands .............................................................................................................305
5.25.1 tacacs-server host .......................................................................................................305
5.25.2 tacacs-server key.........................................................................................................306
5.25.3 tacacs-server timeout...................................................................................................307
5.25.4 tacacs-server source-ip................................................................................................307
5.25.5 show tacacs.................................................................................................................308
5.26 User Interface Commands.....................................................................................................309
5.26.1 enable..........................................................................................................................309
5.26.2 disable .........................................................................................................................310
5.26.3 configure......................................................................................................................310
5.26.4 login.............................................................................................................................311
5.26.5 exit(configuration) ........................................................................................................312
5.26.6 exit(EXEC)...................................................................................................................312
5.26.7 end...............................................................................................................................313
5.26.8 help..............................................................................................................................313
5.26.9 history..........................................................................................................................314
5.26.10 history size.................................................................................................................314
5.26.11show history................................................................................................................315
5.26.12 show privilege............................................................................................................315
5.27 VLAN Commands..................................................................................................................316
5.27.1 vlan database ..............................................................................................................316
5.27.2 vlan..............................................................................................................................317

5.27.3 default-vlan disable......................................................................................................317
5.27.4 interface vlan ...............................................................................................................318
5.27.5 interface range vlan .....................................................................................................319
5.27.6 name............................................................................................................................319
5.27.7 switchport mode...........................................................................................................320
5.27.8 switchport access vlan.................................................................................................321
5.27.9 switchport trunk allowed vlan.......................................................................................321
5.27.10 switchport trunk native vlan........................................................................................322
5.27.11 switchport general allowed vlan.................................................................................323
5.27.12 switchport general pvid..............................................................................................324
5.27.13 switchport general ingress-filtering disable................................................................324
5.27.14 switchport general acceptable-frame-type taggedonly...............................................325
5.27.15 switchport forbidden vlan...........................................................................................326
5.27.16 map protocol protocols-group....................................................................................326
5.27.17 switchport general map protocols-group vlan ............................................................327
5.27.18 ip internal-usage-vlan ................................................................................................328
5.27.19 show vlan...................................................................................................................329
5.27.20 show vlan internal usage ...........................................................................................329
5.27.21 show interfaces switchport.........................................................................................330
5.28 Web Server Commands.........................................................................................................331
5.28.1 ip http server................................................................................................................331
5.28.2 ip http port....................................................................................................................332
5.28.3 ip https server..............................................................................................................332
5.28.4 ip https port..................................................................................................................333
5.28.5 crypto certificate generate ...........................................................................................334
5.28.6 show ip http..................................................................................................................334
5.28.7 show ip https................................................................................................................335
5.29 802.1x Commands.................................................................................................................335
5.29.1 aaa authentication dot1x..............................................................................................335
5.29.2 dot1x system-auth-control............................................................................................336
5.29.3 dot1x port-control.........................................................................................................337
5.29.4 dot1x re-authentication ................................................................................................338
5.29.5 dot1x timeout re-authperiod.........................................................................................338
5.29.6 dot1x re-authenticate...................................................................................................339
5.29.7 dot1x timeout quiet-period ...........................................................................................340
5.29.8 dot1x timeout tx-period ................................................................................................340
5.29.9 dot1x max-req..............................................................................................................341
5.29.10 dot1x timeout supp-timeout........................................................................................342

5.29.11 dot1x timeout server-timeout......................................................................................342
5.29.12 show dot1x.................................................................................................................343
5.29.13 show dot1x users.......................................................................................................345
5.29.14 show dot1x statistics..................................................................................................346
5.29.15 dot1x auth-not-req .....................................................................................................348
5.29.16 dot1x multiple-hosts...................................................................................................348
5.29.17 dot1x single-host-violation .........................................................................................349
5.29.18 show dot1x advanced................................................................................................350
TROUBLE SHOOTING.........................................................................................................................352
APPENDEX A .......................................................................................................................................353
A.1 Switch's RJ-45 Pin Assignments .............................................................................................353
A.2 RJ-45 cable pin assignment ....................................................................................................354
A.3 Available Modules....................................................................................................................355

1. INTRODUCTION
Packet Contents
Check the contents of your package for following parts:
•Managed Fast Ethernet Switch x1
•CD-ROM user's manual x1
•Quick installation guide x1
•19" rack mounting kit x1
•AC adapter x1
•RS-232 console x 1
•Rubber feet x 4
If any of these are missing or damaged, please contact your dealer immediately, if possible, retain the
carton including the original packing material, and use them against to repack the product in case there is
a need to return it to us for repair.
How to Use This Manual
This User Manual is structured as follows:
•Section 2, Installation
The section explains the functions of the Switch and how to physically install the Switch.
•Section 3, Configuration
The section contains the information about the software function of the Switch.
•Section 4, Switch Operation
ThesectioncontainsspecificationsoftheSwitch.
•Appendex A
The section contains cable information of the Switch.
In the following section, terms "Switch" with upper case denotes the WGSD-1022 Managed Ethernet
switch. Terms with lower case "switch" means other Ethernet switch devices.

Product Feature
Generic Features
Comply with the IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3z Gigabit Ethernet
standard
8-Port 10/100Mbps TP interfaces with auto-negotiation.
2 10/100/1000Mbps TP ports and 2 SFP shared combo interfaces
Supports auto-negotiation and Half-Duplex / Full-Duplex modes for all 10Base-T/100Base-TX
and 1000Base-T ports.
Auto-MDI/MDI-X detection on each RJ-45 port
Prevents packet loss with back pressure (Half-Duplex) and IEEE 802.3x PAUSE frame flow
control (Full-Duplex)
High performance Store and Forward architecture, broadcast storm control, runt/CRC filtering
eliminates erroneous packets to optimize the network bandwidth
8K MAC address table, automatic source address learning and ageing
1Mbit embedded memory for packet buffers
Layer-2 Switching
Supports IEEE 802.1Q Tagged based VLAN
GVRP protocol for VLAN Management
Support up to 4 Trunk groups, each trunk for up to maximum 4 port with 800Mbps
bandwidth( Full Duplex Mode)
Support IGMP Snooping
IEEE 802.1d, IEEE 802.1w, classic Spanning Tree Algorithm or Rapid Spanning Tree support
Supports the IEEE 802.1s specification for multiple spanning trees on a single port (spanning
tree per VLAN).
Port Mirroring to monitor the incoming or outgoing traffic on a particular port
Quality of Service
4 priority queues on all switch ports.
Support for strict priority and weighted round robin (WRR) CoS policies
Support QoS and bandwidth control on each port
Traffic-policing policies on the switch port
Security
802.1x Port-Based Authentication
L2-L4 ACL to management the per-flow traffic
Port Security to limit the number of clients to access network
Management
WEB-Based, Telnet, Console Command Line management
Console interface for Switch basic management and setup

Access through SNMPv1,v2c and v3 security set and get requests.
Four groups (history, statistics, alarms, and events) of embedded remote monitoring (RMON)
agents for network monitoring and traffic analysis
Built-in Trivial File Transfer Protocol (TFTP) client
Virtual Cable Test (VCT) technology provides the mechanism to detect and report potential
cabling issues, such as cable opens, cable shorts, etc. on Copper Links
EMI standards comply with FCC, CE class A,WEEE RoHS
Product Specification
Product WGSD-1022
8-Port 10/100Mbps + 2 Gigabit TP / SFP combo Managed Ethernet Switch
Hardware Specification
Ports 8 10/ 100Base-TX RJ-45 Auto-MDI/MDI-X ports
Gigabit ports 2 share 10/100/1000Base-T / SFP combo interfaces
Switch Processing
Scheme Store-and-Forward
Switch fabric 5.6Gbps / Non-Blocking
Throughput 4.17Mpps / Wire-Speed
Address Table 8K entries
Share data Buffer 1 Mbit
Flow Control Back pressure for Half-Duplex, IEEE 802.3x Pause Frame for Full-Duplex
Dimension (W x D x H) 267 x 170 x 45 mm, 1U height
Weight 1.2 KG
Power Requirement 100~240V AC, 50-60, Auto-sensing
Power Consumption 13.2 Watts / 45 BTU
Management Interface Console. Telnet, SSH, Web, SSL, SNMP
Smart function
System Configuration Console / Web / telnet interfaces
Port configuration Port disable/enable. Auto-negotiation 10/100Mbps full and half duplex mode
selection. Flow control Disable / Enable. Bandwidth control on each port.
Port Status Display each port’s speed duplex mode, link status, Flow control status.Auto
negotiation status, trunk status.
VLAN IEEE 802.1Q Tagged Based VLAN ,up to 255 VLAN groups
Port trunking Support 4 groups of 4-Port trunk support
QoS Traffic classification based on Port Number, 802.1p priority, DS/TOS field in

IP Packet
IGMP Snooping Allow to disable or enable.
Standards Conformance
Regulation Compliance FCC Part 15 Class A, CE
Standards Compliance
IEEE 802.3 10BASE-T
IEEE 802.3u 100BASE-TX/100BASE-FX
IEEE 802.3z Gigabit SX/LX
IEEE 802.3ab Gigabit 1000T
IEEE 802.3x Flow Control and Back pressure
IEEE 802.3ad Port trunk with LACP
IEEE 802.1d Spanning tree protocol
IIEEE 802.1w Rapid spanning tree protocol
IEEE 802.1p Class of service
IEEE 802.1Q VLAN Tagging
Environment
Regulation Compliance FCC Part 15 Class A, CE
Operating Temperature 0℃~50℃,
Storage Temperature -40℃~70℃,
Operating Humidity 5% to 90%, relative humidity, non-condensing
Storage Humidity 5% to 90%, relative humidity, non-condensing

2. INSTALLATION
This section describes the functionalities of the Switch's components and guides how to install it on the
desktop or shelf. Basic knowledge of networking is assumed. Please read this chapter completely before
continuing.
2.1 Product Description
The PLANET WGSD-1022 is a 8-Port 10/100Mbps with 2 shared SFP/copper GbE interfaces Gigabit
Ethernet Switch. It boasts a high performance switch architecture that is capable of providing
non-blocking switch fabric and wire-speed throughput as high as 5.6Gbps. Its two built-in GbE uplink
ports also offer incredible extensibility, flexibility and connectivity to the Core switch or Servers.
2.1.1 Product Overview
PLANET WGSD-1022 is loaded with powerful traffic management and QoS features to enhance services
offered by telcos. It provides 4 priority queues per port for different types of traffics, allowing
administrators to set policies for classified filtering and rule-based rate limitation. The WGSD-1022
prioritizes applications with WFQ (Weighted Fair Queuing) scheduling algorithm to allocate more
bandwidth to key traffics such as voice transmission, empowering the enterprise to take full advantages
of the limited network resources and guarantee the best performance.
PLANET WGSD-1022 offers comprehensive Access Control List (ACL) for enforcing security to the edge.
Its protection mechanisms comprised of port-based 802.1x user and device authentication. The
administrators can now construct highly secured corporate networks with time and effort considerably
less then before.
With its built-in web-based management, the PLANET WGSD-1022 offers an easy-to-use,
platform-independent management and configuration facility. The PLANET WGSD-1022 supports
standard Simple Network Management Protocol (SNMP) and can be managed via any standard-based
management software. For text-based management, the WGSD-1022 can also be accessed via Telnet
and the console port. For secure remote management, the WGSD-1022 support SSL and SSH
connection which encrypt the packet content at each session.

2.1.2 Switch Front Panel
Figure 2-1 shows the front panel of the Switch.
mini-GBIC
G1 G2
G1/G2
mini-GBIC
38400, N, 8, 1
Intelligent 8-Port 10/100Mbps+2 Gigabit Ethernet Switch
PWR
LNK/ACT
100
13574268910
LNK/ACT
1000
910
Figure 2-1 WGSD-1022 front panel.
2.1.3 LED Indications
System
LED Color Function
PWR Green Lights to indicate that the Switch has power.
Per 10/100Mbps port
LED Color Function
LNK/ACT Green
Lights to indicate the link through that port is successfully established.
Blink: indicate that the Switch is actively sending or receiving data over
that port.
100 Orange Lights to indicate the port is running in 100Mbps speed.
Off: indicate that the port is operating at 10Mbps.
Per 10/100/1000Base-T port /SFP interfaces
LED Color Function
LNK/ACT Green
Lights to indicate the link through that port is successfully established.
Blink: indicate that the Switch is actively sending or receiving data over that
port.
1000 Orange Lights to indicate the port is running in 1000Mbps speed.
Off: indicate that the port is operating at 10Mbps or 100Mbps.
2.1.4 Switch Rear Panel
Figure 2-2 shows the rear panel of the Switch
Figure 2-2 WGSD-1022 rear panel.
