Planet Networking & Communication WGSW-50040 User manual

1
Configuration Guide
WGSW-50040
50-Port 10/100/1000Mbps
with 4 Shared SFP
Managed Gigabit Switch

2
Trademarks
Copyright © PLANET Technology Corp. 2010.
Contents subject to which revision without prior notice.
PLANET is a registered trademark of PLANET Technology Corp. All other trademarks belong to their
respective owners.
Disclaimer
PLANET Technology does not warrant that the hardware will work properly in all environments and
applications, and makes no warranty and representation, either implied or expressed, with respect to the
quality, performance, merchantability, or fitness for a particular purpose. PLANET has made every effort to
ensure that this User's Manual is accurate; PLANET disclaims liability for any inaccuracies or omissions that
may have occurred.
Information in this User's Manual is subject to change without notice and does not represent a commitment on
the part of PLANET. PLANET assumes no responsibility for any inaccuracies that may be contained in this
User's Manual. PLANET makes no commitment to update or keep current the information in this User's
Manual, and reserves the right to make improvements to this User's Manual and/or to the products described
in this User's Manual, at any time without notice.
If you find information in this manual that is incorrect, misleading, or incomplete, we would appreciate your
comments and suggestions.
FCC Warning
This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to
Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful
interference when the equipment is operated in a commercial environment. This equipment generates, uses,
and can radiate radio frequency energy and, if not installed and used in accordance with the Instruction
manual, may cause harmful interference to radio communications. Operation of this equipment in a residential
area is likely to cause harmful interference in which case the user will be required to correct the interference at
whose own expense.
CE Mark Warning
This is a Class A product. In a domestic environment, this product may cause radio interference, in which
case the user may be required to take adequate measures.
WEEE Warning
To avoid the potential effects on the environment and human health as a result of the
presence of hazardous substances in electrical and electronic equipment, end users of
electrical and electronic equipment should understand the meaning of the crossed-out
wheeled bin symbol. Do not dispose of WEEE as unsorted municipal waste and have to
collect such WEEE separately.
Energy Saving Note of the Device
This power required device does not support Standby mode operation.
For energy saving, please remove the power cable to disconnect the device from the power circuit.
Without removing power cable, the device will still consuming power from the power source. In the view of
Saving the Energy and reduce the unnecessary power consuming, it is strongly suggested to remove the
power connection for the device if this device is not intended to be active.
Revision
PLANET 50-Port 10/100/1000Mbps with 4 Shared SFP Managed Gigabit Switch User's Manual
FOR MODEL: WGSW-50040
REVISION: 1.0 (AUGUST.2010)
Part No: EM-WGSW-50040 (2081-A93200-000)

1
Content
CHAPTER 1 INTRODUTION........................................................................................... 1-1
1.1 PACKET CONTENTS ............................................................................................................................. 1-1
1.2 PRODUCT DESCRIPTION....................................................................................................................... 1-1
1.3 PRODUCT FEATURES ........................................................................................................................... 1-3
1.4 PRODUCT SPECIFICATION..................................................................................................................... 1-2
CHAPTER 2 INSTALLATION.......................................................................................... 2-1
2.1 HARDWARE DESCRIPTION .................................................................................................................... 2-1
2.1.1 Switch Front Panel.................................................................................................................. 2-1
2.1.2 LED Indications....................................................................................................................... 2-2
2.1.3 Switch Rear Panel................................................................................................................... 2-3
2.2 INSTALL THE SWITCH ........................................................................................................................... 2-4
2.2.1 Desktop Installation................................................................................................................. 2-4
2.2.2 Rack Mounting ........................................................................................................................ 2-5
2.2.3 Installing the SFP transceiver ................................................................................................. 2-6
CHAPTER 3 SWITCH MANAGEMENT .......................................................................... 3-8
3.1 MANAGEMENT OPTIONS....................................................................................................................... 3-8
3.1.1 Out-Of-Band Management...................................................................................................... 3-8
3.1.2 In-band Management............................................................................................................ 3-11
3.2 CLI INTERFACE.................................................................................................................................. 3-16
3.2.1 Configuration Modes............................................................................................................. 3-17
3.2.2 Configuration Syntax.............................................................................................................3-19
3.2.3 Shortcut Key Support............................................................................................................3-19
3.2.4 Help Function........................................................................................................................3-20
3.2.5 Input Verification.................................................................................................................... 3-20
3.2.6 Fuzzy Match Support ............................................................................................................3-21
CHAPTER 4 BASIC SWITCH CONFIGURATION .......................................................... 4-1
4.1 BASIC CONFIGURATION........................................................................................................................ 4-1
4.2 TELNET MANAGEMENT......................................................................................................................... 4-2
4.2.1 Telnet....................................................................................................................................... 4-2
4.2.2 SSH......................................................................................................................................... 4-3
4.3CONFIGURATE SWITCH IP ADDRESSES ................................................................................................. 4-5
4.3.1 Switch IP Addresses Configuration Task List.......................................................................... 4-5
4.4 SNMP CONFIGURATION....................................................................................................................... 4-6
4.4.1 Introduction to SNMP.............................................................................................................. 4-6
4.4.2 Introduction to MIB.................................................................................................................. 4-7
4.4.3 Introduction to RMON ............................................................................................................. 4-8

2
4.4.4 SNMP Configuration ............................................................................................................... 4-9
4.4.5 Typical SNMP Configuration Examples ................................................................................ 4-11
4.4.6 SNMP Troubleshooting .........................................................................................................4-13
4.5 SWITCH UPGRADE ............................................................................................................................. 4-13
4.5.1 Switch System Files..............................................................................................................4-13
4.5.2 BootROM Upgrade................................................................................................................4-14
4.5.3 FTP/TFTP Upgrade...............................................................................................................4-16
CHAPTER 5 CLUSTER CONFIGURATION.................................................................... 5-1
5.1 INTRODUCTION TO CLUSTER NETWORK MANAGEMENT............................................................................ 5-1
5.2 CLUSTER NETWORK MANAGEMENT CONFIGURATION SEQUENCE........................................................... 5-1
5.3 EXAMPLES OF CLUSTER ADMINISTRATION ............................................................................................ 5-5
5.4 CLUSTER ADMINISTRATION TROUBLESHOOTING.................................................................................... 5-5
CHAPTER 6 PORT CONFIGURATION........................................................................... 6-1
6.1 INTRODUCTION TO PORT ...................................................................................................................... 6-1
6.2 NETWORK PORT CONFIGURATION TASK LIST........................................................................................ 6-1
6.3 PORT CONFIGURATION EXAMPLE ......................................................................................................... 6-2
6.4 PORT TROUBLESHOOTING.................................................................................................................... 6-3
CHAPTER 7 PORT LOOPBACK DETECTION FUNCTION CONFIGURATION............ 7-4
7.1 INTRODUCTION TO PORT LOOPBACK DETECTION FUNCTION .................................................................. 7-4
7.2 PORT LOOPBACK DETECTION FUNCTION CONFIGURATION TASK LIST .................................................... 7-4
7.3 PORT LOOPBACK DETECTION FUNCTION EXAMPLE............................................................................... 7-6
7.4 PORT LOOPBACK DETECTION TROUBLESHOOTING................................................................................ 7-6
CHAPTER 8 PORT CHANNEL CONFIGURATION ........................................................ 8-1
8.1 INTRODUCTION TO PORT CHANNEL....................................................................................................... 8-1
8.2 PORT CHANNEL CONFIGURATION TASK LIST......................................................................................... 8-2
8.3 PORT CHANNEL EXAMPLES.................................................................................................................. 8-3
8.4 PORT CHANNEL TROUBLESHOOTING .................................................................................................... 8-5
CHAPTER 9 JUMBO CONFIGURATION........................................................................ 9-1
9.1 INTRODUCTION TO JUMBO .................................................................................................................... 9-1
9.2 JUMBO CONFIGURATION TASK SEQUENCE............................................................................................ 9-1
CHAPTER 10 VLAN CONFIGURATION........................................................................10-1
10.1 VLAN CONFIGURATION ................................................................................................................... 10-1
10.1.1 Introduction to VLAN........................................................................................................... 10-1
10.1.2 VLAN Configuration Task List .............................................................................................10-2

3
10.1.3 Typical VLAN Application ....................................................................................................10-4
10.2 GVRP CONFIGURATION ................................................................................................................... 10-5
10.2.1 Introduction to GVRP.......................................................................................................... 10-5
10.2.2 GVRP Configuration Task List............................................................................................. 10-6
10.2.3 Typical GVRP Application ...................................................................................................10-7
10.2.4 GVRP Troubleshooting ....................................................................................................... 10-8
10.3 DOT1Q-TUNNEL CONFIGURATION ..................................................................................................... 10-8
10.3.1 Introduction to Dot1q-tunnel................................................................................................ 10-8
10.3.2 Dot1q-tunnel Configuration................................................................................................. 10-9
10.3.3 Typical Applications of the Dot1q-tunnel...........................................................................10-10
10.3.4 Dot1q-tunnel Troubleshooting........................................................................................... 10-11
10.4 DYNAMIC VLAN CONFIGURATION................................................................................................... 10-11
10.4.1 Introduction to Dynamic VLAN.......................................................................................... 10-11
10.4.2 Dynamic VLAN Configuration ........................................................................................... 10-12
10.4.3 Typical Application of the Dynamic VLAN.........................................................................10-14
10.4.4 Dynamic VLAN Troubleshooting....................................................................................... 10-15
10.5 VOICE VLAN CONFIGURATION ....................................................................................................... 10-15
10.5.1 Introduction to Voice VLAN...............................................................................................10-15
10.5.2 Voice VLAN Configuration.................................................................................................10-16
10.5.3 Typical Applications of the Voice VLAN ............................................................................10-16
10.5.4 Voice VLAN Troubleshooting ............................................................................................ 10-17
CHAPTER 11 MAC TABLE CONFIGURATION.............................................................11-1
11.1 INTRODUCTION TO MAC TABLE ........................................................................................................ 11-1
11.1.1 Obtaining MAC Table........................................................................................................... 11-1
11.1.2 Forward or Filter.................................................................................................................. 11-3
11.2 MAC ADDRESS TABLE CONFIGURATION TASK LIST............................................................................ 11-3
11.3 TYPICAL CONFIGURATION EXAMPLES ............................................................................................... 11-4
11.4 MAC TABLE TROUBLESHOOTING ..................................................................................................... 11-5
11.5 MAC ADDRESS FUNCTION EXTENSION............................................................................................. 11-5
11.5.1 MAC Address Binding ......................................................................................................... 11-5
CHAPTER 12 MSTP CONFIGURATION........................................................................12-1
12.1 INTRODUCTION TO MSTP................................................................................................................. 12-1
12.1.1 MSTP Region......................................................................................................................12-1
12.1.2 Port Roles............................................................................................................................12-3
12.1.3 MSTP Load Balance ...........................................................................................................12-3
12.2 MSTP CONFIGURATION TASK LIST................................................................................................... 12-3
12.3 MSTP EXAMPLE.............................................................................................................................. 12-6
12.4 MSTP TROUBLESHOOTING ............................................................................................................ 12-10
CHAPTER 13 QOS CONFIGURATION..........................................................................13-1

4
13.1 INTRODUCTION TO QOS................................................................................................................... 13-1
13.1.1 QoS Terms .......................................................................................................................... 13-1
13.1.2 QoS Implementation ...........................................................................................................13-2
13.1.3 Basic QoS Model ................................................................................................................ 13-2
13.2 QOSCONFIGURATION TASK LIST ..................................................................................................... 13-6
13.3 QOSEXAMPLE .............................................................................................................................. 13-10
13.4 QOSTROUBLESHOOTING............................................................................................................... 13-12
CHAPTER 14 FLOW-BASED REDIRECTION.............................................................14-13
14.1 INTRODUCTION TO FLOW-BASED REDIRECTION ............................................................................... 14-13
14.2 FLOW-BASED REDIRECTION CONFIGURATION TASK SEQUENCE ....................................................... 14-13
14.3 FLOW-BASED REDIRECTION EXAMPLES.......................................................................................... 14-14
14.4 FLOW-BASED REDIRECTION TROUBLESHOOTING HELP.................................................................... 14-14
CHAPTER 15 LAYER 3 MANAGEMENT CONFIGURATION........................................15-1
15.1 LAYER 3MANAGEMENT INTERFACE .................................................................................................. 15-1
15.1.1 Introduction to Layer 3 Management Interface................................................................... 15-1
15.1.2 Layer 3 Interface Configuration Task List............................................................................ 15-1
15.2 IPCONFIGURATION.......................................................................................................................... 15-2
15.2.1 IP Configuration...................................................................................................................15-2
15.2.2 IPv6 Troubleshooting ..........................................................................................................15-5
15.3 ARP ............................................................................................................................................... 15-5
15.3.1 Introduction to ARP .............................................................................................................15-5
15.3.2 ARP Configuration Task List................................................................................................15-5
15.3.3 ARP Troubleshooting .......................................................................................................... 15-5
CHAPTER 16 ARP SCANNING PREVENTION FUNCTION CONFIGURATION ..........16-1
16.1 INTRODUCTION TO ARP SCANNING PREVENTION FUNCTION .............................................................. 16-1
16.2 ARP SCANNING PREVENTION CONFIGURATION TASK SEQUENCE ...................................................... 16-1
16.3 ARP SCANNING PREVENTION TYPICAL EXAMPLES............................................................................ 16-3
16.4 ARP SCANNING PREVENTION TROUBLESHOOTING HELP................................................................... 16-4
CHAPTER 17 ARP GUARD CONFIGURATION............................................................17-1
17.1 INTRODUCTION TO ARP GUARD ..................................................................................................... 17-1
17.2 ARP GUARD CONFIGURATION TASK LIST ....................................................................................... 17-2
CHAPTER 18 DHCP CONFIGURATION .......................................................................18-1
18.1 INTRODUCTION TO DHCP................................................................................................................. 18-1
18.2 DHCP SERVER CONFIGURATION...................................................................................................... 18-2
18.3 DHCP CONFIGURATION EXAMPLES.................................................................................................. 18-4

5
18.4 DHCP TROUBLESHOOTING.............................................................................................................. 18-5
CHAPTER 19 DHCP SNOOPING CONFIGURATION ...................................................19-1
19.1 INTRODUCTION TO DHCP SNOOPING................................................................................................ 19-1
19.2 DHCP SNOOPING CONFIGURATION TASK SEQUENCE........................................................................ 19-2
19.3 DHCP SNOOPING TYPICAL APPLICATION.......................................................................................... 19-5
19.4 DHCP SNOOPING TROUBLESHOOTING HELP.................................................................................... 19-6
19.4.1 Monitor and Debug Information ..........................................................................................19-6
19.4.2 DHCP Snooping Troubleshooting Help...............................................................................19-6
CHAPTER 20 DHCP SNOOPING OPTION 82 CONFIGURATION................................20-7
20.1 INTRODUCTION TO DHCP SNOOPING OPTION 82............................................................................... 20-7
20.1.1 DHCP option 82 Message Structure................................................................................... 20-7
20.1.2 option 82 Working Mechanism............................................................................................ 20-8
20.2 DHCP SNOOPING OPTION 82 CONFIGURATION TASK LIST................................................................. 20-8
20.3 DHCP OPTION 82 APPLICATION EXAMPLES...................................................................................... 20-9
20.4 DHCP SNOOPING OPTION 82 TROUBLESHOOTING .......................................................................... 20-10
CHAPTER 21 IPV4 MULTICAST PROTOCOL............................................................21-11
21.1 IPV4MULTICAST PROTOCOL OVERVIEW......................................................................................... 21-11
21.1.1 Introduction to Multicast.................................................................................................... 21-11
21.1.2 Multicast Address.............................................................................................................. 21-11
21.1.3 IP Multicast Packet Transmission .....................................................................................21-13
21.1.4 IP Multicast Application .....................................................................................................21-13
21.2 DCSCM........................................................................................................................................ 21-14
21.2.1 Introduction to DCSCM..................................................................................................... 21-14
21.2.2 DCSCM Configuration Task List........................................................................................21-14
21.2.3 DCSCM Configuration Examples......................................................................................21-17
21.2.4 DCSCM Troubleshooting .................................................................................................. 21-18
21.3 IGMP SNOOPING........................................................................................................................... 21-18
21.3.1 Introduction to IGMP Snooping......................................................................................... 21-18
21.3.2 IGMP Snooping Configuration Task List ...........................................................................21-19
21.3.3 IGMP Snooping Examples................................................................................................ 21-21
21.3.4 IGMP Snooping Troubleshooting......................................................................................21-23
CHAPTER 22 IPV6 MULTICAST PROTOCOL..............................................................22-1
22.1 MLD SNOOPING .............................................................................................................................. 22-1
22.1.1 Introduction to MLD Snooping.............................................................................................22-1
22.1.2 MLD Snooping Configuration Task......................................................................................22-1
22.1.3 MLD Snooping Examples....................................................................................................22-3
22.1.4 MLD Snooping Troubleshooting.......................................................................................... 22-5
CHAPTER 23 MULTICAST VLAN .................................................................................23-1

6
23.1 INTRODUCTIONS TO MULTICAST VLAN ............................................................................................. 23-1
23.2 MULTICAST VLAN CONFIGURATION TASK LIST................................................................................. 23-1
23.3 MULTICAST VLAN EXAMPLES.......................................................................................................... 23-2
CHAPTER 24 ACL CONFIGURATION ..........................................................................24-4
24.1 INTRODUCTION TO ACL.................................................................................................................... 24-4
24.1.1 Access-list ........................................................................................................................... 24-4
24.1.2 Access-group ......................................................................................................................24-4
24.1.3 Access-list Action and Global Default Action....................................................................... 24-4
24.2 ACL CONFIGURATION TASK LIST...................................................................................................... 24-5
24.3 ACL EXAMPLE .............................................................................................................................. 24-18
24.4 ACL TROUBLESHOOTING............................................................................................................... 24-22
CHAPTER 25 802.1X CONFIGURATION ......................................................................25-1
25.1 INTRODUCTION TO 802.1X................................................................................................................ 25-1
25.1.1 The Authentication Structure of 802.1x............................................................................... 25-1
25.1.2 The Work Mechanism of 802.1x ......................................................................................... 25-3
25.1.3 The Encapsulation of EAPOL Messages............................................................................25-3
25.1.4 The Encapsulation of EAP Attributes ..................................................................................25-5
25.1.5 Web Authentication Proxy based on 802.1x .......................................................................25-5
25.1.6 The Authentication Methods of 802.1x................................................................................25-6
25.1.7 The Extension and Optimization of 802.1x ....................................................................... 25-11
25.1.8 The Features of VLAN Allocation...................................................................................... 25-12
25.2 802.1X CONFIGURATION TASK LIST................................................................................................ 25-13
25.3 802.1X APPLICATION EXAMPLE...................................................................................................... 25-16
25.3.1 Examples of Guest Vlan Applications ...............................................................................25-16
25.3.2 Examples of IPv4 Radius Applications..............................................................................25-19
25.3.3 Examples of IPv6 Radius Application ...............................................................................25-20
25.3.4 802.1x Web Proxy Authentication Sample Application .....................................................25-21
25.4 802.1X TROUBLESHOOTING ........................................................................................................... 25-22
CHAPTER 26 THE NUMBER LIMITATION FUNCTION OF PORT, MAC IN VLAN
CONFIGURATION..........................................................................................................26-1
26.1 INTRODUCTION TO THE NUMBER LIMITATION FUNCTION OF PORT,MAC IN VLAN ............................... 26-1
26.2 THE NUMBER LIMITATION FUNCTION OF PORT,MAC IN VLAN CONFIGURATION TASK SEQUENCE.......26-1
26.3 THE NUMBER LIMITATION FUNCTION OF PORT,MAC IN VLAN TYPICAL EXAMPLES............................ 26-3
26.4 THE NUMBER LIMITATION FUNCTION OF PORT,MAC IN VLAN TROUBLESHOOTING HELP................... 26-3
CHAPTER 27 OPERATIONAL CONFIGURATION OF AM FUNCTION........................27-1
27.1 INTRODUCTION TO AM FUNCTION ..................................................................................................... 27-1
27.2 AM FUNCTION CONFIGURATION TASK LIST....................................................................................... 27-1

7
27.3 AM FUNCTION EXAMPLE.................................................................................................................. 27-3
27.4 AM FUNCTION TROUBLESHOOTING .................................................................................................. 27-3
CHAPTER 28 SECURITY FEATURE CONFIGURATION..............................................28-1
28.1 INTRODUCTION TO SECURITY FEATURE ............................................................................................. 28-1
28.2 SECURITY FEATURE CONFIGURATION ............................................................................................... 28-1
28.2.1 Prevent IP Spoofing Function Configuration Task Sequence .............................................28-1
28.2.2 Prevent TCP Unauthorized Label Attack Function Configuration Task Sequence .............28-1
28.2.3 Anti Port Cheat Function Configuration Task Sequence.....................................................28-2
28.2.4 Prevent TCP Fragment Attack Function Configuration Task Sequence .............................28-2
28.2.5 Prevent ICMP Fragment Attack Function Configuration Task Sequence ...........................28-3
28.3 SECURITY FEATURE EXAMPLE.......................................................................................................... 28-3
CHAPTER 29 TACACS+ CONFIGURATION.................................................................29-1
29.1 INTRODUCTION TO TACACS+.......................................................................................................... 29-1
29.2 TACACS+ CONFIGURATION TASK LIST............................................................................................ 29-1
29.3 TACACS+ SCENARIOS TYPICAL EXAMPLES..................................................................................... 29-2
29.4 TACACS+ TROUBLESHOOTING ....................................................................................................... 29-3
CHAPTER 30 RADIUS CONFIGURATION....................................................................30-1
30.1 INTRODUCTION TO RADIUS............................................................................................................. 30-1
30.1.1 AAA and RADIUS Introduction............................................................................................ 30-1
30.1.2 Message structure for RADIUS...........................................................................................30-1
30.2 RADIUS CONFIGURATION TASK LIST............................................................................................... 30-3
30.3 RADIUS TYPICAL EXAMPLES.......................................................................................................... 30-5
30.3.1 IPv4 Radius Example.......................................................................................................... 30-5
30.3.2 IPv6 RadiusExample........................................................................................................... 30-6
30.4 RADIUS TROUBLESHOOTING .......................................................................................................... 30-6
CHAPTER 31 MRPP CONFIGURATION .......................................................................31-8
31.1 INTRODUCTION TO MRPP ................................................................................................................ 31-8
31.1.1 Conception Introduction......................................................................................................31-8
31.1.2 MRPP Protocol Packet Types.............................................................................................31-9
31.1.3 MRPP Protocol Operation System.................................................................................... 31-10
31.2 MRPP CONFIGURATION TASK LIST ................................................................................................ 31-10
31.3 MRPP TYPICAL SCENARIO ............................................................................................................ 31-12
31.4 MRPP TROUBLESHOOTING............................................................................................................ 31-14
CHAPTER 32 MIRROR CONFIGURATION.................................................................32-15
32.1 INTRODUCTION TO MIRROR............................................................................................................. 32-15
32.2 MIRROR CONFIGURATION TASK LIST............................................................................................... 32-15

8
32.3 MIRROR EXAMPLES ....................................................................................................................... 32-16
32.4 DEVICE MIRROR TROUBLESHOOTING.............................................................................................. 32-17
CHAPTER 33 SFLOW CONFIGURATION...................................................................33-18
33.1 INTRODUCTION TO SFLOW.............................................................................................................. 33-18
33.2 SFLOW CONFIGURATION TASK LIST................................................................................................ 33-18
33.3 SFLOW EXAMPLES......................................................................................................................... 33-20
33.4 SFLOW TROUBLESHOOTING ........................................................................................................... 33-20
CHAPTER 34 SNTP CONFIGURATION......................................................................34-22
34.1 INTRODUCTION TO SNTP ............................................................................................................... 34-22
34.2 TYPICAL EXAMPLES OF SNTP CONFIGURATION .............................................................................. 34-23
CHAPTER 35 MONITOR AND DEBUG.......................................................................35-24
35.1 PING ............................................................................................................................................. 35-24
35.2 PING6........................................................................................................................................... 35-24
35.3 TRACEROUTE ................................................................................................................................ 35-24
35.4 TRACEROUTE6.............................................................................................................................. 35-24
35.5 SHOW ........................................................................................................................................... 35-25
35.6 DEBUG.......................................................................................................................................... 35-26
35.7 SYSTEM LOG ................................................................................................................................. 35-26
35.7.1 System Log Introduction ...................................................................................................35-26
35.7.2 System Log Configuration.................................................................................................35-28
35.7.3 System Log Configuration Example..................................................................................35-29
CHAPTER 36 RELOAD SWITCH AFTER SPECIFIED TIME........................................36-1
36.1 INTRODUCE TO RELOAD SWITCH AFTER SPECIFID TIME ..................................................................... 36-1
36.2 RELOAD SWITCH AFTER SPECIFID TIME TASK LIST............................................................................ 36-1
CHAPTER 37 DEBUGGING AND DIAGNOSIS FOR PACKETS RECEIVED AND SENT
BY CPU ..........................................................................................................................37-1
37.1 INTRODUCTION TO DEBUGGING AND DIAGNOSIS FOR PACKETS RECEIVED AND SENT BY CPU............. 37-1
37.2 DEBUGGING AND DIAGNOSIS FOR PACKETS RECEIVED AND SENT BY CPU TASK LIST ........................ 37-1
CHAPTER 38 APPENDEX A .........................................................................................38-1
38.1 A.1 SWITCH'S RJ-45 PIN ASSIGNMENTS........................................................................................... 38-1
38.2 A.2 10/100MBPS,10/100BASE-TX................................................................................................. 38-1
CHAPTER 39 GLOSSARY.............................................................................................39-1

1-1
Chapter 1 INTRODUTION
The PLANET WGSW-50040 is 50-Port 10/100/1000Mbps with 4 Shared SFP Managed Gigabit Switch. It
boasts a high performance switch architecture that is capable of providing non-blocking switch fabric and
wire-speed throughput as high as 100Gbps. Terms of “Managed Switch” means the Switches mentioned
titled in the cover page of this User’s manual.
1.1 Packet Contents
Open the box of the Managed Switch and carefully unpack it. The box should contain the following items:
Check the contents of your package for following parts:

WGSW-50040 Switch
X1

User's Manual
X1

Quick Installation Guide
X1

Power Cord
X1

RJ-45-to-DB9 Console Cable
X1

SFP Dust Caps
X4

Rubber Fee
X4
Two Rack-mounting Brackets with
Attachment Screws
X1
If any of these are missing or damaged, please contact your dealer immediately, if possible, retain the carton
including the original packing material, and use them against to repack the product in case there is a need to
return it to us for repair.
1.2 Product Description
Abundant IPv6 Support
The WGSW-50040 provides IPv6 management and enterprise level secure features such as SSH, ACL,
QoS and RADIUS authentication besides the IPv4 protocol supported. Supporting IPv6 management
features and also backward compatible with IPv4, the WGSW-50040 helps the enterprises to step in the IPv6
era with the lowest investment but not need to replace the network facilities while the ISP construct the IPv6
FTTx edge network.
High Performance
The WGSW-50040 provides 50 10/100/1000Mbps Gigabit Ethernet ports with 4 shared Gigabit SFP slots. It
boasts a high performance switch architecture that is capable of providing non-blocking switch fabric and
wire-speed throughput as high as 100Gbps, which greatly simplifies the tasks of upgrading the LAN for
catering to increasing bandwidth demands.

1-2
Robust Layer 2 Features
The WGSW-50040 can be programmed for basic Switch management functions such as Port speed
configuration, Port aggregation, VLAN, Spanning Tree protocol, QoS, bandwidth control and IGMP Snooping.
The WGSW-50040 provides 802.1Q Tagged VLAN, Q-in-Q, voice VLAN and GVRP protocol. The VLAN
groups allowed on the WGSW-50040 will be maximally up to 256. By supporting port aggregation, the
WGSW-50040 allows the operation of a high-speed trunk combining multiple ports. It enables up to 8 groups
of maximum 8-ports for trunking.
Excellent Traffic Control
PLANET WGSW-50040 is loaded with powerful traffic management and QoS features to enhance services
offered by telecoms. The functionality includes QoS features such as wire-speed Layer 4 traffic classifiers and
bandwidth limiting that are particular useful for multi-tenant unit, multi business unit, Telco, or Network Service
Provide applications. It also empowers the enterprises to take full advantages of the limited network
resources and guarantees the best performance at VoIP and Video conferencing transmission.
Powerful Security
The WGSW-50040 supports ACL policies comprehensively. The traffic can be classified by source/destination
IP addresses, source/destination MAC addresses, IP protocols, TCP/UDP, IP precedence, time ranges and
ToS. Moreover, various policies can be conducted to forward the traffic. The WGSW-50040 also provides
IEEE802.1x port based access authentication, which can be deployed with RADIUS, to ensure the port level
security and block illegal users.
Efficient Management
The WGSW-50040 supports IP Stacking function that helps network managers to easily configure up to 24
switches in the same series via one single IP address instead of connecting and setting each unit one by one.
For efficient management, the WGSW-50040 Managed Ethernet Switch is equipped with console, WEB and
SNMP management interfaces. With its built-in Web-based management interface, the PLANET
WGSW-50040 offers an easy-to-use, platform-independent management and configuration facility. The
WGSW-50040 supports standard Simple Network Management Protocol (SNMP) and can be managed via
any standard-based management software. For text-based management, WGSW-50040 can be accessed via
Telnet and the console port. Moreover, the WGSW-50040 offers secure remote management by supporting
SSH connection which encrypts the packet content at each session.
Flexibility and Extension solution
The four mini-GBIC slots built in the WGSW-50040 are compatible with 1000Base-SX/LX and WDM SFP
(Small Form Factor Pluggable) fiber-optic modules. The distance can be extended from 550 meters
(Multi-Mode fiber) up to above 10/20/30/40/50/70/120 kilometers (Single-Mode fiber or WDM fiber). It is well
suited for applications within the enterprise data centers and distributions.

1-3
1.3 Product Features
Physical Port
50-Port 10/100/1000Base-T Gigabit Ethernet RJ-45
4 mini-GBIC/SFP slots, shared with Port-45 to Port-48
RJ-45 to DB9 console interface for Switch basic management and setup
IP Stacking
Connects with stack member via both Gigabit TP/SFP interface
Single IP address management, supports up to 24 units stacking together
Stacking architecture supports Chain and Ring mode
Layer 2 Features
Complies with the IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3z Gigabit Ethernet standard
Supports Auto-negotiation and Half-Duplex / Full-Duplex modes for all 10Base-T/100Base-TX and
1000Base-T ports.
Supports 1000Base-SX/LX for all SFP interfaces
Auto-MDI/MDI-X detection on each RJ-45 port
Prevents packet loss Flow Control:
- IEEE 802.3x PAUSE Frame flow control for Full-Duplex mode
- Back-Pressure Flow Control in Half-Duplex mode
High performance Store and Forward architecture, broadcast storm control, port loopback detect
8CKC MAC address table, automatic source address learning and ageing
Support VLAN
- IEEE 802.1Q Tag-based VLAN
- GVRP for dynamic VLAN Management
- Up to 4K VLANs groups, out of 4041 VLAN IDs
- Provider Bridging (VLAN Q-in-Q) support (IEEE 802.1ad)
- Private VLAN Edge (PVE) supported
- GVRP protocol for Management VLAN
Support Link Aggregation
- Maximum 8 trunk groups, up to 8 ports per trunk group
- IEEE 802.3ad LACP (Link Aggregation Control Protocol)
- Cisco ether-channel (Static Trunk)
Spanning Tree Protocol
- STP, IEEE 802.1D (Classic Spanning Tree Protocol)
- RSTP, IEEE 802.1w (Rapid Spanning Tree Protocol)
- MSTP, IEEE 802.1s (Multiple Spanning Tree Protocol, spanning tree by VLAN)
- Supports BPDU & port guard
Port Mirroring to monitor the incoming or outgoing traffic on a particular port (many to many)
Provides Port Mirror (many-to-1)

1-1
Quality of Service
8 priority queues on all switch ports
Supports for strict priority and Weighted Round Robin (WRR) CoS policies
Traffic classification:
- IEEE 802.1p CoS / ToS
- IPv4 / IPv6 DSCP
- Port-Based QoS
Strict priority and Weighted Round Robin (WRR) CoS policies
Multicast
Support IGMP Snooping v1,v2 and v3, MLD v1 and v2 snooping
Querier mode support
Security
IEEE 802.1x Port-Based network access authentication
MAC-Based network access authentication
Build-in RADIUS client to co-operate with the RADIUS servers for IPv4 and IPv6
TACACS+ login users access authentication
IP-Based Access Control List (ACL)
MAC-Based Access Control List
Supports DHCP Snooping
Supports ARP Inspection
Management
Switch Management Interface
- Console / Telnet Command Line Interface
- Web switch management
- SNMP v1, v2c, and v3 switch management
- SSH secure access
BOOTP and DHCP for IP address assignment
Support DHCP relay function
Firmware upload / download via TFTP or HTTP protocol for IPv4 and IPv6
SNTP (Simple Network Time Protocol) for IPv4 and IPv6
User Privilege levels control
Syslog server for IPv4 and IPv6
Four RMON groups 1, 2, 3, 9 (history, statistics, alarms, and events)
Supports Ping, Trace route function for IPv4 and IPv6
Management IP for IPv4 and IPv6

1-2
1.4 Product Specification
Product WGSW-50040
50-Port 10/100/1000Mbps with 4 Shared SFP Managed Gigabit Switch
Hardware Specification
Copper Ports
50 10/ 100/1000Base-T RJ-45 Auto-MDI/MDI-X ports
SFP / mini-GBIC Slots
4 1000Base-SX/LX SFP interfaces, shared with Port-45 to Port-48
Switch Architecture
Store-and-Forward
Switch Fabric
100Gbps / non-blocking
Switch Throughput
74.4Mpps
Address Table
8K MAC address table with Auto learning function
Share Data Buffer
0.5Mbytes
VLAN Table
4K
ACL Table
1K
Port Queues
8
Flow Control Back pressure for Half-Duplex
IEEE 802.3x Pause Frame for Full-Duplex
Jumbo Frame
9K
LED
System:
PWR, SYS
Ports:
TP Port:10/100/1000 Link/Act
SFP Slot: On/Off
Dimension (W x D x H)
440 x 230 x 44 mm, 1U height
Weight
3215g
Power Consumption
80 Watts / 272.8 BTU (Maximum)
Power Requirement
AC 100~240V, 50/60Hz
Management Function
System Configuration
Console, Telnet, SSH, Web Browser, SNMPv1, v2c and v3
Management
Supports the unite for IPv4 / IPv6 HTTP
Supports the user IP security inspection for IPv4 / IPv6 SNMP
Supports MIB and TRAP
Supports IPv4 / IPv6 FTP/TFTP
Supports IPv4 / IPv6 NTP
Supports RMOM 1, 2, 3, 9 four group
Supports the RADIUS authentication for IPv4 /
IPv6 telnet user name and
password
Supports IPv4 / IPv6 SSH

1-3
The right configuration for users to adopt radius server’s shell management
Supports CLI, Console (RS-232), Telnet
Supports SNMPv1 / v2c / v3
Supports Security IP safety net management function：
avoid unlawful
landing at nonrestrictive area
Support Syslog server for IPv4 and IPv6
Supports TACACS+
Layer2 Function
Port Configuration
Port disable/enable.
Auto-negotiation 10/100/1000Mbps full and half duplex mode selection.
Flow Control disable/enable.
Bandwidth control on each port
Port Loopback detect
Port Status Display each port’s speed duplex mode, link status, Flow control status.
Auto negotiation status.
VLAN
802.1Q Tagged Based VLAN, up to 4K VLAN groups
Q-in-Q
GVRP for VLAN Management
Private VLAN Edge (PVE) supported
Bandwidth Control
TX / RX / Both
Link Aggregation IEEE 802.3ad LACP / Static Trunk
Supports 8 groups of 8-Port trunk
QoS
8 priority queues on all switch ports
Supports for strict priority and weighted round robin (WRR) CoS policies
Traffic classification:
- IEEE 802.1p CoS / ToS
- IPv4 / IPv6 DSCP
- Port-Based QoS
Strict priority and Weighted Round Robin (WRR) CoS policies
IGMP Snooping
IGMP (v1 / v2) Snooping, IGMP Querier mode
Multicast
IGMP v1/ v2 / v3 Snooping
IGMP Querier mode support
MLDv1 / v2, MLD v1/v2 Snooping
Access Control List
Support Standard and Expanded ACL
IP-Based ACL / MAC-Based ACL
Time-Based ACL
Up to 512 entries
Security Support MAC + port binding
IPv4 / IPv6 + MAC + port binding

1-4
IPv4 / IPv6 + port binding
Support MAC filter
ARP Scanning Prevention
Authentication IEEE 802.1x Port-Based network access control
AAAAuthentication: TACACS+ and IPv4 / IPv6 over RADIUS
SNMP MIBs
RFC-1213 MIB-II
RFC-1215 Internet Engineering Task Force
RFC-1271 RMON
RFC-1354 IP-Forwarding MIB
RFC-1493 Bridge MIB
RFC-1643 Ether-like MIB
RFC -1907 SNMP v2
RFC-2011 IP/ICMP MIB
RFC-2012 TCP MIB
RFC-2013 UDP MIB
RFC-2096 IP forward MIB
RFC-2233 if MIB
RFC-2452 TCP6 MIB
RFC-2454 UDP6 MIB
RFC-2465 IPv6 MIB
RFC-2466 ICMP6 MIB
RFC-2573 SnmpV3 notify
RFC-2574 SNMPV3 vacm
RFC-2674 Bridge MIB Extensions (IEEE802.1Q MIB)
RFC-2674 Bridge MIB Extensions (IEEE802.1P MIB)
Standard Conformance
Regulation Compliance
FCC Part 15 Class A, CE
Standards Compliance
IEEE 802.3 10Base-T
IEEE 802.3u 100Base-TX
IEEE 802.3z Gigabit SX/LX
IEEE 802.3ab Gigabit 1000T
IEEE 802.3x Flow Control and Back pressure
IEEE 802.3ad Port trunk with LACP
IEEE 802.1D Spanning tree protocol
IEEE 802.1w Rapid spanning tree protocol
IEEE 802.1s Multiple spanning tree protocol
IEEE 802.1p Class of service
IEEE 802.1Q VLAN Tagging
IEEE 802.1x Port Authentication Network Control

2-1
Chapter 2 INSTALLATION
This section describes the hardware features and installation of the Managed Switch on the desktop or rack
mount. For easier management and control of the Managed Switch, familiarize yourself with its display
indicators, and ports. Front panel illustrations in this chapter display the unit LED indicators. Before
connecting any network device to the Managed Switch, please read this chapter completely.
2.1 Hardware Description
2.1.1 Switch Front Panel
The unit front panel provides a simple interface monitoring the switch. Figure 2-1 shows the front panel of the
Managed Switch.
WGSW-50040 Front Panel
Figure 2-1 WGSW-50040 front panel
■Gigabit TP interface
10/100/1000Base-T Copper, RJ-45 Twist-Pair: Up to 100 meters.
■Gigabit SFP slots
1000Base-SX/LX mini-GBIC slot, SFP (Small Form Factor Pluggable) transceiver module: From 550
meters (Multi-mode fiber), up to 10/20/30/40/50/70/120 kilometers (Single-mode fiber).
■Console Port
The console port is a RJ-45 type, RS-232 male seria port connector. It is an interface for connecting a
terminal directly. Through the console port, it provides rich diagnostic information includes IP Address
setting, factory reset, port management, link status and system setting. Users can use the attached
RS-232 cable in the package and connect to the console port on the device. After the connection, users
an run any terminal emulation program (Hyper Terminal, ProComm Plus, Telix, Winterm and so on) to
enter the statup screen of the device.

2-2
2.1.2 LED Indications
The front panel LEDs indicates instant status of port links, data activity, system operation, Stack status and
system power, helps monitor and troubleshoot when needed.
WGSW-50040 LED indication
Figure 2-2 WGSW-50040 LED panel
■System
LED Color Function
PWR Green Lights to indicate that the Switch has power.
Off Power is off.
SYS
Green Lights to indicate the system diagnoses is completed.
Blink to indicate boot is enable.
Yellow Lights to indicate the system diagnoses is under way.
Blink to indicate the system diagnoses is malfunctioning.
■10/100/1000Base-T interfaces
LED Color Function
LNK/ACT
Green
Lights to indicate the link through that port is successfully established
with
speed 1000Mbps.
Blink to indicate that the switch is actively se
nding or receiving data over that
port.
Yellow
Lights to indicate the link through that port is successfully established
with
speed 100Mbps or 10Mbps.
Blink to indicate that the switch is actively sending or receiving data over that
port.
Off
No flow go through the port.
■SFP interfaces
LED Color Function
LNK/ACT Green Lights to indicate the link through that port is successfully established
with
speed
1000Mbps
.
Off
No flow go through the port.

2-3
2.1.3 Switch Rear Panel
The rear panel of the Managed Switch indicates an AC inlet power socket, which accept input power from 100
to 240V AC, 50-60Hz. Figure 2-3 shows the rear panel of these Managed Switch.
WGSW-50040 Rear Panel
Figure 2-3 Rear panel of WGSW-50040
■AC Power Receptacle
For compatibility with electric service in most areas of the world, the Managed Switch’s power supply
automatically adjusts to line power in the range 100-240VAC and 50/60 Hz.
Plug the female end of the power cord firmly into the receptalbe on the rear panel of the Managed Switch.
Plug the other end of the power cord into an electric service outlet then the power will be ready.
Power Notice:
The device is a power-required device, it means, it will not work till it is powered. If your
networks should active all the time, pl
ease consider using UPS (Uninterrupted Power
Supply) for your device. It will prevent you from network data loss or network downtime.
In some area, installing a surge suppression device may also help to protect your Managed
Switch from being damaged by unregulated surge or current to the Switch or the power
adapter.
