Planet ADE-3100 User manual

ADSLModem Router
ADE-3100
User s Manual

Copyright
Copyright (C) 2004 PLANETTechnologyCorp. All rights reserved.
The products and programs described in this User s Manual are licensed products of
PLANETTechnology,This User s Manual contains proprietaryinformation protected by
copyright, and this User s Manual and all accompanying hardware, software, and
documentation are copyrighted.
No part ofthis User s Manual maybe copied, photocopied, reproduced, translated, or
reduced to anyelectronic medium or machine-readable form byanymeans byelectronic or
mechanical. Including photocopying, recording, or information storage and retrieval
systems, for anypurpose other than the purchaser's personal use, and without the prior
express written permission of PLANETTechnology.
Disclaimer
PLANETTechnology does not warrant that the hardware will work properlyin all
environments and applications, and makes no warrantyand representation, either implied
or expressed, with respect to the quality,performance, merchantability,or fitnessfora
particular purpose.
PLANEThas made everyeffort to ensure that this User s Manual is accurate; PLANET
disclaims liabilityfor anyinaccuracies or omissions that mayhave occurred.
Information in this User sManual is subject to change without notice and does not
represent acommitment on the part ofPLANET.PLANETassumes no responsibilityfor any
inaccuracies that maybe contained in this User sManual. PLANETmakes no commitment
to update or keep current the information inthis User sManual, and reserves the right to
make improvements to this User sManual and/or to the products described in this User s
Manual, at anytime without notice.
If you find information in this manual that is incorrect, misleading, or incomplete, we would
appreciate your commentsand suggestions.
FCC Compliance Statement
This equipment generates and uses radio frequencyenergyand ifnot installed and used
properly, that is, in strict accordance with the instructionsprovided with the equipment, may
cause interference to radio and TV communication. The equipment has been tested and
found to complywith the limits for a Class A computing device in accordance with the
specifications in Subpart B ofPart 15 ofFCC rules, which are designed to provide
reasonable protection against such interference in a residential installation. However, there
is no guarantee that interference will not occur in a particular installation. Ifyou suspect this

equipment is causing interference, turn your Ethernet Switch on and offwhile your radio or
TV is showing interference, ifthe interference disappears when you turn your Ethernet
Switch offand reappears when you turn it back on, there is interference being caused by
the Ethernet Switch.
You can tryto correct the interference byone or more ofthe following measures:
w Reorient the receiving radio or TV antenna where this maybe done safely.
w To the extent possible, relocate the radio, TV or other receiver awayfrom the Switch.
w Plug the Ethernet Switch into a different power outlet so that the Switch and the receiver
are on different branch circuits.
If necessary, you should consult the place ofpurchase or an experienced radio/television
technician for additional suggestions.
CE mark Warning
The is a class B device, In a domestic environment, this product maycause radio
interference, in which case the user maybe required to take adequate measures.
Trademarks
The PLANETlogo is a trademark ofPLANETTechnology.Thisdocumentation mayrefer to
numeroushardware and software productsbytheir trade names. In most, ifnot all cases,
these designationsare claimed as trademarksor registered trademarks bytheir respective
companies.
Revision
User s Manual for PLANETADSLModem Router:
Model: ADE-3100A/ADE-3100B
Rev: 2.0 (Nov2004)
Part No.: EM-ADE3100v2

TABLE OF CONTENTS
1. Introduction............................................................................................................1
1.1 Features..........................................................................................................1
1.2 System Requirements.....................................................................................1
2. Knowing Your Router.............................................................................................2
2.1 Front Panels....................................................................................................2
2.2 Rear Panels....................................................................................................2
2.3 LED Indicators.................................................................................................2
3. Login.......................................................................................................................3
4. Status Pages...........................................................................................................4
4.1 Home Page.....................................................................................................4
4.2 PPPPage........................................................................................................5
4.3 ADSLPage......................................................................................................7
5. Configuration Pages..............................................................................................1
5.1 Modes.............................................................................................................1
5.2 WAN Configuration..........................................................................................2
5.2.1 ATM.......................................................................................................3
5.2.2 DHCPClient..........................................................................................5
5.2.3 MAC Spoofing.......................................................................................5
5.2.4 Static IPSettings...................................................................................5
5.3 LAN Configuration...........................................................................................1
5.3.1 DHCPServer........................................................................................1
5.3.2 Ethernet Mode Setting..........................................................................2
5.4 PPPConfiguration...........................................................................................3
5.4.1 PPPAccount Configuration...................................................................3
5.4.2 PPPSession Configuration...................................................................4
5.4.3 PPPDisconnect Timer Configuration....................................................6
5.4.4 PPPMiscellaneous Configuration.........................................................8
5.5 NATConfiguration Pages................................................................................9
5.6 Virtual Server Configuration..........................................................................11
5.7 Bridge Filtering..............................................................................................12
5.8 DNS Configuration........................................................................................13
5.9 User Password Configuration........................................................................14

5.10 Save Settings / Reboot...............................................................................15
6. Admin Privilege....................................................................................................17
6.1 WAN Status...................................................................................................17
6.2 ATM Status....................................................................................................17
6.3 ADSLConfiguration.......................................................................................18
6.4 Route Table...................................................................................................19
6.4.1 System Default GatewayConfiguration..............................................20
6.4.2 Route Configuration............................................................................20
6.5 Learned MAC Table......................................................................................21
6.6 RIPConfiguration..........................................................................................21
6.6.1 RIPPer Interface Configuration..........................................................23
6.7 Miscellaneous Configuration.........................................................................24
6.8 TCPStatus....................................................................................................26
6.9 Admin Password Configuration.....................................................................27
6.10 Reset to FactoryDefault.............................................................................27
6.11 Diagnostic Test............................................................................................28
6.12 System Log.................................................................................................28
6.13 Local Code Image Update...........................................................................29
APPENDIX A. COMPLIANCE STATEMENT 30
APPENDIX B. ENCAPSULATION MODE 30
APPENDIX C. TROUBLESHOOTING 30
APPENDIX D. SPECIFICATIONS 33

1
1. Introduction
This Router is a highlyintegrated, cost-effective solution. All setup and provisioning is
accomplished via a simple intuitiveWeb interface which further enhances the user
experience.
1.1 Features
l ADSLCompliance
n Compliant with ADSLstandards
u Full-rate ANSI T1.413 Issue 2 and ITU G.dmt (G.992.1) standards
u Splitterless ITU G.lite (G.992.2) specification
u ADSLover POTS (AnnexA) and ADSLover ISDN (AnnexB)
n DMTmodulation and demodulation
n Full-rate adaptive modem
u Maximum downstream rate of 8 Mbps
u Maximum upstream rate of1 Mbps
l ATM Protocols
n WANmode support: PPPover ATM (RFC 2364) and PPPover Ethernet (RFC
2516)
n LAN mode support: bridged/routed Ethernet over ATM (RFC 1483) and
Classical IPover ATM (RFC 1577)
n ATM Forum UNI 3.1/4.0 PVC
n Up to 8 VCs (Virtual Circuits)
l Bridge Mode
n Ethernet to ADSLself-learning Transparent Bridging (IEEE 802.1D)
n Supports up to 128 MAC learning addresses
l Router Mode
n IProuting–RIPv2
n Static routing
n DHCP(Dynamic Host Configuration Protocol) Server and Client
n NAPT(Network Address and Port Translation)
n NAT(Network Address Translation)
n ICMP(Internet Control Message Protocol)
l Security
n User authentication forPPP
n PAP(Password Authentication Protocol)
n CHAP(Challenge Authentication Protocol)
n Password protected system management
1.2 System Requirements
l Pentium III 266 MHzprocessor minimum
l 128 MB RAM minimum
l 20 MB offree disk space minimum
l Ethernet Network Interface Controller (NIC) RJ45 Port
l Internet Browser
l Ethernet (CAT5) Cable

2
2. Knowing Your Router
When selecting the location for the Router, allowroom to accessthe connectionson the
rear panel. You will want to place the Router so that you will be able to see the LED
indicators on the front panel. It maybe convenient for you locate the Router near the PC
you intend to use for initial configuration of the Router.
2.1 Front Panels
Place the Router in a location that permits an easyviewofthe LED indicators shown in
the front panel diagram below.
READY
PWR
TX
RX
ADSL
ACT
LNK ADSL Modem Router
ADE-3100
WAN
LAN
2.2 Rear Panels
The rear panel ofthe Router provides access to the power adapter cord connection as
well as the port connections.
9
VAC
RESET
LANADSL
RESET button: This button has two (2) functions:
1. When pressed and released, ADE-3100 will reboot (restart).
2. When reset button is pressed over 10 seconds and then release. ALLdata will be
clear and restoreALLsettings to the factorydefault values.
2.3 LED Indicators
LEDs Color Active Description
PWRGreen ON The power adaptor is connected to the
Modem.
READY Green Blink The system is readyto use.
ADSL Green ON ADSLconnection is established.
TXGreen Blink Transmitting data via ADSLlink.
WAN
RX Orange Blink Receiving data via ADSLlink.
LNK Green ON The Ethernet connection is established.
LAN
ACT Green Blink Transmitting data or receiving data over
Ethernet link.

3
3. Login
There are two levels of access rights/privileges for the Router:
l Administrator: User name admin, the administrator account hascomplete
read/write access on all pages (Status, Configuration, Admin Privilege, and Firewall
Configuration). Admin account also hasFTPserver access.
l User: User name user, the User account has read/write access to pages under the
Status and Configuration sections.
The following stepswill enable you to log into the Router:
1. Launch the Web browser (Internet Explorer, Netscape, etc.).
2. Enter the LAN port default IPaddress (default gateway) http://10.0.0.2 in the address
bar.
3. Entryof the username and password will be prompted. Enter the default login User
Name and Password:
The default login User Name ofthe administrator is admin, and the default login Password
is epicrouter.The default login User Name for the non-administrator is user, and the
default login Password is password.
4. Remember mypassword checkbox: Bydefault, this boxis not checked. Users can
check this boxso that Internet Explorer will remember the User name and Password
for future logins. It is recommended to leave this boxunchecked for securitypurposes.
Admin and User passwords can be changed after login. Refer to Section 5.9 for User
Password configuration and Section 6.9 for Admin Password configuration for further
instruction.

4
4. Status Pages
The links under the Status column are associated with the pages that represent the status
ofsystem (computer and Router) and interfaces (connections). This includes LAN, WAN,
DHCP, PPP, and ADSL status. These pages can be viewed and modified byboth user and
admin accounts.
4.1 Home Page
The Home page shows the firmware versions; LAN, WAN, and DHCPinterface status;
and Ethernet connection status.
Firmware Version: It is the default version number, which is not changeable.
Customer Software Version: It is the version ofthe firmware that is controllable bythe
ADSLModem/Router manufacturer.
WAN and LAN: It displays the IPaddress, Subnet Mask and MAC address for the WAN
(ADSL) and LAN interface.
Total Number of LANInterfaces: It displays the total number of available interfaces for
the LAN interface. The total number of available interfaces is the amount ofcomputers
that are able to hook up to the DHCPServer.
Number of Ethernet Devices Connected to the DHCPServer: It displays the DHCP
client table with the assigned IPaddresses and MAC addresses.

5
If there are no devicesconnected to the DHCPserver, then a table will not
appear, otherwise a table listing all devicesconnected to DHCPserver will appear on
the bottomof the page.
Ethernet Link Status: It displays the link up or down for the Ethernet connection (up if
connected, down ifnot connected).
USB Link Status (reserved function): It displays the link up or down for the USB
connection (up ifconnected, down ifnot connected).
4.2 PPPPage
The PPPStatus page shows the status of each PPPsession for each PPPinterface.
This page containsinformation that is dynamic and will refresh every8 seconds.
PPPinterfaces can be created, modified, and deleted in the PPPConfiguration
page. Refer to Section 5.4 for further information.
PPP(Point-to-Point Protocol): The table displays the following fields:
l Connection Name: This is user defined. User defined connectionsfor PPPcan
be created in PPPConfiguration page.
l Interface: States the interface that is being used (PVC0 ... PVC7).
l Mode: There are two available modes for the connection:
PPPover Ethernet (PPPoE)
PPPover ATM (PPPoA)
l Status: StateswhetherPPPconnection is Connected or Not Connected.
l Packets Sent: Number ofpackets sent bya particular PPPConnection.
l Packets Received: Number of packets received bya particular PPPConnection.

6
l Bytes Sent: Number ofbytes sent bya particular PPPConnection.
l Bytes Received: Number bytes received bya particular PPPConnection.

7
Connect and Disconnect: It allows you to manuallyconnect/disconnect the PPP
connection for each PPPinterface. In other words, each PPPsession can be connected
and disconnected individually.
l Connection #: Specifies the PPPsession to be connected/disconnected.
l Connect/Disconnect Execute: Press this button to either connect or disconnect.
Connection status dialog will be displayed belowthe Execute button after it is pressed.
Sample dialog with explanation:
l PPPX: Connecting... This is displayed while the PPPsession is attempting to
connect to the ISP.
l PPPX: Connect ERROR This is displayed when a connection cannot be made
due to an error.
l PPPX: is currentlynot connected This is displayed when a disconnect attempt
is made on a session that is not currentlyconnected.
l PPP X: does not exist! This is displayed when aconnect or disconnect attempt is
made on a session number that does not exist.
4.3 ADSLPage
The ADSLStatus page shows the ADSLphysical layer or link status. The information
displayed on this page is either inherent to the Router or set bythe ADSLCentral Office
(CO) DSLAM, neither ofwhich cannot be changed bythe user.This page contains
information that is dynamic and will refresh every2 seconds.
Restart/Stop Execute: It allows you to stop or restart the ADSLconnection byselecting
the appropriate action and clicking Execute.
Showtime Firmware Version: It displays the ADSLdata pump firmware version.

8
ADSLLine Status: It displays the ADSLconnection process and status. The different
states for this field are as follows:
l Activation: The Router is in this state when it is attempting to start the activation
process.
l Initialization: The Router is initializing handshake with the CO.
l Training: It is a part of the handshake process with the CO.
l Channel Analysis: It is a part of the handshake processwith the CO.
l Exchange: It is a part ofthe handshake process with the CO.
l Down: It indicates that the ADSLconnection is down.
l Showtime: It indicatesthat a connection hasbeen established between the
Router and the CO.
ADSLModulation: It displays the ADSLmodulation status, which can either be G.dmt or
T1.413.
ADSL Annex Mode: It displays the ADSLannexmode, which can either be AnnexA or
AnnexB.
ADSLStartup Attempts: It displays the number ofADSLconnection attemptsafter loss
ofshowtime. A connection attempt is recorded onlyifshowtime is attained.
ADSLMax TX Power: It displays the transmit output power level of the CPE (Customer
Premise Equipment), which is the transmit output power level ofthe Router.
ADSLCO Vendor: It displays the Central Office (CO) DSLAM vendor name, ifavailable.
If the Router is not connected to an ADSLvendor, then ‘UNUSED_VENDOR_0 will
appear in this field.
Elapsed Time: It displays the time of the Router has been in operation. This is the
amount oftime the Router is on, not the amount oftime it is connected to the PC or in
showtime status.
Atable contained the information of SNR Margin, Line Attenuation, Errored Seconds,
Loss of Signal, Loss of Frame, CRC Errors, Data Rate, and Latency is also available.

1
5. Configuration Pages
The links under Configuration column are associated to the pagesthat represent the
configurationsofsystem and interfaces. These pages can be viewedand modified byboth
user and admin accounts.
When any settings are changed, please go to the Save Settings page to save the
new setting(s) and reboot the Router. Changes will not take effect until the settings are
saved and the Router is rebooted. If power is lost before saving, all new configurations
since the last save will be lost, even if theywere submitted.
5.1 Modes
Table 5-1 lists the mode configurations.
Table 5-1 Mode Configuration
WAN
Configuration
Bridge Mode Router Mode
(PPPoA/PPPoE)
Router Mode
(Dynamic IP)
Router Mode
(Static IP)
Half Bridge
IP Address N/A Automatically
assigned byISP
Automatically
assigned byISP
Provided byISP Automatically
assigned byISP
Subnet Mask N/A Automatically
assigned byISP
Automatically
assigned byISP
Provided byISP Automatically
assigned byISP
Gateway N/A Automatically
assigned byISP
Automatically
assigned byISP
Provided byISP Automatically
assigned byISP
Encapsulation
1483Bridged IP
LLC, 1483
Bridged IP
VC-Mux
PPPoA
LLC/VC-Mux,
PPPoE
LLC/VC-Mux
1483
Bridged/Routed
IPLLC,1483
Bridged/Routed
IPVC-Mux,
Classical IPover
ATM
1483
Bridged/Routed
IPLLC,1483
Bridged/Routed
IPVC-Mux,
Classical IPover
ATM
PPPoA
LLC/VC-Mux,
PPPoE
LLC/VC-Mux
Bridge Enabled Disabled Disabled Disabled Disabled
PPPService N/A Provided byISP N/A N/A Provided byISP
PPPUser Name
N/A Provided byISP N/A N/A Provided byISP
PPPPassword
N/A Provided byISP N/A N/A Provided byISP
DHCPClient
Enable
Unchedked Unchedked Checked Unchedked Unchedked
PPPHalf Bridge
Disabled Disabled Disabled Disabled
DHCPServer Disabled Enabled Enabled Enabled
NAT Disabled Enabled (Dynamic
NAPT)
Enabled
(Dynamic NAPT)
Enabled
(Dynamic NAPT)
Disabled
DNS Proxy Disabled Enabled Enabled Enabled Disabled
Bridge Mode: Bridge Mode is used when there is one PC connected to the LAN-side
Ethernet port. IEEE 802.1D method oftransport bridging is used to bridge between the
WAN(ADSL) side and the LAN (Ethernet) side, i.e., to store and forward.
Router Mode: Router Mode is used when there is more than one PC connected to the
LAN-side Ethernet port. This enables the ADSLWAN access to be shared with multiple
nodes on the LAN. Network Address Translation (NAT) is supported so that one
WAN-side IPaddress can be shared among multiple LAN-side devices. DHCPis used to
serve each LAN-side device and IPaddress.

2
PPPHalf Bridge: Although the Router mode is capable ofterminating the PPPin the
modem and hence does not require PPPoE client software on the host PC, there are
some disadvantages to Router mode when onlysingle-user support is required. For
instance, Router mode uses NATwhich requires ALG support. PPPHalfBridge also
terminates the PPPin the modem and does not require a PPPoE client on the PC.
However,PPP HalfBridge does not use NATand is not limited byALGs. PPP HalfBridge
will work with Ethernet interface to the PC.
Single-User Mode: Onlyone computer is connected at the LAN side through Ethernet.
Multi-User Mode: Multiple computers are connected at the LAN side through Ethernet.
5.2 WAN Configuration
The WAN configuration page allowsyou to set the configuration for the WAN/ADSL
ports. Before you enterthe WAN Configuration page, you will be asked to select an
adapter (PVC0 through PVC7) first. Once you select the adaptor, then following page will
appear.
Virtual Circuit: Select Enable to activate the current PVC configuration. The current
PVC is displayed at the top of the page in parenthesis. Default is Enabled for PVC0 and
Disabled for PVC1-PVC7.

3
Bridge: Enable to connect the LAN to the WAN (bridge the two connections). This is
available in Bridge Mode only(see Table 5-2). Default is Disabled.
IGMP: IGMP(Internet Group Management Protocol) relay/proxy specification and
environment, default isDisabled. IGMPis available in all modes and all encapsulations.
Support IGMPproxy/relayfunction for Router, based on the following requirement and
cases:
l On CO side, there must be at least one IGMPquerier (router) present. IGMP
querier will send IGMPquerypacket. The Router is responsible to relaythese
IGMPqueries to Ethernet.
l End-user multicast application device sends IGMPreport while receiving IGMP
queryor being activated bythe user.The Router should be responsible to proxy
(that is, change source IPto Router sWAN IP) the IGMPreport to ADSLWAN
side, including all PVCs. The same case is for IGMPleave packet.
l Not necessaryto relaymulticast routing between twoADSLPVCs or two
interfacesin LAN side.
l Special purpose multicast packet (such as RIP2 packet) should run without
Interference.
Table 5-2. Packet Process
RxEntity Packet Class TTL Action
IGMPquery1Relayto Ethernet
IGMPreport 1Ignore
IGMPleave1Ignore
ADSL
General Multicast IP -Relayit to Ethernet
IGMPquery1Ignore
IGMPreport 1Relayto all ADSLPVCs
IGMPleave1Relayto all ADSLPVCs
Ethernet
General Multicast IP -Ignore
Before the IGMPmode is enabled; please go to the MiscellaneousConfiguration
page to enable the IGMPproxy. Otherwise, the IGMPselection will not be valid.
Where can I download the free software to test IGMP?
Answer: Please go to this link http://pf.itd.nrl.navy.mil/projects.php?name=mgen.
Encapsulation: The different types ofencapsulation include PPPoAVC-Mux, PPPoA
LLC, 1483 Bridged IPLLC, 1483 Routed IPLLC, 1483 Bridged IPVC-Mux, 1483 Routed
IPVC-Mux, Classical IPover ATM, PPPoE VC-Mux, PPPoE LLC, and PPPoENone.
5.2.1ATM
VPI: Virtual Path Identifier is a virtual path used for cell routing that is identified byan
eight bit field in the ATM cell header.The VPI field specifies this eight bit identifier for
routing.
Range: 0-255 Default: 0

4
VCI: A Virtual Channel Identifier is a virtual channel that is identified bya unique
numerical tag that is defined bya 16-bit field in the ATM cell header.The purpose of the
virtual channel is to identifywhere the cell should travel. The VCI fieldspecifies this 16 bit
numerical tag that determines the destination.
Range: 0-65535 Default: 35
Service Category: This field allows you to select from the following service categories.
l UBR (default): When configured as UBR (Unspecified Bit Rate), trafficis
delivered with best efforts but with no guarantee. This allows for fluctuation in
times oftemporaryincrease ofavailable bandwidth. For example, ifa PVC with
CBR is temporarilyinactive, the PVC(s) with UBR will utilizethat bandwidth while it
is available. UBR is intended for applicationsthat do not require anymaximum
bound on the transfer delay.
l CBR: When a PVC is specified as a CBR (Constant Bit Rate), that PVC is
guaranteed a certain bandwidth, characterized bythe PeakCell Rate (PCR). The
CBR does not have to transmit with a peak cell rate, and when it does, it is only
when the bandwidth specified bythe PCR is guaranteed.
l VBR-nrt: An PVC enabled with VBR-nrt (Variable Bit Rate - non realtime) can
transmit acell only ifthe PVC has atoken available. The PVC accumulates tokens
at the rate of the Sustainable Cell Rate, and the PVC can onlyaccumulate a
maximum of the value specified byMaximum Burst Size tokens.
When a PVC has a token available, it can transmit cells at the rate ofPCR. After a cell is
transmitted, the PVC loses the token it has accumulated.
In the case of multiple PVCs, CBR specified PVCs will have higher priority than
PVCs with UBR. For example, the CBR PVCs will take their bandwidth and the
remaining bandwidth will be split among the UBR PVCs. In the case oftotal PVC CBR
bandwidth exceeding ADSLupstream, the total upstream bandwidth will be shared
proportionallyto the bandwidth allocated for each CBR PVC.
Peak Cell Rate: This value specifies the maximum, and in some cases guaranteed, cell
rate for CBR and VBR-nrt. Peak Cell Rates are typicallymeasured in Cells/Second,
however, the user entered value is in kbpsand is then converted bythe firmware.
Range: 0-32767 Default: 0
Sustainable Cell Rate: It is the sustained rate at which a PVC enabled with VBR-nrt can
transmit ATM cells. Sustainable Cell Rate (SCR) can be considered as the true reserved
bandwidth for a PVC.
Range: 0-32767 Default: 0
Max Burst Size: It is the number of cells a PVC enabled with VBR-nrt can transmit
continuouslyat peak cell rate (PCR).
Range: 0-32767 Default: 0

5
5.2.2DHCPClient
DHCPClient: It is to enable or disable (default) the Router WAN as a DHCPclient,
where the ISPwould be the DHCPserver. DHCPClient is generallyused in the following
encapsulations: 1483 Bridged IPLLC, 1483 Routed IPLLC, 1483 Bridged IPVC-MUX,
1483 Routed IPVC-Mux, and Classical IPover ATM. This option is for non-static
(dynamic) IPaddresses.
Host Name: When DHCPClient is Enabled, copythe ISPrecognized Host Name here.
The Host Name can be up to 19 characters.
5.2.3MAC Spoofing
MAC Spoofing: Enable MAC Spoofing to make a different MAC Address appear on the
WANside. This is also used to solve the scenario where the ISPonly recognizes one
MAC Address. System default is Disable.
MACAddress: When MAC Spoofing is enabled, copythe ISP-recognized MAC address
here. Format for MAC address is sixpairs ofhexadecimal numbers (0-9, A-F) separated
bycolons. System default is: 00:00:00:00:00:00.
5.2.4Static IPSettings
Static IPSettings are for users who have a Static IPAddress (WAN side) from their ISP.
IPAddress: It is the static IPAddress given bythe ISP.
Range: x.x.x.y,where 0 ≤x≤255 and 1 ≤y≤254 Default: 192.168.241.101
Subnet Mask: It is the subnet mask given bythe ISP.
Range: x.x.x.x, where 0 ≤x≤255 Default: 255.255.255.0
Gateway: It is the Gatewaygiven bythe ISP.
Range: x.x.x.y,where 0 ≤x≤255 and 1 ≤y≤254 Default: 0.0.0.0

1
5.3 LANConfiguration
The LAN configuration page allows you to set the configuration for the LAN port.
LAN IP Address & Subnet Mask: The LAN IPAddress is what the computer uses to
identifyand communicate with the Router (this is the address you enter in the address
bar ofInternet Explorer to access these pages). You can change this to another private IP
address and subnet mask, such as 192.168.1.2 and 255.255.255.0.
Range: x.x.x.x, where 0 ≤x≤255
Default is 10.0.0.2 and 255.0.0.0 (respectively)
5.3.1DHCPServer
Dynamic Host Configuration Protocol (DHCP) is a communications protocol that allows
network administratorsto manage and assign IPaddressesto computers within the
network. DHCPprovides a unique address to a computer in the network which enablesit
to connect to the Internet through Internet Protocol (IP). DHCPis controlled bythe DHCP
Server.The following settings allowyou to configure the DHCPserver.
DHCPServer: Select Enabled (default) to activate DHCPServer.
DHCP Address Pool Selection: Two types ofAddressPool selections are available,
with System Allocated as the default.
l System Allocated: The DHCPaddresspool is based on LAN port IPaddress plus
12 IPaddresses. For example, when the LANIPaddress is 10.0.0.2; the DHCP
address pool the range from 10.0.0.3 to 10.0.0.14.
l User Defined: When User Defined is selected, the DHCPaddresspool starts at the
User Defined Start Address and ends at the User Defined End Address. The

2
maximum pool size can be 253 IPaddresses: 255 total IPaddresses - 1 broadcast
address - 1 LAN port IPaddress.
User Defined Start Address: It is the starting IPaddressofthe DHCPpool for User
Defined DHCPAddress Pool Selection.
Range: x.x.x.x, where 0 ≤x≤255 Default: 10.0.0.4
User Defined End Address: It is the last IPaddress in the DHCPpool for User Defined
DHCPAddress Pool Selection.
Range: x.x.x.x, where 0 ≤x≤255 Default: 10.0.0.15
DHCPGatewaySelection: The default setting for the DHCPGatewaySelection is
Automatic.You can select User Defined and specify User Defined Gateway Address.
The DHCPserver will issue the User DefinedGateway Address to the LAN DHCP
clients.
User Defined Gateway Address: The purpose for the User Defined Gateway Address is
to have two gatewayaddresses, as the LAN IPAddress at the top of the LAN
Configuration page isalso a gatewayaddress.
Lease time: The Lease time is the amount of time a network user will be allowed to
connect with DHCPserver. Ifall fields are 0, the allocated IPaddresses will be effective
forever.
Ranges for Lease Time fields: Days 0-36500, Hours 0-23, Minutes 0-59, Seconds 0-59,
default value is 1 days 0 hours 0 minutes 0 seconds.
User mode: Under the Single User mode, the DHCPserver onlyallocatesone IP
address to a local PC. Under the Multiple User mode (default), the DHCPserver
allocatesthe IPaddresses specified bythe DHCPaddress pool.
Save Configuration: Clicking this will link you to the Save Settings / Reboot page.
5.3.2Ethernet Mode Setting
The Ethernet Mode configuration page allowsyou to set the LAN port into the following
modes:
l AutoSense (default): The Router will automaticallysense which mode to use,
selecting between 100 Mbps Full Duplex, 100 Mbps HalfDuplex, 10 Mbps Full
Duplex, and 10 MbpsHalfDuplex.
l 100 Mbps Full Duplex: Data can be transferred and received simultaneouslyat the
transfer rate of 100 Mega-bits per second.
l 100 Mbps Half Duplex: Data cannot be transferred and received at the same time.
For example, data can be sent, and once the transmission is complete, data can be
received. This is done at a transfer rate of100 Mega-bits per second.
l 10 Mbps Full Duplex: Data can be transferred and received simultaneouslyat the
transfer rate of 10 Mega-bits per second.
l 10 Mbps Half Duplex: Data cannot be transferred and received at the same time.
For example, data can be sent, and once the transmission is complete, data can be
