Planet CAM-ISD52 User manual

23x Indoor Speed Dome Camera
CAM-ISD52
User’s Manual

..
User’s manual 2
CONTENTS
1. Safety Information..............................................................................4
2. Preface...............................................................................................5
3. Features.............................................................................................6
4. Appearance........................................................................................7
4.1 DIP switches ................................................................8
4.2 Set Up Device ID Number ...........................................9
4.3 RS-485 Network and Impedance...............................27
5. Mount the Speed Dome Camera .....................................................30
5.1 Mounting Accessory...................................................31
5.2 Ceiling-drop mount (with CAM-CM)...........................32
5.3 Wall mount (with CAM-WM).......................................33
5.4 Use External Housing (with CAM-OH).......................35
6. Connecting Wires.............................................................................38
6.1 Power.........................................................................38
6.2 Video..........................................................................39
6.3 RS-485.......................................................................40
6.4 Alarm Input and Alarm Output ...................................40
7. Applications......................................................................................43
7.1 Controllers and RS-485 .............................................43
7.2 Connect single dome to console................................44
7.3 Connect two or more domes to console ....................47
8. Camera setup --- OSD functions .....................................................50
8.1 OSD operation ...........................................................50
8.2 System Info ................................................................51
8.3 Display .......................................................................51
8.4 Camera ......................................................................52

..
User’s manual 3
8.5
Scan........................................................................... 61
8.6 Control ....................................................................... 63
8.7 Privacy Mask ............................................................. 64
8.8 Alarm ......................................................................... 66
9. Pre-defined System Functions ........................................................ 69
10. Specification................................................................................... 70

..
User’s manual 4
CAUTION
This Class B digital apparatus meets all requirements of the
Canadian Interference Causing Equipment Regulations.
ATTENTION
Cet appareil numerique de laclasse B respects toutes les
exigencies du Reglement sur le materiel brouilleur du
Canada
1. Safety Information
Federal Communication Commission (FCC) Statement
Notice for customers in Canada
NOTE: This equipment has been tested and found to comply
with the limits of a Class B digital device, pursuant to Part 15 of
the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference when the equipment is
operated in a commercial environment. This device generates,
uses and can radiate radio frequency energy and, if not installed
and used in accordance with the instruction manual, may cause
harmful interference to radio communications. However, there is
no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference,
the user is encouraged to try to correct the interference by on or
more of the following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and
receiver.
Correct the equipment into an output o a circuit different
from that to which the receiver is connected
Consult the dealer or an experienced radio / television
technician for help
FCC Caution: To assure continued compliance, any change
or modification not expressly approved by the
party responsible for compliance could void the
user’s authority to operate this equipment.

..
User’s manual 5
2. Preface
Congratulations for the purchasing of the world most compact PTZ (Pan, Tilt
and Zoom) camera. The camera is designed and manufactured not just to
meet the requirements for traditional CCTV and modern digital surveillance,
but also increase the systems’ overall performance.
This camera line incorporates high resolution color CCD, with two types of
lens available: power zoom or vari-focal. Some image and special effect
functions are related to the type of lens, while other functions are the same
across the line.
The PT mechanism provides controllable panning (360
o
) and tilting (90
o
)+
auto-rotation (180
o
) functions, giving users the capability to manipulate the
camera for precise locating on target. The built-in micro-controller allows users
to program up to 64 presets for quick and accurate capture to specific view
positions. Moving speed, ranging from 0.25 to 300 degrees per second and is
selectable to controller, is variable in 16 optional levels. Dwell time of each
view position is also selectable from 1second up to 255 seconds.
System function includes I/O for alarm function for intrusion management, ID
setup
(maximum to 128) and impedance matching option for multiple node
system, 3 control protocols, 3 options of baud rates, RS-485 communication
format. This device is driven by DC12V power. It can be controlled by
keyboard, PC, video server or standalone DVR.
For the power zoom version, a number of image related functions (such as
DSP functions, lens functions, special effects of video…) are managed via
OSD (On-Screen-Display) menu. These functions are explained in the section
of OSD with details. The CCD can be set up for automatic switching to
black-white mode for night-vision ready when illumination is low.
This camera is designed to be water-resistant for outdoor use, under the
condition of normal temperature range from -10
o
to 50
o
C. A companion
outdoor housing is also available for severe weather condition (extreme low or
high temperature environment).

..
User’s manual 6
3. Features
Compact Size of 5” (135 mm)(10x zoom version 4-1/2” -114 mm) diameter
Continuous panning for 360
o
; Tilt for180
o
(10x zoom version is 90
o
)
Fast rotation speed, up to 240
o
per second
RS-485 digital control, supporting multi-nude topology
BNC connector for video output
Programmable for view position, speed and dwell
View position preset, up to 128 points
Auto-pan and 4 groups of tour
8 alarm inputs and 2 alarm outputs
Compatible to Pelco D/P and Samsung protocols
ID ranges from 1 to 1,024
IR remote control ready
Compatible with keyboard and DVR for CCTV system
Compatible with PC and video server for WAN / LAN surveillance
12V DC or 24V AC power input (AC24V for outdoor housing)
Embedded, surface, wall and ceiling mount
External housing for outdoor environment (Option)

..
User’s manual 7
4. Appearance
4.1 To Access DIP Switches
Before the camera is mounted in place, be sure the following four settings are
properly executed, or the camera may fail the control:
Camera ID setup
Protocol selection
Baud rate selection
Termination impedance
Tools:
Use pencil, pincer, paper clip or small flat screw driver, to move the lever of DIP
switch
Access points:
The DIP switches are located on the bottom of the dome cameras:
DIP switches

..
User’smanual 8
4.1 DIP switches
Overview of DIP switches
There are three sets of DIP switch on board for different setup purposes.
location # bit quantity used for
DS1+DS2 (P1&2) 10 Device ID setup
DS2 (P3~P7) 5 Protocol / baud rate setup
DS3 2 Network impedance
Refer to the picture on below for DIP switch locations.
The following paragraphs are providing the detail descriptions of the three main
setups. Installer should read it with care, before starts doing the hardware mounting
and cabling work.
DS3
DS1 DS2

..
User’smanual 9
remark: D ash line “---“ in tables means to set the bit to “OFF” position
4.2 Set Up Device ID Number
To build correct network for control communication, every speed dome camera in
the network must have an unique ID number, which is set by the bit 1 to 10 of a
DIP switch DS1(bit1-8) & DS2(bit 1~2).
Note: Factory default of device ID is 1
Find DIP switch DS1 & DS2 on the PC board
Complete ID setting involves the whole DS1 (as 1-8) and the two left
pins of DS2 (as 9 and 10) (see picture on above)
Refer to the tables in the following pages for ID setting (which shows
the assignment of each pin for different ID numbered from 1 to 1024)
The highest ID number of this camera is 1024.
All the speed domes in a network must have their unique ID. It is highly
recommended to installers, for future maintenance efficiency and
users’ convenience, to mark the ID of each camera onto its
corresponding location on the site map, and make out a list of cameras
with their ID numbers.
The DIP switch pin assignment for ID setup is in binary format.
DS1
Bit 1~8
DS2
9
&
10
ID setting group ( of 10 pins)

..
User’smanual 10
ID table (1 ~ 64)
ID 1 2 3 4 5 6 7 8 9 10 ID 1 23456789 10
1 -- -- -- -- -- -- -- -- -- -- 33 -- -- -- -- -- on -- -- --
--
2 on -- -- -- -- -- -- -- -- -- 34 on -- -- -- -- on -- -- --
--
3 -- on -- -- -- -- -- -- -- -- 35 -- on -- -- -- on -- -- --
--
4 on on -- -- -- -- -- -- -- -- 36 on on -- -- -- on -- -- --
--
5 -- -- on -- -- -- -- -- -- -- 37 -- -- on -- -- on -- -- --
--
6 on -- on -- -- -- -- -- -- -- 38 on -- on -- -- on -- -- --
--
7 -- on on -- -- -- -- -- -- -- 39 -- on on -- -- on -- -- --
--
8 on on on -- -- -- -- -- -- -- 40 on on on -- -- on -- -- --
--
9 -- -- -- on -- -- -- -- -- -- 41 -- -- -- on -- on -- -- --
--
10 on -- -- on -- -- -- -- -- -- 42 on -- -- on -- on -- -- --
--
11 -- on -- on -- -- -- -- -- -- 43 -- on -- on -- on -- -- --
--
12 on on -- on -- -- -- -- -- -- 44 on on -- on -- on -- -- --
--
13 -- -- on on -- -- -- -- -- -- 45 -- -- on on -- on -- -- --
--
14 on -- on on -- -- -- -- -- -- 46 on -- on on -- on -- -- --
--
15 -- on on on -- -- -- -- -- -- 47 -- on on on -- on -- -- --
--
16 on on on on -- -- -- -- -- -- 48 on on on on -- on -- -- --
--
17 -- -- -- -- on -- -- -- -- -- 49 -- -- -- -- on on -- -- --
--
18 on -- -- -- on -- -- -- -- -- 50 on -- -- -- on on -- -- --
--
19 -- on -- -- on -- -- -- -- -- 51 -- on -- -- on on -- -- --
--
20 on on -- -- on -- -- -- -- -- 52 on on -- -- on on -- -- --
--
21 -- -- on -- on -- -- -- -- -- 53 -- -- on -- on on -- -- --
--
22 on -- on -- on -- -- -- -- -- 54 on -- on -- on on -- -- --
--
23 -- on on -- on -- -- -- -- -- 55 -- on on -- on on -- -- --
--
24 on on on -- on -- -- -- -- -- 56 on on on -- on on -- -- --
--
25 -- -- -- on on -- -- -- -- -- 57 -- -- -- on on on -- -- --
--
26 on -- -- on on -- -- -- -- -- 58 on -- -- on on on -- -- --
--
27 -- on -- on on -- -- -- -- -- 59 -- on -- on on on -- -- --
--
28 on on -- on on -- -- -- -- -- 60 on on -- on on on -- -- --
--
29 -- -- on on on -- -- -- -- -- 61 -- -- on on on on -- -- --
--
30 on -- on on on -- -- -- -- -- 62 on -- on on on on -- -- --
--
31 -- on on on on -- -- -- -- -- 63 -- on on on on on -- -- --
--
32 on on on on on -- -- -- -- -- 64 on on on on on on -- -- --
--

..
User’smanual 11
ID table (65 ~ 128)
ID 1 2 3 4 5 6 7 8 9 10 ID 123456789 10
65 -- -- -- -- -- -- on -- -- -- 97 -- -- -- -- -- on on -- -- --
66 on -- -- -- -- -- on -- -- -- 98 on -- -- -- -- on on -- -- --
67 -- on -- -- -- -- on -- -- -- 99 -- on -- -- -- on on -- -- --
68 on on -- -- -- -- on -- -- -- 100 on on -- -- -- on on -- -- --
69 -- -- on -- -- -- on -- -- -- 101 -- -- on -- -- on on -- -- --
70 on -- on -- -- -- on -- -- -- 102 on -- on -- -- on on -- -- --
71 -- on on -- -- -- on -- -- -- 103 -- on on -- -- on on -- -- --
72 on on on -- -- -- on -- -- -- 104 on on on -- -- on on -- -- --
73 -- -- -- on -- -- on -- -- -- 105 -- -- -- on -- on on -- -- --
74 on -- -- on -- -- on -- -- -- 106 on -- -- on -- on on -- -- --
75 -- on -- on -- -- on -- -- -- 107 -- on -- on -- on on -- -- --
76 on on -- on -- -- on -- -- -- 108 on on -- on -- on on -- -- --
77 -- -- on on -- -- on -- -- -- 109 -- -- on on -- on on -- -- --
78 on -- on on -- -- on -- -- -- 110 on -- on on -- on on -- -- --
79 -- on on on -- -- on -- -- -- 111 -- on on on -- on on -- -- --
80 on on on on -- -- on -- -- -- 112 on on on on -- on on -- -- --
81 -- -- -- -- on -- on -- -- -- 113 -- -- -- -- on on on -- -- --
82 on -- -- -- on -- on -- -- -- 114 on -- -- -- on on on -- -- --
83 -- on -- -- on -- on -- -- -- 115 -- on -- -- on on on -- -- --
84 on on -- -- on -- on -- -- -- 116 on on -- -- on on on -- -- --
85 -- -- on -- on -- on -- -- -- 117 -- -- on -- on on on -- -- --
86 on -- on -- on -- on -- -- -- 118 on -- on -- on on on -- -- --
87 -- on on -- on -- on -- -- -- 119 -- on on -- on on on -- -- --
88 on on on -- on -- on -- -- -- 120 on on on -- on on on -- -- --
89 -- -- -- on on -- on -- -- -- 121 -- -- -- on on on on -- -- --
90 on -- -- on on -- on -- -- -- 122 on -- -- on on on on -- -- --
91 -- on -- on on -- on -- -- -- 123 -- on -- on on on on -- -- --
92 on on -- on on -- on -- -- -- 124 on on -- on on on on -- -- --
93 -- -- on on on -- on -- -- -- 125 -- -- on on on on on -- -- --
94 on -- on on on -- on -- -- -- 126 on -- on on on on on -- -- --
95 -- on on on on -- on -- -- -- 127 -- on on on on on on -- -- --
96 on on on on on -- on -- -- -- 128 on on on on on on on -- -- --

..
User’smanual 12
ID table (129 ~ 256)
ID 1 2 3 4 5 6 7 8 9 10 ID 1 23456789 10
129 -- -- -- -- -- -- -- on -- -- 161 -- -- -- -- -- on -- on -- --
130 on -- -- -- -- -- -- on -- -- 162 on -- -- -- -- on -- on -- --
131 -- on -- -- -- -- -- on -- -- 163 -- on -- -- -- on -- on -- --
132 on on -- -- -- -- -- on -- -- 164 on on -- -- -- on -- on -- --
133 -- -- on -- -- -- -- on -- -- 165 -- -- on -- -- on -- on -- --
134 on -- on -- -- -- -- on -- -- 166 on -- on -- -- on -- on -- --
135 -- on on -- -- -- -- on -- -- 167 -- on on -- -- on -- on -- --
136 on on on -- -- -- -- on -- -- 168 on on on -- -- on -- on -- --
137 -- -- -- on -- -- -- on -- -- 169 -- -- -- on -- on -- on -- --
138 on -- -- on -- -- -- on -- -- 170 on -- -- on -- on -- on -- --
139 -- on -- on -- -- -- on -- -- 171 -- on -- on -- on -- on -- --
140 on on -- on -- -- -- on -- -- 172 on on -- on -- on -- on -- --
141 -- -- on on -- -- -- on -- -- 173 -- -- on on -- on -- on -- --
142 on -- on on -- -- -- on -- -- 174 on -- on on -- on -- on -- --
143 -- on on on -- -- -- on -- -- 175 -- on on on -- on -- on -- --
144 on on on on -- -- -- on -- -- 176 on on on on -- on -- on -- --
145 -- -- -- -- on -- -- on -- -- 177 -- -- -- -- on on -- on -- --
146 on -- -- -- on -- -- on -- -- 178 on -- -- -- on on -- on -- --
147 -- on -- -- on -- -- on -- -- 179 -- on -- -- on on -- on -- --
148 on on -- -- on -- -- on -- -- 180 on on -- -- on on -- on -- --
149 -- -- on -- on -- -- on -- -- 181 -- -- on -- on on -- on -- --
150 on -- on -- on -- -- on -- -- 182 on -- on -- on on -- on -- --
151 -- on on -- on -- -- on -- -- 183 -- on on -- on on -- on -- --
152 on on on -- on -- -- on -- -- 184 on on on -- on on -- on -- --
153 -- -- -- on on -- -- on -- -- 185 -- -- -- on on on -- on -- --
154 on -- -- on on -- -- on -- -- 186 on -- -- on on on -- on -- --
155 -- on -- on on -- -- on -- -- 187 -- on -- on on on -- on -- --
156 on on -- on on -- -- on -- -- 188 on on -- on on on -- on -- --
157 -- -- on on on -- -- on -- -- 189 -- -- on on on on -- on -- --
158 on -- on on on -- -- on -- -- 190 on -- on on on on -- on -- --
159 -- on on on on -- -- on -- -- 191 -- on on on on on -- on -- --
160 on on on on on -- -- on -- -- 192 on on on on on on -- on -- --

..
User’smanual 13
ID table (193 ~ 256)
ID 1 2 3 4 5678910 ID 123456789 10
193 -- -- -- -- -- -- on on -- -- 225 -- -- -- -- -- on on on -- --
194 on -- -- -- -- -- on on -- -- 226 on -- -- -- -- on on on -- --
195 -- on -- -- -- -- on on -- -- 227 -- on -- -- -- on on on -- --
196 on on -- -- -- -- on on -- -- 228 on on -- -- -- on on on -- --
197 -- -- on -- -- -- on on -- -- 229 -- -- on -- -- on on on -- --
198 on -- on -- -- -- on on -- -- 230 on -- on -- -- on on on -- --
199 -- on on -- -- -- on on -- -- 231 -- on on -- -- on on on -- --
200 on on on -- -- -- on on -- -- 232 on on on -- -- on on on -- --
201 -- -- -- on -- -- on on -- -- 233 -- -- -- on -- on on on -- --
202 on -- -- on -- -- on on -- -- 234 on -- -- on -- on on on -- --
203 -- on -- on -- -- on on -- -- 235 -- on -- on -- on on on -- --
204 on on -- on -- -- on on -- -- 236 on on -- on -- on on on -- --
205 -- -- on on -- -- on on -- -- 237 -- -- on on -- on on on -- --
206 on -- on on -- -- on on -- -- 238 on -- on on -- on on on -- --
207 -- on on on -- -- on on -- -- 239 -- on on on -- on on on -- --
208 on on on on -- -- on on -- -- 240 on on on on -- on on on -- --
209 -- -- -- -- on -- on on -- -- 241 -- -- -- -- on on on on -- --
210 on -- -- -- on -- on on -- -- 242 on -- -- -- on on on on -- --
211 -- on -- -- on -- on on -- -- 243 -- on -- -- on on on on -- --
212 on on -- -- on -- on on -- -- 244 on on -- -- on on on on -- --
213 -- -- on -- on -- on on -- -- 245 -- -- on -- on on on on -- --
214 on -- on -- on -- on on -- -- 246 on -- on -- on on on on -- --
215 -- on on -- on -- on on -- -- 247 -- on on -- on on on on -- --
216 on on on -- on -- on on -- -- 248 on on on -- on on on on -- --
217 -- -- -- on on -- on on -- -- 249 -- -- -- on on on on on -- --
218 on -- -- on on -- on on -- -- 250 on -- -- on on on on on -- --
219 -- on -- on on -- on on -- -- 251 -- on -- on on on on on -- --
220 on on -- on on -- on on -- -- 252 on on -- on on on on on -- --
221 -- -- on on on -- on on -- -- 253 -- -- on on on on on on -- --
222 on -- on on on -- on on -- -- 254 on -- on on on on on on -- --
223 -- on on on on -- on on -- -- 255 -- on on on on on on on -- --
224 on on on on on -- on on -- -- 256 on on on on on on on on -- --

..
User’smanual 14
ID table (257 ~ 320)
ID 1 2 3 4 5 6 7 8 9 10 ID 1 23456789 10
257 -- -- -- -- -- -- -- -- on -- 289 -- -- -- -- -- on -- -- on
--
258 on -- -- -- -- -- -- -- on -- 290 on -- -- -- -- on -- -- on
--
259 -- on -- -- -- -- -- -- on -- 291 -- on -- -- -- on -- -- on
--
260 on on -- -- -- -- -- -- on -- 292 on on -- -- -- on -- -- on
--
261 -- -- on -- -- -- -- -- on -- 293 -- -- on -- -- on -- -- on
--
262 on -- on -- -- -- -- -- on -- 294 on -- on -- -- on -- -- on
--
263 -- on on -- -- -- -- -- on -- 295 -- on on -- -- on -- -- on
--
264 on on on -- -- -- -- -- on -- 296 on on on -- -- on -- -- on
--
265 -- -- -- on -- -- -- -- on -- 297 -- -- -- on -- on -- -- on
--
266 on -- -- on -- -- -- -- on -- 298 on -- -- on -- on -- -- on
--
267 -- on -- on -- -- -- -- on -- 299 -- on -- on -- on -- -- on
--
268 on on -- on -- -- -- -- on -- 300 on on -- on -- on -- -- on
--
269 -- -- on on -- -- -- -- on -- 301 -- -- on on -- on -- -- on
--
270 on -- on on -- -- -- -- on -- 302 on -- on on -- on -- -- on
--
271 -- on on on -- -- -- -- on -- 303 -- on on on -- on -- -- on
--
272 on on on on -- -- -- -- on -- 304 on on on on -- on -- -- on
--
273 -- -- -- -- on -- -- -- on -- 305 -- -- -- -- on on -- -- on
--
274 on -- -- -- on -- -- -- on -- 306 on -- -- -- on on -- -- on
--
275 -- on -- -- on -- -- -- on -- 307 -- on -- -- on on -- -- on
--
276 on on -- -- on -- -- -- on -- 308 on on -- -- on on -- -- on
--
277 -- -- on -- on -- -- -- on -- 309 -- -- on -- on on -- -- on
--
278 on -- on -- on -- -- -- on -- 310 on -- on -- on on -- -- on
--
279 -- on on -- on -- -- -- on -- 311 -- on on -- on on -- -- on
--
280 on on on -- on -- -- -- on -- 312 on on on -- on on -- -- on
--
281 -- -- -- on on -- -- -- on -- 313 -- -- -- on on on -- -- on
--
282 on -- -- on on -- -- -- on -- 314 on -- -- on on on -- -- on
--
283 -- on -- on on -- -- -- on -- 315 -- on -- on on on -- -- on
--
284 on on -- on on -- -- -- on -- 316 on on -- on on on -- -- on
--
285 -- -- on on on -- -- -- on -- 317 -- -- on on on on -- -- on
--
286 on -- on on on -- -- -- on -- 318 on -- on on on on -- -- on
--
287 -- on on on on -- -- -- on -- 319 -- on on on on on -- -- on
--
288 on on on on on -- -- -- on -- 320 on on on on on on -- -- on
--

..
User’smanual 15
ID table (321 ~ 384)
ID 1 2 3 4 5 6 7 8 9 10 ID 1 23456789 10
321 -- -- -- -- -- -- on -- on -- 353 -- -- -- -- -- on on -- on --
322 on -- -- -- -- -- on -- on -- 354 on -- -- -- -- on on -- on --
323 -- on -- -- -- -- on -- on -- 355 -- on -- -- -- on on -- on --
324 on on -- -- -- -- on -- on -- 356 on on -- -- -- on on -- on --
325 -- -- on -- -- -- on -- on -- 357 -- -- on -- -- on on -- on --
326 on -- on -- -- -- on -- on -- 358 on -- on -- -- on on -- on --
327 -- on on -- -- -- on -- on -- 359 -- on on -- -- on on -- on --
328 on on on -- -- -- on -- on -- 360 on on on -- -- on on -- on --
329 -- -- -- on -- -- on -- on -- 361 -- -- -- on -- on on -- on --
330 on -- -- on -- -- on -- on -- 362 on -- -- on -- on on -- on --
331 -- on -- on -- -- on -- on -- 363 -- on -- on -- on on -- on --
332 on on -- on -- -- on -- on -- 364 on on -- on -- on on -- on --
333 -- -- on on -- -- on -- on -- 365 -- -- on on -- on on -- on --
334 on -- on on -- -- on -- on -- 366 on -- on on -- on on -- on --
335 -- on on on -- -- on -- on -- 367 -- on on on -- on on -- on --
336 on on on on -- -- on -- on -- 368 on on on on -- on on -- on --
337 -- -- -- -- on -- on -- on -- 369 -- -- -- -- on on on -- on --
338 on -- -- -- on -- on -- on -- 370 on -- -- -- on on on -- on --
339 -- on -- -- on -- on -- on -- 371 -- on -- -- on on on -- on --
340 on on -- -- on -- on -- on -- 372 on on -- -- on on on -- on --
341 -- -- on -- on -- on -- on -- 373 -- -- on -- on on on -- on --
342 on -- on -- on -- on -- on -- 374 on -- on -- on on on -- on --
343 -- on on -- on -- on -- on -- 375 -- on on -- on on on -- on --
344 on on on -- on -- on -- on -- 376 on on on -- on on on -- on --
345 -- -- -- on on -- on -- on -- 377 -- -- -- on on on on -- on --
346 on -- -- on on -- on -- on -- 378 on -- -- on on on on -- on --
347 -- on -- on on -- on -- on -- 379 -- on -- on on on on -- on --
348 on on -- on on -- on -- on -- 380 on on -- on on on on -- on --
349 -- -- on on on -- on -- on -- 381 -- -- on on on on on -- on --
350 on -- on on on -- on -- on -- 382 on -- on on on on on -- on --
351 -- on on on on -- on -- on -- 383 -- on on on on on on -- on --
352 on on on on on -- on -- on -- 384 on on on on on on on -- on --

..
User’smanual 16
ID table (385 ~ 448)
ID 1 2 3 4 5 6 7 8 9 10 ID 1 23456789 10
385 -- -- -- -- -- -- -- on on -- 417 -- -- -- -- -- on -- on on --
386 on -- -- -- -- -- -- on on -- 418 on -- -- -- -- on -- on on --
387 -- on -- -- -- -- -- on on -- 419 -- on -- -- -- on -- on on --
388 on on -- -- -- -- -- on on -- 420 on on -- -- -- on -- on on --
389 -- -- on -- -- -- -- on on -- 421 -- -- on -- -- on -- on on --
390 on -- on -- -- -- -- on on -- 422 on -- on -- -- on -- on on --
391 -- on on -- -- -- -- on on -- 423 -- on on -- -- on -- on on --
392 on on on -- -- -- -- on on -- 424 on on on -- -- on -- on on --
393 -- -- -- on -- -- -- on on -- 425 -- -- -- on -- on -- on on --
394 on -- -- on -- -- -- on on -- 426 on -- -- on -- on -- on on --
395 -- on -- on -- -- -- on on -- 427 -- on -- on -- on -- on on --
396 on on -- on -- -- -- on on -- 428 on on -- on -- on -- on on --
397 -- -- on on -- -- -- on on -- 429 -- -- on on -- on -- on on --
398 on -- on on -- -- -- on on -- 430 on -- on on -- on -- on on --
399 -- on on on -- -- -- on on -- 431 -- on on on -- on -- on on --
400 on on on on -- -- -- on on -- 432 on on on on -- on -- on on --
401 -- -- -- -- on -- -- on on -- 433 -- -- -- -- on on -- on on --
402 on -- -- -- on -- -- on on -- 434 on -- -- -- on on -- on on --
403 -- on -- -- on -- -- on on -- 435 -- on -- -- on on -- on on --
404 on on -- -- on -- -- on on -- 436 on on -- -- on on -- on on --
405 -- -- on -- on -- -- on on -- 437 -- -- on -- on on -- on on --
406 on -- on -- on -- -- on on -- 438 on -- on -- on on -- on on --
407 -- on on -- on -- -- on on -- 439 -- on on -- on on -- on on --
408 on on on -- on -- -- on on -- 440 on on on -- on on -- on on --
409 -- -- -- on on -- -- on on -- 441 -- -- -- on on on -- on on --
410 on -- -- on on -- -- on on -- 442 on -- -- on on on -- on on --
411 -- on -- on on -- -- on on -- 443 -- on -- on on on -- on on --
412 on on -- on on -- -- on on -- 444 on on -- on on on -- on on --
413 -- -- on on on -- -- on on -- 445 -- -- on on on on -- on on --
414 on -- on on on -- -- on on -- 446 on -- on on on on -- on on --
415 -- on on on on -- -- on on -- 447 -- on on on on on -- on on --
416 on on on on on -- -- on on -- 448 on on on on on on -- on on --

..
User’smanual 17
ID table (449 ~ 512)
ID 1 2 3 4 5 6 7 8 9 10 ID 1 23456789 10
449 -- -- -- -- -- -- on on on -- 481 -- -- -- -- -- on on on on --
450 on -- -- -- -- -- on on on -- 482 on -- -- -- -- on on on on --
451 -- on -- -- -- -- on on on -- 483 -- on -- -- -- on on on on --
452 on on -- -- -- -- on on on -- 484 on on -- -- -- on on on on --
453 -- -- on -- -- -- on on on -- 485 -- -- on -- -- on on on on --
454 on -- on -- -- -- on on on -- 486 on -- on -- -- on on on on --
455 -- on on -- -- -- on on on -- 487 -- on on -- -- on on on on --
456 on on on -- -- -- on on on -- 488 on on on -- -- on on on on --
457 -- -- -- on -- -- on on on -- 489 -- -- -- on -- on on on on --
458 on -- -- on -- -- on on on -- 490 on -- -- on -- on on on on --
459 -- on -- on -- -- on on on -- 491 -- on -- on -- on on on on --
460 on on -- on -- -- on on on -- 492 on on -- on -- on on on on --
461 -- -- on on -- -- on on on -- 493 -- -- on on -- on on on on --
462 on -- on on -- -- on on on -- 494 on -- on on -- on on on on --
463 -- on on on -- -- on on on -- 495 -- on on on -- on on on on --
464 on on on on -- -- on on on -- 496 on on on on -- on on on on --
465 -- -- -- -- on -- on on on -- 497 -- -- -- -- on on on on on --
466 on -- -- -- on -- on on on -- 498 on -- -- -- on on on on on --
467 -- on -- -- on -- on on on -- 499 -- on -- -- on on on on on --
468 on on -- -- on -- on on on -- 500 on on -- -- on on on on on --
469 -- -- on -- on -- on on on -- 501 -- -- on -- on on on on on --
470 on -- on -- on -- on on on -- 502 on -- on -- on on on on on --
471 -- on on -- on -- on on on -- 503 -- on on -- on on on on on --
472 on on on -- on -- on on on -- 504 on on on -- on on on on on --
473 -- -- -- on on -- on on on -- 505 -- -- -- on on on on on on --
474 on -- -- on on -- on on on -- 506 on -- -- on on on on on on --
475 -- on -- on on -- on on on -- 507 -- on -- on on on on on on --
476 on on -- on on -- on on on -- 508 on on -- on on on on on on --
477 -- -- on on on -- on on on -- 509 -- -- on on on on on on on --
478 on -- on on on -- on on on -- 510 on -- on on on on on on on --
479 -- on on on on -- on on on -- 511 -- on on on on on on on on --
480 on on on on on -- on on on -- 512 on on on on on on on on on

..
User’smanual 18
ID table (513 ~ 576)
ID 1 2 3 4 5 6 7 8 9 10 ID 1 23456789 10
513 -- -- -- -- -- -- -- -- -- on 545 -- -- -- -- -- on -- -- -- on
514 on -- -- -- -- -- -- -- -- on 546 on -- -- -- -- on -- -- -- on
515 -- on -- -- -- -- -- -- -- on 547 -- on -- -- -- on -- -- -- on
516 on on -- -- -- -- -- -- -- on 548 on on -- -- -- on -- -- -- on
517 -- -- on -- -- -- -- -- -- on 549 -- -- on -- -- on -- -- -- on
518 on -- on -- -- -- -- -- -- on 550 on -- on -- -- on -- -- -- on
519 -- on on -- -- -- -- -- -- on 551 -- on on -- -- on -- -- -- on
520 on on on -- -- -- -- -- -- on 552 on on on -- -- on -- -- -- on
521 -- -- -- on -- -- -- -- -- on 553 -- -- -- on -- on -- -- -- on
522 on -- -- on -- -- -- -- -- on 554 on -- -- on -- on -- -- -- on
523 -- on -- on -- -- -- -- -- on 555 -- on -- on -- on -- -- -- on
524 on on -- on -- -- -- -- -- on 556 on on -- on -- on -- -- -- on
525 -- -- on on -- -- -- -- -- on 557 -- -- on on -- on -- -- -- on
526 on -- on on -- -- -- -- -- on 558 on -- on on -- on -- -- -- on
527 -- on on on -- -- -- -- -- on 559 -- on on on -- on -- -- -- on
528 on on on on -- -- -- -- -- on 560 on on on on -- on -- -- -- on
529 -- -- -- -- on -- -- -- -- on 561 -- -- -- -- on on -- -- -- on
530 on -- -- -- on -- -- -- -- on 562 on -- -- -- on on -- -- -- on
531 -- on -- -- on -- -- -- -- on 563 -- on -- -- on on -- -- -- on
532 on on -- -- on -- -- -- -- on 564 on on -- -- on on -- -- -- on
533 -- -- on -- on -- -- -- -- on 565 -- -- on -- on on -- -- -- on
534 on -- on -- on -- -- -- -- on 566 on -- on -- on on -- -- -- on
535 -- on on -- on -- -- -- -- on 567 -- on on -- on on -- -- -- on
536 on on on -- on -- -- -- -- on 568 on on on -- on on -- -- -- on
537 -- -- -- on on -- -- -- -- on 569 -- -- -- on on on -- -- -- on
538 on -- -- on on -- -- -- -- on 570 on -- -- on on on -- -- -- on
539 -- on -- on on -- -- -- -- on 571 -- on -- on on on -- -- -- on
540 on on -- on on -- -- -- -- on 572 on on -- on on on -- -- -- on
541 -- -- on on on -- -- -- -- on 573 -- -- on on on on -- -- -- on
542 on -- on on on -- -- -- -- on 574 on -- on on on on -- -- -- on
543 -- on on on on -- -- -- -- on 575 -- on on on on on -- -- -- on
544 on on on on on -- -- -- -- on 576 on on on on on on -- -- -- on

..
User’smanual 19
ID table (577 ~ 640)
ID 1 2 3 4 5 6 7 8 9 10 ID 1 23456789 10
577 -- -- -- -- -- -- on -- -- on 609 -- -- -- -- -- on on -- -- on
578 on -- -- -- -- -- on -- -- on 610 on -- -- -- -- on on -- -- on
579 -- on -- -- -- -- on -- -- on 611 -- on -- -- -- on on -- -- on
580 on on -- -- -- -- on -- -- on 612 on on -- -- -- on on -- -- on
581 -- -- on -- -- -- on -- -- on 613 -- -- on -- -- on on -- -- on
582 on -- on -- -- -- on -- -- on 614 on -- on -- -- on on -- -- on
583 -- on on -- -- -- on -- -- on 615 -- on on -- -- on on -- -- on
584 on on on -- -- -- on -- -- on 616 on on on -- -- on on -- -- on
585 -- -- -- on -- -- on -- -- on 617 -- -- -- on -- on on -- -- on
586 on -- -- on -- -- on -- -- on 618 on -- -- on -- on on -- -- on
587 -- on -- on -- -- on -- -- on 619 -- on -- on -- on on -- -- on
588 on on -- on -- -- on -- -- on 620 on on -- on -- on on -- -- on
589 -- -- on on -- -- on -- -- on 621 -- -- on on -- on on -- -- on
590 on -- on on -- -- on -- -- on 622 on -- on on -- on on -- -- on
591 -- on on on -- -- on -- -- on 623 -- on on on -- on on -- -- on
592 on on on on -- -- on -- -- on 624 on on on on -- on on -- -- on
593 -- -- -- -- on -- on -- -- on 625 -- -- -- -- on on on -- -- on
594 on -- -- -- on -- on -- -- on 626 on -- -- -- on on on -- -- on
595 -- on -- -- on -- on -- -- on 627 -- on -- -- on on on -- -- on
596 on on -- -- on -- on -- -- on 628 on on -- -- on on on -- -- on
597 -- -- on -- on -- on -- -- on 629 -- -- on -- on on on -- -- on
598 on -- on -- on -- on -- -- on 630 on -- on -- on on on -- -- on
599 -- on on -- on -- on -- -- on 631 -- on on -- on on on -- -- on
600 on on on -- on -- on -- -- on 632 on on on -- on on on -- -- on
601 -- -- -- on on -- on -- -- on 633 -- -- -- on on on on -- -- on
602 on -- -- on on -- on -- -- on 634 on -- -- on on on on -- -- on
603 -- on -- on on -- on -- -- on 635 -- on -- on on on on -- -- on
604 on on -- on on -- on -- -- on 636 on on -- on on on on -- -- on
605 -- -- on on on -- on -- -- on 637 -- -- on on on on on -- -- on
606 on -- on on on -- on -- -- on 638 on -- on on on on on -- -- on
607 -- on on on on -- on -- -- on 639 -- on on on on on on -- -- on
608 on on on on on -- on -- -- on 640 on on on on on on on -- -- on
