Planet GSW-601S User manual

10/100/1000Mbps
Gigabit Ethernet Smart Swtich
GSW-601S
User s Manaul

PLANET NOVASwitch series
Trademarks
Copyright PLANET TechnologyCorp. 2001.
Contentssubject to revision without prior notice.
PLANETis aregistered trademark ofPLANET
TechnologyCorp. All othertrademarksbelong to their
respective owners.
FCCWarning
Thisequipment has beentested and found tocomplywith
thelimits for a ClassAdigitaldevice, pursuanttoPart 15
oftheFCC Rules. Theselimits are designedto provide
reasonable protectionagainstharmful interferencewhen
theequipmentisoperatedin acommercial environment.
Thisequipmentgenerates,uses, andcanradiate radio
frequency energy and, if not installedandusedin
accordancewith theInstructionmanual, may cause
harmful interferenceto radiocommunications.Operation
ofthis equipmentinaresidentialareaislikelyto cause
harmful interferencein whichcase theuserwill be
required to correct the interferenceat hisown expense.
CE Mark Warning
ThisisaClass Aproduct. In adomesticenvironment, this
productmay causeradiointerference, inwhichcasetheuser
may berequiredtotake adequatemeasures.
Revision
PLANETNOVASwitch User's Manual
FOR MODELS:GSW-601S
Part No.: EM-GSW6V1
Before Starting
In this User's Manual, "Switch" isused for GSW-601S,
NovaSwitch”for PLANET’s19”-range Ethernet Switch,
where switch”represent the third partyswitch.

GSW-601S User's Manual
TABLE OF CONTENTS
1. INTROUCTION....................................................................7
1.1 CHECKLIST.......................................................................7
1.2 ABOUT THE SWITCH..........................................................7
1.3 FEATURES........................................................................8
1.4 SPECIFICATIONS .............................................................10
2. HARDWARE DESCRIPTION.............................................11
2.1 FRONT PANEL.................................................................11
2.2 REAR PANEL ..................................................................13
2.3 HARDWARE INSTALLATION...............................................13
3.CONFIGURATION..............................................................17
3.1 CONNECTTO PC........................................................17
3.2 MAIN MENU....................................................................18
3.3 SUBMENU: (0) PORT SETTING.........................................19
3.4 SUBMENU :(1) VLAN......................................................20
3.5 SUBMENU: (2) TRUNK...................................................21
3.6 SUBMENU: (3) AGING CONTROL ......................................22
3.7 SUBMENU: (4) PORT ENABLE/DISABLE ............................23
3.8 SUBMENU: (5) PORT MIRRORING.....................................24
3.9 SUBMENU: (6) PORT-BASE PRIORITY...............................25
3.10 SUBMENU: (7) MAC ADDRESS FILTER.............................26
3.11 SUBMENU: (8) CHANGE PASSWORD...............................27
3.12 SUBMENU: (9) RESTORETO FACTORY DEFAULT ............27
4 SWITCH OPERATION........................................................28
4 SWITCH OPERATION........................................................29
4.1 ADDRESS TABLE.............................................................29
4.2 LEARNING.......................................................................29
4.3 FORWARDING &FILTERING .............................................29
4.4 STORE-AND-FORWARD ...................................................30
4.4 AUTO-NEGOTIATION........................................................31
5. TROUBLESHOOTING.......................................................33

PLANET NOVASwitch series
A.1 SWITCH‘S RJ-45 PIN ASSIGNMENTS ...............................35
A.2 10/100MBPS, 10/100BASE-TX......................................35
A.3 RJ-45 CABLE PIN ASSIGNMENT........................................36

GSW-601S User's Manual
Thispage intentionallyleft blank!

GSW-601S User s Manual 7
1. INTROUCTION
1.1Checklist
Check the contents ofyour package for following parts:
l GSW-601S.
l User's manual.
l Power cord.
l 19”rackmount brackets.
l RS-232 cable.
Ifanyofthesepieces are missing or damaged, please
contactyour dealer immediately,if possible, retain the
carton including the original packing material,and usethem
againstto repack the product in casethere is aneed to
return it to usfor repair.
1.2About the Switch
The Switch GSW-601S is designed to allow simultaneous
transmission ofmultiple packetsvia an internal high-speed
data channel.This means that it can partition anetwork
more efficientlythan bridges or routersin most
environments.
The Switch isequipped with Category5copper cable or
fiber optic cable foruplinking to anetworkbackbone or
network server.It iscompatible with all10Mbps, 100Mbps
and 1000MbpsEthernet environments. The increased
speed and extra bandwidth offered byGigabit Ethernet will
support faster and more users applicationswith generating
more traffic.

PLANET NOVASwitch series
8
In addition, the Switch isalso supportone module slot for 2
Gigabit Ethernet portsto uplinkto aserver ornetwork
backbone. These Switchesare designed forPlug and Play
installation, allowsthe network administrator to simply
connectthe networkand powercables and the
Switching/bridging functions begin automatically.
The front panel oftheseSwitches provide LEDsfor easy
recognition ofthe switchoperation statusand for
troubleshooting. These LEDsdisplaythe powerstatus for
the systemand link/speed/ collision, full-duplex,transmit
and receive status for each port.
The built-in console interface can be used to configure the
Switch’ssetting for VLAN, and Port TrunkGroups,Port
Mirroring and Port Speed, Port enable/ disable.
1.3Features
w Complies with the IEEE802.3, IEEE802.3u, IEEE802.3zand
IEEE802.3ab Gigabit Ethernet standard, IEEE802.1p Priority
Queues
w Provide amodule slot for2-port10/100/1000Mbps-TX or
1000Mbps-SXoption ofmodules.
w FeaturesStore-and-Forward mode with wire-speed filtering
and forwarding rates
w Each port can be configured to 10/100Mbps half or
full-duplex, orto 1000Mbpsfull-duplexmode
w Automatic source addresslearning and aging.
w Support up to 8KMAC address
w Support up to total 512Kbyte packet buffer
w IEEE802.3x compliant full-duplex flowcontrol, HOL blocking
prevention
w Broadcaststormcontrol, runt and CRC Filtering eliminates
erroneous packetsto optimize the network bandwidth

GSW-601S User s Manual 9
w Support to handle up to 1522 bytes packet
w LED indicators for simple diagnosticsand management
w Provide a reset switch in front panel
w Internal power supply
w Auto MDI/ MDI-Xon each port
w Smart function for advanced configuration:
− Support one console port forswitch configuration change,
− Support per portPort-based VLAN and L2 Trunking with
linkredundancy, load balancing
− Support four ClassofService(CoS) queues per egress
port
− Support per port setting, enabled/ disabled
− Support port mirroring
− Support 24 MAC addressfiltering
− Support password setting

PLANET NOVASwitch series
10
1.4 Specifications
StandardIEEE802.3, IEEE802.3u, IEEE802.3ab, IEEE802.3x
Network
Media:
10Base-T,UTP/STP category 3or 5cable
100Base-TX,UTP/STP category 5 cable
1000Base-T,UTP/STP category 5e cable, 4 pairs
1000Base-SX,Multi-mode62.5/125μm, 50/125μm
fiber optic cable
Connector STP RJ-45port for 10/100/1000MbpsTX
SC connector for 1000Mbps SX
LED
indicators
Power, Smart
Individual port (copper)—1000,100,10
FDX/COL, TX, RX
Individual port (fiber) —Link, Activity
Dimension440mm(L) x245mm(W) x45mm(H)
Temperature
Operating —0to 40 Storage—20 to70
Humidity: Operating —10% to90%RH
Storage —5% to90%RH
Input Power
Requirement
100-240VAC,50-60Hz,Auto-sensing
Registrations FCC ClassA,CE,CUL,TUV,LVD
*After module installed

GSW-601S User s Manual 11
2. HARDWARE DESCRIPTION
This product seriesprovide three different running speed –
10Mbps,100Mbps, and 1000Mbps in the sameswitch and
automaticallydistinguish the speed of incoming connection.
This section describesthe hardwarefeaturesof theseSwitches.
For easiermanagement and control ofthe switch, familiarize
yourself with its displayindicators, and ports. Front panel
illustrationsin this chapterdisplaythe unit LED indicators.
Beforeconnecting anynetwork deviceto the switch, read this
chapter carefully
There are two choice ofdifferent module for expansion:
l
2port Copper module
l 2port Fiber module
2.1Front Panel
The unit front panel providesa simple interface monitoring
the switching hub. It includes a power smart and port
indicatorforeach port.
GSW-601S Switch front panel

PLANET NOVASwitch series
12
GSW-2GT module front panel
GSW-2SXmodule front panel
LED indicators
GSW-601S and GSW-2GT
PWRGreen Lit: Power on
SMART Green Lit: CPU initial completed
10/100/1000 Green Lit: indicate linkstatus and traffic Speed (10 for10M, 100 for 100M,
1000 for1000M)
TX/ RX Green Lit: indicate data traffic status (TX for transmitting, RXfor
receiving)
FDX/ COL Green Lit: Full-Duplex Blink: Half-Duplex/ Collision
Off: Half-duplex or not connected
GSW-2SX
LINK
Green Lit: indicate linkstatus and traffic
speed
ACTGreen Blink: activity
Reset button
At the right side offront panel, the reset button is designed
forreconfiguring the switch without turn offand on the
power.

GSW-601S User s Manual 13
2.2Rear Panel
The rearpanel ofthe Switch indicates a AC inlet power
socket, which accepts input power from100 to 240VAC,
50-60Hz. And a RS-232 console port for setting up the
switchvia aconnection to aterminal or PC using aterminal
emulation program.
PowerNotice:
1.The deviceis apower-required device, it means, it will
not work till it is powered. If your networksshould active
all the time, please considerusing UPS (Uninterrupted
PowerSupply)for yourdevice. It willprevent you from
networkdata loss or networkdowntime.
2.In some area, installing a surge suppression device may
also helpto protect your switch frombeing damaged by
unregulated surge or current to the Switch orthe power
adapter.
2.3Hardware Installation
2.3.1 Connecting end node or hub or switch
1. Place the Switch on asmooth surface or fasten the
mounting brackets with the provided screws in a
standard 19”rack.
2. Connect switch orPC to one portof the Switch using
Category3/4/5 UTP/STP cabling.
3. Connect anotherswitch or PC to the other port of
Switchbyfollowing the sameprocess as described in
Step3.
Notice:
Cable distance for Switch
The cable distance between Ethernet Switchand hub/PC
should not exceed 100 meter for UTP/STPcable, 220m
for62.5/125 fiber cable and 500mfor 50/125 fiber cable.

PLANET NOVASwitch series
14
Make sure the wiring is correct
It can be used Category3/4/5 cablein 10 Mbpsoperation.
Toreliablyoperate your networkat 100Mbpsand
1000Mbps, you mustusean Unshielded Twisted-Pair
(UTP) Category5cable, or better Data Grade cabling.
While aCategory 3or 4cable mayinitiallyseemto work,
it will soon cause data loss.
2.3.2 Connecting to Network Backbone or
Server
Connect to the Gigabit Ethernet portswith Category5
copper cable or fiber optic cable for uplinking to a
network backbone ornetworkserver.These ports
operate at 1000Mbps in full-duplex mode. Avalid
connection is indicated when the LinkLEDis light. The
following sections describe the function ofLEDson the
front panel
CPU LED
Color Green
Label Smart
Function: The LEDlight up steadilymeans CPU
completed to initialthe switch.
Power LED
Color Green
Label PWR
Function: The LED light up steadilymeansPower turned
on.

GSW-601S User s Manual 15
Link/Speed LED
Color Green
Label 10/100/1000
Function
The LED light up steadilyto indicate the
transmitting speed
10 light up steadilyto indicate linkup at speed
10M
100 light up steadilyto indicate linkup at speed
100M
1000 Light up steadilyto indicate linkup at speed
1000M
Full/ Half Duplex and Collision LED
Color Green
Label FDX/ COL
Function: The indicator LED flashup whenever there isa
collision between adirectlyattached end node and any
other node, and light up steadilyfor Full-duplexmode.
TXActivity
Color Green
Label TX
Function: Each RJ45 station porton the switchis
assigned one LED fortransmitting the data.
RX Activity
Color Green
Label RX
Function: Each RJ45 station port on the switch is
assigned one LED for receiving the data.

PLANET NOVASwitch series
16
Thispage intentionallyleft blank!

GSW-601S User's Manual 17
3.CONFIGURATION
3.1CONNECT TO PC
RS-232 serial cable
PrepareaRS-232 serial cable. Attachthe 9-pin female
connectorto the male connector on the switch. Plug the
other side of this cable to your PC.
Hyper Terminal
In Windows 95/98/2000/XP,launch HyperTerminal”,
create a newconnection, and adjust settingsasbelow:

3.2Main Menu
Launchthe new terminal you justset up, and then, turnon
the switch. See the following messages for successful
connection.
To enter anyof the submenus, simplytype the number
on the command line.
PLANET GSW-601S Gigabit Ethernet Smart Switch
Configuration menu [ver. :x.xx]
(0)Port Setting
(1)VLAN
(2)TrunkPort
(3)Aging Control
(4)Port Enable/Disable
(5)Port Mirroring
(6)Port-base priority
(7)Macaddressfilter
(8)Change password
(9)Restore to FactoryDefault
Select :>>

GSW-601S User's Manual 19
3.3Submenu: (0) Port Setting
UseTab or U”,”D”,”L”,”R”to movethe item which to be
change, pressspacebarto change it, ”S”forsavethis
configuration.
[Port Setting]
[1] [2] [3] [4] [5] [6] [7] [8]
Auto Neg. O O O O O O O O
Speed 1000 1000 1000 1000 1000 1000 1000 1000
Duplex F F F F F F F F
Flow Control O O O O O O O O
[Tab] : Move to next item
[Space Bar] : Toggle item
[S] : Save & Exit
[Q] : Quit
[U]:Up, [L]:Left
[D]:Down, [R]:Right

PLANET NOVASwitch series
20
3.4Submenu :(1) VLAN
Oàenables the port you select
Xàdisablesthe port you select
Use Tabor U”,”D”,”L”,”R”to movetheitemwhich tobechange,
press space bar to change it, ”S”for savethis configuration
[Port base VLAN]
[1] [2] [3] [4] [5] [6] [7] [8]
[Group 1] O O O O O O O O
[Group 2] x x x x x x x x
[Group 3] x x x x x x x x
[Group 4] x x x x x x x x
[Group 5] x x x x x x x x
[Group 6] x x x x x x x x
[Group 7] x x x x x x x x
[Group 8] x x x x x x x x
member port of trunk group must belong to same VLAN
[Tab] : Move to next item
[Space Bar] : Toggle item
[S] : Save & Exit
[Q] : Quit
[U]:Up, [L]:Left
[D]:Down, [R]:Right
