PLANET 8-Port 10/100Mbps 802.3at PoE Desktop Switch User's Manual
For Model: FSD-808HP
Revision: 1.0 (December 2012)
Part No.: 2351-AK3130-000

Table Of Contents
1. Introduction ............................................................................................... 5
1.1 Checklist............................................................................................. 5
1.2 Product Description.............................................................................. 5
1.3 Features ............................................................................................. 6
1.4 Specication........................................................................................ 7
2. Hardware Description .................................................................................. 8
2.1 Front Panel ......................................................................................... 8
2.1.1 LED Indicators ........................................................................... 8
2.2 Rear Panel .......................................................................................... 9
3. Hardware Installation .................................................................................10
3.1 Desktop Installation ............................................................................10
3.2 Rack Mounting ...................................................................................12
3.3 Product Application .............................................................................14
3.3.1 Supports IEEE 802.3af and IEEE 802.3at Standard ......................14
3.3.2 IP Ofce Department / Workgroup PoE Switch .............................15
3.4 Power over Ethernet Powered Device ..................................................16
4. Power Over Ethernet Overview ...................................................................17
5. Troubleshooting .........................................................................................20
Appendix A Networking Connection ..................................................................21
A.1 PoE Switch RJ-45 Port Pin Assignments .................................................21
A.2 10/100Mbps, 10/100Base-TX ................................................................21

5
1. Introduction
1.1 Checklist
Check the contents of your package for following parts:
FSD-808HP x 1l
User's Manual x 1l
19” Rack Mount Accessory Kit x 1l
Rubber Feet x 4l
Power Cord x 1l
If any of these pieces are missing or damaged, please contact your dealer
immediately, if possible, retain the carton including the original packing material,
and use them against to repack the product in case there is a need to return it to
us for repair.
1.2 Product Description
To fulll the demand of High Power PoE for network applications, the PLANET
802.3at PoE Fast Ethernet Switch family -FSD-808HP is an ideal solution. Each
10/100Mbps port of FSD-808HP features IEEE 802.3af and High Power IEEE
802.3at Power over Ethernet (PoE) that combines up to 140 Watts power output
and data per port over one Cat. 5E / 6 Ethernet cable, with totally 140 Watts PoE
budget on whole system, it is designed specically to satisfy the growing demand
of higher power consuming network PD (powered devices) such as PTZ (Pan, Tilt
& Zoom) / Speed Dome network cameras, multi-channel (802.11a / b / g /
n) wireless LAN access points and other network devices by providing double PoE
power than conventional 802.3af PoE currently.
The 8 10/100Mbps High Power PoE ports in the FSD-808HP supports both 802.3af
and 802.3at PoE standards and allows users exibly connect standard and high
powered devices simultaneously, the FSD-808HP offering 140 Watts PoE budget,
eight 15.4 Watts IEEE 802.3af devices or four 30 Watts IEEE 802.3at devices can
be easily installed without the power-socket limitation.
To facilitate power management, the FSD-808HP equips two orange LEDs hardware
designed that located on left side of FSD-808HP front panel, it call “PoE Power
Usage”. 1-4 is meaning that counting from port 1 to 4 of PoE output and 5-8 is
meaning that counting from port 5 to 8 of PoE output. The 80% is meaning that,
when 1-4 or 5-8 PoE output is over 80%, the LED will be light to advise customers.
With these LED indications, you can monitor current PoE power used status of FSD-
808HP easily and efciently.
Providing data transfer and High Power PoE in one unit, the FSD-808HP shall
reduce the need of extension cables and dedicated electrical outlets on the wall,

6
ceiling or any unreachable place. It helps to lower the installation costs and simplify
the installation effort. Besides, the rst important key feature is energy saving.
With more efcient switching power supply, the efciency of the FSD-808HP would
be much better than eight linear power adapters in the long run. Furthermore, it is
the ideal device for bridging among Fast Ethernet and Gigabit Ethernet workgroups
and networks. With Gigabit throughput and eight IEEE 802.3af / 802.3at PoE
interfaces supported, the FSD-808HP is ideal for small business and workgroups
to efciently deploy the High Power PoE network for the wireless access points, IP-
based surveillance camera or IP phones in any places.
All RJ-45 copper interfaces in the FSD-808HP support 10/100Mbps Auto-Negotiation
for optimal speed detection through RJ-45 Category 6, 5 or 5e cables. It also
supports standard Auto-MDI/MDI-X that can detect the type of connection to any
Ethernet device without requiring special straight or crossover cables.
1.3 Features
RJ-45 Interfacen
8-Port 10/100Mbps Fast Ethernet portsl
8-Port supports 52V DC power to PoE Powered Devicel
Power over Ethernetn
Comply with IEEE 802.3af / IEEE 802.3at Power over Ethernet End-Span PSEl
Up to 8 IEEE 802.3af / IEEE 802.3at devices poweredl
Supports PoE Power up to 30 Watts for each PoE portl
Auto detect powered device (PD)l
Circuit protection prevents power interference between portsl
PoE Usage Alarm LEDl
Remote power feeding up to 100ml
Switchingn
Hardware based 10/100Mbps Auto-Negotiation and Auto MDI/MDI-Xl
Flow control for Full Duplex operation and back pressure for Half Duplex oper-l
ation
Integrates address look-up engine, supporting 2K absolute MAC addressesl
Automatic address learning and address agingl
Supports Energy-Efcient Ethernet (EEE) function (IEEE 802.3az)l
Hardwaren
12-inch desktop size, 1U heightl
LED indicators for PoE ready, PoE activity and PoE Usage Alarml
Fanless designl

7
1.4 Specication
Model FSD-808HP
8-Port 10/100Mbps 802.3at PoE Desktop Switch
Hardware Specication
Network Connector 8-Port RJ-45 for 10/100Base-TX
PoE Inject Port 8-Port with 802.3af / 802.3at PoE injector function
LED Display
System: Power (Green)
PoE Usage Alarm: 1-4 (Orange)
5-8 (Orange)
Per port : PoE in-use (Green)
LNK/ACT (Green)
Switch Architecture Store and Forward switch architecture
MAC Address 2K MAC address table with Auto learning function
Switch Fabric 1.6Gbps
Switch Throughput 1.19Mpps@64Bytes
Power Requirement AC 100~240V, 50/60Hz, 2A max.
Power Consumption Max. 150 Watts / 511 BTU
Dimension (W x D x H) 280 x 180 x 44 mm
Weight 1.65kg
Power over Ethernet
PoE Standard IEEE 802.3af
IEEE 802.3at
Power over Ethernet / PSE
Enhancement Power over Ethernet / PSE
PoE Power Supply Type End-Span
PoE Power Output Per Port 52V DC Max. 30.8 Watts
Power Pin Assignment 1/2(+), 3/6(-)
PoE Power Budget 140 Watts
Environment
Operating environment 0 ~ 50 Degree C
Storage environment -40 ~ 70 Degree C
Operating Humidity 5 ~ 95%, relative humidity, non-condensing
Storage Humidity 5 ~ 95%, relative humidity, non-condensing
Standard Conformance
Standard Compliance
IEEE 802.3
IEEE 802.3u
IEEE 802.3x
IEEE 802.3af
IEEE 802.3at
IEEE 802.3az
Ethernet
Fast Ethernet
Flow Control
Power over Ethernet
Enhancement Power over Ethernet
Energy-Efcient Ethernet
EMI Safety FCC Class B, CE

8
2. Hardware Description
This product provides two different running speeds – 10Mbps and 100Mbps in the
same switch and automatically distinguishes the speed of incoming connection.
This section describes the hardware features of FSD-808HP. For easier management
and control of the Switch, familiarize yourself with its display indicators, and
ports. Front panel illustrations in this chapter display the unit LED indicators.
Before connecting any network device to the FSD-808HP, please read this chapter
carefully.
2.1 Front Panel
The Front Panel of the FSD-808HP PoE Ethernet Switch consists of 8x Auto-Sensing
10/100Mbps Ethernet RJ-45 Ports. The LED Indicators are also located on the front
panel of the FSD-808HP.
1234 6785
PoE
13574682
PWR
80%
5-8
1-4
ACTLNK
FSD-808HP
8-Port 10/100Mbps 802.3at PoE Ethernet Switch
PoE
Usage
Alarm
Figure 2-1: FSD-808HP Switch Front Panel
2.1.1 LED Indicators
System
LED Color Function
PWR Green Light: Indicate the Switch has power.
Per 10/100Mbps Port
LED Color Function
PoE Green Light: Indicate the port is providing 52V DC in-line power.
LNK/ACT Green
Light: Indicate the link through that port is successfully
established.
Blink: Indicate that the Switch is actively sending or
receiving data over that port.

9
PoE Usage Alarm Port
LED Color Function
1-4 Orange Light: Indicate the PoE Usage is over 80%
Blink: Indicate the PoE Usage is 100%
5-8 Orange Light: Indicate the PoE Usage is over 80%
Blink: Indicate the PoE Usage is 100%
2.2 Rear Panel
The rear panel of the FSD-808HP indicates an AC inlet power socket, which accepts
input power from 100 to 240V AC, 50-60Hz.
100~240V AC
50 / 60Hz, 2A max.
Figure 2-2: FSD-808HP Switch Rear Panel
Power
Notice
1. The device is a power-required device, it means, it will not work
till it is powered. If your networks should active all the time,
please consider using UPS (Uninterrupted Power Supply) for your
device. It will prevent you from network data loss or network
downtime.
2. In some area, installing a surge suppression device may also
help to protect your FSD-808HP from being damaged by unregu-
lated surge or current to the FSD-808HP or the power adapter.

10
3. Hardware Installation
Start up
Please refer to the followings for your cabling:
10/100Base-TX
All 10/100Base-TX ports come with Auto-Negotiation capability. They
automatically support 100Base-TX and 10Base-T networks. Users only need to
plug a working network device into one of the 10/100Base-TX ports, and then
turn on the FSD-808HP. The port will automatically runs in 10Mbps, 20Mbps,
100Mbps or 200Mbps after the negotiation with the connected device.
Cabling
Each 10/100Base-TX ports use RJ-45 sockets -- similar to phone jacks -- for
connection of unshielded twisted-pair cable (UTP). The IEEE 802.3 / 802.3u Fast
Ethernet standard requires Category 5, 5e UTP for 100Mbps 100Base-TX. 10Base-T
networks can use Cat. 3, 4, 5 (see table below). Maximum distance is 100meters
(328 feet).
Port Type Cable Type Connector
10Base-T Cat. 3, 4, 5, 2-pair RJ-45
100Base-TX Cat. 5, 5e UTP, 4-pair RJ-45
Any Ethernet devices like hubs/PCs can connect to the FSD-808HP by using
straight-through wires. The eight-10/100Mbps ports are auto-MDI/MDI-X can be
used on straight-through or crossover cable.
3.1 Desktop Installation
To install the Switch on desktop, simply follow the next steps:
Step1: Attach the rubber feet to the recessed areas on the bottom of the Switch,
as shown in Figure 3-1.
Figure 3-1: Attaching the Rubber Feet to the PoE Fast Ethernet Switch

11
Step2: Place the Switch on desktop near an AC power source.
Step3: Keep enough ventilation space between the Switch and the surrounding
objects.
Note
When choosing a location, please keep in mind the environmental
restrictions discussed in Chapter 1, Section 4, in Specification.
Step4: Connect your Switch to 802.3af / 802.3at complied Power Devices (PD)
and other network devices.
A. Connect one end of a standard network cable to the 10/100 RJ-45
ports at front panel of the Switch.
B. Connect the other end of the cable to the network devices such as
printer servers, workstations or routers…etc.
Note
Connection to the Switch requires UTP Category 5, 5e, 6 network
cabling with RJ-45 tips. For more information, please see the
Cabling Specification in Appendix A.
Step5: Supply power to the Switch.
A. Connect one end of the power cable to the Switch.
B. Connect the power plug of the power cable to a standard wall outlet.
When the Switch receives power, the Power LED should remain solid Green.

12
3.2 Rack Mounting
To install the Switch in a 19-inch standard rack, follow the instructions described
below.
Step1: Place your POE Fast Ethernet Switch on a hard at surface, with the front
panel positioned towards your front side.
Step2: Attach a rack-mount bracket to each side of the Switch with supplied
screws attached to the package. Figure 3-2 shows how to attach brackets
to one side of the Switch.
Figure 3-2: Attaching the Brackets to the Switch.
You must use the screws supplied with the mounting brackets.
Damage caused to the parts by using incorrect screws would invali-
date the warranty.
Step3: Secure the brackets tightly.
Step4: Follow the same steps to attach the second bracket to the opposite side.

13
Step5: After the brackets are attached to the Switch, use suitable screws to
securely attach the brackets to the rack, as shown in Figure 3-3.
Figure 3-3: Mounting the Switch in a Rack
Step6: Proceeds with the steps 4 and steps 5 of session 3.1 Desktop Installation
to connect the network cabling and supply power to your Switch.

14
3.3 Product Application
3.3.1 Supports IEEE 802.3af and IEEE 802.3at Standard
FSD-808HP is an ideal solution for IEEE 802.3af and High Power IEEE 802.3at
Power over Ethernet (PoE) application. It combines up to 140 Watts power output
budget and data transfer over one Cat. 5E / 6 Ethernet cable. With totally 140
Watts PoE budget on whole system, it is designed specically to satisfy the growing
demand of higher power consuming network PD (powered devices) such as PTZ
(Pan, Tilt & Zoom) / Speed Dome network cameras, multi- channel (802.11a / b /
g / n) wireless LAN access points and other network devices by providing double
PoE power than conventional 802.3af PoE currently.
802.3at PoE
PTZ / Speed Dome
IP Camera
802.3at PoE Splitter+
Non-PoE Device
802.3at PoE
Multi-Channel /
High Power Wireless AP
802.3af PoE
IP Camera
802.3at
PoE Splitter
FSD-808HP
Power
PoE
PoE
PoE
PoE
30W
30W
15W
a
DC
PoE
100Base-TX UTP w PoE
Power
DC Power Line (DC)
100Base-TX UTP
5GHz 802.11a
a
2.4GHz 802.11n
N
N
Figure 3-4: Kind of IEEE 802.3af and IEEE 802.3at devices

15
Note
Cable distance for Switch
The cable distance between the FSD-808HP and PC should not
exceed 100 meter for UTP/STP cable.
Make sure the wiring is correct
It can be used Category 3/4/5 cable in 10 Mbps operation. To
reliably operate your network at 100Mbps, you must use an
Unshielded Twisted-Pair (UTP) Category 5/5e cable, or better Data
Grade cabling. While a Category 3 or 4 cables may initially seem
to work, it will soon cause data loss.
3.3.2 IPOfceDepartment/WorkgroupPoESwitch
As the business expands, the additional telephones required could be installed
in less cost via the implementation of PoE IP Telephony system than that of the
traditional circuit wiring telephony system. PLANET FSD-808HP PoE Switch helps
enterprises to efciently create an integrated data, voice, and powered VoIP
network. PLANET IEEE 802.3af compliant IP Phones can be installed without any
power cable because it can be powered via the standard Ethernet cable from the
connected FSD-808HP. With the FSD-808HP, IP Telephony deployment becomes
more reliable and cost effective, which helps enterprises save tremendous
cost when upgrading from the traditional telephony system to IP Telephony
communications infrastructure.
PoE
PoE
PoE
PoE
DC
802.3at splitter
PoE VoIP
Phone
Phone
Laptop
N
N
PTZ Camera
PoE VoIP ATA
PoE IP
Camera
Core
Switch
PoE Wireless AP
PC Group
FSD-808HP
PoE
100Base-TX UTP w PoE
100Base-TX UTP
DC Power Line (DC)
Telephone wire
PoE
FSD-808HP
Figure 3-5: IP Ofce Department / Workgroup PoE Switch Connection

16
3.4 Power over Ethernet Powered Device
3~5 Watts
Voice over IP phones
Enterprise can install POE VoIP Phone, ATA and other
Ethernet/non-Ethernet end-devices to the central
where UPS is installed for un-interrupt power system
and power control system.
6~12 Watts
Wireless LAN Access Points
Museum, Sightseeing, Airport, Hotel, Campus, Factory,
Warehouse can install the Access Point any where
with no hesitation.
10~12 Watts
IP Surveillance
Enterprise, Museum, Campus, Hospital, Bank, can
install IP Camera without limits of install location – no
need electrician to install AC sockets.
3~12 Watts
PoE Splitter
PoE Splitter split the PoE 48V DC over the Ethernet
cable into 5/12V DC power output. It frees the device
deployment from restrictions due to power outlet
locations, which eliminate the costs for additional AC
wiring and reduces the installation time.
30 Watts
High Power Speed Dome
This state-of-the-art design is considerable to t in
various network environments like trafc centers,
shopping malls, railway stations, warehouses, airports,
and production facilities for the most demanding
outdoor surveillance applications- no need electrician
to install AC sockets.
Note
Since the FSD-808HP per PoE port supports 52V DC PoE power
output, please check and assure the Powered Device (PD) accept-
able DC power range is from 52V DC. Otherwise, it will damage the
Powered Device (PD).

17
4. Power Over Ethernet Overview
What is PoE?
The PoE is an abbreviation of Power over Ethernet; the PoE technology means
a system to pass electrical power safely, along with data on Ethernet UTP cable.
The IEEE standard for PoE technology requires Category 5 cable or higher for high
power PoE levels, but can operate with category 3 cable for low power levels.
Power is supplied in common modeover two or more of the differential pairs of
wires found in the Ethernetcables and comes from a power supply within a PoE-
enabled networking device such as an Ethernet switch or can be injected into a
cable run with a mid-span power supply.
The original IEEE 802.3af-2003 PoE standard provides up to 15.4 W of DC power
(minimum 44V DC and 350mA) to each device. Only 12.95 W is assured to be
available at the powered device as some power is dissipated in the cable.
The updated IEEE 802.3at-2009 PoE standard also known as PoE+ or PoE plus,
provides up to 25.5 W of power. The 2009 standard prohibits a powered device
from using all four pairs for power
The 802.3af / 802.3at dene two types of source equipment: Mid-Span and End-
Span.
Mid-Span
Mid-Span device is placed between legacy switch and the powered device. Mid-
Span is tap the unused wire pairs 4/5 and 7/8 to carry power, the other four is for
data transmit.
End-Span
End-Span device is direct connecting with power device. End-Span could also tap
the wire 1/2 and 3/6.
PoE System Architecture
The specication of PoE typically requires two devices: the Powered Source
Equipment (PSE) and the Powered Device (PD). The PSE is either an End-Span
or a Mid-Span, while the PD is a PoE-enabled terminal, such as IP Phones, Wireless
LAN, etc. Power can be delivered over data pairs or spare pairs of standard CAT-5
cabling.
Powered Source Equipment (PSE)
Power sourcing equipment (PSE) is a device such as a switch that provides
(sources) power on the Ethernet cable. The maximum allowed continuous output
power per cable in IEEE 802.3af is 15.40 W. A later specication, IEEE 802.3at,

18
offers 25.50 W. When the device is a switch, it is commonly called an End-span
(although IEEE 802.3af refers to it as endpoint). Otherwise, if it's an intermediary
device between a non PoE capable switch and a PoE device, it's called a Mid-span.
An external PoE injector is a Mid-span device.
Powered device
A powered device (PD) is a device powered by a PSE and thus consumes energy.
Examples include wireless access points, IP Phones, and IP cameras. Many powered
devices have an auxiliary power connector for an optional, external, power supply.
Depending on the PD design, some, none, or all power can be supplied from the
auxiliary port, with the auxiliary port sometimes acting as backup power in case of
PoE supplied power failure.
How Power is Transferred Through the Cable
A standard CAT5 Ethernet cable has four twisted pairs, but only two of these are
used for 10BASE-T and 100BASE-TX. The specication allows two options for using
these cables for power, shown in Figure 1 and Figure 2:
The spare pairs are used. Figure 1 shows the pair on pins 4 and 5 connected
together and forming the positive supply, and the pair on pins 7 and 8 connected
and forming the negative supply. (In fact, a late change to the spec allows either
polarity to be used).
POWER SOURCING
EQUIPMENT (PSE)
POWERED DEVICE
(PD)
SPARE PAIR
SPARE PAIR
SIGNAL PAIR
SIGNAL PAIR
Converter
DC / DC
RX
TX
TX
RX
48V
4
5
1
2
3
6
7
8
4
5
1
2
3
6
7
8
+
-Converter
Figure 1: Power Supplied over the Spare Pins

19
The data pairs are used. Since Ethernet pairs are transformer coupled at each
end, it is possible to apply DC power to the center tap of the isolation transformer
without upsetting the data transfer. In this mode of operation the pair on pins 3
and 6 and the pair on pins 1 and 2 can be of either polarity.
POWER SOURCING
EQUIPMENT (PSE)
POWERED DEVICE
(PD)
SPARE PAIR
SPARE PAIR
SIGNAL PAIR
SIGNAL PAIR
DC / DC
RX
TX
TX
RX
48V
4
5
1
2
3
6
7
8
4
5
1
2
3
6
7
8
+/-
+/-Converter
Figure 2: Power Supplied over the Data Pins

20
5. Troubleshooting
This chapter contains information to help you solve problems. If the Switch is
not functioning properly, make sure the Ethernet Switch was set up according to
instructions in this manual.
The Link LED is not light
Solution:
Check the cable connection and remove duplex mode of the Switch.
Performance is bad
Solution:
Check the full duplex status of the Switch. If the Ethernet Switch is set to full
duplex and the partner is set to half duplex, then the performance will be poor.
100Base-TXportlinkLEDislight,butthetrafcisirregular
Solution:
Check that the attached device is not set to dedicate full duplex. Some devices use
a physical or software switch to change duplex modes. Auto-negotiation may not
recognize this type of full-duplex setting.
Why the Switch doesn’t connect to the network
Solution:
Check the LNK/ACT LED on the switch Try another port on the Switch Make sure
the cable is installed properly Make sure the cable is the right type Turn off the
power. After a while, turn on power again.
Why connects PoE device to FSD-808HP and it cannot power on?
Solution:
Please check the cable type of the connection from FSD-808HP (port 1 to port 8)
to the other end. The cable should be an 8-wire UTP, Category 5 or above, EIA568
cable within 100 meters. A cable with only 4-wire, short loop or over 100 meters,
all will affect the power supply.
Please check and assure the device that fully complied with IEEE 802.3af / IEEE
802.3at standard.
What is the power output of each PoE port?
Solution:
1. Each PoE port supports 52V DC, 535mA, max 30 Watts power output. Detect
and inject by the standard of IEEE 802.3at.
2. Each PoE port supports 52V DC, 275mA, max 15.4 Watts power output. Detect
and inject by the standard of IEEE 802.3af.
