Planet IFGS-1022HPT User manual

Industrial 8-Port 10/100TX 802.3at PoE+
plus 2-Port Gigabit TP/SFP Combo Ethernet Switch
IFGS-1022HPT
User’s Manual

Table of Contents
1. Package Contents................................................................................. 3
2. Hardware Introduction .......................................................................... 4
2.1 Physical Dimensions ....................................................................... 4
2.2 Switch Front Panel......................................................................... 5
2.3 LED Indicators............................................................................... 7
2.4 Switch Upper Panel........................................................................ 8
2.5 Wiring the Power Inputs................................................................. 8
2.6 Wiring the Fault Alarm Contact ....................................................... 9
2.7 Product Features...........................................................................10
 2.8 ProductSpecications ...................................................................11
3. Installation .........................................................................................14
3.1 DIN-rail Mounting Installation ........................................................14
3.2 Wall-mount Plate Mounting ............................................................16
3.3 Installing the SFP Transceiver ........................................................17
3.4 Removing the Transceiver Module...................................................18
4. Troubleshooting ...................................................................................19
APPENDIX A: Networking Connection..........................................................20
A.1 PoE RJ45 Port Pin Assignments (End-span) .....................................20
A.2 Switch’s RJ45 Pin Assignments .......................................................20
A.3 RJ45 Cable Pin Assignments...........................................................21
A.4 Fiber Optic Cable Connection Parameter ..........................................22
APPENDIX B: Approved PLANET SFP Transceivers ........................................23

3
1. Package Contents
Thank you for purchasing PLANET industrial 8-Port 10/100TX 802.3at PoE+ plus
2-Port Gigabit TP/SFP combo Ethernet Switch, IFGS-1022HPT. In the following
sections, the term “Industrial PoE+ Switch” means the IFGS-1022HPT.
Open the box of the Industrial PoE+ Switch and carefully unpack it. The box
should contain the following items:
Industrial PoE+ Switch x 1 QR Code Sheet x 1
DIN-rail Kit x 1 Wall-mount Kit x 1
If any of these are missing or damaged, please contact your dealer
immediately; if possible, retain the carton including the original packing
material, and use them again to repack the product in case there is a need to
return it to us for repair.

4
2. Hardware Introduction
2.1 Physical Dimensions
Dimensions (W x D x H): 66 x 107 x 152 mm
18 [0.71]
152 [5.98]
66 [2.60] 107 [4.21]
28 [1.10]130 [5.12]
48.8 [1.92]
130 [5.12]
18 [0.71] 44 [1.73]
58.29 [2.29]
36.55 [1.44] 30 [1.18]
Top View
Side View Front View Side View
Mounting Kit Mounting Kit
DIN-Rail Kit
Rear View
Bottom View
Unit: mm
PWR1 PWR2
Alarm
DC Input: 48-54V , 5.5A max.
Max. Fault Alarm Loading: 24V, 1A
IFGS-1022HPT
AlarmP2P1
Extended Standard
LNK ACT
PoE-in-Use
LNK ACT
1000
802.3at PoE+
Long Reach Mode
9
5 3 1 7
9
10
10
6 4 2 8
1 2 3 4 5 6 7 8
DIP ON

5
2.2 Switch Front Panel
The front panel of the Industrial PoE+ Switch consists of 8 10/100/BASE-TX
ports featuring 30-watt 802.3at PoE+, and 2 additional Gigabit copper/SFP
combo interfaces for Gigabit Ethernet extension and video uplink. The LED
indicators are also located on the front panel of the Industrial PoE+ Switch.
Figure 2-1 shows the front panel of Industrial PoE+ Switch.
IFGS-1022HPT
AlarmP2P1
Extended Standard
LNK ACT
PoE-in-Use
LNK ACT
1000
802.3at PoE+
Long Reach Mode
9
5
3
1
7
9
10
10
6
4
2
8
1
2
3
4 5 6 7 8
DIP ON
Figure 2-1: IFGS-1022HPT Front Panel
Fast Ethernet TP interfaces (Port 1 to port 8)
10/100BASE-TX copper, RJ45 twisted-pair: Up to 100 meters.
Gigabit TP/SFP Combo Interfaces (Port 9 to port 10)
10/100/1000BASE-T copper, RJ45 twisted-pair: Up to 100 meters.
Gigabit SFP/SFP Combo Interfaces (Port 9 to port 10)
1000BASE-SX/LX mini-GBIC slot, SFP (small factor pluggable) transceiver
module:From550meters(multi-mode ber)to10/20/40/80/120 kilometers
(single-modeberorWDMber).

6
DIP Switch
The Industrial PoE+ Switch has a built-in solid DIP switch that provides
“Standard” and “Extend” operation modes. The Industrial PoE+ Switch
operates as a normal IEEE 802.af/at PoE+ Switch in the “Standard” operation
mode.
In the “Extend” operation mode, the Industrial PoE+ Switch operates on a
per-port basis at 10Mbps full duplex operation but can support 30-watt PoE
power output over a distance of up to 250 meters overcoming the 100m
limit on Ethernet UTP cable. With this brand-new feature, the Industrial PoE+
Switch provides an additional solution for 802.3af/at PoE+ distance extension.
Extended PoE Mode
250 meters (820 feet)
Default PoE Mode
100 meters (328 feet)
PoE
PoE IP
Camera
PoE
PoE
100BASE-TX UTP with PoE
PoE IP
Camera
FaultP2P1
Extended Standard
Long Reach Mode
1
2
3
4 5 6 7 8
DIP ON
FaultP2P1
Extended Standard
Long Reach Mode
1
2
3
4 5 6 7 8
DIP ON
2.3 LED Indicators
System
LED Color Function
P1 Green Lit: Indicates power 1 has power.
P2 Green Lit: Indicates power 2 has power.
Alarm Red Lit: Indicates neither power 1 nor power 2 has power.

7
Per 802.3at PoE+ 10/100BASE-TX Interface (Port 1 to Port 8)
LED Color Function
LNK/
ACT Green
Lit: Indicates the link through that port is successfully
established at 10Mbps or 100Mbps.
Blinking: Indicates that the switch is actively sending or
receiving data over that port.
PoE
In-Use Amber
Lit: Indicates the port is providing DC in-line power.
O: Indicates the connected device is not a PoE powered
device (PD).
Per 10/100/1000BASE-T Interface (Shared with Port 9 to Port 10)
LED Color Function
LNK/
ACT Green
Lit: Indicates the link through that port is successfully
established at 10/100/1000Mbps.
Blinking: Indicates that the switch is actively sending or
receiving data over that port.
1000 Amber
Lit: Indicates the link through that port is successfully
established at 1000Mbps.
O: Indicates the link through that port is successfully
established at 10/100Mbps.
Per 1000X SFP Slot (Shared with Port 9 to Port 10)
LED Color Function
LNK/
ACT Green
Lit: Indicates the link through that port is successfully
established at 1000Mbps.
Blinking: Indicates that the switch is actively sending or
receiving data over that port.
1000 Amber
Lit: Indicates the link through that port is successfully
established at 1000Mbps.
O: Indicates the link through that port is not established.
2.4 Switch Upper Panel
The upper panel of the Industrial PoE+ Switch consists of one terminal block
connector within two DC power inputs.

8
Figure 2-2 shows the upper panel of the Industrial PoE+ Switch.
PWR1 PWR2
Alarm
DC Input:
48-54V , 5.5A max.
Max. Fault Alarm Loading: 24V, 1A
1 2 3 4 5 6
Figure 2-2: Industrial PoE+ Switch Upper Panel
2.5 Wiring the Power Inputs
The 6-contact terminal block connector on the top panel of Industrial PoE+
Switch is used for two DC redundant power inputs. Please follow the steps
below to insert the power wire.
When performing any of the procedures like inserting the wires
or tightening the wire-clamp screws, make sure the power is
OFF to prevent from getting an electric shock.
1. Insert positive and negative DC power wires into Contacts 1 and 2 for Power
1, or Contacts 5 and 6 for Power 2.
PWR1 PWR2
Alarm
DC Input:
48-54V , 5.5A max.
Max. Fault Alarm Loading: 24V, 1A
1 2 3 4 5 6

9
2. Tighten the wire-clamp screws for preventing the wires from loosening.
123456
Power 1 Alarm Power 2
+ - + -
1. The wire gauge for the terminal block should be in the range
between 12 and 24 AWG.
2. The DC power input range is 48V ~ 54V DC.
PWR1 and PWR2 must provide exactly the same DC voltage for
power load balance while operating with dual power input.
Grounding the Device
Users MUST complete grounding wired with the device; otherwise, a sudden
lightning could cause fatal damage to the device.
PWR1 PWR2
Alarm
DC Input:
48-54V , 5.5A max.
Max. Fault Alarm Loading: 24V, 1A
1 2 3 4 5 6
Earth Ground

10
2.6 Wiring the Fault Alarm Contact
The fault alarm contacts are in the middle of the terminal block connector as
the picture shows below. Inserting the wires, the Industrial PoE+ Switch will
detect the fault status of the power failure and then forms an open circuit. The
following illustration shows an application example for wiring the fault alarm
contacts.
Fault Alarm Contacts
The Fault Alarm Contacts are
energized (CLOSE) for normal
operation and will OPEN when
failure occurs
Fault
Alarm
Insert the wires into the fault alarm contacts
1. The wire gauge for the terminal block should be in the range
between 12 and 24 AWG.
2. Alarm relay circuit accepts up to 24V with a maximum current
of 1A.
2.7 Product Features
Physical Port
zEight 10/100BASE-TX Fast Ethernet RJ45 ports with IEEE 802.3at/af PoE+
injector function (Port 1 to Port 8)
zTwo 10/100/1000BASE-T Gigabit Ethernet RJ45 ports (Port 9 and Port 10)
zTwo 1000BASE-X mini-GBIC/SFP slots for SFP type auto detection (Port 9
and Port 10)
Power over Ethernet
zComplies with IEEE 802.3at Power over Ethernet Plus, end-span PSE

11
zBackward compatible with IEEE 802.3af Power over Ethernet
zUp to 8 ports of IEEE 802.3af/802.3at devices powered
z240-watt PoE budget
zSupports PoE power up to 30 watts for each PoE port
zAuto detects PD
zCircuit protection prevents power interference between ports
zRemote power feeding up to 100 meters
Industrial Case and Installation
zIP30 metal case
zDIN-rail and wall-mount designs
z48~54V DC, redundant power with reverse polarity protection
zSupports 6000V DC Ethernet ESD protection
z-40 to 75 degrees C operating temperature
Switching
zHardware-based 10/100Mbps (half/full duplex), 1000Mbps (full duplex),
auto-negotiation and auto MDI/MDI-X
zFeatures Store-and-Forward mode with wire-speed ltering and forwarding
rates
zIEEE 802.3x ow control for full duplex operation and back pressure for half
duplex operation
z16K MAC address table size
z10K jumbo frame
zIEEE 802.1Q VLAN transparency
zHardware-based DIP switch for “Standard” and “Extend” mode selection;
the “Extend” mode features 30-watt PoE transmission distance of 250m at
speed of 10Mbps
zAutomatic address learning and address aging
zSupports CSMA/CD protocol

12
2.8 ProductSpecications
Product IFGS-1022HPT
HardwareSpecications
Fast Ethernet Copper Ports Eight 10/100BASE-TX RJ45 auto-MDI/MDI-X
ports (Ports 1 to 8)
Gigabit Ethernet Copper
Ports
Two 10/100/1000BASE-T RJ45 auto-MDI/MDI-X
ports (shared with Ports 9 to 10)
SFP/mini-GBIC Slots Two 1000BASE-SX/LX/BX SFP interfaces (shared
with Ports 9 to 10)
PoE Injector Port Eight ports with 802.3af/802.3at PoE+ injector
function (Ports 1 to 8)
DIP Switch (Port-1 to
Port-8)
Standard mode: 30-watt PoE transmit distance
of 100m at speed of 10/100Mbps
Extend mode: 30-watt PoE transmit distance of
250m at speed of 10Mbps
Connector
Removable 6-pin terminal block
 Pin 1/2 for Power 1
 Pin 3/4 for power fault alarm
 Pin 5/6 for Power 2
Alarm One relay output for power failure.
Alarm relay current carry ability: 1A @ 24V AC
Power Requirements 48~54V DC, 5.5A (max.)
(>51V DC for PoE+ output recommended)
Power Consumption/
Dissipation
4.3 watts, 14.6BTU (Standby without PoE
function) at DC 54V power input 256 watts,
873BTU (Full loading with PoE function) at DC
54V power input
Dimensions (W x D x H) 66 x 107 x 152 mm
Weight 829g
ESD Protection 6KV DC
Enclosure IP30 metal case
Installation DIN-rail kit and wall-mount kit

13
LED
3 x LED for System and Power:
 Green: DC Power 1
 Green: DC Power 2
 Red: Power Fault Alarm
2 x LED for PoE Copper Port (Ports 1 to 8):
 Green: LNK/ACT (10/100Mbps)
 Amber: PoE-In-Use
2 x LED for 10/100/1000T Copper Port
(Ports 9 to 10):
 Green: LNK/ACT
 Amber: 1000
2 x LED for per mini-GBIC interface
(Ports 9 to 10)
 Green: LNK/ACT
 Amber: 1000
SwitchingSpecications
Switch Architecture Store-and-Forward
Switch Fabric 5.6Gbps/non-blocking
Switch Throughput@64
bytes 4.1Mpps @64 bytes
MAC Address Table 16K entries
SharedDataBuer 4Mb SRAM
Flow Control IEEE 802.3x pause frame for full duplex
Back pressure for half duplex
Jumbo Frame 10 Kbytes
Power over Ethernet
PoE Standard IEEE 802.3at Power over Ethernet Plus/PSE
PoE Power Supply Type End-span
Power Pin Assignment 1/2(+), 3/6(-)
PoE Power Output
IEEE 802.3af Standard
- Per port 48V~51V DC (depending on the
power supply), max. 15.4 watts IEEE 802.3at
Standard
- Per port 51V~54V DC (depending on the
power supply), max. 30 watts

14
PoE Power Budget Dual power input: maximum 240W (depending
on power input)
Max. Number of Class 2
PDs 8
Max. Number of Class 3
PDs 8
Max. Number of Class 4
PDs 8
Standards Conformance
Regulatory Compliance FCC Part 15 Class A, CE
Stability Testing
IEC 60068-2-32 (free fall)
IEC 60068-2-27 (shock)
IEC 60068-2-6 (vibration)
Standards Compliance
IEEE 802.3 10BASE-T
IEEE 802.3u 100BASE-TX
IEEE 802.3ab Gigabit 1000BASE-T
IEEE 802.3z Gigabit SX/LX
IEEE 802.3x Flow Control and Back Pressure
IEEE 802.3af Power over Ethernet
IEEE 802.3at Power over Ethernet Plus
Environment
Operating Temperature -40 ~ 75 degrees C
Storage Temperature -40 ~ 85 degrees C
Humidity 5 ~ 95% (non-condensing)

15
3. Installation
This section describes the functionalities of the Industrial PoE+ Switch’s
components and guides you to installing it on the DIN-rail and wall. Basic
knowledge of networking is assumed. Please read this chapter completely
before continuing.
This following picture shows the user how to install the device,
and the device is not IFGS-1022HPT.
3.1 DIN-rail Mounting Installation
1
2

16
3.2 Wall-mount Plate Mounting
3.3 Installing the SFP Transceiver
The sections describe how to insert an SFP transceiver into an SFP slot.
The SFP transceivers are hot-pluggable and hot-swappable. You can plug in
and out the transceiver to/from any SFP port without having to power down
the Industrial PoE+ Switch as Figure 3-1 shows.
MGB Series
Transceiver
Figure 3-1: Plugging in the SFP Transceiver

17
PLANET Industrial PoE+ Switch supports 1000Mbps mode with both single
mode and multi-mode SFP transceivers.
1. Before we connect Industrial PoE+ Switch to the other network device, we
have to make sure both sides of the SFP transceivers are with the same
media type, for example, 1000BASE-SX to 1000BASE-SX, 1000BASE-LX to
1000BASE-LX.
2.Check whether the ber-optic cable type matches with the SFP transceiver
requirement.
zTo connect to 1000BASE-SX SFP transceiver, please use the multi-mode
bercablewithonesidebeingthemaleduplexLCconnectortype.
zTo connect to 1000BASE-LX or 1000BASE-BX SFP transceiver, please
use the single-mode ber cable with one side being the male duplex LC
connector type.
Connecting the Fiber Cable
1. Insert the duplex LC connector into the SFP transceiver.
2. Connect the other end of the cable to a device with SFP transceiver
installed.
3. Check the LNK/ACT LED of the SFP slot on the front of the Industrial PoE+
Switch. Ensure that the SFP transceiver is operating correctly.
4. Check the Link mode of the SFP port if the link fails.
It is recommended to use PLANET SFPs on the Industrial PoE+
Switch. If you insert an SFP transceiver that is not supported,
the Industrial PoE+ Switch will not recognize it.

18
3.4 Removing the Transceiver Module
1. Make sure there is no network activity by consulting or checking with the
network administrator. Or through the management interface of the switch/
converter (if available) to disable the port in advance.
2. Remove the Fiber Optic Cable gently.
3. Turn the lever of the MGB series module to a horizontal position.
4. Pull out the module gently through the lever.
MGB Series
Transceiver
Figure 3-2: Pulling Out the Transceiver
Never pull out the module without pulling the lever or the
push bolts on the module. Directly pulling out the module with
force could damage the module and the SFP module slot of the
Industrial PoE+ Switch.

19
4. Troubleshooting
This chapter contains information to help you solve issues. If the Industrial
PoE+ Switch is not functioning properly, make sure the Industrial PoE+ Switch
was set up according to instructions in this manual.
The per port LED is not lit
Solution:
Check the cable connection of the Industrial PoE+ Switch.
Per port LED is lit, but the trac is irregular
Solution:
Check whether the attached device is not set to dedicated full duplex. Some
devices use a physical or software switch to change duplex modes. Auto-
negotiation may not recognize this type of full-duplex setting.
Why the Industrial POE+ Switch doesn’t connect to the network
Solution:
Check each port LED on the Industrial PoE+ Switch. Try another port on the
Industrial PoE+ Switch. Make sure the cable is installed properly and the right
type.Turnothepower.Afterawhile,turnonthepoweragain.
Can I install MGB-SX or other non wide temperature SFP module into
SFP slot of Industria PoE+ Switch?
Solution:
Yes, you can. However, the MGB-SX and the other non wide temperature SFP
module cannot operate under -40 to 75 degrees C.

20
APPENDIX A: Networking Connection
A.1 PoE RJ45 Port Pin Assignments (End-span)
1 2 3 4 5 6 7 8
PIN NO RJ45 POWER ASSIGNMENT
1Power +
2Power +
3Power -
6Power -
A.2 Switch’s RJ45 Pin Assignments
1000Mbps, 1000BASE-T
Contact MDI MDI-X
1BI_DA+ BI_DB+
2BI_DA- BI_DB-
3BI_DB+ BI_DA+
4BI_DC+ BI_DD+
5BI_DC- BI_DD-
6BI_DB- BI_DA-
7BI_DD+ BI_DC+
8BI_DD- BI_DC-
10/100Mbps, 10/100BASE-TX
RJ45 Connector Pin Assignment
Contact MDI
Media Dependent Interface
MDI-X
Media Dependent Interface -- Cross
1Tx + (transmit) Rx + (receive)
2Tx - (transmit) Rx - (receive)
3Rx + (receive) Tx + (transmit)
4, 5 Not used
6Rx - (receive) Tx - (transmit)
7, 8 Not used
