User’s Manual
ICF-1700
Touch Screen Internet Multimedia
Phone
1

Copyright
Copyright (C) 2012 PLANET Technology Corp. All rights reserved.
The products and programs described in this User’s Manual are licensed products of PLANET
Technology, This User’s Manual contains proprietary information protected by copyright, and this
User’s Manual and all accompanying hardware, software, and documentation are copyrighted.
No part of this User’s Manual may be copied, photocopied, reproduced, translated, or reduced to any
electronic medium or machine-readable form by any means by electronic or mechanical. Including
photocopying, recording, or information storage and retrieval systems, for any purpose other than the
purchaser's personal use, and without the prior express written permission of PLANET Technology.
Disclaimer
PLANET Technology does not warrant that the hardware will work properly in all environments and
applications, and makes no warranty and representation, either implied or expressed, with respect to
the quality, performance, merchantability, or fitness for a particular purpose.
PLANET has made every effort to ensure that this User’s Manual is accurate; PLANET disclaims
liability for any inaccuracies or omissions that may have occurred.
Information in this User’s Manual is subject to change without notice and does not represent a
commitment on the part of PLANET. PLANET assumes no responsibility for any inaccuracies that may
be contained in this User’s Manual. PLANET makes no commitment to update or keep current the
information in this User’s Manual, and reserves the right to make improvements to this User’s Manual
and/or to the products described in this User’s Manual, at any time without notice.
If you find information in this manual that is incorrect, misleading, or incomplete, we would appreciate
your comments and suggestions.
CE mark Warning
The is a class B device, In a domestic environment, this product may cause radio interference, in
which case the user may be required to take adequate measures.
WEEE Warning
To avoid the potential effects on the environment and human health as a result of the
presence of hazardous substances in electrical and electronic equipment, end users of
electrical and electronic equipment should understand the meaning of the crossed-out
wheeled bin symbol. Do not dispose of WEEE as unsorted municipal waste and have to
collect such WEEE separately.
Trademarks
The PLANET logo is a trademark of PLANET Technology. This documentation may refer to numerous

hardware and software products by their trade names. In most, if not all cases, their respective
companies claim these designations as trademarks or registered trademarks.
Revision
User’s Manual for PLANET Touch Screen Internet Multimedia Phone
Model: ICF-1700
Rev: 1.0 (2012, January)
Part No. EM-ICF-1700v1_v1.0

Table of Contents
UChapter 1 IntroductionU.....................................................................................6
U1.1 OVERVIEWU....................................................................................................................................................................6
U1.2 FEATURESU.....................................................................................................................................................................6
U1.3 PACKAGE CONTENTU......................................................................................................................................................7
U1.4 PHYSICAL DETAILSU.......................................................................................................................................................8
UChapter 2 InstallationU.....................................................................................13
U2.1 GETTING STARTU..........................................................................................................................................................13
UChapter 3 LCD MenuU.......................................................................................15
U3.1 MAIN MENUU...............................................................................................................................................................15
U3.2 BASIC FUNCTIONU........................................................................................................................................................16
UChapter 4 Video Phone SettingU.......................................................................25
U4.1 SYSTEM INFOU..............................................................................................................................................................25
U4.2 NETWORKU...................................................................................................................................................................26
U4.3ACCOUNTU....................................................................................................................................................................30
U4.4 CALLU...........................................................................................................................................................................33
U4.5 DISPLAYU......................................................................................................................................................................36
U4.6 SOUNDU........................................................................................................................................................................39
U4.7 LANGUAGEU.................................................................................................................................................................41
U4.8 DATE TIMEU..................................................................................................................................................................42
U4.9 MAINTAINU...................................................................................................................................................................43
U4.10AUDIOU.......................................................................................................................................................................46
U4.11 VIDEOU.......................................................................................................................................................................48
U4.12 CALL FIREWALLU........................................................................................................................................................50
UChapter 5 Phone ApplicationU...........................................................................52
U5.1 PHONEU........................................................................................................................................................................52
U5.2 CALL OPTIONSU............................................................................................................................................................55
U5.3 CONTACTSU..................................................................................................................................................................57
U5.4 CALL LOGU...................................................................................................................................................................63
U5.5 MEMORY KEYU.............................................................................................................................................................65
U5.6 NETWORK PHONEBOOKU..............................................................................................................................................66
U5.7 MWIU...........................................................................................................................................................................67
UChapter 6 Other ApplicationU............................................................................68

U6.1 EMAILU.........................................................................................................................................................................68
U6.2 CALCULATORU..............................................................................................................................................................71
U6.3 NOTE PADU...................................................................................................................................................................73
U6.4 BROWSERU....................................................................................................................................................................74
U6.5 RECORDERU..................................................................................................................................................................74
U6.6ALARM CLOCKU...........................................................................................................................................................76
U6.7 GALLERYU....................................................................................................................................................................76
U6.8 FILE MANAGERU...........................................................................................................................................................78
U6.9 CAMERAU.....................................................................................................................................................................80
U6.10 MUSICU.......................................................................................................................................................................81
U6.11 SCREEN CALIBRATIONU..............................................................................................................................................83
U6.12 CALENDARU................................................................................................................................................................83
U6.13 PINGBOXU..................................................................................................................................................................83
UChapter 7 Android SettingU.....................................................................................84
U7.1ANDROID SETTINGSU.....................................................................................................................................................84
U7.2 VOIPSETTINGSU...........................................................................................................................................................89
U7.3 CALL SETTINGSU...........................................................................................................................................................93
U7.4ADVANCED SETTINGSU..................................................................................................................................................96
U7.5ABOUT PHONEU.............................................................................................................................................................98
UChapter 8 Web page configuration descriptionU........................................................100
U8.1 BASICU.......................................................................................................................................................................101
U8.2 VOIPU........................................................................................................................................................................102
U8.3 PHONEU....................................................................................................................................................................107
U8.4. MAINTENANCEU...................................................................................................................................................108
U8.5 SYSTEM LOGOUTU......................................................................................................................................................110
UAppendix A SpecificationsU.............................................................................111
UAppendix B Firmware UpgradeU.....................................................................114
UAppendix C Auto provisionU............................................................................115

1
0BChapter 1
Introduction
9B1.1 Overview
PLANET’s Video Conferencing products, ICF-1700, bring you a vivid video conferencing experience
through the Internet. No PC is required and none of the usual complications of complex web camera,
sound card and software settings and specialized data connections. Furthermore, the ICF-1700 has a
built-in 7” LCD monitors in a telephone form factor ideal for desktop use.
The ICF-1700 compliant with the SIP 2.0 standard, which means you can have a seamless
conferencing experience with other SIP compliant video conferencing systems, voice gateway, IP
phones, ATA and IP PBX System. With SIP Proxy Server, MCU support, the ICF-1700 from PLANET
make communications with your business partners quick and cost-effective.
The ICF-1700 has the multiple language features and it base on based on Android OS 2.1 which can
provide the friendly operation interface for which user. It also can connect with the external USB disk
to manage the media file or input the photograph to show the media information.
The feature video outputs which can be used to connect to external monitor for group meetings for
showing video or photographs ,it with outstanding picture and sound quality, the PLANET Internet
Video Conferencing Phone offers you a superior communications experience via the Internet.
10B1.2 Features
Hardware Features
7" Color adjustable LCD touch screen with 800x480 pixels
Built-in High Quality tiltable 2Mega pixel CMOS camera
Full duplex hands-free speakerphone
Ergonomic handset (acoustical cochlea)
1 x WAN and LAN: support switch mode
Compliant IEEE 802.3af PoE standard
Network Feature
DHCP Client on WAN
Main DNS and secondary DNS server
NTP Client
QoS with DiffServ
TR-069
MD5 authentication
Network tools in telnet server: including ping, trace route, telnet client
VOIP Features
Compliant with SIP 2.0
4 SIP servers, and 3 backup SIP servers
6

7
Voice Gain Setting, VAD, CNG
Support SIP domain, SIP authentication (none, basic, MD5),
DNS name of server, Peer to Peer/ IP call
DTMF Relay
Customized music rings
Support STUN
SMS based on SIP
Professional Speaker/HD Voice
Phone book records export/import
XML phone book
Media player(mp3, wav, wma)
USB disk & System files management
Support VoIP(SIP/RTP) encryption
Management
System Base on Android 2.1
Multilanguage realizes localization
Third party android application, e.g. email, IM, internet Radio, web browser
Application market
Web ,telnet and keypad management
Management with different account right
Encrypted configuration files download with AES
11B1.3 Package Content
The contents of your product should contain the following items:
Video phone x 1
Power Adapter x 1
CD-ROM x 1
Quick Guide x 1
RJ-45 cable x 1

12B1.4 Physical Details
The following figure illustrates the components of ICF-1700
Front Panel
No. Item No. Item
1 Handset 2 Handset Cord
3 LCD Display 4 Video Camera
5 Soft Key 1 to 4 6 Numeric Keypad
7 Line button 1 to 4 8 Volume button(down/Mute/Up)
9 Navigation key 10 Menu key
11 Return key 12 Headset key.
13 Resend key 14 Home Key
15 Confirm key. 16 Delete key.
17 Hands-free key. 18 Hook
19 Speaker
8

Keypad
No. Icon Description
A
Telephone four keys are respectively
corresponding to the screen of the four Soft key
keys, different window representing the
different attribute.
B
Line button on the dial pad corresponding
agreement with the Sip.
C
Digital keyboard.
D
Entering the function menu. You can browse
through the menu all functions of the system
are applied, and the execution of the
application.
E
Headset key.
F
Resend key. The phone will automatically dial
the last outgoing call.
9

G
Return key. Click on this button will jump
out the current window.
H
The hands-free key.
I
Home key. Click on this button will return to idle
screen.
Volume control key. You can be in the player
program or call ringing using this key to adjust
the volume size.
J
Mute key-In the call mode, press
this button you can hear other's voices, but the
others cannot hear your voice; press this button
again to leave this mode. In the call state, you
can press this button to turn off the ring tips.
K
Confirm key.
L
Navigation key.
M
Delete key.
10
