Plantronics CS10 User manual

Cordless
Telephone
Headset
System
Product Information Booklet
Power
Charge
Tal k
Page
VOLUME
CHANNEL MUTE
TALK
TALK
Includes:
safety
instructions
specific
operating
instructions
alternate
headset
configurations
troubleshooting
warranty
and other
information
CS10Prdct Info Bklt13.R2 12/27/01 4:23 PM Page 1

Thank you for purchasing
the CS10 Cordless Telephone
Headset System. This Product
Information Booklet provides
additional product details
once you have used the
Quick Start Guide to set up
and test your system.
Power
Charge
Talk
Page
– +
VOLUME
CHANNELMUTE
TALK
TALK
WELCOME
Table of Contents
Safety Information 1
Operating Instructions 5
Re-configure Headset 7
Features 9
Troubleshooting 11
Accessories 14
Warranty & Service 15
FCC Information 17
CS10Prdct Info Bklt13.R2 12/27/01 4:23 PM Page 2

WELCOME
1
5Do not place this product
on an unstable cart,
stand or table. The prod-
uct may fall, causing
serious damage.
6This product should never
be placed near or over
a radiator or heat regis-
ter. It should not be
placed in a built-in
installation unless proper
ventilation is provided.
7This product should be
operated only from the
type of power source
indicated on the marking
label. If you are not sure
of the type of power sup-
ply to your home, consult
your dealer or local
power company.
8Do not allow anything to
rest on the power cord.
Do not locate this product
where the cord will be
damaged by persons
walking on it.
SAFETY INSTRUCTIONS
When using your telephone
equipment these basic
safety precautions should
be followed to reduce the
risk of fire, electric shock,
and injury to persons.
1Read and understand
all instructions.
2Follow all warnings and
instructions marked on the
product. The symbol
identifies and alerts the
user to the presence of
important operating and
service instructions.
3Unplug this product from
the wall outlet before
cleaning. Do not use
liquid cleaners or aerosol
cleaners. Use a damp
cloth for cleaning.
4Do not locate this product
near water, for example,
near a bathtub, wash
bowl, kitchen sink, or
laundry tub, in a wet
basement or near a
swimming pool.
CS10Prdct Info Bklt13.R2 12/27/01 4:23 PM Page 3

2
trical storm. There may be
a remote risk of electric
shock from lightning.
13 Do not use telephone
equipment to report a
gas leak in the vicinity
of the leak.
14 Unplug this product from
the wall outlet and refer
servicing to qualified serv-
ice personnel under the
following conditions:
a) When the power
supply cord or plug is
damaged or frayed.
b) If liquid has been
spilled into the product.
c) If the product has been
exposed to rain or water.
d) If the product does
not operate normally by
following the operating
instructions. (Adjust only
those controls that are
covered by the operating
instructions because
improper adjustments of
other controls may result
9Do not overload outlets
and extension cords as
this can result in risk of
fire or electric shock.
10 Never push objects of
any kind into this product
as they may touch dan-
gerous voltage points or
short out parts that could
result in a risk of fire or
electric shock. Never
spill liquid of any kind
on the product.
11 To reduce the risk of
electric shock, do not
disassemble this product,
but take it to qualified
service personnel when
service or repair work
is required. Opening or
removing covers may
expose you to dangerous
voltages or other risks.
Incorrect reassembly
can cause electric shock
when the product is
subsequently used.
12 Avoid using telephone
equipment during an elec-
CS10Prdct Info Bklt13.R2 12/27/01 4:23 PM Page 4

3
in damage and will often
require extensive work
by a qualified technician
to restore the product to
normal operation.)
e) If the product has been
dropped or the base unit
has been damaged.
f) If the product exhibits
a distinct change in
performance.
15 Never install telephone
wiring during a lightning
storm.
16 Never install telephone
jacks in wet locations
unless the jack is specifi-
cally designed for wet
locations.
17 Never touch uninsulated
telephone wires or termi-
nals unless the telephone
line has been disconnect-
ed at the network inter-
face.
18 Use caution when
installing or modifying
telephone lines.
19 This product is intended
to be supplied by a Listed
Class 2 Direct Plug-In
Power Unit rated 9VDC
800mA. Plantronics Part
No. 45669-01, rated at
an input voltage of 120
VAC, 60Hz and an
output voltage of 9 VDC
at 800mA.
20 This product requires
AC power in order to
operate. In order to have
phone service during
a power outage, have
another telephone avail-
able that is powered only
by the telephone line.
21 Keep all product cords
and cables away from
operating machinery.
Save these instructions
CS10Prdct Info Bklt13.R2 12/27/01 4:23 PM Page 5

4
4Exercise care in handling
the battery pack in order
not to short the battery
contacts with conducting
materials such as rings,
bracelets,and keys. The
battery or conductor
may overheat and
cause burns.
5Charge the battery pack
in accordance with
instructions supplied
with this unit.
6Observe proper orienta-
tion between battery
pack and charger
contacts.
BATTERY
PRECAUTIONS
To reduce the risk of
fire or injury to persons,
read and follow these
instructions.
1Use only the battery
pack supplied with this
product.
2Do not dispose of battery
pack in a fire. The cells
may explode. Check with
local codes for possible
disposal instructions.
3Do not open or mutilate
battery pack. Released
electrolyte is corrosive
and may cause damage
to eyes or skin and may
be toxic if swallowed.
Save these instructions
CS10Prdct Info Bklt13.R2 12/27/01 4:23 PM Page 6

5
If you do not sound loud
enough, move the transmit
level switch (located on
the back side of base) to
position 1.
If you sound too loud, move
transmit level switch to posi-
tion 3. You can further fine-
tune the transmit level with
the talk volume control locat-
ed on side of the base.
Adjust the volume of your
co-worker’s voice by using
the listen volume control on
the remote.
Replace the handset upon
completion of the call and
press the talk button on either
the remote or the base. The
in-use indicator lights will
go out.
Placing a Call
With your headset in
position move the telephone
handset off its cradle.
Press the talk button on
either the remote or the base
unit. The in-use indicators
light and you will hear a
dial tone.
If you do not hear a dial
tone, move the configuration
switch (A/B) to the opposite
setting.
If you still do not hear a dial
tone see the Troubleshooting
section.
Dial a co-worker. When
your party answers, speak
normally and ask how your
voice sounds.
OPERATING
INSTRUCTIONS
A B
123
CS10Prdct Info Bklt13.R2 12/27/01 4:23 PM Page 7

6
Receiving a Call
When your telephone notifies
you of an incoming call, put
on your headset and lift the
telephone handset off its
cradle.
Press the talk button on either
the remote or the base. The
in-use indicator lights will
go on. Begin speaking.
Replace the handset upon
completion of the call and
press the talk button on either
the remote or the base. The
in-use indicator lights will
go out.
Securing Your
Headset
Attach the clothing clip at
about the chest level. Using
the clip keeps the weight
of the headset cable off the
headset and allows you to
move freely.
This is particularily important
when configured in the Over-
the-Ear configuration.
Optional
Handset Lifter
The lifter allows either the
remote or base unit’s talk
buttons to automatically lift
or replace the telephone’s
handset. See the accessories
section of this booklet.
CS10Prdct Info Bklt13.R2 12/27/01 4:23 PM Page 8

7
HOW TO
RE-CONFIGURE
YOUR HEADSET
Your CS10 system comes
with the Plantronics Convert-
ible headset. This headset
allows for use in the Over-
the-Head or Over-the-Ear
configuration on the right
side or left side.
The headset is shipped in the
Over-the-Head configuration.
You can adjust for the right
ear or left ear by simply
rotating the voice boom
180 degrees.
Adjust the voice boom to
be about one inch from the
corner of your mouth.
Disassemble
for Other
Configurations
Unsnap the headband from
the headset assembly and
pull off the ear cushion
assembly as shown.
CS10Prdct Info Bklt13.R2 12/27/01 4:23 PM Page 9

8
12
2
Over-the-Ear
Configuration
Right Ear
Reassemble components as
shown 1and 2.
1. Push pivot ball ring over
the headset assembly.
2. Push pin portion of the
flexible earloop through hole
in pivot ball ring. Reverse the
pin direction for left ear.
assembly to allow the ear-
loop to be stretched open to
slide easily over the ear. Use
your thumb in the thumb loop
and forefingers to stretch the
earloop.
Once the earloop is over
your ear, push the speaker
toward your ear.
Adjust voice boom to a
position one inch from the
corner of the mouth.
Note: For added stability,
press the headset cord under
the cord retainers on the ear-
loop.
Move the flexible earloop
away from the headset
