Plasson PLASSNEST EXPULSION TIMER User manual

PLASSNEST EXPULSION TIMER
Quick Setup Guide
Copyright © 2020 Plasson, all rights reserved

2
Nest opening
The timer’s C1 channel opens the expulsion grids (i.e., moves them to
vertical position). C1 needs to be active for two minutes.
This guide explains how to set up the expulsion system timer and
includes the following steps:
• Initial Timer Setupn (see page 3)
• Programming Nest Opening (see page 6)
• Programming Nest Closing (see page 13)
The timer’s C2 channel closes the expulsion grids (i.e., moves them to
diagonal position). C2 needs to be active for six minutes.
Nest closing
Overview

3
english
A. Press and hold
Res using a pen tip
B. ENGLISH flashes
1. Resetting the timer
2. Setting the language
french
B. Various languages
are displayed
C. Press ok to choose
the desired language
A. Press +or -to
select a language
Initial Timer Setup
Perform the following steps once to set up the timer for operation.

4
3. Setting the current date
year
A. Year value flashes
C. Press ok
B. Press +or -to
select the year
20 20
month
D. Month value flashes
F. Press ok
E. Press +or -to
select the month
09
day
G. Day value flashes
I. Press ok
21 . 09
H. Press +or -to
select the day

5
4. Setting the current time
5. Main screen is displayed
21 09 20
16 : 20
hour
A. Hour value flashes
C. Press ok
16 : 00
B. Press +or -to
select the hour
minute
D. Minute value flashes
F. Press ok
E. Press +or -to
select the month
16 : 20

6
1. Selecting the nest opening (C1) channel
program
C. Press ok
A. Press Menu
B. program is displayed
new prog
D. NEW P rog flashes
E. Press ok
Programming Nest Opening
Perform the following steps to define the time of day when the nests
open and allow chickens entry.

7
channel
c1
F. channel is displayed
and c1 flashes
G. Press ok
2. Setting the nest opening start time (C1 On)
time on
c1
A. time on is displayed
and O nflashes
B. Press ok
NOTE:
At nest opening
start time, the
expulsion motor
moves the
expulsion grids
to open (vertical)
position
On
c1
E. Press ok
On
hour
C. Hour value flashes
6: 00
D. Press +or -to
select the hour

8
NOTE:
The dened start
time must be
copied to all days
of the week
c1
H. Press ok
On
minute
F. Minute value flashes
G. Press +or -to
select the minute
6 : 20
3. Setting the start time for all days of the week
c1
B. Press ok
On
monday
A. monday flashes
6 : 20
c1
D. Press ok
On
copy
C. copy flashes
6 : 20

9
c1
F. Press ok
On
add tu
E. add tu flashes
6 : 20
G. Press ok for
add we , add Th ,
add fr , add sa ,
and add su
4. Storing the nest opening start time
c1
B. Press ok
On
store
A. store flashes
6 : 20
new prog
A. NEW P rog flashes
B. Press ok
5. Selecting the nest opening (C1) channel

10
channel
c1
C. channel is displayed
and c1 flashes
D. Press ok
6. Setting the nest opening end time (C1 Off)
time off
c1
A. time off is displayed
and off flashes
B. Press ok
NOTE:
This step is
necessary to turn
off the opening
command after the
grids are in place
c1
E. Press ok
hour
C. Hour value flashes
6: 00
D. Press +or -to
select the hour
NOTE:
Opening end time
should be two
minutes after
opening start time

11
NOTE:
The dened end
time must be
copied to all days
of the week
c1
H. Press ok
minute
F. Minute value flashes
G. Press +or -to
select the minute
6 : 22
7. Setting the end time for all days of the week
c1
B. Press ok
monday
A. monday flashes
6 : 22
c1
D. Press ok
copy
C. copy flashes
6 : 22

12
c1
F. Press ok
add tu
E. add tu flashes
6 : 22
G. Press ok for
add we , add Th ,
add fr , add sa ,
and add su
8. Storing the nest opening end time
c1
B. Press ok
store
A. store flashes
6 : 22

13
new prog
A. NEW P rog flashes
B. Press ok
1. Selecting the nest closing (C2) channel
channel
c1
C. channel is displayed
and c1 flashes
E. Press ok
D. Press +to
switch to c2
Programming Nest Closing
Perform the following steps to define the time of day when the nests
close and don’t allow chickens entry.

14
2. Setting the nest closing start time (C2 On)
time on
c2
A. time on is displayed
and O nflashes
B. Press ok
NOTE:
At nest closing start
time, the expulsion
motor moves the
expulsion grids to
closed (diagonal)
position
On
c2
E. Press ok
On
hour
C. H our value flashes
18 : 00
D. Press +or -to
select the hour
c2
H. Press ok
On
minute
F. Minute value flashes
G. Press +or -to
select the minute
18 : 20

15
NOTE:
The dened start
time must be
copied to all days
of the week
3. Setting the start time for all days of the week
c2
B. Press ok
On
monday
A. monday flashes
18 : 20
c2
D. Press ok
On
copy
C. copy flashes
18 : 20
c2
F. Press ok
On
add tu
E. add tu flashes
18 : 20
G. Press ok for
add we , add Th ,
add fr , add sa ,
and add su

16
4. Storing the nest closing start time
c2
B. Press ok
On
store
A. store flashes
18 : 20
new prog
A. NEW P rog flashes
B. Press ok
5. Selecting the nest closing (C2) channel
channel
c2
C. channel is displayed
and c2 flashes
D. Press ok

17
6. Setting the nest closing end time (C2 Off)
time off
c2
A. time off is displayed
and off flashes
B. Press ok
NOTE:
This step is
necessary to turn
off the opening
command after the
grids are in place
c2
E. Press ok
hour
C. Hour value flashes
18 : 00
D. Press +or -to
select the hour
NOTE:
Closing end time
should be six
minutes after
closing start time
c2
H. Press ok
minute
F. Minute value flashes
G. Press +or -to
select the minute
18 : 26

18
NOTE:
The dened end
time must be
copied to all days
of the week
7. Setting the end time for all days of the week
c2
B. Press ok
monday
A. monday flashes
18 : 26
c2
D. Press ok
copy
C. copy flashes
18 : 26
c2
F. Press ok
add tu
E. add tu flashes
18 : 26
G. Press ok for
add we , add Th ,
add fr , add sa ,
and add su

19
8. Storing the nest closing end time
c2
B. Press ok
store
A. store flashes
18 : 26
new prog
9. Returning to the main screen
A. Press Menu
