Plasson PN16 User manual

Plasson Universal
Slip Repair Coupler
Pull-Out Resistant
PN16

Plasson Universal Slip
Steel/Acier
Acero/Acciaio
Copper/Cuivre
Cobre/Rame
Lead/Plomb
Plomó/Piombo
PB, PP-R
PVC-U, ABS
PE, PP, PEX
Fits a wide range of pipe materials
EN
Compatible con una amplia variedad
de tuberías y materiales
ES
Compatible avec un grand nombre
de tubes
FR
Adatto per la giunzione di un’ampia
gamma di materiali
IT
Product Diameter Range
24-28mm
(0.94"-1.1")
176100024028
19-22 mm
(0.75"-0.87")
176100019022
31-35 mm
(1.22"-1.37")
176100031035
40-43 mm
(1.57"-1.69")
176100040043
48-51 mm
(1.89"-2.00")
176100048051
60-64 mm
(2.36"-2.52")
176100060064

Assembly Instructions
2
3
1
1Mark pipe insertion depth on the pipe
(approximately half the fitting length). Undo nuts 1
to 2 turns while ensuring they remain on the fitting.
2Insert the pipe until the mark reaches the end of
the nut.
3While holding the fitting body with a Plasson
wrench (or a similar tool) tighten the nut firmly with
a second wrench.
Note: If the fitting is reused, make sure metal teeth
are present in the split ring.
EN
1Marquer la longueur d’emboîtement sur chaque
tube (au plus une demi-longueur de manchon).
Dévisser les écrous de 1 ou 2 tours en les laissant
sur le manchon.
2Insérer chaque tube jusqu’au marquage.
3Serrer l’écrou fermement avec une clé (Plasson ou
équivalent) en maintenant le corps avec une autre
clé.
NB: Raccord réutilisable. Vérifier de la conformité de
la bague.
FR
1Marque la profundidad de inserción en la tubería
(aproximadamente la mitad de la longitud del
accesorio). Desenroscar 1 o 2 vueltas los racores
de apriete del accesorio, asegurándose que éstas
no se desmontan completamente.
2Introduzca el accesorio hasta que las marcas en
la tubería queden alineadas con el final de los
racores de apriete.
3Mantenga el cuerpo del accesorio fijo utilizando
una llave Plasson o similar mientras aprieta los
racores del accesorio.
Nota: Si reutiliza el accesorio, asegúrese que los
dientes metálicos del casquillo de apriete se
encuentran en perfectas condiciones.
ES
1Marcare sul tubo la profondità di inserimento (circa
la metà della lunghezza del manicotto). Svitare le
ghiere di 1 o 2 giri assicurandosi che rimangano
sul raccordo.
2Inserire il tubo fino al punto in cui la fine della
ghiera è allineata alla marcatura.
3Stringere la ghiera con una chiave Plasson (o
utensile simile) tenendo fermo il corpo del
raccordo con un’altra chiave.
Nota: In caso di riutilizzo del raccordo verificare la
presenza dei dentini metallici sullo split ring.
IT

PLASSON Ltd. Maagan Michael D.N. Menashe 3780500 Israel, Tel: [phone], Fax: [phone]
E-mail: [email protected], www.plasson.com
Fitting Diameter Range
Pipe Type Size Standard
PE - Metric 25
ISO 4427
EN 12201
AS 4130 (series1,series2)
PVC - Metric 25 EN/ISO/BS 1452
PP - Metric 25 ISO 15874
STEEL -
Galvanized
Schedules 40,80
3/4"
ASTM A53
ANSI/ASME B36
EN 10208/10216
BS 3601/3602
DIN 1629/2448
PE - IPS
Imperial 3/4"
ASTM D3035
ASTM F714
AWWA C906
BS 1972
BS 3284
PVC - IPS, Imperial 3/4"
ASTM D1785
Schedules 40,80,120
UPVC Imperial
BS 3505:1968
PE (Australia) - NB NB20
AS 4130 (series3 nominal
inside diameter-based
on IPS)
COPPER
(Australia) 25 (1") AS 1432
PVC (Australia)
- NB NB20 AS 1477 UPVC
PE (USA) - Inside
controlled
diameter SDR
9,11.5,15
3/4" ASTM D2239
PE (USA) - CTS
outside controlled
diameter
3/4" ASTM D2737
COPPER (USA) -
Water tube 3/4" ASTM B88
PE (Ireland) -
Heavy Gauge +
Normal Gauge
3/4" IS 134 table 1+ table 2
Pipe Type Size Standard
PE - Metric 20
ISO 4427
EN 12201
AS 4130 (series1,series2)
PVC - Metric 20 EN/ISO/BS 1452
PP - Metric 20 ISO 15874
STEEL -
Galvanized
Schedules 40,80
1/2"
ASTM A53
ANSI/ASME B36
EN 10208/10216
BS 3601/3602
DIN 1629/2448
PE -
IPS Imperial 1/2"
ASTM D 3035
ASTM F 714
AWWA C906
BS1972
BS 3284
PVC -
IPS Imperial 1/2"
ASTM D 1785
Schedules 40,80,120
UPVC imperial
BS 3505:1968
PE (Australia) - NB NB15
AS 4130 (series3 nominal
inside diameter-based
on IPS)
COPPER
(Australia) 20 (3/4") AS 1432
PVC (Australia)
- NB NB15 AS 1477 UPVC
PE (USA) - Inside
controlled
diameter SDR
7,9,11.5,15
1/2" ASTM D 2239
PE (USA) - CTS
outside controlled
diameter
5/8”, 3/4” ASTM D 2737
COPPER (USA) -
Water tube 5/8”, 3/4” ASTM B 88
PE (Ireland) -
Heavy Gauge 1/2" IS 134 table 2
Pipe Type Size Standard
PE - Metric 32
ISO 4427
EN 12201
AS 4130 (series1,series2)
PVC - Metric 32 EN/ISO/BS 1452
PP - Metric 32 ISO 15874
STEEL -
Galvanized
Schedules 40,80
1"
ASTM A53
ANSI/ASME B36
EN 10208/10216
BS 3601/3602
DIN 1629/2448
PE - IPS
Imperial 1"
ASTM D3035
ASTM F714
AWWA C906
BS 1972
BS 3284
PVC - IPS, Imperial 1"
ASTM D1785
Schedules 40,80,120
UPVC Imperial
BS 3505:1968
PE (Australia) - NB NB25
AS 4130 (series3 nominal
inside diameter-based
on IPS)
COPPER
(Australia) 32 (1.1/4") AS 1432
PVC (Australia)
- NB NB25 AS 1477 UPVC
PE (USA) - Inside
controlled
diameter, SDR
9, 11.5
3/4" ASTM D2239
PE (USA) - CTS
outside controlled
diameter
1" ASTM D2737
COPPER (USA) -
Water tube 1" ASTM B88
PE (Ireland) -
Heavy Gauge 1" IS 134 table 1
PE (Ireland) -
Heavy Gauge 1.1/4" IS 134
24-28mm (0.94”-1.1”)19-22mm (0.75”-0.87”)
Pipe Type Size Standard
PE - Metric 40
ISO 4427
EN 12201
AS 4130 (series1,series2)
PVC - Metric 40 EN/ISO/BS 1452
PP - Metric 40 ISO 15874
STEEL -
Galvanized
Schedules 40,80
1.1/4"
ASTM A53
ANSI/ASME B36
EN 10208/10216
BS 3601/3602
DIN 1629/2448
PE - IPS
Imperial 1.1/4"
ASTM D3035
ASTM F714
AWWA C906
BS 1972
BS 3284
PVC - IPS
Imperial 1.1/4"
ASTM D1785
Schedules 40,80,120
UPVC Imperial
BS 3505:1968
PE (Australia) - NB NB32
AS 4130 (series3 nominal
inside diameter-based
on IPS)
COPPER
(Australia) 40 (1.1/2") AS 1432
PE (Australia) -
RURAL 1.1/2" (40) AS 2698
PVC (Australia)
- NB NB32 AS 1477 UPVC
PE (USA) - Inside
controlled
diameter, SDR
11.5
1.1/4" ASTM D2239
PE (USA) - CTS
outside controlled
diameter
1.1/4" ASTM D2737
COPPER (USA) -
Water tube 1.1/4" ASTM B88
PE (Ireland) -
Heavy Gauge 1.1/4" IS 134 table 2
40-43mm (1.57”-1.69”)
Pipe Type Size Standard
PE - Metric 50
ISO 4427
EN 12201
AS 4130 (series1,series2)
PVC - Metric 50 EN/ISO/BS 1452
PP - Metric 50 ISO 15874
STEEL -
Galvanized
Schedules 40,80
1.1/2"
ASTM A53
ANSI/ASME B36
EN 10208/10216
BS 3601/3602
DIN 1629/2448
PE - IPS
Imperial 1.1/2"
ASTM D3035
ASTM F714
AWWA C906
BS 1972
BS 3284
PVC - IPS
Imperial 1.1/2"
ASTM D1785
Schedules 40,80,120
UPVC Imperial
BS 3505:1968
PE (Australia) - NB NB40
AS 4130 (series3 nominal
inside diameter-based
on IPS)
COPPER
(Australia) 50 (2") AS1432
PVC (Australia)
- NB NB40 AS 1477 UPVC
PE (USA) - Inside
controlled
diameter SDR 9 +
SDR 11.5
1.1/2" ASTM D2239
PE (Ireland) -
Heavy Gauge 1.1/2" IS 134 table 2
48-51mm (1.89”-2.00”)
Pipe Type Size Standard
PE - Metric 63
ISO 4427
EN 12201
AS 4130 (series1,series2)
PVC - Metric 63 EN/ISO/BS 1452
PP - Metric 63 ISO 15874
STEEL -
Galvanized
Schedules 40,80
2"
ASTM A53
ANSI/ASME B36
EN 10208/10216
BS 3601/3602
DIN 1629/2448
PE - IPS
Imperial 2"
ASTM D3035
ASTM F714
AWWA C906
BS 1972
BS 3284
PVC - IPS
Imperial 2"
ASTM D1785
Schedules 40,80,120
UPVC Imperial
BS 3505:1968
PE (Australia) - NB NB50
AS 4130 (series3 nominal
inside diameter-based
on IPS)
COPPER
(Australia) 65 (3") AS1432
PVC (Australia)
- NB NB50 AS 1477 UPVC
PE (USA) - Inside
controlled
diameter SDR 11.5
2" ASTM D2239
PE (Ireland) -
Heavy Gauge 2" IS 134 table 2
60-64mm (2.36”-2.52”)
31-35mm (1.22”-1.37”)
14127 10.18
