LAGUNARecliningShower&ToiletChair
PHS1000
AssemblyandOperationManual

PREPARINGFORUSE 
Step1.Removepartsfrompackageandarrangethemonaflatsurfaceforeasyassembly.
TheLagunawillbeinsixparts:Chairframe,headrest,footrest,paddedseatandtwoarmrests.
Fourboltandknobsetsareincludedforfasteningthechairassemblyalongwithapailandlid.
A)Chairframe F)Headrest
B)Twoarmrests G)BoltandKnobset(4boltsx4knobs)
C)Seatframe H)Pailwithlid
D)PaddedseatI)Frontbasefootbar
E)Footrestwithstrap 


B
C D
E
F
H
G
A
I


PHONE:888.550.2410EMAIL:[e-mail]www.platinumhealthllc.com
Step2. Placechairframe(A)onfloor.Toavoidunnecessarymovementduringassembly,pressthebrakeson
thewheelstolockthefourcasters.



Step3.
Placetheseatframe(C)intotheblackinsertsontheinnerpartofthechairframe.
Thepaddedseat(D)maybeinstalledbysnappingitonthetopofseatframe.


Step4.
Installaboltandknobset(G)byinsertingaboltthroughtheholeoftheblackplasticinsertofseat
frameandtightenwithaknob.Repeatonother3insertsofframe.






PHONE:888.550.2410EMAIL:[e-mail]www.platinumhealthllc.com
Step5.Attachthearmrest(B) tothesideofthechairframe.Placetheboltthroughthearmrestand
frame.Tosecurethearmtightentheknob.Repeatontheoppositeside.

 

Step6.Insertthefrontbasefootbar(I)intotheblackinsertsonthelowerbaseofthechairframeuntil
thegoldspringtensionbuttonsclickintoplace.
 

Step7.Insertfootrest(E)intothesupportbarontheinsidebaseofthechairframe,makingsurethe
goldspringtensionbuttonclicksintoplace.Repeatonoppositeside.Thefootrestwillbeabletofoldup
anddown.NOTE:Alwaysensureeachgoldspringtensionbuttonisproperlylockedinplace.
   




PHONE:888.550.2410EMAIL:[e-mail]www.platinumhealthllc.com
Step8. Removethepaillidandslidepailundertheseatframe.


Step9.
Insertheadrest(F)intothetubeonbackofchairframe,adjusttothesuitableheightandtightenin
placewithknob.Theheadrestcanbeadjustedtothedesiredheightpositionbylooseningtheknob,adjusting
andretightening.

  

TheLagunaisnowreadyforuse.







PHONE:888.550.2410EMAIL:[e-mail]www.platinumhealthllc.com
OperationInstructions
 


TransferringtheUserintheLagunaShowerChair:

1.
WheeltheLagunashowerchairasclosetotheuseraspossibleandlockthecasters.Neverperformatransfer
withoutfirstlockingthecasters.
2. Forlateraltransfers,removeanarmresttopositiontheuserontotheLagunaseatthenreattacharmrest.
3. Ifperformingastandingtransfer,flipupthefootrestsandbacktheuserontotheshowerseat.
4. AssisttheuserontotheLagunabygentlyrestingthemontotheseat.Oncetheuserisseatedflipthefootrests
downandplacetheirfeetonthefootrests.Besurebotharmrestsarelevelforusersafetyandcomfort.
5. Bringthechestsafetybeltaroundthefrontoftheuserandfastenforaddedsecurity.
6. Thecasterscannowbeunlockedfortransportintoashowerordesignatedbatharea.
7. TheLagunacanbereclinedduringshoweringforamorecomfortableposition.Torecline,gentlyliftthesilver
knobbehindthebackrest.Releasethesilverknobtolockthebackrestintoplace.Castersshouldbelockedfor
showering.

8.Whenshoweringiscomplete,returntheLagunabackresttoitsmostuprightposition,unlockthecastersand
transporttheusertothedesiredarea.









