PlayStation PULSE 3D CFI-ZWH1 User manual

PULSE 3D™
Wireless Headset and Adaptor
Instruction Manual
CFI-ZWH1
CFI-ZWD1
Downloaded from manualsnet.com search engine

2
WARNING
To prevent possible hearing damage, do not listen at high volume levels for long periods.
Table of Contents
Safety and precautions 3
Cleaning 4
Battery 4
Storage conditions 5
Part names and functions 6
Initial setup 7
Using your headset wirelessly with a PlayStation®5 console or PlayStation®4 console 8
Audio selection 9
Using your headset with PlayStation®VR 9
Using your headset wirelessly with a USB device 9
Using your headset with other devices 10
Charging the headset 10
Status indicator display 11
Resetting the headset 12
Rating Label 13
Specifications 14
GUARANTEE 15
EN
Downloaded from manualsnet.com search engine

3
Safety and precautions
Carefully read the documentation included in the package and information on the package
before using this product. Retain all documentation for future reference.
For more detailed instructions about the use of this product, see: playstation.com/help
Safety
ˎObserve all warnings, precautions and instructions.
ˎKeep this product out of the reach of small children. Small children may swallow
small parts or may wrap the cables around themselves, which may inflict injury
or cause an accident or a malfunction.
ˎThis product has magnets which may interfere with pacemakers, defibrillators and
programmable shunt valves or other medical devices. Do not place this product close
to such medical devices or persons who use such medical devices. Consult your doctor
before using this product if you use such medical devices.
ˎStop using the system immediately if you begin to feel tired or if you experience
discomfort or pain in your head while operating the wireless headset. Ifthe condition
persists, consult a doctor.
ˎAvoid prolonged use of the wireless headset. Take a break at about 15-minute intervals.
ˎPermanent hearing loss may occur if the headset is used at high volume. Set the volume
to a safe level.
Over time, increasingly loud audio may start to sound normal but can actually be
damaging to your hearing.
If you experience ringing in your ears or muffled speech, stop listening and have your
hearing checked.
The louder the volume, the sooner your hearing could be affected. To protect
your hearing:
ˋLimit the amount of time you use the headset at high volume.
ˋAvoid raising the volume to block out noisy surroundings.
ˋLower the volume if you can’t hear people speaking near you.
ˎIf you feel that the headset is irritating your skin, stop using it immediately.
ˎIf the internal battery fluid leaks, stop using the product immediately and contact technical
support for assistance. If the fluid gets on to your clothes, skin or into your eyes,
immediately rinse the affected area with clean water and consult your doctor.
The battery fluid can cause blindness.
Downloaded from manualsnet.com search engine

4
Use and handling
ˎAvoid leaving the headset near speakers while the microphones are on, as this may
produce feedback (audio noise).
ˎDo not disassemble or insert foreign objects into the headset because this may cause
damage to the internal components or cause injury to you.
ˎThe battery used in this device may present a risk of fire or chemical burn if mistreated. Do
not disassemble, heat above 60 °C, or incinerate.
ˎObserve all signs and instructions that require an electrical device or radio product to be
switched off in designated areas, such as gas/refuelling stations, hospitals, blasting areas,
potentially explosive atmospheres or aircraft.
ˎDo not use the headset while cycling, driving or engaged in any other activity where your
full attention is required. Doing so may result in an accident.
ˎDo not allow liquid or small particles to get into the headset.
ˎDo not touch the product with wet hands.
ˎDo not throw or drop the headset, or subject it to strong physical shock.
ˎDo not put heavy objects on the headset.
ˎDo not place any rubber or vinyl materials on the headset exterior for an extended period
of time.
Cleaning
ˎUse a soft, dry cloth to clean the headset. Do not use solvents or other chemicals.
Do not wipe with a chemically treated cleaning cloth.
Battery
Caution – using the built-in battery:
ˎThis product contains a lithium-ion rechargeable battery.
ˎBefore using this product, read all instructions for handling and charging the battery and
follow them carefully.
ˎTake extra care when handling the battery. Misuse can cause fire and burns.
ˎNever attempt to open, crush, heat or set fire to the battery.
ˎDo not leave the battery charging for a prolonged period of time when the product
is not in use.
ˎAlways dispose of used batteries in accordance with local laws or requirements.
ˎDo not handle the damaged or leaking battery.
Battery life and duration
ˎThe battery has a limited lifespan. Battery charge duration gradually decreases with
repeated usage and age. Battery life also varies depending on the storage method, usage
state, environment and other factors.
ˎCharge in an environment where the temperature range is between 10 °C and 30 °C.
Charging may not be as effective when performed in other environments.
ˎBattery duration may vary depending on the usage condition and environmental factors.
Downloaded from manualsnet.com search engine

When not in use
When the product is not used for an extended period of time, it is recommended that you
fully charge it at least once a year in order to maintain its functionality.
Storage conditions
ˎDo not expose the headset and battery to extremely high or low temperatures during
operation, transportation, or storage.
ˎDo not leave it in direct sunlight for extended periods (such as in a car during summer).
ˎDo not store the headset by hanging it from the headband strap. After a period of time,
the strap can stretch and loosen the fit of the headset.
NOTE:
This equipment generates, uses, and can radiate radio frequency energy and, if not installed
and used in accordance with the instructions, may cause harmful interference
to radio communications. However, there is no guarantee that interference will not occur in
a particular installation. If this equipment does cause harmful interference to radio
or television reception, which can be determined by turning the equipment off and
on, the user is encouraged to try to correct the interference by one or more of the following
measures:
ˋReorient or relocate the receiving antenna.
ˋIncrease the distance between the equipment and receiver.
ˋConnect the equipment into an outlet on a circuit different from that to which
the receiver is connected.
ˋConsult the dealer or an experienced radio/TV technician for help.
The wireless headset brings dynamic sound to your interactive experience. Please note,
wireless products may be affected by the presence of other wireless devices in the general
vicinity. If you experience any unexpected performance with your wireless headset please
contact us before returning it to your retailer. For details visit playstation.com/help
5
Downloaded from manualsnet.com search engine

Part names and functions
Front
Rear
Bottom
Headband
Headband strap
Microphones (hidden)
Status indicator
CHAT/GAME buttons
MONITOR switch
VOLUME +/- buttons
(mute) button
USB Type-C® port
3.5 mm audio input jack
(power) switch
6
Downloaded from manualsnet.com search engine

Wireless adaptor (CFI-ZWD1)
Connects the headset wirelessly to your console.
Initial setup
1 Connect the included USB cable to charge the headset.
ˎWhen charging while the headset is not connected to the wireless adaptor, the status
indicator on the headset pulses orange. When fully charged, the status indicator turns off.
ˎWhen charging while the headset is connected to the wireless adaptor, the status indicator
on the headset is white. When fully charged, the status indicator blinks orange once and
then turns solid white to show it’s still connected.
2 Connect the wireless adaptor to a USB port on your PlayStation®5 or
PlayStation®4 console.
The status indicator on the adaptor blinks white while searching for the headset.
3 Slide the (power) switch on. When your headset powers on, it looks for the
wireless adaptor. The headset status indicator blinks blue while searching and turns solid
white when the connection is complete.
You can also check by sound. When your headset powers on, it will beep and search for
the adaptor. When the connection is complete, another beep sounds.
If a connection can’t be made, the headset turns off. Slide the switch off,
and then on. If a connection still can’t be made, try resetting the headset
(see “Resetting the headset”).
Reset button
Status indicator
7
Downloaded from manualsnet.com search engine

Using your headset wirelessly with a PlayStation®5 console
or PlayStation®4 console
ˎBe sure to always update your system software to the latest version.
ˎYou can use up to 2 wireless headsets at the same time on your PS5 console
or PS4 console.
ˎIf you move out of range for more than 30 seconds, you’ll hear a low beep to indicate the
connection is lost. When you move back into range, you’ll hear a high beep to indicate the
connection is restored.
ˎThis headset supports 3D audio on PS5 consoles if the game supports 3D audio.
ˎThe Headset Companion app for PS4 consoles does not support this headset.
On screen status
When first connecting to your console or when changing the settings, status icons appear
on the screen.
Volume level
Volume muted
Mic on
Mic muted
Battery full
Battery medium
Battery low
Battery empty
Icons may vary depending on compatible PlayStation® console used.
8
Downloaded from manualsnet.com search engine

Audio selection
Mic mute ( button)
To mute the headset microphones, press the mute button on the headset.
To unmute, press the button again. Mute is active when the button shows orange.
Mic monitoring (MONITOR switch)
Mic monitoring is a feature that allows you to hear your own voice, so you can
hear how you sound to your friends. Slide the switch to enable mic monitoring.
You’ll hear a beep:
ˎOn: high beep
ˎOff: low beep
When mute is on, mic monitoring is turned off.
Chat and game volume balance (CHAT/GAME buttons)
You can listen to both game audio and chat audio simultaneously. Use the
CHAT/GAME buttons to adjust the relative volume of chat audio versus
game audio. Press the CHAT and GAME buttons at the same time to reset
the relative volume.
Some games may have a chat feature that is incompatible with the CHAT/GAME function.
ˎTo change the audio output on your PS5 console, select
Settings > Sound > Audio Output > Output to Headphones.
ˎTo change the audio output on your PS4 console, select
Settings > Devices > Audio Devices > Output to Headphones.
Using your headset with PlayStation®VR
You can use the included audio cable to connect your headset to the stereo headphone jack
of the VR headset. This provides all audio processed by PS VR, including 3D audio, if
supported by the game.
Using your headset wirelessly with a USB device
You can use the headset with compatible PCs (Windows® or macOS®) or other devices that
have USB audio output.
Insert the wireless adaptor into a USB Type-A port on your compatible device, and then
turn on the headset.
The CHAT/GAME feature can be used only when the headset is connected to a
PS5 console or PS4 console.
If you move out of range for more than 30 seconds, you’ll hear a low beep to indicate
the connection is lost. When you move back into range, you’ll hear a high beep to
indicate the connection is restored.
9
Downloaded from manualsnet.com search engine

Using your headset with other devices
You can use the included audio cable (4-conductor) to connect your headset to the 3.5 mm
audio jack of compatible devices.
The headset functions as a passive headset when you use an audio cable. Turn off the
headset when you use an audio cable.
Wireless connection and the following functionality is disabled when you use
an audio cable.
ˎChat and game volume balance
ˎMic mute
ˎMic monitoring
ˎVolume levels
You must use the included audio cable in order to use the headset mics on a compatible
device. If your device isn’t compatible with the included 4-conductor cable, you can’t use
your headset’s mics with that device.
4-conductor audio cable (included) Stereo-only audio cable (not included)
ˎOn mobile devices, 3D audio is not supported.
ˎOutput volume varies depending on the mobile device that is connected.
Adjust volume accordingly.
Charging the headset
When the battery is empty, fully charging the headset on a PS5 console or PS4 console
takes approximately 3.5 hours.
To determine the charge level of your headset, turn the power on and then press the CHAT
and VOLUME– buttons at the same time. The status indicator blinks and you hear beeps.
Battery level Status indicator Audio indicator
Purple, 3 blinks 3 beeps
Purple, 2 blinks 2 beeps
Purple, 1 blink 1 beep
Orange, fast blinks 1 high beep, 1 low beep
When the battery level is low, the status indicator blinks orange and the headset beeps.
Charge the battery by connecting the headset to a supported USB device such as your PS5
console or a PC using the included USB cable.
10
Downloaded from manualsnet.com search engine
