Plevo Up User manual

UP
User's manual

01
Contents
Chapter 1: Overview of the PLEVO UP.
Chapter 2: First steps.
Download the PLEVO App.
Turning on the suitcase.
Pairing.
Chapter 3: Removable battery.
Parts and characteristics.
Installation.
Extraction.
Loading devices.
Backup battery.
Chapter 4: Removable wheels.
Installation.
Disassembly.
Chapter 5: Opening and closing the suitcase.
General components of the closure.
Opening with a key
Mixed-use warning.
Electronic opening and closing by Face ID / Touch ID.
Electronic opening and closing by Morse Code.
Chapter 6: Digital scale.
Sensors.
Using the scale.
Chapter 7: GPS Location of the suitcase.
Chapter 8: Dispatch and withdraw a PLEVO suitcase.
Chapter 9: Lights.
Indicator lights and lock alerts.
Indicator lights and alerts on the front board and panel.
Chapter 10: Search for a mobile device.
03
04
04
04
05
07
07
07
08
09
10
11
11
12
13
13
14
15
16
18
21
21
21
23
24
25
25
26
27
UP User's manual

02
Chapter 11: Shutting down the suitcase.
Chapter 12: Unlinking a device.
Chapter 13: Garment cover system.
Components.
System operation.
Hanger's operation.
Suit holder's anchors.
PLEVO UP - User's manual
2019
28
28
29
29
30
31
32
UP User's manual

01 - Overview of the Plevo UP.
Below are the external components of the suitcase.
Body
Electronic closure
Side handle
Closure Flaps
Removable wheel
Support plugs
Hinge
Aluminum frame
03
Main handle
button
Main handle
Indicative front
light
Front badge
Cover
Battery access
cover.
Rear badge
Dashboard
Wheel fastener
UP User's manual
Note: Some external components of the UP model vary between the Runner and Infinite models.

02 - First steps.
Download the PLEVO App
In order to start using all the electronic functions of the suitcase it is necessary to
download the PLEVO App in the App Store for the iOS operating system or in Google
Play for the Android system.
- Follow the steps indicated in the App to perform the registration and be able to access
the different functions.
Turning on the suitcase
After registering in the App it is necessary to turn on the suitcase to make the pairing
between a mobile device and the PLEVO UP.
- Press the Power Button for 2 seconds until you hear the warning sound. Doing so for
the first time will show a flash of red light on the board and the front panel.
Red light
Flash every 2.5 seconds
Indicates that the suitcase is available to pair with a
device via Bluetooth.
Scan the code to download
Scan the code to download
04UP User's manual

Pairing
To connect your UP suitcase with a mobile device, follow these steps:
1) Activate the Bluetooth of your mobile device.
2) Select the model of your suitcase in the App and bring the device close to the
suitcase's board for two seconds until the CYAN lights on the board and front panel gets
turn on.
on / off button
Raise the main handle to access the button.
CYAN light
Single ignition for 8 sec.
CYAN light
Flash every 10 seconds.
Indicates that the suitcase has just been successfully
linked to a mobile device
Indicates that the suitcase is linked to a mobile
device.
05
Dashboard
Front Panel
UP User's manual

Important: in case of problems in pairing with Android devices, we recommend that you
move the phone closer to the board to improve the Bluetooth connection. After making
the connection with the suitcase, the user can get away from it perfectly and use the
different functions.
06UP User's manual

Tapa engomada
03 - Removable battery
All PLEVO suitcases incorporate a removable 8,000 mAh battery that supplies power to the
internal backup battery and allows the charging of mobile devices.
Parts and characteristics
Installation
Raise the main handle and access the rubber
cover located on the back of the board. This
cover protects the internal components from
blows, dust, and water, so it is recommended
to keep it closed.
1
07UP User's manual
Power button
Charging Lights

Extraction
Open the rubber cover to the right in order to
access the internal compartment of the board.
Place the battery horizontally (with the PLEVO
logo facing up) and press until it locks the
mechanism and is anchored.
2
3
Open the rubber cover to the right in order to
access the internal compartment of the board.
Press slightly forward until the ejection
mechanism is released.
2
1
08UP User's manual

Remove the battery horizontally backwards,
without exerting upward or lateral pressure.
3
Loading devices
To charge a mobile device with the battery of the suitcase it is necessary to connect a
USB type cable to one of the available ports (USB or USB 3.0). The battery can provide
power when installing in the suitcase or outside it.
To display the charge level, press the button and the lights will turn on automatically
indicating the battery status. The maximum load level is represented by 4 lights lit CYAN
color.
Charging lights
Power button
09UP User's manual

10
Backup battery
Backup battery
All PLEVO suitcases have a Nickel ion backup battery located inside the board that
complies with all established regulations. It is responsible for feeding the suitcase
system when the removable battery is not installed.
Important: The backup battery is charged automatically when the removable battery is
installed. The load percentage can be viewed by entering the PLEVO App and its
duration is 72 hours of continuous use approximately.
In case of simultaneous exhaustion of the charge of
the backup battery and the removable battery, the
suitcase can be opened with a key.
See the section "Opening with a key", p. 19
UP User's manual

04 - Removable wheels
To install the wheels and remove them, it is necessary to access the four locks located in
the lower part of the suitcase.
Installation
Follow steps 1 to 3 to remove the locks and install the wheels.
Slide and hold the safety lock back and place
the wheel bolt in the hole in the support
following the shape of the wheel.
Put pressure on the wheel until the bolt fully
enters the support orifice.
Bolt
Support orifice
Wheels locks
11UP User's manual

Disassembly
Follow steps 1 and 2 to remove the locks and disassemble the wheels.
Bolt
Release the lock to allow the final adjustment.
Thus, the wheel will be ready to use.
Press and hold the lock back to release the
bolt.
Pull the wheel back while holding the safety
lock.
The wheel will be dismantled once the bolt
has come completely out of the hole.
12UP User's manual

05 - Opening and closing the suitcase
General components of the closure
13
Secondary
handle
Morse code
button
TSA logo
Indicator
light
TSA Lock
Using Travel Sentry Approved lock allows your
luggage to be unlocked and inspected by security
authorities without damage.
UP User's manual

Opening with a key
All PLEVO suitcases have a set of keys approved by the TSA to open and close
in an alternate way.
Locate the set of keys that accompanies the
PLEVO suitcase and enter one of them inside the
TSA lock.
- Turn the key to the right to release the lock.
Thus, the flaps will open automatically.
- Important: Return the key to its initial position
after opening as it is necessary for closing,
otherwise the flaps cannot be anchored.
1
2
To operate with this method it is necessary to follow the following steps:
Flap
14UP User's manual

Important: Do not use the App to open or close the suitcase by Morse
Code or Face ID / Touch ID while you are operating with keys.
This can cause system clogging.
15UP User's manual
Mixed-use warning

16
Electronic opening and closing by Face ID / Touch ID
With the PLEVO App, it is possible to open or close the suitcase using biometric
data. According to the mobile model used, facial recognition or fingerprinting can be
used.
Opening
Select the opening option with biometric data
within the App. Depending on the type of mobile
device used, the App will ask you to enter the
fingerprint or face for recognition.
If the entries by Face ID or by Touch ID are correct,
the light will turn on for a few seconds in CYAN
color indicating the opening and the closing flaps
will open automatically.
1
2
Indicator
Light
UP User's manual

Flaps opening
Important: Avoid operating with the keys, App or button on / off during
this process of opening-closing as it can cause the system to clog.
Closing
After opening the lock, the system automatically prepares for closing, so it is only
necessary to anchor the flaps in the holes.
Turn both flaps until anchoring them in the
holes. In this way, the suitcase will be
completely closed.
17
Orifice
UP User's manual

Electronic opening and closing by Morse Code
All PLEVO suitcases have an alternative closure system by Morse Code. Only one
configuration of the code is required for one time and will be ready to be used at any
time without relying on the mobile device.
Important: To perform an opening or closing with
this method, it is necessary to carry out a previous
configuration.
Go to the Password section of the App and set up
a four-digit numeric code. Allowed numbers: From
1 to 5. For example, 1234
Opening
Follow steps 1 and 2 after configuring the code to use this function.
Press the button repeatedly according to the digit
previously set. When doing so, the light will turn on
red indicating the entrance.
See example on next page.
1
Indicator
Light
18UP User's manual

Example: Code set 1-2-1-3
Pause Pause Pause
Press the button once while
the red light stays on.
Press the button once while
the red light stays on.
Press the button once while
the red light stays on.
Press the button once while
the red light stays on.
12 11 3
Important:
Between each number set it is necessary to pause until the red light goes out. Later you
can continue with the next number.
Red
Light
Red
Light
Red
Light
Red
Light
When entering the code correctly, the light will turn
on in CYAN color for 3 seconds and the closing
flaps will open automatically.
2
Indicator
light
Flap
CYAN Light
On for 3 sec.
Red Light
On for 3 sec.
Indicates that the suitcase was opened correctly
using the Morse Code.
Indicates that the Morse Code was entered
incorrectly.
19UP User's manual
